Banner Sure Cross DX80 User manual

Datasheet
Configurable DX80 Gateway that uses DIP switches to map inputs from up to six Nodes (or Wireless Q45 Sensors) to the
Gateway's outputs
DX80...C Model
DX80 Model
The Sure Cross®wireless system is a radio frequency network with integrated I/O that operates
in most environments and eliminates the need for wiring runs. Systems are built around a
Gateway, which acts as the wireless network master device, and one or more Wireless Q45
Sensors.
• Wireless industrial I/O device with six discrete (sourcing) inputs and six discrete
(sourcing) outputs
• DIP switches allow the user to select one of eight defined I/O mapping configurations to
automatically map the Nodes' inputs to this Gateway's outputs
• Frequency Hopping Spread Spectrum (FHSS) technology ensures reliable data delivery
within the unlicensed Industrial, Scientific, and Medical (ISM) band
• Transceivers provide bidirectional communication between the Gateway and Node,
including fully acknowledged data transmission
• Site Survey analyzes the network’s signal strength and reliability and displays the results
on the Gateway's LCD
• LCD shows I/O status, Site Survey results, and network status information
• Lost RF links are detected and relevant outputs set to user-defined conditions
For additional information, updated documentation, and a list of accessories, refer to Banner Engineering's website,
www.bannerengineering.com.
WARNING:
•Do not use this device for personnel protection
• Using this device for personnel protection could result in serious injury or death.
• This device does not include the self-checking redundant circuitry necessary to allow its use in
personnel safety applications. A device failure or malfunction can cause either an energized (on) or de-
energized (off) output condition.
Models
Model Frequency Environmental Rating I/O
DX80G2M6-Q
2.4 GHz ISM Band
IP67, NEMA 6 Inputs: Six sourcing discrete
Outputs: Six sourcing discrete
DX80G2M6-QC IP20, NEMA 1
Configure and Install Your Q45 Network
Follow these steps to set up and install your Wireless Q45 network.
1. On the Wireless Q45 Sensor Node:
a) Configure the DIP switches (if applicable).
b) Apply power.
2. On the Gateway or DXM:
a) Configure the DIP switches (if applicable).
b) Wire the I/O.
c) Apply power.
3. Bind the Q45 to the master radio.
4. Observe the LED behavior to verify the devices are communicating to each other.
5. Using the configuration software, configure the I/O mapping between the Q45 and its master radio.
6. Conduct a Site Survey between the Gateway and the Wireless Q45.
7. Install your devices.
Configure the Gateway
Sure Cross®DX80 Gateway for Wireless Q45
Sensors
Original Document
161862 Rev. E
3 December 2020
161862

Configure the DIP Switches
Before changing DIP switch positions, disconnect the power. Any changes made to the DIP switches are not recognized until after
power is cycled to the device.
For parameters not set using the DIP switches, use the User Configuration Software to make configuration changes. For
parameters set using the DIP switches, the DIP switch positions override any changes made using the User Configuration
Software.
Access the Internal DIP Switches
Follow these steps to access the internal DIP switches.
1. Unscrew the four screws that mount the cover to the bottom housing.
2. Remove the cover from the housing without damaging the ribbon cable or the pins the cable plugs into.
3. Gently unplug the ribbon cable from the board mounted into the bottom housing. Skip this step if there is no ribbon cable
(integrated battery models) or the ribbon cable is glued down (C housing models).
4. Remove the black cover plate from the bottom of the device's cover.
The DIP switches are located behind the rotary dials.
5. Make the necessary changes to the DIP switches.
6. Place the black cover plate back into position and gently push into place.
7. If necessary, plug the ribbon cable in after verifying that the blocked hole lines up with the missing pin.
8. Mount the cover back onto the housing.
DIP Switch Settings
At this time, DIP switch 1 is not used.
Modbus/UCT Configured or DIP Switch Configured— In Modbus/Software Configured mode, use the User Configuration Software
or a Modbus command to change the device parameters. DIP switch positions 3 through 8 are ignored. In DIP Switch Configured
mode, use the DIP switches to configure the parameters listed in the table. By default, this Gateway uses the DIP switches to
configure the device.
