BANDELIN SONOPULS HD 5020 User manual

51846-000 en/2022-07
Instructions for use
SONOPULS
Ultrasonic homogeniser
Valid for:
SONOPULS HD 5020
SONOPULS HD 5050
SONOPULS HD 5100
SONOPULS HD 5200
SONOPULS HD 5400
Dokument:51846-000Sprache: enVersion:2022-07

2/36 51846-000 en/2022-07
© 2022
1 2 GmbH & Co. KG, Heinrichstr. 3–4, 12207 Berlin, Ger-
many
Phone: [phone], Fax: [phone], [email protected]
Certified in accordance with ISO 9001 and ISO 13485

51846-000 en/2022-07 3/36
Table of contents
Table of contents
1 About this operating manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Use of the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Explosion hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Hazards due to high temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Danger of electric shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Danger due to ultrasound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.6 Danger due to the sonicating medium . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.7 Harmful to health due to ultrasound noise . . . . . . . . . . . . . . . . . . . . . 8
2.8 Keep out of reach of children . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.9 Damage to the probe and sonication vessel . . . . . . . . . . . . . . . . . . . . 8
2.10 Disturbance of wireless communication . . . . . . . . . . . . . . . . . . . . . . . 8
3 Design and function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Symbols and buttons on the touch screen . . . . . . . . . . . . . . . . . . . . . 10
3.3 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Preparation for operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Set up homogeniser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Mounting/removing the probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Mounting/removing standard horn or booster horn. . . . . . . . . . . . . 12
4.4 Switching the device on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 Select probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1 Immersion depth notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2 Preselect parameters for sonication . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.1 Set amplitude or power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2.2 Enter sonication time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2.3 Set pulsation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2.4 Setting temperature monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.3 Start sonication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.4 Creating and starting programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.4.1 About programs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table of contents
4/36 51846-000 en/2022-07
5.4.2 Creating a program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.4.3 Activating and deactivating a program . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4.4 Starting a program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.5 Creating documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.6 Set settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6.1 Adjusting the button function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6.2 Adjust brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6.3 Set the language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6.4 Setting the time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6.5 Set sleep mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.6.6 Configuring the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.6.7 Set temperature unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.7 Troubleshooting a malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Cleaning the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 Refurbish probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.3 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8 Device information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8.2 Ambient conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9.1 Available probes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9.2 Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9.3 Optional tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

51846-000 en/2022-07 5/36
About this operating manual/1
1 About this operating manual
These instructions for use contain necessary and useful information on how to
operate the ultrasound bath safely and efficiently.
• Read these instructions for use before using the ultrasound bath.
• Pay special attention to chapter 2Safety.
• If you pass this ultrasound bath on to others, please enclose these instruc-
tions for use.
• Contact your specialist dealer or BANDELIN if any of your questions are not
answered in these instructions for use. Information on service can be found in
chapter 6.3Repair.
Illustrations are provided as examples and are not to scale.

2 / Safety
6/36 51846-000 en/2022-07
2Safety
2.1 Use of the device
The device is used in laboratories, clinics and in industrial research. It performs
diverse tasks during sample preparation in Quality Assurance, scientific experi-
ments, analyses, and in pilot or short-series manufacture.
Examples of applications are:
• Disruption of cells, bacteria, viruses, tissue
• Production of the finest emulsions
• Homogenising of substances
• Degassing of liquids
• Sample preparation for the grain size analysis
• Acceleration of chemical reactions
• Sample preparation for sewerage analysis
2.2 Explosion hazard
Do not use the device with combustible liquids as a sonicating medium.
Combustible vapours may be generated when flammable liquids are sonicated.
Vapours may ignite, e.g. on electrical components, resulting in an explosion.
Do not use combustible solvents in open sonication vessels, as the operational
safety of the device could be compromised. Safe extraction of combustible
vapours must be guaranteed.
2.3 Hazards due to high temperature
Ultrasound heats up the sonicating medium. The device, the sonicating medium
and the sonication vessel can become very hot during prolonged ultrasound oper-
ation. Contact with these products may cause burns.
• Do not leave the ultrasound switched on for longer than necessary.
• Allow the probe and sonication vessel to cool down before touching them.
Non-aqueous liquids can heat up many times faster than water. A possible flash-
point can be reached or exceeded after a very short sonication time. In the case of
high-boiling liquids, the temperature can rise to over 120 °C due to the energy
input of the ultrasound. This can lead to fires and severe burns.

