SMC Networks ProtoAir FPA-W34 User guide

Document Revision: 1.B
Web Configurator
Template Revision: 2
ProtoAir FPA-W34
Start-up Guide
For Interfacing the Siemens MAG6000
To Building Automation Systems:
BACnet/IP, Modbus TCP/IP and EtherNet/IP
APPLICABILITY & EFFECTIVITY
Explains ProtoAir hardware and installation.
The instructions are effective for the above as of June 2018.

Siemens ProtoAir Start-up Guide
Page 2 of 43
Technical Support
Thank you for purchasing the ProtoAir for Siemens.
Please call Siemens for technical support of the ProtoAir product.
Sierra Monitor Corporation does not provide direct support. If Siemens needs to escalate the concern,
they will contact Sierra Monitor Corporation for assistance.
Support Contact Information:
Siemens Industry, Inc.
2060 Detwiler Road, Suite 111
Harleysville, PA 19438
Customer Service:
Toll Free [phone]
Outside US [phone]
Website: www.usa.siemens.com/eip-gateway
For Support Online: create a support request via
usa.siemens.com/support
-request

Siemens ProtoAir Start-up Guide
Page 3 of 43
Quick Start Guide
1. Record the information about the unit. (Section 3.1)
2. Set COM settings for the devices that will be connected to ProtoAir. (Section 3.3)
3. Connect Power to ProtoAir’s 3 pin connector. (Section 4)
4. Connect a PC to the ProtoAir via Ethernet cable or connect using Wi-Fi access point to ensure the
PC is on the same subnet as the ProtoAir. Set the IP Address of the ProtoAir to the subnet of the
intended Network and reset IP details of the PC. (Section 5)
5. Use a web browser to access the ProtoAir Web Configurator page to select the profiles of the devices
attached to the ProtoAir and enter the IP Address of each device. Once the devices are selected, the
ProtoAir automatically builds and loads the appropriate configuration. (Section 6)

Siemens ProtoAir Start-up Guide
Page 4 of 43
TABLE OF CONTENTS
1Certification..........................................................................................................................................6
1.1 BTL Mark –BACnet®Testing Laboratory.......................................................................................6
2Introduction..........................................................................................................................................7
2.1 ProtoAir Gateway............................................................................................................................7
3ProtoAir Setup......................................................................................................................................8
3.1 Record Identification Data ..............................................................................................................8
3.2 Point Count Capacity and Registers per Device ............................................................................8
3.3 Configuring Device Communications .............................................................................................9
3.3.1 Input COM Settings on the Device Connected to the ProtoAir .................................................9
3.3.2 Set Node-ID for the Device Attached to the ProtoAir................................................................9
3.3.3 BACnet: Calculating the Default Device Instance.....................................................................9
3.4 Attaching the Antenna ....................................................................................................................9
4Interfacing ProtoAir to Devices........................................................................................................10
4.1 Device Connections to ProtoAir....................................................................................................10
4.1.1 Bias Resistor DIP Switches.....................................................................................................11
4.1.2 Termination Resistor ...............................................................................................................12
4.2 Power-Up ProtoAir........................................................................................................................13
5Connect the PC to the ProtoAir over Ethernet or Wi-Fi.................................................................14
5.1 Connecting to the ProtoAir via Ethernet .......................................................................................14
5.1.1 Changing the Subnet of the Connected PC............................................................................14
5.1.2 Changing the IP Address of the ProtoAir with FieldServer Toolbox .......................................15
5.2 Connecting to the ProtoAir via Wi-Fi Access Point ......................................................................16
5.3 Updating Network Settings ...........................................................................................................17
5.3.1 Navigate to the FS-GUI Network Settings ..............................................................................17
5.3.2 IP Settings...............................................................................................................................19
5.3.3 Wi-Fi Client Settings................................................................................................................20
5.3.4 Wi-Fi AP –Access Point Settings ...........................................................................................21
5.3.5 Common Settings....................................................................................................................22
6Configure the ProtoAir......................................................................................................................23
7BACnet: Setting Node_Offset to Assign Specific Device Instances...........................................25
8How to Start the Installation Over: Clearing Profiles.....................................................................26
Appendix A. Troubleshooting..................................................................................................................27
Appendix A.1. Lost or Incorrect IP Address ............................................................................................27
Appendix A.2. Viewing Diagnostic Information .......................................................................................28
Appendix A.3. Checking Wiring and Settings..........................................................................................29
Appendix A.4. LED Diagnostics for Communications Between ProtoAir and Devices ...........................30
Appendix A.5. Taking Diagnostic Capture with the FieldServer Toolbox................................................30
Appendix A.6. Take a Diagnostic Capture via FS-GUI ...........................................................................33
Appendix A.7. Wi-Fi Signal Strength .......................................................................................................34
Appendix B. Additional Information........................................................................................................35
Appendix B.1. Updating Firmware...........................................................................................................35
Appendix B.2. BACnet: Setting Network_Number for more than one ProtoAir on Subnet .....................35
Appendix B.3. Securing ProtoAir with Passwords...................................................................................36
Appendix B.4. Mounting ..........................................................................................................................37
Appendix B.5. Physical Dimension Drawings .........................................................................................38
Appendix C. Vendor Information –Siemens..........................................................................................39
Appendix C.1. MAG6000 Modbus RTU Mappings to BACnet/IP and EtherNet/IP .................................39
Appendix D. Reference.............................................................................................................................42
Appendix D.1. Specifications...................................................................................................................42
Appendix D.1.1. Compliance with UL Regulations..............................................................................42
Appendix E. Limited 2 Year Warranty.....................................................................................................43

