Baileigh Industrial WJT-4747-HD User manual

OPERATOR’S MANUAL
WELD FIXTURE TABLE
MODELS: WJT-4747-HD, OR WJT-7839-HD
© 2017 Baileigh Industrial, Inc.
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL Pty.
LTD IS PROHIBITED. Baileigh Industrial Pty. LTD does not assume and hereby disclaims any liability for any damage
or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other
occurrence.
Rev. 03/2017
BAILEIGH INDUSTRIAL Pty. Ltd.
P.O Box 1573, 122-126 Melrose Drive
Tullamarine,
VIC 3043 Australia
Ph. 61.383.743.888
[email protected]

Table of Contents
STANDARD TERMS AND CONDITIONS OF SALE.......................................................1
INTRODUCTION.............................................................................................................5
GENERAL NOTES..........................................................................................................5
SAFETY INSTRUCTIONS ..............................................................................................6
SAFETY PRECAUTIONS ...............................................................................................8
Dear Valued Customer:................................................................................................... 8
TECHNICAL SPECIFICATIONS................................................................................... 10
TECHNICAL SUPPORT ............................................................................................... 10
UNPACKING AND CHECKING CONTENTS................................................................ 11
Cleaning .................................................................................................................... 11
TRANSPORTING AND LIFTING .................................................................................. 12
INSTALLATION............................................................................................................. 13
ASSEMBLY AND SET UP ............................................................................................ 14
Attention Before Operation........................................................................................ 14
Table Top .................................................................................................................. 15
Basic Parts ................................................................................................................ 15
Locating Parts............................................................................................................ 16
Clamping Parts.......................................................................................................... 16
Lock Pin..................................................................................................................... 16
Other accessories...................................................................................................... 17
LUBRICATION AND MAINTENANCE ..........................................................................18

1
1
STANDARD TERMS AND CONDITIONS OF SALE
1 INTERPRETATION
1.1 In these Conditions the following words have the following meanings:
Word Meaning
“Buyer” the person(s), firm or company from whom an order to supply Goods is received by the Company;
“Buyer Materials” any documents or other materials and any data or other information provided by the Buyer relating to the
Goods;
“Company” Baileigh Industrial Limited, a company incorporated in England and Wales (Company Number
05672861) whose registered office is at Unit D Swift Point, Swift Valley Industrial Estate, Rugby,
West Midland, CV21 2QH
“Company Materials” any documents or other materials, and any data or other information provided by the Company relating
to the Goods;
“Conditions” the standard terms and conditions of sale as set out in this document;
“Contract” any contract between the Company and the Buyer for the sale and purchase of the Goods;
“Delivery Point” the place where delivery of the Goods is to take place under Condition 4.1;
