7.2 Wireless Broadband
Home Network Gateway
3G9WB – Next G™ Router with Wi-Fi and 4 Ethernet Ports
The BigPond 7.2 Wireless Broadband Home Network Gateway connects
to the Telstra Next G™ network. The device has a peak downlink speed of
7.2 Mbps, typical downlink speeds are 550kbps to 3Mbps, bursting up to
6Mbps and typical uplink speeds of 300kbps – 1Mbps, bursting to 1.3Mbps
in most places in CBD, metro and other areas.* The gateway also creates
a network around your home or office without the messy wires. So now
everyone can be online at the same time from almost anywhere in a
typical home or small office. This allows you to access the Telstra Next
G™ network making it easy for you to watch movies and download music,
without the need for a fixed internet connection.
The BigPond 7.2 Home Network Gateway has a WLAN IEEE802.11b/g AP
and four Ethernet 10/100Mbps ports and features state of the art security
features such as WPA data encryption, SPI Firewall and VPN pass through.
This feature packed unit allows you to quickly create a secure wireless
802.11g network and provide access to the Internet using the Next
G™ network. The BigPond 7.2 Home Network Gateway provides a fast
wireless broadband network with greater coverage through Australia
than any other wireless broadband network#.
# At the time of release, Telstra covers over 99% of Australian population with its Next G™ network
® and TM - Registered trade mark and trade mark of Telstra Corporation Limited ABN 33 051 775 556.
KEY FEATURES
Combines Next G™ Broadband service, Wi-Fi and Ethernet gateway in one device
Tri-band HSUPA/HSDPA/UMTS (850 / 1900 / 2100 Mhz), quad-band EDGE/GSM (850 / 900 / 1800 / 1900 Mhz)
Embedded multimode HSUPA/HSDPA/UMTS/EDGE/GPRS/GSM module
UPnP CLI command interface
WEP/WPA/WPA2 and 802.1x Web-based management
MAC address and IP filtering Supports VPN Pass-through
Static route functions Integrated 802.11g AP (backward compatible with 802.11b)
DNS Proxy DHCP Server/Relay/Client
NAT/PAT Configuration backup and restoration

TECHNICAL SPECIFICATIONS
NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia
P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are subject to change without notice. Images
shown may vary slightly from the actual product.
Internet
54Mbps Wireless Link
LAN 1 LAN 2 LAN 3 LAN 4
Next G Carriers Tower
BigPond 7.2 Home Network Gateway
A reliable wireless network for simple and affordable networking
• Create a network at home or in the office with multiple wireless devices; including PC’s, laptops,
Wi-Fi phones and PDAs.
• No phone line or FOXTEL cable needed – works with the Telstra Next G™ network.
• Mobile business solution can provide workers with remote high-speed access to large volumes of
data, emails, Internet and business applications on the move.
• Ideal for country areas that do not have ADSL/cable but are in the Next G™ coverage areas.
• Broadband in the car – plug your BigPond 7.2 Home Network Gateway into a DC converted power
supply. No more bored kids on long car trips!
• Easy to use and as reliable as your mobile phone connection.
• Provides a reliable 3G connection to the Internet.
• Designed to allow small and medium enterprise customers and home users to enjoy the freedom
of secure, high-speed-Internet connectivity on the go!
• Peak downlink speeds of 7.2 Mbps & 1.9 Mbps upstream.
• Typical downlink speeds of 550kbps to 3Mbps, bursting up to 6Mbps and typical uplink speeds of
300kbps – 1Mbps, bursting to 1.3Mbps in most places in CBD, metro and other areas*
• Connects multiple wired or wireless devices to the one secure Internet connection.
• Allows users to watch movies, download music or access e-mail without the need of a fixed line
Internet connection.
• Multiple users can share the one data bundle, making it a cost effective device.
7.2 Wireless Broadband
Home Network Gateway
3G9WB – Next G™ Router with Wi-Fi and 4 Ethernet Ports
WAN INTERFACE
• HSPA x 1
LAN INTERFACE
• Ethernet x 4
WLAN
• MAC Address Filtering, WEP, WPA, IEEE 802.1X
• 10, 25, 50, 100mW @ 22MHz channel
bandwidth Output power level can be
selected according to the environment
Standard
• IEEE 802.11g, backward compatible with
802.11b Encryption
• 64, 128-bit Wired Equivalent Privacy (WEP,
WPA2) Data Encryption
Channels
• 11 Channels (US, Canada)
• 13 Channels (Europe, Australia)
• 14 Channels (Japan)
WLAN Data Rate
• Up to 54Mbps
WAN CONNECTION
PPP
• Yes
Standard
• Comply with the 3GPP release 5 UMTS
specification
Band
• Support Quad-band GSM/GRPS (850 / 900 /
1800 / 1900 MHz)
• Support tri-band UTMS/HSDPA/HSUPA (850 /
1900 /2100 MHz)
Data Rate*
• HSUPA (up to 1.9 Mbps uplink)
• HSDPA and UMTS (up to 7.2 Mbps downlink
and 384 Kbps uplink)
• EDGE / GPRS / GSM (up to 247 Kbps)
Antenna Type
• Removable antenna
MANAGEMENT
• SNMP, SNTP, Telnet, Web-based
management, Configuration backup and
restoration
• Firmware upgrade via HTTP, TFTP client and
server, or FTP server
ROUTING FUNCTIONS
• Static route, NAT/PAT, DMZ, DHCP Client/
Server/Relay, DNS Proxy, DDNS
SECURITY FUNCTIONS
• Stateful Packet Inspection, Packet filtering,
Denial Of Service protection, Management
Authentication protocols
• PAP, CHAP
VPN
• PPTP/L2TP/IpSec pass-through
LED
• Power, LAN 4, LAN 3, LAN2, LAN 1, Wi-Fi,
Internet, 3G, 2G, Signal Strength for Low, Med
and High LEDs
POWER
• External power adapter
• 100-240Vac to 12Vdc /1.5A
ENVIRONMENTAL CONDITIONS
Operating temperature
• 0 ~ 50 degrees Celsius
Relative humidity
• 5 ~ 90% (non-condensing)
DIMENSIONS
• 205 mm (W) x 47 mm (H) x 145 mm (D)
* Speeds may vary due to congestion, distance from the cell,
local conditions, hardware, software and other factors.