Siemens ProtoAir Start-up Guide
Page 5 of 43
LIST OF FIGURES
Figure 1: ProtoAir Part Numbers...................................................................................................................8
Figure 2: Supported Point Count Capacity ...................................................................................................8
Figure 3: Registers per Device .....................................................................................................................8
Figure 4: COM Settings.................................................................................................................................9
Figure 5: RS-485 Connections to the FieldServer ......................................................................................10
Figure 6: MAG6000 RS-485 Wiring Setup..................................................................................................10
Figure 7: Bias Resistors..............................................................................................................................11
Figure 8: Termination Resistor....................................................................................................................12
Figure 9: Required Current Draw for the ProtoAir.......................................................................................13
Figure 10: Power Connections....................................................................................................................13
Figure 11: Ethernet Port Location ...............................................................................................................14
Figure 12: Web Configurator Landing Page ...............................................................................................17
Figure 13: FS-GUI Landing Page ...............................................................................................................17
Figure 14: Generic FS-GUI Navigation Panel –Network Settings .............................................................18
Figure 15: FS-GUI Ethernet Port Network Settings ....................................................................................19
Figure 16: FS-GUI Wi-Fi Client Network Settings.......................................................................................20
Figure 17: FS-GUI Wi-Fi AP Network Settings ...........................................................................................21
Figure 18: FS-GUI Common Network Settings...........................................................................................22
Figure 19: Web Configurator Screen Showing no Active Profiles ..............................................................23
Figure 20: Web Configurator Showing Active Profile Additions..................................................................24
Figure 21: Web Configurator Node Offset Field..........................................................................................25
Figure 22: Active Profiles ............................................................................................................................25
Figure 23: Ethernet Port Location ...............................................................................................................27
Figure 24: Error Messages Screen .............................................................................................................28
Figure 25: Diagnostic LEDs ........................................................................................................................30
Figure 26: Ethernet Port Location ...............................................................................................................30
Figure 27: Wi-Fi Signal Strength Listing .....................................................................................................34
Figure 28: Web Configurator –Network Number Field...............................................................................35
Figure 29: FS-GUI Passwords Page...........................................................................................................36
Figure 30: Password Recovery Page .........................................................................................................36
Figure 31: DIN Rail......................................................................................................................................37
Figure 32: ProtoAir FPA-W34 Dimensions .................................................................................................38
Figure 33: Specifications.............................................................................................................................42

Siemens ProtoAir Start-up Guide
Page 6 of 43
1 CERTIFICATION
1.1 BTL Mark –BACnet®1 Testing Laboratory
1BACnet is a registered trademark of ASHRAE
The BTL Mark on ProtoAir is a symbol that indicates that a product has
passed a series of rigorous tests conducted by an independent laboratory
which verifies that the product correctly implements the BACnet features
claimed in the listing. The mark is a symbol of a high-quality BACnet product.
Go to www.BACnetInternational.net for more information about the BACnet
Testing Laboratory. Click here for the BACnet PIC Statement.