51846-000 en/2022-07 7/36
Safety/2
2.4 Danger of electric shock
The device is an electrical device. Failure to follow safety rules can result in a life-
threatening electric shock.
• Protect the device from moisture and wetness. Keep the surfaces and the
touchscreen clean and dry.
• Do not spray or expose the device to splash water.
• Do not cover the device.
• Position the device so that it is easy to unplug the mains connection at any
time and without difficulty.
• Only connect the device to a power outlet with a grounded socket.
• If you notice a defect in the device, disconnect the mains plug immediately. Do
not connect a defective device to the mains.
• Repairs should only be carried out by the manufacturer.
2.5 Danger due to ultrasound
Strong ultrasound destroys cell structures. Exposing a body part to ultrasound
can lead not just to skin damage, but also to internal tissue damage. On fingers,
the periosteum can become damaged.
• Do not touch the probe, the booster horn or the standard horn during opera-
tion. Do not touch the sonication fluid during operation.
• Never sonicate living beings.
2.6 Danger due to the sonicating medium
The sonicating media treated with the device can be toxic, corrosive or otherwise
harmful to health. Vapours and aerosols can also be dangerous.
• Wear gloves and safety goggles when handling hazardous preparations.
• Make sure that the sonicating medium does not splash. This can particularly
occur with small quantities of sonicating medium. Only switch on the device
once the probe has been immersed in the sonicating medium. Start sonication
with a low amplitude.
• Do not lean over the ultrasound bath, in order to avoid vapours from coming
into contact with the eyes or from being inhaled.
• In case of dangerous vapours, use a suction device.

2 / Safety
8/36 51846-000 en/2022-07
2.7 Harmful to health due to ultrasound noise
The ultrasound noise typical of the process can be perceived as very unpleasant.
Remaining within a radius of 2 m for an extended period of time may cause dam-
age to health.
• Use a sound proof box; see 9Accessories. The sound proof box significantly
reduces the noise level.
• When operating without a sound proof box, wear hearing protection.
2.8 Keep out of reach of children
Children cannot identify hazards posed by the ultrasound bath. Therefore, keep
the ultrasound bath out of the reach of children.
2.9 Damage to the probe and sonication vessel
Probes are sensitive to shock. Handle the probes with care.
Make sure that the probe does not touch the sonication vessel. This can damage
the probe and the vessel.
Foreign bodies on the contact surface between the probe and standard horn or
booster horn can destroy both parts. Therefore, always clean the contact surfaces
thoroughly before mounting the probe.
The sound-emitting surface of the probe is subject to erosion. Erosion reduces
the efficiency of the sonication process. The sonication of corrosive liquids leads
to increased wear.
The sound-emitting surface can be reconditioned up to a certain point of erosion.
See 6.2Refurbish probe.
2.10 Disturbance of wireless communication
The device may interfere with other wireless communication ultrasound baths in
the immediate vicinity.
If interference occurs with the operation of a wireless device, move it further
away from the ultrasound bath.

51846-000 en/2022-07 9/36
Design and function/3
3 Design and function
3.1 Overview
Fig. 1 Overview of the device
1Ultrasoundgenerator
2 Touchscreen
3 Connector for ultrasonic converter
4LANconnection
5USBTypeBport
6USBTypeAport
7Mainsswitch
8 Cold device socket with fuse holder
9 Ultrasonic converter
10 Start/Stop key
11 Standard horn/booster horn
12 Probe
21
5
6
7
8 10
11
12
9
4
3

3 / Design and function
10/36 51846-000 en/2022-07
3.2 Symbols and buttons on the touch screen
3.3 Function
The device transforms the absorbed grid energy into high-frequency energy. The
ultrasonic converter converts the high-frequency energy into ultrasound. At the
tip of the probe, mechanical deflections are created that are transferred into the
sonicating medium as ultrasonic waves with a high power density. The standard
horn or booster horn allows multiple amplification of the mechanical amplitude at
the probe tip.
For sonication, the power or amplitude can be selected as the reference variable.
If the amplitude is selected as the reference variable, it is kept constant by the
ultrasonic converter regardless of the load, provided that the permissible maxi-
mum power is not exceeded. An optional temperature sensor enables the tem-
perature of the sonicating medium to be monitored.
The device saves documentation of its function. Documentation can be backed up
via a USB port or LAN port for evaluation and archiving.
The device is operated with a touchscreen. In addition, the ultrasound can be
switched on and off with a button on the ultrasonic converter.
Return to previous screen
Reset values
Confirm/Save
Go to startup screen
Calling up the screen help
Start
Pause
Stop