DIP Switch
2 Modbus/UCT Configured or DIP Switch Configured
OFF * DIP switch configured
ON Modbus or UCT configured (DIP switches 3-8 are ignored)
Output State During a Radio Link Loss— The Sure Cross®wireless devices use a deterministic radio link time-out method to
address RF link interruption or failure. When a radio link fails, all pertinent wired outputs are set to defined states until the link is
recovered, ensuring that disruptions in the communications link result in predictable system behavior. Select the state the outputs
are changed to during a link loss.
DIP Switches
3 4 Output State During a Radio Link Loss
OFF * OFF * Off (discrete) or 0 mA (analog)
OFF ON On (discrete) or 20 mA (analog)
ON OFF Hold last stable state
ON ON Reserved
* Default configuration
Heartbeat—In heartbeat mode, the Nodes send "heartbeat" messages to the Gateway at specific intervals to indicate the radio link
is active. The heartbeat is always initiated by the Node and is used only to verify radio communications. In this network, the
Wireless Q45 Sensors act as Nodes.
DIP Switch
5 Heartbeat Settings
OFF * 30 seconds (30 to 60 second link loss timeout)
ON 5 seconds (5 to 10 second link loss timeout)
* Default configuration
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
2 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 161862 Rev. E

I/O and Link Loss Alarm Mapping - Wireless Q45 Sensors—The link loss alarm is set to zero (0) when the radio link is working and
set to one (1) when the radio link is lost.
Six Wireless Q45 Sensors to One Gateway DIP Switches
6 = OFF* 7 = OFF* 8 = OFF*
Gateway
Node 01
Node 02
Node 04
Node 03
Node 05
Node 06
Six Q45 Wireless Sensors:
Q45 1 → Gateway OUT 1
Q45 2 → Gateway OUT 2; etc.
* Default configuration. To use up to 47 Nodes or Wireless Q45 Sensors with this Gateway, you must use a Modbus host controller
system. For more information about using a host controller system, refer to the
Host Configuration manual, Banner document part
number 132114.
Three Wireless Q45 Sensors to One Gateway DIP Switches
6 = OFF 7 = OFF 8 = ON
Gateway
Node 01
Node 02
Node 03
Three Wireless Q45 Sensors and three link loss:
Q45 1 → Gateway OUT 1; Link loss alarm for Q45 1 → Gateway OUT 2
Q45 2 → Gateway OUT 3; Link loss alarm for Q45 2 → Gateway OUT 4
Q45 3 → Gateway OUT 5; Link loss alarm for Q45 3 → Gateway OUT 6
Three Wireless Q45 Sensors to One Gateway DIP Switches
6 = OFF 7 = ON 8 = OFF
Gateway
Node 01
Node 02
Node 03
Three Wireless Q45 Sensors, two inputs each:
Q45 1, IN 1 → Gateway OUT 1; Q45 1, IN 2 → Gateway OUT 2
Q45 2, IN 1 → Gateway OUT 3; Q45 2, IN 2 → Gateway OUT 4
Q45 3, IN 1 → Gateway OUT 5; Q45 3, IN 2 → Gateway OUT 6
Two Wireless Q45 Sensors to One Gateway DIP Switches
6 = OFF 7 = ON 8 = ON
Gateway
Node 01
Node 02
Two Wireless Q45 Sensors, two inputs each, with link loss:
Q45 1, IN 1 → Gateway OUT 1
Q45 1, IN 2 → Gateway OUT 2
Link loss alarm for Q45 1 → Gateway OUT 3
Q45 2, IN 1 → Gateway OUT 4
Q45 2, IN 2 → Gateway OUT 5
Link loss alarm for Q45 2 → Gateway OUT 6
I/O and Link Loss Mapping - Nodes and Gateways