“Goods” any goods agreed in the Contract to be supplied to the Buyer by the Company (including any part or
parts of them).
1.2 In these Conditions references to any statute or statutory provision shall, unless the context otherwise requires, be construed as a
reference to that statute or statutory provision as from time to time amended, consolidated, modified, extended, re-enacted or
replaced.
1.3 In these Conditions references to the masculine include the feminine and the neuter and to the singular include the plural and vice
versa as the context admits or requires.
1.4 In these Conditions headings will not affect the construction of these Conditions.
2 APPLICATION OF TERMS
2.1 Subject to any variation under Condition 2.3 the Contract will be on these Conditions to the exclusion of all other terms and
conditions (including any terms or conditions which the Buyer purports to apply under any purchase order, confirmation of order,
specification or other document).
2.2 No terms or conditions endorsed upon, delivered with or contained in the Buyer’s purchase order, confirmation of order,
specification or other document will form part of the Contract simply as a result of such document being referred to in the Contract.
2.3 These Conditions apply to all the Company’s sales of Goods and any variation to these Conditions and any representations about
the Goods shall have no effect unless expressly agreed in writing and signed the designated agent/employee of the Company.
2.4 The Buyer must ensure that the terms of its order and any applicable specification are complete and accurate.
2.5 Any quotation given by the Company is an offer which is valid for a period of 30 days only, provided that the Company has not
previously withdrawn it. The offer is accepted by the Buyer and a contract is formed when the Company receives a purchase order
for the Goods, provided that such purchase order does not purport to contract on terms other than these Conditions.
2.6 If the Buyer requires an order confirmation providing the date of shipment this should be clearly stated in the Buyer’s purchase
order.
3 DESCRIPTION
3.1 The description of the Goods shall be as set out in the Company’s quotation.
3.2 All drawings, descriptive matter, specifications and advertising issued by the Company on any packaging of the Goods or
elsewhere and any descriptions or illustrations contained in the Company's catalogues or brochures are issued or published for the
sole purpose of giving an approximate idea of the Goods described in them. They will not form part of this Contract and no
warranty is given that the Goods will comply with or perform in accordance with any such description.
4 DELIVERY
4.1 Any dates specified by the Company for delivery of the Goods are intended to be an estimate and time for delivery shall not be
made of the essence by notice. If no dates are so specified, delivery will be within a reasonable time.
4.2 Subject to the other provisions of these Conditions the Company will not be liable for any loss (including loss of profit), costs,
damages, charges or expenses caused directly or indirectly by any delay in the delivery of the Goods (even if caused by the
Company’s negligence), nor will any delay entitle the Buyer to terminate or rescind the Contract unless such delay exceeds 180
days.
4.3 If for any reason the Buyer will not accept delivery of any of the Goods when they are ready for delivery, or the Company is unable
to deliver the Goods on time because the Buyer has not provided appropriate instructions, documents, licenses or authorizations:
4.3.1 risk in the Goods will pass to the Buyer (including for loss or damage caused by the Company’s negligence);
4.3.2 the Goods will be deemed to have been delivered; and
4.3.3 the Company may store the Goods until delivery whereupon the Buyer will be liable for all related costs and expenses
(including without limitation storage and insurance).
4.4 The Buyer will provide at its expense at the Delivery Point adequate and appropriate equipment and manual labor for loading the
Goods.

