Diagnostic precision redefined
Building on nearly twenty years of experience in state-of-the-art visualization, Barco
is constantly improving PACS display technology, combining the highest possible
image quality with the lowest cost of ownership. While keeping its eye on the future,
Barco remains focused on its main goal: providing radiologists with innovative display
technology that helps them to diagnose with ultimate precision and confidence.

Coronis
display systems
Coronis diagnostic display systems combine high-grade PACS displays with a high-
speed medical display controller and a user-friendly MediCal QAWeb software
tool. Uniting proven technology with cutting edge enhancements and progressive
ergonomics, Coronis systems redefine diagnostic precision in both grayscale and
color.
Ergonomics
• User-denable reading comfort
• Fully integrated multi-head
configurations
• Reduced eye fatigue
Productivity
• Grayscale technology perfected
• The benets of color without
compromising on grayscale
quality
• Fully transparent calibration
and QA
Diagnostic performance
• Impressive performance in 2D and 3D
• Uniform image rendering across the entire screen
• Worry-free DICOM-conformance under all light-
ing conditions
Innovation in three dimensions

Increased productivity through versatility

Me d i Ca l
QaWe b
Server
Secured
internet
connection
Healthcare facility
Healthcare facility
Remote office
Transparent calibration and
Quality Assurance
Coronis benefits from an
innovative softcopy QA
system that brings a new
degree of transparency to
your QA routine. Together with the
intelligent I-Guard sensor, MediCal
QAWeb provides an easy-to-use tool
for calibration and QA, ensuring
continuous diagnostic quality and
maximum uptime of your workstation.
Running in the background, MediCal
QAWeb allows you to continue
diagnoses while automated QA checks
are being executed. The system also
includes a secure online web service
for remote, centralized image quality
management. Comprehensive asset
management tools provide a complete
overview of the workstations connected
to MediCal QAWeb. In the occurrence
of a performance problem, the right
people will be notified.
Grayscale technology
perfected
Building on proven
technology, Coronis
grayscale displays provide
ultimate precision and
performance while maintaining a
reputation for the highest brightness
and contrast. The advanced 10-bit
architecture ensures accurate
image representations with 1024
simultaneous shades of gray out of a
palette of 4096.
The benefits of color
without compromising on
grayscale quality
Medicaldiagnosticimagingis
facing a colorful future. New
color–augmented modalities
deliver larger data sets
with richer content. 3D imaging and
Computer Aided Diagnosis (CAD) are
improving the workflow to provide
better clinical decision-making. Until
today, color displays could not generate
sufficient brightness for diagnostic
grayscale imaging.
But with the unique Coronis Color
3MP DL however, you no longer
have to choose between color and
grayscale. Engineered with the latest
LCD technology, the display system
provides unprecedented brightness
(500 cd/m²), excellent contrast ratio
(300:1) and DICOM accuracy over the
entire lifetime of the display. It means
that, from now on, all modalities and
all color enriched applications can be
viewed from a single, multi-modality
display system.

Unprecedented diagnostic performance
3D - CT Cine speed benchmark
0 20 40 60 80 100
Frames per second
2 slice - Thinner slab -
typical of 4 slice CT
30 slice - Thicker slab -
typical of 64 slice CT
Barco’s MXRT-5100
Standard medical display controllers
2D - Image manipulation speed benchmark
0 500%
Relative performance
1000% 1500%
Fill (used to clear
window backgrounds)
Copy (used to pan image
and move windows)
Image download 1.2 GB/s
5.1 GB/s
8.2 GB/s

Worry-free DICOM
compliance under all
lighting conditions
The integrated I-Guard
continually guards and
adjusts the luminance
output of the diagnostic
viewing area. Combined with the
MediCal QAWeb software, the patented
I-Guard brings fast and easy calibrations,
automatic Quality Assurance testing
and remote diagnoses of the display.
The latest version of I-Guard has been
further improved with increased read-
out speed and enhanced sensitivity
down to the lowest luminance levels.
The intelligent Ambient Light
Compensation (ALC) system assures
that Coronis systems remain DICOM
compliant under all lighting conditions
by adapting their brightness relative
to the ambient light conditions. If
the level of ambient light no longer
corresponds to the predefined range,
users will automatically be notified.
Uniform image rendering
across the entire screen
While traditional LCD
display systems typically
suffer from luminance
non-uniformities up to
30%, the new Coronis displays deliver
perfectly balanced luminance over the
entire screen. Based on an individual
characterization of the image down
to pixel level, the proprietary Uniform
Luminance Technology (ULT) corrects
non-uniformities caused by the LCD
as well as the backlight. Thanks to
this technology, diagnostic images are
DICOM-conform not just in the center
but everywhere on the screen.
Impressive performance in
2D and 3D
As image data sets become
larger with every new
generation of acquisition
devices, patient throughput
becomes an ever increasing concern.
In line with this evolution, Barco
combines the Coronis displays with a
high-performance, 10-bit ATI FireGL
graphics processing unit based on the
PCI Express interface. The powerful
display controller is your guarantee for
ultra-fast and smooth image loading,
roaming and manipulation in 2D and
3D.
With medical software applications
increasingly relying on OpenGL 2.0
or Microsoft DirectX 9.0, Barco also
provides specific support for 3D enabled
medical software applications. This
results in dedicated driver solutions
that make medical applications run
faster and more efficiently.
Continuous diagnostic confidence thanks to
I-Guard technology
Uniform brightness across the screen with
Uniform Luminance Technology (ULT)
High-performance display controller for
maximum speed and precision
Without ULT With ULT

Elegant mounting of a third monitor for RIS, HIS,...
Best-in-class ergonomics
Fully integrated multi-head
configurations
Featuring an integrated pedestal
concept, Coronis enables customized
multi-head configurations. Color and
grayscale, portrait and landscape, 2D
and 3D can be combined as specified
by the user. Thanks to the patent
pending ‘virtual’ hinge system, the
individual heads will move and track
as one integrated system when they
are being adjusted. The very thin bezel
design ensures enhanced reading
comfort in a multi-head setup.