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
P/N 161862 Rev. E www.bannerengineering.com - Tel: + 1 888 373 6767 3

One Node to One Gateway DIP Switches
6 = ON 7 = OFF 8 = OFF
GatewayNode 01
One SureCross DX80 Node with 6 inputs and 6 outputs:
Node 1, IN 1 → Gateway OUT 1; Gateway IN 1 → Node 1, OUT 1
Node 1, IN 2 → Gateway OUT 2; Gateway IN 2 → Node 1, OUT 2
Node 1, IN 3 → Gateway OUT 3; Gateway IN 3 → Node 1, OUT 3
Node 1, IN 4 → Gateway OUT 4; Gateway IN 4 → Node 1, OUT 4
Node 1, IN 5 → Gateway OUT 5; Gateway IN 5 → Node 1, OUT 5
Node 1, IN 6 → Gateway OUT 6; Gateway IN 6 → Node 1, OUT 6
Two Nodes to One Gateway DIP Switches
6 = ON 7 = OFF 8 = ON
Gateway
Node 01
Node 02
Two SureCross DX80 Nodes, each with 3 inputs and 3 outputs
Node 1, IN 1 → Gateway OUT 1; Gateway IN 1 → Node 1, OUT 1
Node 1, IN 2 → Gateway OUT 2; Gateway IN 2 → Node 1, OUT 2
Node 1, IN 3 → Gateway OUT 3; Gateway IN 3 → Node 1, OUT 3
Node 2, IN 1 → Gateway OUT 4; Gateway IN 4 → Node 2, OUT 1
Node 2, IN 2 → Gateway OUT 5; Gateway IN 5 → Node 2, OUT 2
Node 2, IN 3 → Gateway OUT 6; Gateway IN 6 → Node 2, OUT 3
Three Nodes to One Gateway DIP Switches
6 = ON 7 = ON 8 = OFF
Gateway
Node 01
Node 02 Node 03
Three SureCross DX80 Nodes, each with 2 inputs and 2 outputs
Node 1, IN 1 → Gateway OUT 1; Gateway IN 1 → Node 1, OUT 1
Node 1, IN 2 → Gateway OUT 2; Gateway IN 2 → Node 1, OUT 2
Node 2, IN 1 → Gateway OUT 3; Gateway IN 3 → Node 2, OUT 1
Node 2, IN 2 → Gateway OUT 4; Gateway IN 4 → Node 2, OUT 2
Node 3, IN 1 → Gateway OUT 5; Gateway IN 5 → Node 3, OUT 1
Node 3, IN 2 → Gateway OUT 6; Gateway IN 6 → Node 3, OUT 2
Six Nodes to One Gateway DIP Switches
6 = ON 7 = ON 8 = ON
Gateway
Node 01
Node 02 Node 03
Node 06
Node 04
Node 05
Six SureCross DX80 Nodes, each with 1 input and 1 output
Node 1, IN 1 → Gateway OUT 1; Gateway IN 1 → Node 1, OUT 1
Node 2, IN 1 → Gateway OUT 2; Gateway IN 2 → Node 2, OUT 1
Node 3, IN 1 → Gateway OUT 3; Gateway IN 3 → Node 3, OUT 1
Node 4, IN 1 → Gateway OUT 4; Gateway IN 4 → Node 4, OUT 1
Node 5, IN 1 → Gateway OUT 5; Gateway IN 5 → Node 5, OUT 1
Node 6, IN 1 → Gateway OUT 6; Gateway IN 6 → Node 6, OUT 1
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
4 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 161862 Rev. E

Wire the Gateway's I/O
PWR
GND
DO6
DO5
DO4
DO3
DO2
DO1
PWR
GND
DI6
DI5
DI4
DI3
DI2
DI1
Wire the
Gateway’s I/O
DI1
DI2
DI3
DI4
DI5
DI6
V-
V-
V+
V+
DO6
DO5
DO1
DO2
DO3
DO4
Tx/+
Rx/-
DI x . Discrete IN x
DO x . Discrete OUT x
GND. Ground/DC common connection
PWR. 10 to 30 V DC power connection
RX/-. Serial communication line for the Gateway. No connection
for Nodes
TX/+. Serial communication line for the Gateway; no connection
for Nodes
V+. 10 to 30 V DC power connection
V–. Ground/DC common connection
Discrete Input Wiring for PNP Sensors Discrete Output Wiring (PNP)
Discrete IN
PWR
10-30V dc
Discrete OUT
GND
PWR
10-30V dc
Load
dc common
Modbus Register Table for the Gateway with Switch-Based Mapping
I/O Modbus Holding
Register (Gateway)
I/O Type I/O Range Holding Register
Representation
Terminal Block
Labels
Min. Max. Min. (Dec.) Max. (Dec.)