2
2
5 NON-DELIVERY
5.1 The quantity of any consignment of Goods as recorded by the Company upon dispatch from the Company’s place of business shall
be conclusive evidence of the quantity received by the Buyer on delivery unless the Buyer can provide conclusive evidence proving
the contrary.
5.2 The Company shall not be liable for any non-delivery of Goods (even if caused by the Company’s negligence) unless written notice
is given to the Company within [7] days of the date when the Goods would in the ordinary course of events have been received.
5.3 Any liability of the Company for non-delivery of the Goods shall be limited to replacing the Goods within a reasonable time or issuing
a credit note at the pro rata Contract rate against any invoice raised for such Goods.
6 RISK/TITLE
6.1 The Goods are at the risk of the Buyer from the time of delivery.
6.2 Ownership of the Goods shall not pass to the Buyer until the Company has received in full (in cash or cleared funds) all sums due to
it in respect of:
6.2.1 the Goods; and
6.2.2 all other sums which are or which become due to the Company from the Buyer on any account.
6.3 Until ownership of the Goods has passed to the Buyer, the Buyer must:
6.3.1 hold the Goods on a fiduciary basis as the Company’s bailee;
6.3.2 store the Goods (at no cost to the Company) separately from all other goods of the Buyer or any third party in such a way that
they remain readily identifiable as the Company’s property;
6.3.3 not destroy, deface or obscure any identifying mark or packaging on or relating to the Goods;
6.3.4 maintain the Goods in satisfactory condition insured on the Company’s behalf for their full price against all risks to the
reasonable satisfaction of the Company. On request the Buyer shall produce the policy of insurance to the Company; and
6.3.5 hold the proceeds of the insurance referred to in Condition 6.3.4 on trust for the Company and not mix them with any other
money, nor pay the proceeds into an overdrawn bank account.
6.4 The Buyer may resell the Goods before ownership has passed to it solely on the following conditions:
6.4.1 any sale shall be effected in the ordinary course of the Buyer’s business at full market value; and
6.4.2 any such sale shall be a sale of the Company’s property on the Buyer’s own behalf and the Buyer shall deal as principal when
making such a sale.
6.5 The Buyer’s right to possession of the Goods shall terminate immediately if:
6.5.1 the Buyer has a bankruptcy order made against him or makes an arrangement or composition with his creditors, or otherwise
takes the benefit of any Act for the time being in force for the relief of insolvent debtors, or (being a body corporate) convenes
a meeting of creditors (whether formal or informal), or enters into liquidation (whether voluntary or compulsory) except a
solvent voluntary liquidation for the purpose only of reconstruction or amalgamation, or has a receiver and/or manager,
administrator or administrative receiver appointed of its undertaking or any part thereof, or a resolution is passed or a petition
presented to any court for the winding up of the Buyer or for the granting of an administration order in respect of the Buyer, or
any proceedings are commenced relating to the insolvency or possible insolvency of the Buyer; or
6.5.2 the Buyer suffers or allows any execution, whether legal or equitable, to be levied on his/its property or obtained against
him/it, or fails to observe/perform any of his/its obligations under the Contract or any other contract between the Company and
the Buyer, or is unable to pay its debts within the meaning of section 123 of the Insolvency Act 1986 or the Buyer ceases to
trade; or
6.5.3 the Buyer encumbers or in any way charges any of the Goods.
6.6 The Company shall be entitled to recover payment for the Goods notwithstanding that ownership of any of the Goods has not
passed from the Company.
6.7 The Buyer grants the Company, its agents and employees an irrevocable license at any time to enter any premises where the
Goods are or may be stored in order to inspect them, or, where the Buyer’s right to possession has terminated, to recover them.
7 PRICE
7.1 The price for the Goods shall be the price set out in the Company’s estimate/quotation. All estimates/quotes are good for 30 days
from the date on the top of the estimate/quote.
7.2 The price for the Goods shall be exclusive of any value added tax and all costs or charges in relation to loading, unloading, carriage
and insurance all of which amounts the Buyer will pay in addition when it is due to pay for the Goods.
8 PAYMENT
8.1 Payment of the price for the Goods is due and payable before shipment of the goods occurs unless otherwise negotiated by the
Company and the customer.
8.2 Time for payment shall be of the essence.
8.3 No payment shall be deemed to have been received until the Company has received cleared funds.
8.4 All payments payable to the Company under the Contract shall become due immediately upon termination of this Contract despite
any other provision.
8.5 The Buyer shall make all payments due under the Contract without any deduction whether by way of set-off, counterclaim, discount,
abatement or otherwise unless the Buyer has a valid court order requiring an amount equal to such deduction to be paid by the
Company to the Buyer.
8.6 If the Buyer fails to pay the Company any sum due pursuant to the Contract the Buyer will be liable to pay interest to the Company
on such sum from the due date for payment at the annual rate of 10% above the base lending rate from time to time of LIBOR,
accruing on a daily basis until payment is made, whether before or after any judgment.
8.7 The Company reserves the right to claim interest and fixed sum compensation under the Late Payment of Commercial Debts
(Interest) Act 1998.