51846-000 en/2022-07 11/36
Preparation for operation/4
4 Preparation for operation
4.1 Set up homogeniser
1. Place the ultrasonic generator on a firm, level and dry surface.
2. Screw the probe onto the standard horn or booster horn, or to the ultrasonic
converter (HD 5020/5050); see 4.2Mounting/removing the probe.
3. Clamp the ultrasonic converter on the black housing in a suitable holder. BAN-
DELIN recommends the HG 40 stand; see 9Accessories.
4. If you are using a sound proof box, place the holder with the ultrasonic con-
verter in the sound proof box.
5. Insert the plug of the ultrasonic converter into the connection on the rear of
the ultrasonic generator.
6. Optional: Connect the temperature sensor to the ultrasonic converter.
7. Check that the mains switch is set to "0". Insert the mains plug into a
grounded socket.
4.2 Mounting/removing the probe
NOTICE
Damage to the ultrasonic converter
If the ultrasonic oscillating system in the housing of the ultrasonic converter
twists, the ultrasonic converter will be damaged.
– Always use the sickle spanner to secure the standard horn or booster horn.
– Never hold the ultrasonic converter by the housing when tightening or loos-
ening the probe.
Requirement
• The ultrasonic converter is disconnected from the ultrasonic generator.
• Tools required: 1 sickle spanner, 1 spanner (supplied tool set)
Procedure
1. Clean the mounting surfaces of the standard horn, booster horn, or the ultra-
sonic converter (HD 5020/5050) and the probe.
2. Screw the probe on hand-tight.
3. Place the ultrasonic converter on a firm tabletop. In the case of probes, sup-
port the probe tip with a thick underlay if necessary.
4. Place the sickle spanner on the standard horn, booster horn, or the ultrasonic
converter (HD 5020/5050). Support the sickle spanner on the tabletop; see
also the following figures.
5. Firmly tighten the probe with the spanner. Use of a torque wrench (Code No.
3662) is recommended – not for HD 5020 and HD 5400. The required tight-
ening torque can be found in the product information supplied with the probe.

4 / Preparation for operation
12/36 51846-000 en/2022-07
Fig. 2 Loosen (A) and tighten (B) the probe
A video on loosening and attaching the probe is available:
https://www.youtube.com/watch?v=hjTC_cvO4kQ
4.3 Mounting/removing standard horn or booster horn
NOTICE
Damage to the ultrasonic converter
If the ultrasonic oscillating system in the housing of the ultrasonic converter
twists, the ultrasonic converter will be damaged.
– Always use the sickle spanner to secure the standard horn or booster horn.
– Never hold the ultrasonic converter by the housing when tightening or loos-
ening the probe.
Requirement
• The ultrasonic converter is disconnected from the ultrasonic generator.
• Tools required: Sickle spanner for ultrasonic converter and standard horns or
booster horns (supplied tool set).
Procedure
1. Place a sickle spanner on the ultrasonic converter. Place the ultrasonic con-
verter on a fixed tabletop and support the sickle spanner on the tabletop.
2. Place a sickle spanner on the standard horn or booster horn. Loosen the
standard horn or booster horn.
20 mm
20 mm
B
A

51846-000 en/2022-07 13/36
Preparation for operation/4
Fig. 3 Removing standard horn or booster horn
1. Unscrew the standard horn or booster horn by hand.
2. Clean the mounting surfaces of the ultrasonic converter and the standard
horn or booster horn, as well as the thread of the threaded pin, with a lint-
free cloth soaked in alcohol.
3. Screw the standard or booster horn hand-tight into the ultrasonic converter.
4. Place a sickle spanner on the ultrasonic converter. Place the ultrasonic con-
verter on a fixed tabletop and support the sickle spanner on the tabletop.
5. Place a sickle spanner on the standard horn or booster horn. Tighten firmly.
Use of a torque wrench (Code No. 3662) is recommended. The required tight-
ening torque can be found in the product information supplied with the stand-
ard horn or booster horn.
Fig. 4 Tightening standard horn or booster horn
A video is available for mounting and disassembling the standard
horn or booster horn:
https://www.youtube.com/watch?v=NXbGc6nAb5c

4 / Preparation for operation
14/36 51846-000 en/2022-07
4.4 Switching the device on and off
Switching on the ultrasonic homogeniser for the first time
Allow the device to stand for 2 hours at its operating location before switching it
on so that it can adapt to the climatic conditions.
1. Switch on the device using the mains switch on the rear of the ultrasonic gen-
erator.
» The "Language" screen appears.
2. Select your language.
» The "Time/Date" screen appears.
3. Tap the values to be changed. Enter the desired values. Confirm the entries
with the "Confirm/Save" button. Exit the "Time/Date" screen by pressing the
"Confirm/Save" button.
» The startup screen appears.
If the language and time are set, the startup screen will appear immediately the
next time the device is switched on. If the startup screen does not appear, see
5.7Troubleshooting a malfunction.
Switching the ultrasonic homogeniser off
Switch off the device using the mains switch on the rear of the ultrasonic genera-
tor.
4.5 Select probe
The control unit of the device automatically detects the connected ultrasonic con-
verter. The mounted probe must be selected via the touchscreen.
1. On the startup screen, tap "Probe".
2. Select the probe used.
3. Confirm your entry with the "Confirm/Save" button.

