Coronis®technical specifications
Coronis®displays Coronis®2MP Coronis®3MP Coronis®Color 2MP Coronis®Color 3MP DL
Display MDCG 2121 MDCG 3120 MDCC 2121 MDCC 3120
Display technology SA-SFT AM LCD
IPS technology
TFT AM LCD Dual Domain
IPS technology
TFT AM LCD Dual Domain
IPS technology
TFT AM LCD Dual Domain
IPS technology
Active screen diagonal 540 mm (21.3“) 528 mm (20.8”) 540 mm (21.3”) 528 mm (20.8“)
Active screen width 432 mm (17.0”) 424 mm (16.7”) 432 mm (17.0”) 424 mm (16.7”)
Active screen height 324 mm (12.8”) 318 mm (12.5”) 324 mm (12.8”) 318 mm (12.5”)
Pixel pitch 0.270 mm (0.01063”) 0.207 mm (0.00815”) 0.270 mm (0.01063”) 0.207 mm (0.00815”)
Resolution 1600x1200 / 1200x1600 2048x1536 / 1536x2048 1600x1200 / 1200x1600 2048x1536 / 1536x2048
Maximum luminance 900 cd/m2
(262.68 fL) (typ)
1000 cd/m2
(291.87 fL) (typ)
400 cd/m2
(116.75 fL) (typ)
800 cd/m2
(233.49 fL) (typ)
DICOM calibrated
luminance
500 cd/m2
(145.93 fL)
500 cd/m2
(145.93 fL)
220 cd/m2
(64.20 fL)
500 cd/m2
(145.93 fL)
Contrast ratio
(dark reading room) 700:1 (typ) 900:1 (typ) 500:1 (typ) 400:1 (typ)
Viewing angle 170° 170° 170° 170°
Display LUT 12 bit 12 bit 30 bit color 30 bit color
Video input DVI DVI DVI DVI
Image stabilization embedded I-Gu a r d ®embedded I-Gu a r d ®embedded I-Gu a r d ®embedded I-Gu a r d ®
Uniform Luminance
Technology Yes Yes Yes Yes
Ambient Light
Compensation (ALC) Yes Yes Yes Yes
Display dimensions
portrait (WxHxD) (*)
369 x 559 x 285 mm
14.53” x 22.01” x 11.22”
369 x 559 x 285 mm
14.53” x 22.01” x 11.22”
369 x 559 x 285 mm
14.53” x 22.01” x 11.22”
369 x 559 x 285 mm
14.53” x 22.01” x 11.22”
Display dimensions
landscape (WxHxD)(*)
477 x 504 x 285 mm
18.78” x 19.84” x 11.22”
477 x 504 x 285 mm
18.78” x 19.84” x 11.22”
477 x 504 x 285 mm
18.78” x 19.84” x 11.22”
477 x 504 x 285 mm
18.78” x 19.84” x 11.22”
Display weight 16.5 kg (36.4 lb) 16.5 kg (36.4 lb) 16.5 kg (36.4 lb) 16.5 kg (36.4 lb)
Approvals EN60601-1-2 EN60601-1-2 EN60601-1-2 EN60601-1-2
FCC-B FCC-B FCC-B FCC-B
CE,CCC, ICES-001,
KETI, PSE
CE,CCC, ICES-001,
KETI, PSE
CE,CCC, ICES-001,
KETI, PSE
CE,CCC, ICES-001,
KETI, PSE
Operational
temperature range
0°C to + 40°C
(32°F to 98°F)
0°C to + 40°C
(32°F to 98°F)
0°C to + 40°C
(32°F to 98°F)
0°C to + 40°C
(32°F to 98°F)
Within spec
temperature range
+15°C to +35°C
(59°F to 95°F)
+15°C to +35°C
(59°F to 95°F)
+15°C to +35°C
(59°F to 95°F)
+15°C to +35°C
(59°F to 95°F)
Power consumption 74 W (typ) 85 W (typ) 100 W (typ) 120 W (typ)
(*) Pedestal in max position

www.barcomedical.com
Coronis®display
controllers BarcoMed Coronis®PCIe MXRT 2100 MXRT 5100 MXRT 7100
SYSTEM REQUIREMENTS
Bus compatibility PCI Express®x8 PCI Express®x16 native
support
PCI Express®x16 native
support
PCI Express®x16 native
support
Power consumption < 15 W
Computer power
supply of 375 W or
higher recommended
Computer power
supply of 375 W or
higher recommended
Computer power
supply of 375 W or
higher recommended
Form factor 106 x 176 x 16 mm
(4.2” x 6.9” x 0.6”)
106 x 228 x 18 mm
(4.2” x 9.0” x 0.6”)
106 x 228 x 37 mm
(4.2” x 9.0” x 1.5”)
106 x 228 x 37 mm
(4.2” x 9.0” x 1.5”)
Operating system Windows®2000, XP, X64 Windows 2000®, XP, X64 Windows 2000®, XP, X64 Windows 2000®, XP, X64
Platforms Intel®architectures Intel®and AMDTM
architectures
Intel®and AMDTM
architectures
Intel®and AMDTM
architectures
CHARACTERISTICS
Graphics accelerator Barco Aura ATI FireGLTM ATI FireGLTM ATI FireGLTM
Display memory 128 MB 128 MB 256 MB 1 GB
Look-Up Table 10 bits in/ 10 bits out 32 bits in / 32 bits out 32 bits in / 32 bits out 32 bits in / 32 bits out
Pixel depth 10 bit Up to 64 bit color Up to 64 bit color Up to 64 bit color
Electrical standard Single Link DVI complying
to v1.0 specification
Dual Link DVI complying
to v1.0 specification
Dual Link DVI complying
to v1.0 specification
Dual Link DVI complying
to v1.0 specification
Direct 3D HW support na
Microsoft DirectX v9.0,
Vertex Shader v3.0,
Pixel Shader v3.0
Microsoft DirectX v9.0,
Vertex Shader v3.0,
Pixel Shader v3.0
Microsoft DirectX v9.0,
Vertex Shader v3.0,
Pixel Shader v3.0
OpenGL®HW support na OpenGL®2.0 OpenGL®2.0 OpenGL®2.0
VIDEO OUTPUT
Connectors Two DVI-D connectors Two DVI-I connectors Two DVI-I connectors Two DVI-I connectors
Supported resolutions Up to 2560x2048 Up to 2048x1536 Up to 2560x2048 Up to 2560x2048
VGA at boot-up VGA at boot-up VGA at boot-up VGA at boot-up
APPROVALS
Approvals and
compliance
FCC-B, CE, EN55022 B,
EN 61000-6,
IEC 60601-102
FCC, CE, BSMI, C-Tick, UL FCC, CE, BSMI, C-Tick, UL FCC, CE, BSMI, C-Tick, UL
ENVIRONMENTAL
Operational
temperature
10° to 60°C
(50° to 140°F)
O° to 55°C
(32° to 131°F)
O° to 55°C
(32° to 131°F)
O° to 55°C
(32° to 131°F)
K5906090 Rev. 02 0308 © 2008 Barco