3
3
9 WARRANTY
9.1 The Company warrants that (subject to the other provisions of these Conditions) upon delivery, and for a period of 12 months from
the date of delivery, the Goods will be of satisfactory quality within the meaning of the Sale of Goods Act 1994. Warranty provisions
are strictly at the determination of the Company on a case by case basis. The Company’s determinations regarding a warranty
claim are final.
9.2 The Company shall not be liable for a breach of the warranty in Condition 9.1 unless:
9.2.1 the Buyer gives written notice of the defect to the Company, and (if the defect is as a result of damage in transit) to the
carrier, within a reasonable amount of time when the Buyer discovers or ought to have discovered the defect; and
9.2.2 the Company is given a reasonable opportunity after receiving the notice to examine such Goods and the Buyer (if asked to
do so by the Company) returns such Goods to the Company's place of business at the Buyer's expense for the examination
to take place there.
9.3 The Company shall not be liable for a breach of the warranty in Condition 9.1 if:
9.3.1 the Buyer makes any further use of such Goods after giving such notice; or
9.3.2 the defect arises because the Buyer failed to follow the Company’s oral or written instructions as to the storage, installation,
commissioning, use or maintenance of the Goods; or
9.3.3 the defect arises as a result of ordinary wear and tear; or
9.3.4 the Buyer alters or repairs such Goods without the written consent of the Company.
9.4 The following are expressly excluded from the warranty in Condition 9.1:
9.4.1 die sets, tooling and saw blades; and
9.4.2 machine maintenance, adjustment and set ups.
9.5 Subject to Conditions 9.2 and 9.3, if any of the Goods do not conform with the warranty in Condition 9.1 the Company shall at its
option repair or replace such Goods (or the defective part) or refund the price of such Goods at the pro rata Contract rate provided
that, if the Company so requests, the Buyer shall, at the Buyer's expense, return the Goods or the part of such Goods which is
defective to the Company.
9.6 If the Company complies with Condition 9.4 it shall have no further liability for a breach of the warranty in Condition 9.1 in respect
of such Goods.
9.7 Any Goods which have been replaced will belong to the Company and any repaired or replacement Goods will be guaranteed on
these terms for the unexpired portion of the 12 month period.
9.8 All work carried out under the warranty contained in Condition 9.1 must be approved by the Company.
9.9 All electrical components and gearboxes carry a one-year replacement warranty from the manufacturer. This warranty does not
include labour or shipping costs.
10 RETURNS
10.1 The Buyer shall not be entitled to cancel any order or Contract or return any goods without the prior written approval of the
Company.
10.2 Special orders cannot be cancelled under any circumstances.
10.3 If the Company agrees to accept the return of any Goods it shall be on terms that
a) They are returned at the Buyer’s expense to the Company within 30 days of delivery
b) They are received by the Company in “as new” condition without any damage or use
c) Any refund will be subject to a 15% “restocking charge”
and such other terms as the Company may impose.
11 LIMITATION OF LIABILITY
11.1 Subject to Condition 9, the following provisions of this Condition 10 set out the entire financial liability of the Company (including
any liability for the acts or omissions of its employees, agents and sub-contractors) to the Buyer in respect of:
11.1.1 any breach of these Conditions; and
11.1.2 any representation, statement or tortious act or omission including negligence arising under or in connection with the
Contract.
11.2 All warranties, conditions and other terms implied by statute or common law (save for the conditions implied by section 12 of the
Sale of Goods Act 1979) are, to the fullest extent permitted by law, excluded from the Contract.
11.3 Nothing in these Conditions excludes or limits the liability of the Company for death or personal injury caused by the Company’s
negligence or for fraudulent misrepresentation.
(THE BUYER’S ATTENTION IS DRAWN TO THE PROVISIONS OF CONDITION 11.4 BELOW)
11.4 Subject to Conditions 11.2 and 11.3:
11.4.1 the Company’s total liability in contract, tort (including negligence or breach of statutory duty), misrepresentation or
otherwise, arising in connection with the performance or contemplated performance of this Contract shall be limited to the
invoiced amount per each and every individual transaction; and
11.4.2 the Company shall not be liable to the Buyer for any indirect or consequential loss or damage (whether for loss of profit, loss
of business, depletion of goodwill or otherwise), costs, expenses or other claims for consequential compensation
whatsoever (howsoever caused) which arise out of or in connection with the Contract.
12 INTELLECTUAL PROPERTY
12.1 The property and any copyright or other intellectual property rights in:
12.1.1 any Buyer Materials shall belong to the Buyer;
12.1.2 any Company Materials shall, unless otherwise agreed in writing between the Buyer and the Company, belong to the
Company, subject only to a license in favor of the Buyer to use the Company Materials for the purposes of receiving the
Goods.