1 1 Discrete IN 1 0 1 0 1 DI1
2 2 Discrete IN 2 0 1 0 1 DI2
3 3 Discrete IN 3 0 1 0 1 DI3
4 4 Discrete IN 4 0 1 0 1 DI4
5 5 Discrete IN 5 0 1 0 1 DI5
6 6 Discrete IN 6 0 1 0 1 DI6
7 7 Reserved
8 8 Device Message
9 9 Discrete OUT 1 0 1 0 1 DO1
10 10 Discrete OUT 2 0 1 0 1 DO2
11 11 Discrete OUT 3 0 1 0 1 DO3
12 12 Discrete OUT 4 0 1 0 1 DO4
13 13 Discrete OUT 5 0 1 0 1 DO5
14 14 Discrete OUT 6 0 1 0 1 DO6
15 15 Control Message
16 16 Reserved
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
P/N 161862 Rev. E www.bannerengineering.com - Tel: + 1 888 373 6767 5

Discrete Bit-Packed Registers
Discrete bit-packed registers include the discrete status registers, discrete inputs, and discrete outputs.
Bit packing involves using a single register, or range of contiguous registers, to represent I/O values.
When networks use similar Nodes to gather data using the same I/O registers for each Node, discrete data from multiple Nodes
can be bit packed into a single register on the Gateway. The bit-packed data is arranged by I/O point starting at Modbus register
6601. For example, Discrete IN 1 for all the Nodes in the network is stored in three contiguous 16-bit registers.
The most efficient way to read (or write) discrete data from a Sure Cross®DX80 Gateway is by using these bit-packed registers
because users can read or write registers for all devices using one Modbus message. The following registers contain discrete bit-
packed I/O values for the Gateway and all Nodes. Values are stored first for the Gateway, then for each Node in order of Node
address.
Bit-Packed Device Status Registers
Bit Position
Register Address 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
6601 Node 15 Node 14 Node 13 Node 12 Node 11 Node 10 Node 9 Node 8 Node 7 Node 6 Node 5 Node 4 Node 3 Node 2 Node 1 Gateway
6602 Node 31 Node 30 Node 29 Node 28 Node 27 Node 26 Node 25 Node 24 Node 23 Node 22 Node 21 Node 20 Node 19 Node 18 Node 17 Node 16
6603 Node 47 Node 46 Node 45 Node 44 Node 43 Node 42 Node 41 Node 40 Node 39 Node 38 Node 37 Node 36 Node 35 Node 34 Node 33 Node 32
Bit-Packed Discrete Input 1
Bit Position
Register Address 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
6611 Node 15 Node 14 Node 13 Node 12 Node 11 Node 10 Node 9 Node 8 Node 7 Node 6 Node 5 Node 4 Node 3 Node 2 Node 1 Gateway
6612 Node 31 Node 30 Node 29 Node 28 Node 27 Node 26 Node 25 Node 24 Node 23 Node 22 Node 21 Node 20 Node 19 Node 18 Node 17 Node 16
6613 Node 47 Node 46 Node 45 Node 44 Node 43 Node 42 Node 41 Node 40 Node 39 Node 38 Node 37 Node 36 Node 35 Node 34 Node 33 Node 32
Bit-Packed Discrete Output 1
Bit Position
Register Address 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
6691 Node 15 Node 14 Node 13 Node 12 Node 11 Node 10 Node 9 Node 8 Node 7 Node 6 Node 5 Node 4 Node 3 Node 2 Node 1 Gateway
6692 Node 31 Node 30 Node 29 Node 28 Node 27 Node 26 Node 25 Node 24 Node 23 Node 22 Node 21 Node 20 Node 19 Node 18 Node 17 Node 16
6693 Node 47 Node 46 Node 45 Node 44 Node 43 Node 42 Node 41 Node 40 Node 39 Node 38 Node 37 Node 36 Node 35 Node 34 Node 33 Node 32
Inputs Outputs
Modbus Register Address
(Decimal)
Description (Inputs) Modbus Register Address
(Decimal)
Description (Outputs)
6601–6603 Status for all devices
6611–6613 Input 1 from all devices 6691–6693 Output 1 from all devices
6621–6623 Input 2 from all devices 6701–6703 Output 2 from all devices