User-definable reading
comfort
From the start, the new Coronis has
been designed for convenience. The
system is easy to set up and the
handy, solid pedestal makes precise,
user-specific adjustments, such as
lifting, tilting and swiveling very easy
to perform. All cables can be neatly
tucked away thanks to an integrated
cable management system.
Reduced eye fatigue
To counteract eye fatigue,
the screen has been
treated with a special,
non-reflective coating. A
protective front cover will also protect
the valuable LCD against damage
from intensive use in clinical rooms.
Moreover, the new Coronis display
system can be fitted with an optional
keyboard illumination device. Installed
underneath the display, the dimmable
LED light avoids reflections due to
ambient light and creates the ideal
lighting conditions for every individual
workstation.
Integrated multi-head design LED keyboard illumination
Protective non-reflective glass cover
5-year warranty
Built to deliver maximum
peace of mind, Coronis
display systems come
with a 5-year warranty.
In addition, Barco offers an array of
dedicated support services to help you
reduce unscheduled downtime and
keep your expenses under control.
Barco’s global organization is your
guarantee for professional support,
wherever you are, whenever you need it.

Coronis: a family of diagnostic precision
MDCG-2121 MDCG-3120 MDCC-2121 MDCC-3120
For more detailed technical specifications, please check the dedicated sheet or visit www.barcomedical.com.
FireGL is a registered trademark of Advanced Micro Devices, Inc.
Coronis online
Visit the dedicated Coronis microsite at
www.barcomedical.com/coronis
Configure your own Coronis system at
www.barcomedical.com/coronis > configure

Coronis
A full range of premium diagnostic display systems
Request more information
Europe, Middle East,Africa
& Latin America
Phone: [phone]
[e-mail]
North America
Phone: [phone]
[e-mail]
Taiwan
Phone: [phone]
[e-mail]
South Korea
Phone: [phone]
[e-mail]
China
Phone: [phone]
[e-mail]
Singapore
Phone: [phone]
[e-mail]
Australia
Phone: [phone]
[e-mail]
Japan
Phone: [phone]
Barco medical
imaging systems
Over the years, Barco has established a
solid reputation in the medical imaging
market by providing high-performance
imaging technology for conventional
X-ray, digital radiography, digital
mammography, ultrasound, magnetic
resonance, computed tomography, PACS
and 3D imaging.
Its full line of color and grayscale
diagnostic displays, display controllers,
radiology display systems, 3D software
applications and softcopy QA tools
facilitate confident diagnoses while
guaranteeing perfect image quality over
time and across displays.
Barco’s expertise is supported by
a worldwide network of research,
development and support services.
A global sales organization, with
regional support personnel familiar
with local languages and requirements,
complements Barco’s partnership
approach.
6
Si gma
In search of continuous improvement
K5906085 v00 printed 0108 © 2007 Barco
Technical specifications are subject to change without prior notice
Integrated pedestal for dual-head
display system
Integrated pedestal for triple-head
display system
LED keyboard illumination
MediCal QAWeb service:
Premium level
MXRT-7100
High-end 3D display controller
Coronis options
www.barcomedical.com

Coronis
A full range of premium diagnostic display systems
Request more information
Europe, Middle East,Africa
& Latin America
Phone: [phone]
[e-mail]
North America
Phone: [phone]
[e-mail]
Taiwan
Phone: [phone]
[e-mail]
South Korea
Phone: [phone]
[e-mail]
China
Phone: [phone]
[e-mail]
Singapore
Phone: [phone]
[e-mail]
Australia
Phone: [phone]
[e-mail]
Japan
Phone: [phone]
Barco medical
imaging systems
Over the years, Barco has established a
solid reputation in the medical imaging
market by providing high-performance
imaging technology for conventional
X-ray, digital radiography, digital
mammography, ultrasound, magnetic
resonance, computed tomography, PACS
and 3D imaging.
Its full line of color and grayscale
diagnostic displays, display controllers,
radiology display systems, 3D software
applications and softcopy QA tools
facilitate confident diagnoses while
guaranteeing perfect image quality over
time and across displays.
Barco’s expertise is supported by
a worldwide network of research,
development and support services.
A global sales organization, with
regional support personnel familiar
with local languages and requirements,
complements Barco’s partnership
approach.
6
Si gma
In search of continuous improvement
K5906085 v00 printed 0108 © 2007 Barco
Technical specifications are subject to change without prior notice
Integrated pedestal for dual-head
display system
Integrated pedestal for triple-head
display system
LED keyboard illumination
MediCal QAWeb service:
Premium level
MXRT-7100
High-end 3D display controller
Coronis options
www.barcomedical.com