Siemens ProtoAir Start-up Guide
Page 7 of 43
2 INTRODUCTION
2.1 ProtoAir Gateway
The ProtoAir wireless gateway is an external, high performance building automation multi-protocol
gateway that is preconfigured to auto-discover any of Siemens’products (hereafter called “device”)
connected to the ProtoAir and automatically configures them for BACnet/IP, Modbus TCP/IP and
EtherNet/IP.
It is not necessary to download any configuration files to support the required applications. The ProtoAir is
pre-loaded with tested profiles/configurations for the supported devices.
FPA-W34 Connectivity Diagram:

Siemens ProtoAir Start-up Guide
Page 8 of 43
3 PROTOAIR SETUP
3.1 Record Identification Data
Each ProtoAir has a unique part number located on the side or the back of the unit. This number should
be recorded, as it may be required for technical support. The numbers are as follows:
Model
Part Number
ProtoAir
FPA-W34-1673
Figure 1: ProtoAir Part Numbers
•ProtoAir units have the following 2 ports: RS-485 + Ethernet
3.2 Point Count Capacity and Registers per Device
The total number of registers presented by all of the devices attached to the ProtoAir cannot exceed:
Part number
Total Registers
FPA-W34-1673
1,500
Figure 2: Supported Point Count Capacity
Devices
Registers Per Device
MAG6000
150
Figure 3: Registers per Device

Siemens ProtoAir Start-up Guide
Page 9 of 43
3.3 Configuring Device Communications
3.3.1 Input COM Settings on the Device Connected to the ProtoAir
•The connected serial device MUST have the same baud rate, data bits, stop bits, and parity
settings as the ProtoAir.
•Figure 4 specifies the device serial port settings required to communicate with the ProtoAir.
Port Setting
Devices
Protocol
Modbus RTU
Baud Rate
19200
Parity
Even
Data Bits
8
Stop Bits
1
Figure 4: COM Settings
NOTE: The COM parameters are adjustable.
3.3.2 Set Node-ID for the Device Attached to the ProtoAir
•Set Node-ID for the device attached to ProtoAir to 1.
•Document the Node-ID that is assigned to the device. The Node-ID’s assigned are used for
deriving the Device Instance for BACnet/IP. (Section 3.3.3)
NOTE: The Modbus TCP/IP field protocol Node-IDs are automatically set to be the same value as
the Node-ID of the device.
3.3.3 BACnet: Calculating the Default Device Instance
•The Device Instance value is automatically generated using the following formula:
BACnet Device Instance = (Device Node-ID) + (Default Node Offset)
NOTE: The default Node Offset is 50,000.
For example, if Device A has a Node-ID of 1 then:
BACnet Device Instance A = (1) + (50000) = 50001
NOTE: The Node-ID is set in Section 3.3.2.
•To reach a specific BACnet Device Instance result, refer to Section 7.
3.4 Attaching the Antenna
Wi-Fi Antenna:
Screw in the Wi-Fi antenna to the front of the unit as shown in Figure 32.

Siemens ProtoAir Start-up Guide
Page 10 of 43
4 INTERFACING PROTOAIR TO DEVICES
4.1 Device Connections to ProtoAir
•Connect the RS-485 network wires to the 3-pin RS-485 connector on the ProtoAir. (Figure 5)
oUse standard grounding principles for RS-485 GND
BMS
Wiring
ProtoAir
Pin #
Pin
Assignment
RS-485 +
Pin 1
RS-485 +
RS-485 -
Pin 2
RS-485 -
-
Pin 3
RS-485 GND
Figure 5: RS-485 Connections to the FieldServer
G
-
+
Figure 6: MAG6000 RS-485 Wiring Setup

Siemens ProtoAir Start-up Guide
Page 11 of 43
4.1.1 Bias Resistor DIP Switches
To enable Bias Resistors, move both the BIAS- and BIAS+ dip switches to the right.
The ProtoAir bias resistors are used to keep the RS-485 bus to a known state, when there is no
transmission on the line (bus is idling), to help prevent false bits of data from being detected. The bias
resistors typically pull one line high and the other low - far away from the decision point of the logic.
In the RS-485 carrier, the bias resistor is 510 ohms which is in line with the BACnet spec. It should only
be enabled at one point on the bus (on the Brian field port were there are very weak bias resistors of
100k). Since there are no jumpers, many Brains can be put on network without running into the bias
resistor limit which is < 500 ohms.
NOTE: See www.ni.com/support/serial/resinfo.htm for additional pictures and notes.
Bias Resistor DIP
Switches (2 and 3)
Figure 7: Bias Resistors