6631–6633 Input 3 from all devices 6711–6713 Output 3 from all devices
6641–6643 Input 4 from all devices 6721–6723 Output 4 from all devices
6651–6653 Input 5 from all devices 6731–6733 Output 5 from all devices
6661–6663 Input 6 from all devices 6741–6743 Output 6 from all devices
6671–6673 Input 7 from all devices 6751–6753 Output 7 from all devices
6681–6683 Input 8 from all devices
Status registers (6601–6603) contain a bit-packed representation defining the devices that are operational in the wireless system.
Each bit indicates Node in Sync (1) or Node Not in Sync (0).
A one (1) written to the Discrete Status Register area indicates the device is active within the wireless system. A zero (0) indicates
the device is not active within the wireless network.
Input registers from all devices use Modbus registers 6611 through 6683 to organize the least significant bit into a sequential array
of registers. The first register contains the least significant bit from the input values for the Gateway through Node 15. The second
register contains the input values for Node 16 through Node 31, and the third register contains the input values for Nodes 32
through 47.
For discrete inputs, only the least significant bit is used. For analog inputs, the least significant bit indicates if the analog value is
above or below the selected threshold value (when using the threshold parameter configured in the User Configuration Software).
For example, a least significant bit of one (1) indicates the analog value is above the selected threshold value. A least significant bit
of zero (0) indicates the analog value is below the threshold value.
Output registers from all devices use Modbus registers 6691 through 6753 to organize the least significant bit into a sequential
array of registers. Output 8 (I/O point 16) cannot be written using the discrete format.
Apply Power to the Gateway
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
6 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 161862 Rev. E

5-pin M12/Euro-style Wiring for Gateways and DX85s
Wiring the 5-pin M12/Euro-style connector depends on the model and power requirements of the device. Connecting power to the
communication pins will cause permanent damage.
5-pin M12/Euro-style Connector (male) Pin Wire Color Description
1
4
5
3
2
1 Brown (bn) 10 to 30 V DC
2 White (wh) RS485 / D1 / B / +
3 Blue (bu) DC common (GND)
4 Black (bk) RS485 / D0 / A / –
5 Gray (gy) Comms Gnd
DX80...C Wiring
Wiring power to the DX80...C models varies depending the power requirements of the model. Connecting DC power to the
communication pins (Tx/Rx) causes permanent damage. For Flex Power devices, do not apply more than 5.5 V to the B+ terminal.
Terminal Label Gateway and DX85 10 to 30 V DC Powered Nodes Battery Powered Nodes
V+ 10 V DC to 30 V DC 10 V DC to 30 V DC
Tx/+ RS485 / D1 / B / +
V– DC common (GND) DC common (GND) DC common (GND)
Rx/– RS485 / D0 / A / -
B+ 3.6 to 5.5 V DC
Bind to the Gateway and Assign the Node Address
Before beginning the binding procedure, apply power to all the devices. Separate the devices by two meters when running binding
procedure. Put only one Gateway into binding at a time to prevent binding to the wrong Gateway.
1. On the Gateway: Enter binding mode.
• For housed DX80 Gateways, triple-click button 2 on the Gateway. Both LEDs flash red.