51846-000 en/2022-07 15/36
Operation/5
5Operation
5.1 Immersion depth notes
The recommended immersion depth for probes is 10 ... 20 mm, to prevent the
aspiration and mixing-in of air. If mixed-in air is desired, the probe may be
immersed just a few millimetres.
When producing emulsions, the probe should be immersed to the height of the
surface separating the liquids to be mixed.
5.2 Preselect parameters for sonication
5.2.1 Set amplitude or power
Information
In the case of greater immersion depths or the sonication of liquids with high vis-
cosities, the probe is more heavily damped. As a result, the preset amplitude may
not be reached.
The device can regulate the emitted ultrasonic power so that either a set ampli-
tude is kept constant or a set power is kept constant. The amplitude is given in %.
The absolute value of the amplitude depends on the combination of standard
horn or booster horn and probe. The power is specified in watts and depends on
the respective ultrasonic converter.
1. On the startup screen, tap "Parameters".
2. Tap "Ampl./Power".
3. Tap "Amplitude" if sonication is to be carried out with a constant amplitude, or
"Power" if sonication is to be carried out with a constant power.
4. Select the desired value for amplitude or power. You can move the bar of the
selected setting parameter or enter a numerical value.
5. Confirm your entry with the "Confirm/Save" button.
With amplitude regulation, the amplitude is kept constant. The power can vary
depending on the condition of the medium. When the respective maximum power
is reached, the amplitude is reduced.
Power control keeps the power constant. The power can vary depending on the
condition of the medium. When the respective maximum amplitude is reached,
the power is reduced.

5 / Operation
16/36 51846-000 en/2022-07
5.2.2 Enter sonication time
1. On the startup screen, tap "Parameters".
2. Tap on "Time".
3. Make the desired settings for the sonication time.
» A time setting is only effective if "Continuous operation" is not activated.
4. Confirm your entry with the "Confirm/Save" button.
5.2.3 Set pulsation
The sonication can be switched on continuously or in pulses.
1. On the startup screen, tap "Parameters".
2. Tap "Pulsation".
3. Turn pulsation on or off.
4. Enter how long you want the sonication to be alternately switched on and off.
5. Confirm your entry with the "Confirm/Save" button.
5.2.4 Setting temperature monitoring
If you use a temperature sensor, you can monitor the temperature of the sonicat-
ing medium during sonication. You can set whether the ultrasound is switched off
or only a warning tone is emitted when a limit value between 0 °C and 100 °C is
reached. To do this, connect the TM 5000 temperature sensor to the lid of the
respective ultrasonic converter after removing the dust cap. The temperature
now appears on the display.
1. On the startup screen, tap "Parameters".
2. Tap “Temperature.”
3. Make the desired changes. To set the temperature, you can move the bar or
enter a numerical value.
4. Confirm your entry with the "Confirm/Save" button.

51846-000 en/2022-07 17/36
Operation/5
5.3 Start sonication
Requirement
• The probe tip is immersed in the sonicating medium; see 5.1Immersion
depth notes.
1. On the startup screen, tap the "Start" button.
» The “Sonication” screen appears.
» The preselected sonication parameters are displayed; see 5.2Preselect
parameters for sonication
2. Optional: Tap one of the buttons "Amplitude," "Power," "Time," "Pulsation" or
"Temperature" to change the preselected settings for the current sonication.
Confirm the new settings by tapping the "Confirm/Save" button.
3. Tap the "Start" button at the bottom of the screen.
» The sonication begins.
» If the timer was set, the sonication ends automatically after the set time.
» You can interrupt the sonication at any time with the "Pause" button or end
it with the "Stop" button.
» After the end of sonication, a screen with a summary of the sonication
appears.
4. Tap the "Confirm/Save" button.
» The sonication screen reappears with the last settings.
5.4 Creating and starting programs
5.4.1 About programs
Programs are saved parameter sets for sonication. Amplitude or power, time and
pulsation are stored in a program. A total of eight programs can be stored. Each
program can be active or inactive. The sequence in which the programs are exe-
cuted can be defined as required.
5.4.2 Creating a program
1. On the startup screen, tap "Programs".
» The "Programs" overview screen is shown.
2. Tap on a program number.
3. If a screen with the summary of the program parameters appears, tap "Edit".
4. Tap the "Ampl./Power," "Time" or "Pulsation" button to edit the program
parameters; see 5.2Preselect parameters for sonication. Confirm your entry
with the "Confirm/Save" button.
5. Tap the "Confirm/Save" button to save the program.