Siemens ProtoAir Start-up Guide
Page 12 of 43
4.1.2 Termination Resistor
If the ProtoAir is the last device on the Serial trunk, then the End-Of-Line Termination Switch needs to be
enabled. To enable the Termination Resistor, move the TERM dip switch to the right.
Termination resistor is also used to reduce noise. It pulls the two lines of an idle bus together. However,
the resistor would override the effect of any bias resistors if connected.
Termination Resistor
DIP Switch (1)
Figure 8: Termination Resistor

Siemens ProtoAir Start-up Guide
Page 13 of 43
4.2 Power-Up ProtoAir
Check power requirements in the table below:
Power Requirement for ProtoAir External Gateway
Current Draw Type
ProtoAir Family
12V DC
24V DC
FPA –W34 (Typical)
170mA
100mA
FPA –W34 (Maximum)
240mA
140mA
NOTE: These values are ‘nominal’ and a safety margin should be added to the power supply of the host
system. A safety margin of 25% is recommended.
Figure 9: Required Current Draw for the ProtoAir
Apply power to the ProtoAir as shown below in Figure 10. Ensure that the power supply used complies
with the specifications provided in Appendix D.1.
•The ProtoAir accepts 12-24V DC on pins 4 and 5.
•Frame GND should be connected.
Power to
ProtoAir
ProtoAir
Pin #
Pin
Assignment
Power In (+)
Pin 4
V +
Power In (-)
Pin 5
V -
Frame Ground
Pin 6
FRAME GND
Figure 10: Power Connections

Siemens ProtoAir Start-up Guide
Page 14 of 43
5 CONNECT THE PC TO THE PROTOAIR OVER ETHERNET OR WI-FI
5.1 Connecting to the ProtoAir via Ethernet
First, connect a CAT5 Ethernet cable (straight through or cross-over) between the local PC and ProtoAir.
There are two ways to access the ProtoAir via an Ethernet connection, either by changing the subnet of
the connected PC or using the FieldServer Toolbox to change the IP Address of the ProtoAir.
5.1.1 Changing the Subnet of the Connected PC
The default IP Address for the ProtoAir Ethernet connection is 192.168.1.24, Subnet Mask is
255.255.255.0. If the PC and ProtoAir are on different IP networks, assign a static IP Address to the PC
on the 192.168.1.xxx network.
For Windows 10:
Right click on > >
> >
Right-click on Local Area Connection > Properties
Highlight >
Use the following IP Address:
Click twice.
Ethernet Port
Figure 11: Ethernet Port Location

Siemens ProtoAir Start-up Guide
Page 15 of 43
5.1.2 Changing the IP Address of the ProtoAir with FieldServer Toolbox
•Ensure that FieldServer Toolbox is loaded onto the local PC. Otherwise, download the
FieldServer-Toolbox.zip via the Sierra Monitor Resource Center Software Downloads.
•Extract the executable file and complete the installation.
•Double click on the FS Toolbox Utility and click Discover Now on the splash page.
•Find the desired gateway and click the Configure Device button (gear icon) to the right of the
gateway information.
•Select Network Settings in the Configure Device window.
•Modify the IP Address (N1 IP Address field) of the gateway Ethernet port.
oThe following fields may also be changed as needed: Netmask (N1 Netmask field), DHCP
Client State (N1 DHCP Client State field), IP Gateway (Default Gateway field) and DNS 1 & 2
(Domain Name Server fields)
NOTE: If the gateway is connected to a router, the Default Gateway field of the gateway should be
set to the IP Address of the connected router.
NOTE: Do not change the DHCP Server State (N1 DHCP Server State field).
NOTE: If DNS settings are unknown, set DNS1 to “8.8.8.8” and DNS2 to “8.8.4.4”.
•Click Update IP Settings, then click on the Change and Restart to restart the Gateway and
activate the new IP Address.