• For Gateway board modules, triple-click the button. The green and red LED flashes.
2. Assign the DX80 a Node address using the Gateway's rotary dials. Use the left rotary dial for the left digit and the right
rotary dial for the right digit. For example, to assign your DX80 to Node 10, set the Gateway's left dial to 1 and the right dial
to 0. Valid Node addresses are 01 through 47.
3. On the Q45: Loosen the clamp plate on the top of the DX80 and lift the cover.
4. Enter binding mode on the DX80 by triple-clicking the DX80's button.
The red and green LEDs flash alternately and the sensor searches for a Gateway in binding mode. After the DX80 is bound,
the LEDs stay solid momentarily, then they flash together four times. The DX80 exits binding mode.
5. Label the sensor with the DX80's Node address number for future reference.
6. Repeat steps 2 through 5 for as many DX80s as are needed for your network.
7. On the Gateway: After binding all DX80s, exit binding mode.
• For housed DX80 Gateways, double-click button 2.
• For board-level DX80 Gateways, double-click the button.
For Gateways with single-line LCDs: After binding your DX80 to the Gateway, make note of the binding code displayed under the
Gateway's *DVCFG menu, XADR submenu on the LCD. Knowing the binding code prevents having to re-bind all DX80s if your
Gateway is ever replaced.
Verify Communication Between the Gateway and the Wireless Q45 Sensors
After powering up and binding the Wireless Q45 Sensors to the Gateway, verify all devices are communicating properly. Verify the
Gateway's LED 1 is green. Until communication is established with the Gateway, the Q45's red LED flashes. After communication
is established, the Q45's green LED flashes.
When testing the Gateway and Wireless Q45 Sensors, verify all radios are at least two meters apart or the communications may
fail.
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
P/N 161862 Rev. E www.bannerengineering.com - Tel: + 1 888 373 6767 7

Conducting a Site Survey (Gateway and Nodes)
A Site Survey, also known as a Radio Signal Strength Indication (RSSI), analyzes the radio communications link between the
Gateway and any Node within the network by analyzing the radio signal strength of received data packets and reporting the
number of missed packets that required a retry.
Perform a Site Survey before permanently installing the radio network to ensure reliable communication. Activate Site Survey mode
from either the Gateway buttons or the Gateway Modbus holding register 15. Only the Gateway can initiate a Site Survey, and the
Site Survey analyzes the radio communications link with one Node at a time.
Conduct a Site Survey Using the Menu System
Initiate a Site Survey using the Gateway’s buttons and menu system.
1. Remove the Gateway's rotary dial access cover.
2. Set the Gateway's rotary dials to the desired Node number.
For example, to check the status of Node 1, set the Gateway's left rotary dial to 0 and the right rotary dial to 1. To check
the status of Node 32, set the Gateway's left rotary dial to 3 and the right rotary dial to 2.
The Gateway is now enabled to read the status of the selected Node. The display scrolls through the Node’s I/O status.
3. Single-click button 1 to scroll across the menu levels until reaching the Site Survey (SITE) menu.
4. Single-click button 2 to enter the Site Survey menu.
5. Single-click button 2 to begin conducting a Site Survey with the Node selected in step 2.
The Gateway analyzes the quality of the signal from the selected Node by counting the number of data packets it receives
from the Node.
6. Examine reception readings (M, R, Y, G) of the Gateway at various locations.
Site survey results display as a percentage. M represents the percent of missed packets while R, Y, and G represent the
percent of received packets at a given signal strength.
M = Percent of missed packets; R = RED marginal signal; Y = YELLOW good signal; G = GREEN excellent signal. Record
the results if you need troubleshooting assistance from the factory.
7. Change the Gateway's rotary dials to conduct a Site Survey with another Node and repeat steps 2 through 6.
8. To end the Site Survey, double-click the Gateway's button 2.
9. Change the Gateway's rotary dials back to 0.
The LCD displays the device readings for the Gateway.