5 / Operation
18/36 51846-000 en/2022-07
5.4.3 Activating and deactivating a program
Activating a program
1. On the startup screen, tap "Programs".
» The "Programs" overview screen is shown.
2. Tap on a program number.
3. If a screen with the summary of the program parameters appears, tap "Edit".
4. Under "Sequence," select the position in the sequence of programs.
5. Set the sliding switch to "on".
6. Tap the "Confirm/Save" button to save the activation.
7. Tap the "Back" button on the screen with the summary of the program
parameters.
» The "Programs" overview screen is shown.
» Activated programs are shown in colour.
» For programs that are assigned a position in the sequence, the three dots
under the program number are shown in black.
Deactivating a program
1. On the startup screen, tap "Programs".
» The "Programs" overview screen is shown.
2. Tap on a program number that is highlighted in colour.
» The screen with the summary of program parameters appears.
3. Tap the "Deactivate" button.
» The button changes to "Activate".
» The program is deactivated.
» The position of the program in the sequence remains reserved.
4. Tap the "Back" button.
» The "Programs" overview screen is shown.
» The deactivated program is shown in grey.
Deactivate a program and release its position in the sequence
1. On the startup screen, tap "Programs".
» The "Programs" overview screen is shown.
2. Tap on a program number that is highlighted in colour.
3. Tap the "Edit" button.
4. Tap the "Reset" button below.
» The number after "Sequence" changes to "0".
» The slide switch changes to "off".
5. Tap the "Confirm/Save" button.
6. Tap the "Back" button.
» The "Programs" overview screen is shown.
» The deactivated program is shown in grey.
» The three dots under the program number are shown in light colour.

51846-000 en/2022-07 19/36
Operation/5
5.4.4 Starting a program
To start set and activated programs in the specified sequence, proceed as fol-
lows:
Requirement
• The probe tip is immersed in the sonicating medium; see 5.1Immersion
depth notes.
• At least one program is activated and a space is assigned in the sequence; see
5.4.3Activating and deactivating a program.
1. On the startup screen, tap "Programs".
» The "Programs" overview screen is shown. The sequence of activated pro-
grams is displayed at the top.
2. Tap the “Start” button.
» The "Sonication" screen appears with the settings of the first activated pro-
gram in the specified sequence. The individual parameters can still be
changed by tapping one of the buttons "Amplitude," "Power," "Time," "Pul-
sation" or "Temperature". Confirm the new settings by tapping the "Con-
firm/Save" button.
3. Optional: Tap one of the buttons "Amplitude," "Power," "Time," "Pulsation" or
"Temperature" to change the preselected settings for the first program. Con-
firm the new settings by tapping the "Confirm/Save" button. The changed
parameters now only apply to the current sonication process. The parameters
stored in the programs remain unchanged.
4. Tap the “Start” button.
» The sonication begins.
» The sonication ends automatically after completion of the activated pro-
grams.
» You can interrupt the sonication at any time with the "Pause" button or end
it with the "Stop" button.
» After the end of sonication, a screen with a summary of the sonication
appears.
5. Tap the "Confirm/Save" button.
» The "Sonication" screen appears again.

5 / Operation
20/36 51846-000 en/2022-07
5.5 Creating documentation
Activate logging
Information
The logs are also generated without connection of a USB device. They can be
exported later, as long as the device has not been switched off in the meantime.
The logs are lost when the device is switched off.
1. On the startup screen, tap “Settings”.
2. Tap "Documentation".
3. Activating logging.
4. Confirm your entry with the "Confirm/Save" button.
Define institution
The data specified under "Institution" is stored in the documentation issued.
1. On the startup screen, tap “Settings”.
2. Tap "Documentation".
3. Tap "Institution".
4. Enter the desired data.
5. Confirm your entry with the "Confirm/Save" button.
Export documentation via USB
You can connect a USB device to the back of the ultrasonic generator to secure
data even without a network connection.
1. On the startup screen, tap “Settings”.
2. Tap "Documentation".
3. Tap "USB Export".
4. Select the desired medium.
Deleting documentation
1. On the startup screen, tap “Settings”.
2. Tap "Documentation".
3. Tap on "Delete".
4. Select the desired documentation.
5. Confirm your entry with the "Confirm/Save" button.