Siemens ProtoAir Start-up Guide
Page 16 of 43
5.2 Connecting to the ProtoAir via Wi-Fi Access Point
When the ProtoAir is first powered up the Wi-Fi access point will be enabled allowing direct connection to
the ProtoAir via Wi-Fi.
To connect to the ProtoAir Wi-Fi access point:
•Click the icon (found in the bottom-right corner of the computer screen) to open the available
Wireless Network Connections.
•Select the desired ProtoAir and click Connect.
•Enter the Security key; the default is 12345678.
The available Wireless Network Connection menu should now show that the computer is connected to
the ProtoAir.

Siemens ProtoAir Start-up Guide
Page 17 of 43
5.3 Updating Network Settings
5.3.1 Navigate to the FS-GUI Network Settings
After setting a local PC on the same subnet as the ProtoAir (Section 5.1 or Section 5.2), open a web
browser on the PC and enter the IP Address of the ProtoAir; the default Ethernet address is
192.168.1.24, the default Wi-Fi access point address is 192.168.50.1. Alternatively, the Web Configurator
page can be accessed by clicking the Connect button in the FieldServer Toolbox (Section 5.1.2).
NOTE: If the IP Address of the ProtoAir was previously changed, the assigned IP Address can be
discovered using the FS Toolbox utility. See Appendix A.1 for instructions.
•From the Web Configurator landing page, click the “Diagnostics & Debugging” button to open the
FS-GUI page.
•Find the Navigation tree on the left side of the screen.
Figure 13: FS-GUI Landing Page
Figure 12: Web Configurator Landing Page

Siemens ProtoAir Start-up Guide
Page 18 of 43
•Click the orange arrow next to the ProtoAir CN number and title to expand the tree.
•Click on the orange arrow next to Setup to expand the tree.
•Click on Network Settings.
Figure 14: Generic FS-GUI Navigation Panel –
Network Settings

Siemens ProtoAir Start-up Guide
Page 19 of 43
5.3.2 IP Settings
IP Settings tab is the landing page when selecting Network Settings on the navigation tree.
To change the IP settings, follow these instructions:
•Enable DHCP Client State to automatically assign IP Settings or modify the settings manually as
needed, via these fields: IP Address, Netmask, Default Gateway and Domain Name Server1/2.
NOTE: If the ProtoAir is connected to a router, the Default Gateway of the ProtoAir should be set
to the same IP Address of the router.
•Click Update IP Settings, then click on System Restart to restart the Gateway and activate the
new IP Address.
NOTE: If the FS-GUI was open in a browser, the browser will need to be pointed to the new IP
Address of the ProtoAir before the FS-GUI will be accessible again.
IP Setting Fields
Definition
Connection Status
Status of connection
MAC Address
Ethernet MAC Address
Tx/Rx Msgs
Number of transmitted and received messages
Tx/Rx Msgs Dropped
Number of unanswered Tx or Rx messages
Figure 15: FS-GUI Ethernet Port Network Settings

Siemens ProtoAir Start-up Guide
Page 20 of 43
5.3.3 Wi-Fi Client Settings
From the FS-GUI Network Settings landing page, click on the Wi-Fi Client tab.
To change the Wi-Fi client settings, follow these instructions:
•The Wi-Fi Status field must be set to ENABLED to allow the ProtoAir to communicate with other
devices via Wi-Fi.
•Enable DHCP to automatically assign all Wi-Fi Client Settings fields or modify the Settings
manually, via the fields immediately below the note (Wi-Fi SSID, Wi-Fi Password, IP Address,
etc.).
NOTE: If the FieldServer is connected to a router, the IP gateway of the FieldServer should be set
to the same IP Address of the router.
•Click Update IP Settings, then click on the System Restart to restart the gateway and activate the
new IP Address.
Wi-Fi Client Fields
Definition
Connection Status
Status of connection
MAC Address, BSSID, Channel
Wi-Fi Client MAC Address, BSSID, and Channel
Tx/Rx Msgs
Number of transmitted and received messages
Tx/Rx Msgs Dropped
Number of unanswered Tx or Rx messages
Pairwise Cipher
Type of encryption used for unicast traffic
Group Cipher
Identifies the type of encryption used for multicast / broadcast traffic
Key Mgmt
Encryption type
Link
Connection speed
Signal Level
Signal level in dBm
Figure 16: FS-GUI Wi-Fi Client Network Settings
