Barco GRAPHICS 808s User manual

R9000904
OWNER'S MANUAL
GRAPHICS
808s
All manuals and user guides at all-guides.com
all-guides.com

All manuals and user guides at all-guides.com

BARCO PROJECTION SYSTEMS
Date :
160403
Art. No. :
R5976283
R9000904
OWNER'S MANUAL
GRAPHICS
808s
Revision :
01
All manuals and user guides at all-guides.com

Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, April 2003.
All rights reserved.
Trademarks are the rights of their respective owners.
Printed in Belgium
BARCO n.v./Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Tel : [phone]
Fax : [phone]
E-mail : [email protected]
Visite Barco at the web : http://www.barco.com
Printed in Belgium
All manuals and user guides at all-guides.com

Table of contents
i-1
5976283 BARCOGRAPHICS 808s 160403
TABLE OF CONTENTS
TABLE OF CONTENTS ............................................................................................................................................................................... I-1
SAFETY INSTRUCTIONS .......................................................................................................................................................................... 1-1
On safety ........................................................................................................................................................................................... 1-1
On installation .................................................................................................................................................................................... 1-2
On servicing ...................................................................................................................................................................................... 1-2
On cleaning ........................................................................................................................................................................................ 1-2
On repacking ..................................................................................................................................................................................... 1-2
On illumination .................................................................................................................................................................................... 1-2
LOCATION AND FUNCTIONS OF CONTROL .......................................................................................................................................... 2-1
Rear panel terminology ...................................................................................................................................................................... 2-1
Control panel terminology .................................................................................................................................................................. 2-2
a. The Local Keypad ......................................................................................................................................................................... 2-2
b. RCU control panel terminology ...................................................................................................................................................... 2-2
CONNECTIONS .......................................................................................................................................................................................... 3-1
AC Power (mains) Cord Connection ................................................................................................................................................ 3-1
Power Check ..................................................................................................................................................................................... 3-1
Switching On/Off .............................................................................................................................................................................. 3-1
Signal Input Connection to the Projector : ......................................................................................................................................... 3-2
Connecting a RGB Analog source to port 3. .................................................................................................................................... 3-3
Connecting a RGB Analog source to port 4/5. ................................................................................................................................. 3-3
Connecting a RGB Analog source with Tri-level sync to port 4/5. .................................................................................................. 3-4
Connecting a Component Video source to port 4/5. ........................................................................................................................ 3-4
Connecting a Component Video source with Tri-level sync to port 4/5. ......................................................................................... 3-4
Connecting a computer to the projector. .......................................................................................................................................... 3-5
Peripheral equipment ......................................................................................................................................................................... 3-5
Connecting a RCVDS 05 switcher to the projector. ......................................................................................................................... 3-5
Connecting a VS05 switcher to the projector. ................................................................................................................................. 3-5
CONTROLLING .......................................................................................................................................................................................... 4-1
Battery installation in the RCU. .......................................................................................................................................................... 4-1
How to use your RCU ....................................................................................................................................................................... 4-2
Projector Address ............................................................................................................................................................................. 4-2
How to display a projector address? ............................................................................................................................................... 4-2
How to program an address into the RCU? ..................................................................................................................................... 4-3
Input selection ................................................................................................................................................................................... 4-3
Analog Picture Controls .................................................................................................................................................................... 4-3
Controlling chained projectors. ......................................................................................................................................................... 4-4
START UP OF THE ADJUSTMENT MODE ............................................................................................................................................... 5-1
Adjustment Mode ............................................................................................................................................................................... 5-1
RANDOM ACCESS ADJUSTMENT MODE ............................................................................................................................................... 6-1
Starting-Up the Random Access Adjustment mode. ........................................................................................................................ 6-1
Overview 'Random Access Adjustment' mode ................................................................................................................................ 6-1
Selecting Setup Pattern ..................................................................................................................................................................... 6-3
Internal Cross Hatch Pattern ............................................................................................................................................................. 6-3
Random access adjustment mode selection menu. ......................................................................................................................... 6-4
Picture Tuning .................................................................................................................................................................................... 6-4
Color Balance .................................................................................................................................................................................... 6-4
Sync Fast/Slow Adjustment ............................................................................................................................................................. 6-5
Peaking .............................................................................................................................................................................................. 6-5
Clamp Tuning ..................................................................................................................................................................................... 6-5
Port 2 : Video or S-Video .................................................................................................................................................................. 6-6
Line Doubler (option) ......................................................................................................................................................................... 6-6
Color Select ....................................................................................................................................................................................... 6-6
Focusing ............................................................................................................................................................................................ 6-7
Focusing color select. ....................................................................................................................................................................... 6-7
Midpoint focusing .............................................................................................................................................................................. 6-7
Top image focusing ........................................................................................................................................................................... 6-7
Bottom image focusing ...................................................................................................................................................................... 6-7
Left image focusing ........................................................................................................................................................................... 6-7
Right image focusing ......................................................................................................................................................................... 6-7
Blue on source .................................................................................................................................................................................. 6-7
i
All manuals and user guides at all-guides.com