10. Double-click button 2 to move back to the top level menu.
11. Single-click button 1 to return to RUN mode.
12. Install the rotary dial access cover, referring to the Installation section of the manual to create an IP67 seal.
Interpreting the Site Survey Results
Site Survey results are listed as a percentage of data packets received and indicate the signal strength of the received signal.
Result Description
Green Packets received at a strong signal strength. A strong signal strength is greater than −90 dBm at
the receiver.
Yellow Packets received at a good signal strength. A good signal is between −90 and −100 dBm at the
receiver.
Red Packets received at a weak signal strength. A weak signal is less than −100 dBm at the receiver.
Missed Packets not received on the first transmission and requiring a retry.
Judging if the reliability of a network’s signal meets the needs of the application is not just a matter of green, yellow, and red
packets received. In normal operating mode, when data packets are not received, the transmitter re-sends the packet until all data
is received.
For slow monitoring applications such as a tank farm, where data is required in terms of seconds or minutes, receiving most of the
data in the ‘red’ range, indicating a weak but reliable signal, transmits enough data for accurate monitoring. Nodes positioned near
the outside range of the radio signal may have 90% of the data packets received in the red zone, again indicating a weak, but
reliable signal.
We recommend keeping the missed packets average to less than 25%. When the network misses more than 25% of the data
packets, the signal is usually too unreliable or obstacles may be interfering with the signal. When Site Survey reports the missed
packets are 25% or higher, improve the radio system performance by:
•Mounting the network’s antennas higher to clear obstacles in the area and improve the line of sight between Sure Cross®
devices
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
8 www.bannerengineering.com - Tel: + 1 888 373 6767 P/N 161862 Rev. E

•Using higher gain antennas to focus the energy of the radio signal in a specific direction and extend the signal’s range
•Adding data radios to the network to extend the range of a radio network. For more information on data radios, please refer
to Banner’s white paper on range extension on www.bannerengineering.com/wireless.
Specifications
Performance 2.4 GHz Radio Specifications
Radio Range 1
2.4 GHz, 65 mW: Up to 3.2 km (2 miles)
Antenna Minimum Separation Distance
2.4 GHz, 65 mW: 0.3 m (1 ft)
Radio Transmit Power
2.4 GHz, 65 mW: 18 dBm (65 mW) conducted, less than or equal to 20 dBm
(100 mW) EIRP
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
2.4 GHz Compliance
FCC ID UE300DX80-2400: FCC Part 15, Subpart C, 15.247
Radio Equipment Directive (RED) 2014/53/EU
IC: 7044A-DX8024
Antenna Connection
Ext. Reverse Polarity SMA, 50 Ohms
Max Tightening Torque: 0.45 N·m (4 lbf·in)
Link Timeout
Gateway: Configurable via User Configuration Software
Node: Defined by Gateway
RS-485 Communication Specifications
Communication Hardware (RS-485)
Interface: 2-wire half-duplex RS-485
Baud rates: 9.6k, 19.2k (default), or 38.4k
Data format: 8 data bits, no parity, 1 stop bit
Gateway Q Specifications
Supply Voltage
10 V DC to 30 V DC; Outside the USA: 12 V DC to 24 V DC, ± 10%
For European applications, power this device from a Limited Power Source
as defined in EN 60950-1.