4
4
13 ASSIGNMENT
13.1 The Buyer shall not be entitled to assign the Contract or any part of it without the prior written consent of the Company.
13.2 The Company may assign the Contract or any part of it to any person, firm or company.
14 FORCE MAJEURE
The Company reserves the right to defer the date of delivery or to cancel the Contract or reduce the volume of the Goods ordered by the
Buyer (without liability to the Buyer) if it is prevented from or delayed in the carrying on of its business due to circumstances beyond the
reasonable control of the Company including, without limitation, acts of God, governmental actions, war or national emergency, riot, civil
commotion, fire, explosion, flood, epidemic, lock-outs, strikes or other labor disputes (whether or not relating to either party's workforce), or
restraints or delays affecting carriers or inability or delay in obtaining supplies of adequate or suitable materials Provided that, if the event
in question continues for a continuous period in excess of [180] days, the Buyer shall be entitled to give [not less than [3] days] notice in
writing to the Company to terminate the Contract.
15 GENERAL
15.1 Each right or remedy of the Company under the Contract is without prejudice to any other right or remedy of the Company whether
under the Contract or not.
15.2 If any provision of the Contract is found by any court, tribunal or administrative body of competent jurisdiction to be wholly or partly
illegal, invalid, void, voidable, unenforceable or unreasonable it shall to the extent of such illegality, invalidity, voidness, voidability,
unenforceability or unreasonableness be deemed severable and the remaining provisions of the Contract and the remainder of
such provision shall continue in full force and effect.
15.3 Failure or delay by the Company in enforcing or partially enforcing any provision of the Contract will not be construed as a waiver of
any of its rights under the Contract.
15.4 Any waiver by the Company of any breach of, or any default under, any provision of the Contract by the Buyer will not be deemed a
waiver of any subsequent breach or default and will in no way affect the other terms of the Contract.
15.5 The parties to this Contract do not intend that any term of this Contract will be enforceable by virtue of the Contracts (Rights of
Third Parties) Act 1999 by any person that is not a party to it.
15.6 The formation, existence, construction, performance, validity and all aspects of the Contract shall be governed by English law and
the parties submit to the exclusive jurisdiction of the English courts.
16 COMMUNICATIONS
16.1 All communications between the parties about this Contract must be in writing and delivered by hand or sent by pre-paid first class
post or sent by facsimile transmission:
16.1.1 (in case of communications to the Company) to its registered office or such changed address as shall be notified to the
Buyer by the Company; or
16.1.2 (in the case of the communications to the Buyer) to the registered office of the addressee (if it is a company) or (in any other
case) to any address of the Buyer set out in any document which forms part of this Contract or such other address as shall
be notified to the Company by the Buyer.
16.2 Communications shall be deemed to have been received:
16.2.1 if sent by pre-paid first class post, 2 days (excluding Saturdays, Sundays and bank and public holidays within the UK) after
posting (exclusive of the day of posting);
16.2.2 if delivered by hand, on the day of delivery;
16.2.3 if sent by facsimile transmission on a working day prior to 4.00 p.m., at the time of transmission and otherwise on the next
working day. Communications addressed to the Company shall be marked for the attention of the designated purchasing
agent for the buyer.
17 EXPORT
17.1 In these Conditions “Incoterms” means the international rules for the interpretation of trade terms of the International Chamber of
Commerce as in force at the date when the Contract is made. Unless the context otherwise requires, any term or expression which
is defined in or given a particular meaning by the provisions of Incoterms shall have the same meaning in these Conditions, but if
there is any conflict between the provisions of Incoterms and these Conditions, the latter shall prevail.
17.2 Where the Goods are supplied for export from the United Kingdom, the provisions of this Condition 17 shall (subject to any special
terms agreed in writing between the Buyer and the Company) apply notwithstanding any other provision of these Conditions.
17.3 The Buyer shall be responsible for complying with any legislation or regulations governing the importation of the Goods into the
country of destination and for the payment of any duties on them.
17.4 Unless otherwise agreed in writing between the Buyer and the Company, the Goods shall be delivered fob the air or sea port of
shipment and the Company shall be under no obligation to give notice under section 32(3) of the Sale of Goods Act 1979.
17.5 The Buyer shall be responsible for arranging for testing and inspection of the Goods at the Company’s premises before shipment.
The Company shall have no liability for any claim in respect of any defect in the Goods which would be apparent on inspection and
which is made after shipment, or in respect of any damage during transit.