Table of contents
i-2 5976283 BARCOGRAPHICS 808s 160403
Geometry Adjustments ...................................................................................................................................................................... 6-8
Horizontal Phase Adjustment ............................................................................................................................................................ 6-8
Raster Shift Adjustment .................................................................................................................................................................... 6-9
Left-Right (east-west) Adjustments .............................................................................................................................................. 6-10
Seagull correction .......................................................................................................................................................................... 6-11
Left Side Correction ....................................................................................................................................................................... 6-11
Top-Bottom (north-south) Adjustments ......................................................................................................................................... 6-12
Seagull Correction .......................................................................................................................................................................... 6-13
Horizontal Size Adjustment ............................................................................................................................................................ 6-13
Vertical Linearity Adjustment ......................................................................................................................................................... 6-14
Vertical Size Adjustment ................................................................................................................................................................ 6-14
Blanking Adjustments ..................................................................................................................................................................... 6-15
Convergence Adjustment .............................................................................................................................................................. 6-16
Coarse Convergence Adjustment. ................................................................................................................................................ 6-16
Horizontal sides .............................................................................................................................................................................. 6-16
Vertical corners ............................................................................................................................................................................. 6-17
Fine Convergence Adjustment. ...................................................................................................................................................... 6-17
SERVICE MODE ......................................................................................................................................................................................... 7-1
Starting up the Service mode. ........................................................................................................................................................... 7-1
Overview flowchart 'Service' mode. ................................................................................................................................................ 7-1
Identification ....................................................................................................................................................................................... 7-2
Copy a block ...................................................................................................................................................................................... 7-2
Deletion of blocks .............................................................................................................................................................................. 7-3
Deleting block by block ...................................................................................................................................................................... 7-3
Deletion of all blocks .......................................................................................................................................................................... 7-3
Change password ............................................................................................................................................................................ 7-4
Change Language ............................................................................................................................................................................. 7-4
Run time ............................................................................................................................................................................................. 7-4
Set to midposition .............................................................................................................................................................................. 7-5
Undo Midposition ............................................................................................................................................................................... 7-5
Convergence Mid .............................................................................................................................................................................. 7-5
Undo Convergence Mid(position) ..................................................................................................................................................... 7-5
Dynamic Astigmatism (spot shape adjustment) ............................................................................................................................... 7-6
G2 Adjust ........................................................................................................................................................................................... 7-7
Gamma corrections ........................................................................................................................................................................... 7-7
CRT run in cycle ................................................................................................................................................................................ 7-7
Projector Warm Up ............................................................................................................................................................................ 7-8
CRT Drive Mode ................................................................................................................................................................................. 7-8
MESSAGES, WARNINGS AND FAILURE CODES ..................................................................................................................................... 8-1
OPTIONS .................................................................................................................................................................................................... 9-1
Hardwired RCU. ................................................................................................................................................................................ 9-1
Projector Control software ............................................................................................................................................................... 9-1
RCVDS 05 Source Selector .............................................................................................................................................................. 9-1
VS05 Switcher .................................................................................................................................................................................. 9-1
MAGIK Interface ................................................................................................................................................................................ 9-2
Adapter and communication cables ................................................................................................................................................. 9-2
Appendix A : Adjustment blocks and source numbers 90 - 99 ............................................................................................................... A-1
All manuals and user guides at all-guides.com
all-guides.com