Consumption: Less than 1.4 W (60 mA) at 24 V DC
Discrete Inputs
Rating: 3 mA max current at 30 V DC
Sample Rate: 62.5 milliseconds
Report Rate: On change of state
ON Condition (PNP): Greater than 8 V
OFF Condition (PNP): Less than 5 V
Discrete Outputs
Update Rate: 125 milliseconds
ON Condition: Supply minus 2 V
OFF Condition: Less than 2 V
Output State Following Timeout: OFF
Discrete Output Rating (PNP)
100 mA max current at 30 V DC
ON-State Saturation: Less than 3 V at 100 mA
OFF-state Leakage: Less than 10 μA
Housing
Polycarbonate housing and rotary dial cover; polyester labels; EDPM rubber
cover gasket; nitrile rubber, non-sulphur cured button covers
Weight: 0.26 kg (0.57 lbs)
Mounting: #10 or M5 (SS M5 hardware included)
Max. Tightening Torque: 0.56 N·m (5 lbf·in)
Interface
Indicators: Red/Green Power LED, Red/Yellow Signal LED
Wiring Access
Two 1/2-inch NPT
Certifications
Environmental Specifications
Operating Conditions
–40 °C to +85 °C (–40 °F to +185 °F) (Electronics); –20 °C to +80 °C (–4 °F to
+176 °F) (LCD)
95% maximum relative humidity (non-condensing)
Radiated Immunity: 10 V/m (EN 61000-4-3)
Shock and Vibration
All models meet IEC 60068-2-6 and IEC 60068-2-27 testing criteria
Shock: 30G 11 ms duration, half sine wave per IEC 60068-2-27
Vibration: 10 Hz to 55 Hz, 0.5 mm peak-to-peak amplitude per IEC
60068-2-6
Environmental Ratings
IEC IP67; NEMA 6
Refer to the Sure Cross®Wireless I/O Networks Instruction Manual (p/n
132607) for installation and waterproofing instructions.
Operating the devices at the maximum operating conditions for
extended periods can shorten the life of the device.
1Radio range is with the 2 dB antenna that ships with the product. High-gain antennas are available, but the range depends on the environment and line of sight. Always verify your wireless
network's range by performing a Site Survey.
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
P/N 161862 Rev. E www.bannerengineering.com - Tel: + 1 888 373 6767 9

Warnings
Install and properly ground a qualified surge suppressor when installing a remote antenna system. Remote antenna configurations installed without surge suppressors invalidate the
manufacturer's warranty. Keep the ground wire as short as possible and make all ground connections to a single-point ground system to ensure no ground loops are created. No surge
suppressor can absorb all lightning strikes; do not touch the Sure Cross®device or any equipment connected to the Sure Cross device during a thunderstorm.
Exporting Sure Cross®Radios. It is our intent to fully comply with all national and regional regulations regarding radio frequency emissions. Customers who want to re-export this product
to a country other than that to which it was sold must ensure the device is approved in the destination country. The Sure Cross wireless products were certified for use in these countries
using the antenna that ships with the product. When using other antennas, verify you are not exceeding the transmit power levels allowed by local governing agencies. This device has
been designed to operate with the antennas listed on Banner Engineering’s website and having a maximum gain of 9 dBm. Antennas not included in this list or having a gain greater that 9
dBm are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen such that the equivalent isotropically radiated power (EIRP) is not more than that permitted for successful communication. Consult with Banner Engineering Corp. if
the destination country is not on this list.
Banner Engineering Corp. Limited Warranty
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or
replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not
cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product.
THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE), AND WHETHER ARISING UNDER COURSE OF PERFORMANCE, COURSE OF DEALING OR TRADE USAGE.
This Warranty is exclusive and limited to repair or, at the discretion of Banner Engineering Corp., replacement. IN NO EVENT SHALL BANNER ENGINEERING CORP. BE LIABLE TO
BUYER OR ANY OTHER PERSON OR ENTITY FOR ANY EXTRA COSTS, EXPENSES, LOSSES, LOSS OF PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES
RESULTING FROM ANY PRODUCT DEFECT OR FROM THE USE OR INABILITY TO USE THE PRODUCT, WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT,
STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE.
Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously
manufactured by Banner Engineering Corp. Any misuse, abuse, or improper application or installation of this product or use of the product for personal protection applications when the
product is identified as not intended for such purposes will void the product warranty. Any modifications to this product without prior express approval by Banner Engineering Corp will
void the product warranties. All specifications published in this document are subject to change; Banner reserves the right to modify product specifications or update documentation at
any time. Specifications and product information in English supersede that which is provided in any other language. For the most recent version of any documentation, refer to:
www.bannerengineering.com.
For patent information, see www.bannerengineering.com/patents.
Sure Cross®DX80 Gateway for Wireless Q45 Sensors
©Banner Engineering Corp. All rights reserved