5
5
INTRODUCTION
The quality and reliability of the components assembled on a Baileigh Industrial machine
guarantee near perfect functioning, free from problems, even under the most demanding
working conditions. However if a situation arises, refer to the manual first. If a solution cannot be
found, contact the distributor where you purchased our product. Make sure you have the serial
number and production year of the machine (stamped on the nameplate). For replacement parts
refer to the assembly numbers on the parts list drawings.
Our technical staff will do their best to help you get your machine back in working order.
In this manual you will find: (when applicable)
Safety procedures
Correct installation guidelines
Description of the functional parts of the machine
Capacity charts
Set-up and start-up instructions
Machine operation
Scheduled maintenance
Parts lists
GENERAL NOTES
After receiving your equipment remove the protective container. Do a complete visual
inspection, and if damage is noted, photograph it for insurance claims and contact your
carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the
unexpected occurrence. Temporarily suspend installation.
Take necessary precautions while loading / unloading or moving the machine to avoid any
injuries.
Your machine is designed and manufactured to work smoothly and efficiently. Following proper
maintenance instructions will help ensure this. Try and use original spare parts, whenever
possible, and most importantly; DO NOT overload the machine or make any unauthorized
modifications.
Note: This symbol refers to useful information throughout the manual.

6
6
LEARN TO RECOGNIZE SAFETY INFORMATION
This is the safety alert symbol. When you see this symbol on
your machine or in this manual, BE ALERT TO THE
POTENTIAL FOR PERSONAL INJURY!
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
A signal word –DANGER, WARNING, or CAUTION
is used with the safety alert symbol. DANGER
identifies a hazard or unsafe practice that will result in
severe Injury or Death.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
CAUTION also calls attention to safety messages in this
manual.
IMPORTANT
PLEASE READ THIS OPERATORS MANUAL CAREFULLY
It contains important safety information, instructions, and necessary operating
procedures. The continual observance of these procedures will help increase your
production and extend the life of the equipment.
SAFETY INSTRUCTIONS

7
7
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
PROTECT EYES
Wear safety glasses or suitable eye protection
when working on or around machinery.
BEWARE OF CRUSH HAZARD
NEVER place your hands, fingers, or any part of your body in the die
area of this machine.
Wear Safety Gloves Wear Eye Protection
Read Manual Two Person Lift
Crush Hazard Heat/Hot Surface

8
8
SAFETY PRECAUTIONS
Metal working can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using
the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator
may result.
Safety equipment such as guards, hold-downs, safety glasses, dust masks and hearing
protection can reduce your potential for injury. But even the best guard won’t make up for poor
judgment, carelessness or inattention. Always use common sense and exercise caution in
the workshop. If a procedure feels dangerous, don’t try it.
REMEMBER: Your personal safety is your responsibility.
Dear Valued Customer:
•All Baileigh machines should be used only for their intended use.
•Baileigh does not recommend or endorse making any modifications or alterations to a
Baileigh machine. Modifications or alterations to a machine may pose a substantial risk of
injury to the operator or others and may do substantial damage to the machine.
•Any modifications or alterations to a Baileigh machine will invalidate the machine's warranty.
PLEASE ENJOY YOUR BAILEIGH MACHINE!....PLEASE ENJOY IT SAFELY!
1. FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE
MACHINE. Learn the machine’s application and limitations as well as the specific hazards.
2. Only trained and qualified personnel can operate this machine.
3. Make sure guards are in place and in proper working order before operating
machinery.
4. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools
have been removed.
5. Keep work area clean. Cluttered areas invite injuries.
6. Overloading machine. By overloading the machine you may cause injury from flying parts.
DO NOT exceed the specified machine capacities.
7. Dressing material edges. Always chamfer and deburr all sharp edges.
WARNING:FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS PERSONAL INJURY

9
9
8. Do not force tool. Your machine will do a better and safer job if used as intended. DO NOT
use inappropriate attachments in an attempt to exceed the machines rated capacity.
9. Use the right tool for the job. DO NOT attempt to force a small tool or attachment to do the
work of a large industrial tool. DO NOT use a tool for a purpose for which it was not
intended.
10.Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in
moving machine parts. Protective clothing and steel toe shoes are recommended when
using machinery. Wear a restrictive hair covering to contain long hair.
11.Use eye and ear protection. Always wear ISO approved impact safety goggles. Wear a full-
face shield if you are producing metal filings.
12.Do not overreach. Maintain proper footing and balance at all times. DO NOT reach over or
across a running machine.
13.Stay alert. Watch what you are doing and use common sense. DO NOT operate any tool or
machine when you are tired.
14.Check for damaged parts. Before using any tool or machine, carefully check any part that
appears damaged. Check for alignment and binding of moving parts that may affect proper
machine operation.
15.Observe work area conditions. DO NOT use machines or power tools in damp or wet
locations. Do not expose to rain. Keep work area well lighted. DO NOT use electrically
powered tools in the presence of flammable gases or liquids.
16.Keep children away. Children must never be allowed in the work area. DO NOT let them
handle machines, tools, or extension cords.
17.Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust.
Always lock up tools and keep them out of reach of children.
18.DO NOT operate machine if under the influence of alcohol or drugs. Read warning
labels on prescriptions. If there is any doubt, DO NOT operate the machine.
19.Sparks and hot material from welding or cutting can easily go through small cracks and
openings into adjacent areas.
20.Do not weld where the atmosphere might contain flammable dust, gas, or liquid vapors such
as from gasoline.
21.Wear oil-free protective garments such as leather gloves, heavy shirt, high shoes or boots,
cuffless trousers, and a cap.
22.Watch for fire and keep a fire extinguisher close by.
23.Be sure all equipment is properly installed and grounded according to national, state, and
local codes.
24.Keep all cords dry, free from grease and oil, and protected from sparks and hot metal.
25.Keep visitors a safe distance from the work area.