Safety Instructions
1-1
5976283 BARCOGRAPHICS 808s 160501
WARNING
TOPREVENTFIREORELECTRICALSHOCK
HAZARD,DONOTEXPOSETHISEQUIPMENTTO
RAINORMOISTURE
FEDERAL COMMUNICATION COMMISSION (FCC STATEMENT)
This equipment has been tested and found to comply with the limits
ofaclassAdigitaldevice,pursuanttoPart15oftheFCCRules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note :
The use of shielded cables is required to comply within the limits of
Part 15 of FCC rules and EN55022.
*Allthesafetyandoperatinginstructionsshouldbereadbeforeusing
this unit.
*Thesafety andoperatinginstructions manualshouldbe retained for
future reference.
* All warnings on the equipment and in the documentation manuals
should be adhered to.
* All instructions for operating and use of this equipment must be
followed precisely.
Onsafety
1. This product should be operated from an AC power source.
This projector may be connected to an IT-power system.
Operating AC power voltage of the projector:
Powervoltage is autoranging between 100V(-10%) and 240V (+6%)
If you are not sure of the type of AC power available, consult your
dealer or local power company.
2.Thisproductisequippedwitha3-wiregroundingplug,aplughaving
a third (grounding) pin. This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the purpose of the grounding-type plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE
GROUNDED (EARTHED) via the supplied 3 conductor AC power
cable.
(If the supplied power cable is not the correct one, consult your
dealer.)
A. Mains lead (Power cord) with CEE 7 plug:
The wires of the mains lead are colored in accordance with the
following code.
Green and yellow:earth (safety earth)
Blue: neutral
Brown: line (live)
1SAFETY INSTRUCTIONS
Notice on Safety
This equipment is built in accordance with the requirements of the
international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology
equipment including electrical business equipment.
These safety standards impose important requirements on the use
of safety critical components, materials and isolation, in order to
protect the user or operator against risk of electric shock and energy
hazard, and having access to live parts.
Safety standards also impose limits to the internal and external
temperaturerises,radiation levels, mechanicalstabilityandstrength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the
equipment to the user even when the equipment's normal operation
fails.
INSTALLATIONINSTRUCTIONS
Before operating this equipment please read this manual
thoroughly, and retain it for future reference.
Installation and preliminary adjustments should be
performed by qualified BARCO personnel or by author-
ized BARCO service dealers.
OWNER’SRECORD
Thepartnumberandserialnumberarelocatedatthebacksideofthe
projector. Record these numbers in the spaces provided below.
Referto them whenever you call upon yourBARCO dealerregarding
this product.
PARTNUMBER:
SER.NUMBER:
DEALER:
The lightning flash with an arrowhead within a
triangleisintendedtotelltheuserthatpartsinsidethis
product may cause a risk of electrical shock to
persons.
Theexclamation pointwithina triangleis intendedto
telltheuserthatimportantoperatingand/orservicing
instructions are included in the technical documen-
tation for this equipment.
All manuals and user guides at all-guides.com

Safety Instructions
1-2 5976283 BARCOGRAPHICS 808s 160501
B. Power cord with ANSI 73.11 plug:
The wires of the power cord are colored in
accordance with the following code.
Green/yellow:ground
White: neutral
Black: line (live)
3. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
Todisconnectthecord,pullitoutbytheplug.Neverpullthecorditself.
4. If an extension cord is used with this product, make sure that the
totaloftheampereratings on the productspluggedintotheextension
cord does not exceed the extension cord ampere rating. Also make
sure that the total of all products plugged into the wall outlet does not
exceed 15 amperes.
5. Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a risk of fire or electrical shock.
Neverspill liquid ofany kindon the product.Should anyliquidor solid
object fall into the cabinet, unplug the set and have it checked by
qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a
lightning storm, or when it is left unattended and unused for long
periodsoftime,unplugitfromthewalloutlet.Thiswillpreventdamage
to the projector due to lightning and AC power-line surges.
On installation
Onservicing
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage potentials
and risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following condi-
tions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c.If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating
instructions are followed.
Note : Adjust only those controls that are covered by the operating
instructions since improper adjustment of the other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to normal operation.
e.Ifthe producthasbeen droppedorthe cabinet hasbeen damaged.
f. If the product exhibits a distinct change in performance, indicating
a need for service.
Replacement parts - When replacement parts are required, be
sure the service technician has used original BARCO replacement
parts or authorized replacement parts which have the same char-
acteristics as the BARCO original part. Unauthorized substitutions
mayresultindegradedperformanceandreliability,fire,electricshock
or other hazards. Unauthorized substitutions may void warranty.
Safety check - Upon completion of any service or repairs to this
projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
- To keep the cabinet looking brand-new, periodically clean it with a
soft cloth. Stubborn stains may be removed with a cloth lightly
dampenedwithmild detergentsolution. Neveruse strong solvents,
such as thinner or benzine, or abrasive cleaners, since these will
damage the cabinet.
- To ensure the highest optical performance and resolution, the
projection lenses are specially treated with an anti-reflective
coating, therefore, avoid touching the lens. To remove dust on the
lens, use a soft dry cloth. Do not use a damp cloth, detergent
solution, or thinner.
On repacking
Savetheoriginalshippingcartonandpackingmaterial;theywillcome
in handy if you ever have to ship your equipment. For maximum
protection, repack your set as it was originally packed at the factory.
On illumination
Inordertoobtainthebestqualityfortheprojectedimage,itisessential
that the ambient light which is allowed to fall on the screen be kept
to an absolute minimum.
Wheninstallingthe projector andscreen,caremust betakentoavoid
exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting
fixtures.
Theuseofcontrolledambientlighting,suchasincandescentspotlight
or a dimmer, is recommended for proper room illumination. Where
possible,careshouldalsobetakentoensurethatthefloorsand walls
of the room in which the projector is to be installed are non-reflecting,
dark surfaces. Brighter surfaces will tend to reflect and diffuse the
ambient light and hence reduce the contrast of the projected image
on the screen.
CAUTION FIRE HAZARD
WARNING: DO NOT PLACE FLAMMABLE OR
COMBUSTIBLE MATERIALS NEAR PROJECTOR !
BARCO large screen projection products are designed and manufactured to
meet the most stringent safety regulations. This projector radiates heat on
its external surfaces and from ventilation ducts during normal operation,
which is both normal and safe.
Exposing flammable or combustible materials into close proximity of this
projector could result in the spontaneous ignition of that material, resulting
in a fire. For this reason, it is absolutely necessary to leave an exclusion
zone around all external surfaces of the projector whereby no flammable or
combustible materials are present. The exclusion zone must be not less
than 10 cm (4) for BARCO Retro Projectors and not less than 40 cm (16)
for all other BARCO projectors. Do not cover the projector with any material
while the projector is in operation.
Keep flammable and combustible materials away from the projector at all
times. Mount the projector in a well ventilated area away from sources of
ignition and out of direct sun light. Never expose the projector to rain or
excessive moisture. In the event of fire, use sand, CO2, or dry powder fire
extinguishers; never use water on an electrical fire.
Always have service performed on this projector by authorized BARCO
service personnel. Always insist on genuine BARCO replacement parts.
Never use non-BARCO replacement parts as they may degrade the safety
of this projector.
This product complies to standards set by Underwriters Laboratories, Inc., Canadian
Standards Association, and meets all applicable U.S. / Canadian and European
government regulations or directives.
1. Do not place this equipment on an unstable cart, stand, or table.
The product may fall, causing serious damage to it.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are
providedforventilation;toensurereliableoperationoftheproductand
to protect it from overheating, these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product
should never be placed near or over a radiator or heat register.
Theprojectorshouldnotbeplacedinabuilt-ininstallationorenclosure
unless proper ventilation is provided.
4. Do not block the projector cooling fans or free air movement under
and around the projector. Loose papers or other objects may not be
nearer to the projector than 4" on any side.
All manuals and user guides at all-guides.com