10
10
TECHNICAL SPECIFICATIONS
WJT-4747-HD
WJT-7839-HD
Table Weight
1000lbs. (454kg)
1433lbs. (650kg)
Table Size (L x W x H)
1200 x 1200 x 200mm
2000 x 1000 x 200mm
Load Capacity**
4000lbs (1814kg)
** IMPORTANT: The load capacity is based upon the stands provided.
Clamping Surfaces
5
Graduations Marks (mm)
2 Edges
Grid Pattern
100mm x 100mm
Clamping Hole Pattern
100mm x 100mm
Grid Hole Diameter
28mm
Material
Cast Iron
Surface
Plasma Nitride
TECHNICAL SUPPORT
Our technical support department can be reached at [email protected] listing support and
the model number in the subject line. Tech Support handles questions on machine setup,
schematics, warranty issues, and individual parts needs: (other than die sets and blades).
List the model number, serial number and contact name and phone number as well as a brief
description of the nature of the contact in the body of the message.
For specific application needs or future machine purchases contact the Sales Department at:
phone: 61.383.743.888 or email: [email protected].
Note: The photos and illustrations used in this manual are representative only and
may not depict the actual color, labeling or accessories and may be intended to illustrate
technique only.
Note: The specifications and dimensions presented here are subject to change
without prior notice due to improvements of our products.

11
11
UNPACKING AND CHECKING CONTENTS
Your Baileigh machine is shipped complete. Separate all parts from the packing material and
check each item carefully. Make certain all items are accounted for before discarding any
packing material.
Cleaning
Your machine may be shipped with a rustproof waxy coating and/or grease on the exposed
unpainted metal surfaces. Fully and completely remove this protective coating using a
degreaser or solvent cleaner. Moving items will need to be moved along their travel path to
allow for cleaning the entire surface. For a more thorough cleaning, some parts will occasionally
have to be removed. DO NOT USE acetone or brake cleaner as they may damage painted
surfaces.
Follow manufacturer’s label instructions when using any type of cleaning product. After cleaning,
wipe unpainted metal surfaces with a light coating of quality oil or grease for protection.
Important: This waxy coating is NOT a lubricant and will cause the machine to
stick and lose performance as the coating continues to dry.
WARNING: SUFFOCATION HAZARD! Immediately discard any plastic
bags and packing materials to eliminate choking and suffocation hazards to children
and animals.
If any parts are missing, DO NOT place the machine into service until the missing
parts are obtained and installed correctly.
WARNING: DO NOT USE gasoline or other petroleum products to clean
the machine. They have low flash points and can explode or cause fire.
CAUTION: When using cleaning solvents work in a well-ventilated area.
Many cleaning solvents are toxic if inhaled.
GAS

12
12
TRANSPORTING AND LIFTING
Follow these guidelines when lifting:
Always lift and carry the machine with the lifting holes
provided at the top of the machine.
Use lift equipment such as straps, chains, capable of lifting 1.5
to 2 times the weight of the machine.
Take proper precautions for handling and lifting.
Check if the load is properly balanced by lifting it an inch or
two.
Lift the machine, avoiding sudden accelerations or quick changes of direction.
Locate the machine where it is to be installed, and lower slowly until it touches the floor.
The lift truck must be able to lift at least 1.5 –2 times the
machines gross weight.
Make sure the machine is balanced. While transporting,
avoid rough or jerky motion, and maintain a safe
clearance zone around the transport area.
Use a fork lift with sufficient lifting capacity and forks that
are long enough to reach the complete width of the
machine.
Remove the securing bolts that attach the machine to the pallet.
Approaching the machine from the side, lift the machine on the frame taking care that there
are no cables or pipes in the area of the forks.
Move the machine to the required position and lower gently to the floor.
Level the machine so that all the supporting feet are taking the weight of the machine and no
rocking is taking place.
CAUTION: Lifting and carrying operations should be carried out by
skilled workers, such as a truck operator, crane operator, etc. If a crane is used to lift
the machine, attach the lifting chain carefully, making sure the machine is well
balanced. Choose a location that will keep the machine free from vibration and dust
from other machinery. Keep in mind that having a large clearance area around the
machine is important for safe and efficient working conditions.