Location and Functions of Control
2-1
5976283 BARCOGRAPHICS 808s 160403
2LOCATION AND FUNCTION OF CONTROLS
REAR PANEL TERMINOLOGY
1 AC Power Switch : to switch on the projector.
Depending on the set-up of the projector during installation, the projector switches to standby or to 'Operational mode. If in standby,
the standby LED lights up.
2 AC Power Input : connect the supplied AC power (mains) cord here and to the wall outlet.
3 Communication Port (800 peripherals)
* Allows communication between the RCVDS switcher and the projector.
* Allows connection of a remote IR receiver unit to the projector.
4 Port 3
RGB Analog Input (9 pin female sub D connector). Allows a character generator, microcomputer, etc. having analog RGB outputs
to be connected to the projector.
5 Port 4/5 : RGB-S Input (5x BNC connector):
RGB-S input : allows a character generator, microcomputer, video camera, etc. having analog RGB output to be connected to the
projector.
Line inputs: - Signals RED-GREEN-BLUE
- COMPOSITE sync. signal
- Tri level sync signal (option)
6 DEFOCUS: For future expansion
775 ohm Termination Switch for S- Video signals
8 X-POS / Y-POS: For future expansion
975 ohm Termination Switch forVideo signals
10 IR Remote
Connector for remote input for hard wired remote control
11 Projector Pilot Lamp : Indicates the status of the projector.
- Unlit : mains (power) switch is not pressed.
- Lit : mains (power) switch is pressed and the indicated color shows the projector mode:
Green color : operational mode of the projector.
Red color : standby mode of the projector.
Important : projector ("Operational" or "Standby") mode is defined during the installation of the projector. (Refer to a qualified
technician for change).
12 IR Sensor
Receiver for control signals transmitted from the RCU.
13 RS 232 Output Port
RS 232 Input Port allows a communication link for PC or MAC to the next projector in a series of projector.
14 RS 232 Input Port
Connection between the projector and an IBM PC (or compatible) or MAC (RS422) for remote computer control and data communication.
ONOFF
POWER / MAINS
800 peripherals RGB
Comp-/H-SyncV-Sync
COMM. PORT PORT 3 PORT 4/5
V-nom
I-nom
Freq
See installation i nstructions before connecting to the suppl y.
Voir la noti ced’installation avant de raccorder au rØseau.
120/230 V
7/5 Amp
50/60 Hz
DEFOCUS OFF - ON
75 Ohm X-POS Y-POS green : operation
red : standby
PORT 2 PORT 1
OFF - ON
75 Ohm
PROJECTOR MODE
1 2 3 4 5 76 8 9 10
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1). This
device may not cause harmful inter-
ference, and (2) this device must
accept any interference receiv ed
including interference that may cause
undesir ed operation"
All manuals and user guides at all-guides.com

Location and Functions of Control
2-2 5976283 BARCOGRAPHICS 808s 160403
CONTROL PANEL TERMINOLOGY
a. Gaining access to the keyboard
The local keypath is underneath the top cover door with the BARCO logo.
To open this door, push and turn it to the front side of the projector.
This local keypad has the same functions as the Remote Control Unit (RCU).
b. RCU control panel
This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely.
This remote control is used for source selection, control, adaptation and set-up. It includes automatic storing of :
- Picture controls (Brightness, Sharpness,....)
- Picture geometry adjustments
- Convergence adjustments
Other functions of the remote control are:
- Switching between standby and operational modes
- Switching to "pause" (blanked picture, full power for
immediate restarting)
- Direct access to all connected sources
- Variable adjustment speed : when pushing continuously on the control stick or the picture keys, the adjustment will be
executed in an accelerated fashion.
1 Back light key : When activated, all keys will be lit up and
visible in the dark.
2 ADJ. : Adjust key, to enter or exit the adjustment mode.
3 Address key (recessed key), to enter the address of the
projector (between 0 and 9). Press the address key,
followed by pressing one digit button between 0 and 9.
4 STBY : Stand by button :
- To initiate remote power up operation
- To stop projection without main power off.
5 Pause : To blank the image, press PAUSE. The image
disappears but full power is retained for immediate restart-
ing.
6 Digit buttons : Direct input selection.
7 Picture controls : Use these buttons to obtain the desired
level (see also 'Controlling') for each picture function.
8TEXT : When adjusting one of the image controls during a
meeting, the displayed bar scale can be removed by pressing
'TEXT' key first. To re-display the bar scale on the screen,
press 'TEXT' key again. 'TEXT' key is only active in operational
mode. When 'TEXT' is off, no warning message will be
displayed.
11 Control stick key : To make menu selections when in the
adjustment mode. Also allows to increment or decrement an
adjustment in the adjustment mode.
control stick forward = up arrow in the menus
control stick backward = down arrow in the menus
control stick to the right = arrow to the right on the menus
control stick to the left = arrow to the left on the menus
15 RC operating indication : Lights up (green) when a button
on the remote control is pressed. (This is a visual indicator
to check the operation of the remote control)
stand-by
sharpness
pause/park
tint
color
brightness
contrast
















(17(5
F
3$86(
7(;7
(;,7
$'-
67%<
6+$531(66
7,17
&2/25
%5,*+71(66
&2175$67
All manuals and user guides at all-guides.com