13
13
INSTALLATION
IMPORTANT:
Consider the following when looking for a suitable location to place the machine:
Overall weight of the machine.
Weight of material being processed.
Sizes of material to be processed through the machine.
Space needed for auxiliary stands, work tables, or other machinery.
Clearance from walls and other obstacles.
Maintain an adequate working area around the machine for safety.
Have the work area well illuminated with proper lighting.
Keep the floor free of oil and make sure it is not slippery.
Remove scrap and waste materials regularly, and make sure the work area is free from
obstructing objects.
If long lengths of material are to be fed into the machine, make sure that they will not extend
into any aisles.
LEVELING: The machine should be sited on a level, concrete floor. Provisions for securing it
should be in position prior to placing the machine. The accuracy of any machine depends on
the precise placement of it to the mounting surface.
FLOOR: This tool distributes a large amount of weight over a small area. Make certain that
the floor is capable of supporting the weight of the machine, work stock, and the operator.
The floor should also be a level surface. If the unit wobbles or rocks once in place, be sure to
eliminate by using shims.
WORKING CLEARANCES: Take into consideration the size of the material to be
processed. Make sure that you allow enough space for you to operate the machine freely.

14
14
ASSEMBLY AND SET UP
1. Safely lift and support the table so that the bottom of the table is high enough for the legs to
fit under the table.
2. Install a leg onto each corner and secure with the shoulder bolt provided.
3. Place the table at the desired location.
4. Using the adjustable feet, level the table in all directions as well as removing any rocking.
Attention Before Operation
Spray all fixturing surfaces with rust inhibitor when not in use.
Spray all fixturing surfaces with anti-spatter before and periodically during use.
Ensure reliable conductive ground connection.
Periodically clean the welding slag on the platform surface with oil stone.
To the extent possible, try not to fixture in the same exact area of the table every time. Using
the entire table surface will even the wear on the table and clamping hole and prolong the
table life.
DO NOT leave unused accessories or tooling on the table surface.
IMPORTANT: Keep the surface and hole clean.
To avoid damage to the platform surface
oRough and heavy body parts should not be put on the platform directly. The contact
with the workpiece should be through the use of locating block.
oIt is recommended to use protective plate or pads when welding on.

15
15
To avoid table surface deformation, note the following points:
oIt is better to be mainly used for tack and spot welding on the platform.
oIf full welding is needed, Use blocks top raise the material off of the surface to avoid
deformation caused by high temperature.
oAlways check the forces of supporting legs. Level the table as require.
Table Top
Table top has a perforated grid plate with D28 mounting holes precisely laid out on a 100mm x
100mm grid pattern. These holes can be used for various positioning module and fixtures.
Basic Parts
The table comes with the legs. The clamping and fixturing devises are optional items sold as
an accessory package (shown below). A wide variety of clamping and fixturing devises are
available at most welding supply houses.
Note: Optional Accessory Package Shown. Sold Separately

16
16
Locating Parts
Position Square and Bars; through a combination of hole and slots between each other,
these bars can be mounting is about as many ways as can be imagined.
V-shape locate block: For positioning and supporting of round stock.
Clamping Parts
Fixed Clamps Adjustable Clamp 45° Clamp
Each clamp may be interchanged with each other mounting and clamping hardware. The
clamps are also easily combined with the other components from the optional accessory
package.
Insert the post is the desired hole, adjust the height and tighten the clamp.
Lock Pin
Fast Lock Pin
The fast lock pins use balls to lock the pin into the hole. Rotate the cap clockwise to tighten and
extend the balls to lock the pin in place. Rotate the cap counter-clockwise to loosen and allow
the balls to retract for removal and repositioning.
It is recommended to hand tighten only and use the hex slot only as needed to assist in
loosening.
Ball recessed, can pull out
Ball protruding, locked

17
17
Countersunk Lock Pin
Connect accessories to the table or other accessories by installing and tightening the
countersunk pins. Both the lock body and the screw heads are countersunk. This provides
clamping that will not interfere externally.
Other accessories
1. Platform and accessories or attachments and accessories are pressed by the pin through
the holes. Users can assemble a reasonable combination according to products shape and
actual situation.
2. For individual cases, some special-purpose parts may need to be custom made according to
products shape and concert with flexible 3D system. Consult a local tooling shop for
assistance.

18
18
LUBRICATION AND MAINTENANCE
Check daily for any unsafe conditions and fix immediately.
Check that all nuts and bolts are properly tightened.
On a weekly basis clean the machine and the area around it.
Apply rust inhibitive lubricant to all non-painted surfaces.
Note: Proper maintenance can increase the life expectancy of your machine.
1. Keep the platform clean, spray anti-rust oil when do not use for while.
2. Keep the hole inside clean and clear with brush regularly.
3. After welding, wipe away the solder residues on the platform with oil stone slightly.
4. After using period of time, the surface may be a little concave or convex. The convex surface
shall be polished to be smooth with oil stone. The concave one would not affect the
operation.