Connections
3-1
5976283 BARCOGRAPHICS 808s 160403
ONOFF
PO WE R / MAIN S
800 peripherals
RGB
Comp-/H-SyncV-Sync
COMM. PORT PORT 3 PORT 4/5
V-nom
I-nom
Freq
See installati on instructions before connecting to the supply.
Voi r l a noticed’installati on avant de raccorder au rØseau.
120/230 V
7/5 Amp
50/60 Hz
DEFOCUS OFF - ON
75 Ohm
X-POS Y-POS green : ope ration
red : sta ndby
PORT 2
PORT 1
OFF - ON
75 Ohm
PROJECTOR MODE
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1). This
device may not cause harmful inter-
ference, and (2) this device must
accept any interference received
including interference that may cause
undesir ed operation"
3CONNECTIONS
AC Power (mains) Cord Connection
Use the supplied power cord to connect your projector to
the wall outlet. Plug the female power connector into the
male connector on the lower part at the backside of the
projector.
Power Check
The Power voltage is autoranging between 100V (-10%) and 240V (+6%)
If the wall outlet voltage is different, call a qualified technician for power adaptation of the projector.
Switching On/Off
The projector is switched ON and OFF using the power (mains) switch ON/OFF on the rear panel.
Pressed : ON
Not pressed : OFF
The projector can start in the 'operational mode' (image displayed) or in the 'stand by mode', depending on the position of the 'power up' dip
switch on the controller unit. This DIP switch must be set during installation by a qualified technician. If you want to change this start up
mode, call a qualified technician.
Stand by indication lamp (projector mode) :
No light up : projector switched off
Green color : projector in Operational mode
Red color : projector is in Standby mode.
When starting up the projector, with the power switch or via the stand-by key, the projector can start up in two ways if the "CRT run in"
cycle option is switched OFF.
- full white image (projector warm up) or
- immediate image display.
The way of starting up can be set in the service mode.
21 2))
32: (5   0 $, 16
9 QR P
,QRP
)UHT
9
$PS
+]
9,'(2 JUHHQRSHUDWLRQ
UHGVWDQGE\
3257
2))21
2KP
352-(&72502'(
7KLVGHYLFHFRPSOLHVZLWKSDUWRI
WKH)&&UXOHV2SHUDWLRQLVVXEMHFWWR
IROORZLQJWZRFRQGLWLRQV7KLV
GHYLFHPD\QRWFDXVHKDUPIXOLQWHU
IHUHQFHDQGWKLVGHYLFHPXVW
DFFHSWDQ\LQWHUIHUHQFHUHFHLY HG
LQFOXGLQJLQWHUIHUHQFHWKDWPD\FDXVH
XQGHVLUHGRSHUDWLRQ
All manuals and user guides at all-guides.com
all-guides.com

Connections
3-2 5976283 BARCOGRAPHICS 808s 160403
Start up with full white image.
The next menu will be displayed for 30 seconds.
a. Start up with warm up period.
If no action is taken, a white image will be displayed for 20 minutes.
This white image will be shifted on the faceplate of the CRT to avoid a CRT burn in.
During this warm up period, it is possible to interrupt this white image projection by
pressing the EXIT key. The previous menu will be repeated for another 30 seconds
but the remaining time will be indicated.
If EXIT is pressed, the remaining warm up period will be skipped.
During the warm up period, every 30 seconds a text box with the remaining time will
be displayed on the screen for 2 seconds. This text box will be displayed each time
in a different place.
If another key, different from EXIT, is pressed, a text box with following text will be
displayed :
Please use <EXIT> to leave this procedure.
b. Start up without warm up period.
If the EXIT key is pressed, the warm up period will be skipped and the projector is immediately ready for
use.
Warning : skipping this warm up procedure can reduce the initial picture quality of the
projected image.
Signal Input Connection to the Projector :
- RGBS or RGsB
- RGB3S or RG3sB (option)
Only available when the optional Tri-level sync mod-
ule is installed.
Port No Projector input Press Digit Button
1 For future expansion -
2 For future expansion -
3 RGB23
4/5 RGB24 or 5
4/5 Componentvideo36
4/5 RGB with Tri level sync47
4/5 Component video
with Tri-level sync58
2Input signal : R, G and B with automatic sync
detection between seperate sync (separate com-
posite sync or with separate Hor and Vert. sync)
or sync on green (composite sync).
3Input signal : R-Y, Y and B-Y with separate
composite sync or with separate Hor and Vert.
sync or with composite sync on Y.
4Input signal : R, G and B with separate Tri level
sync or with Tri-level sync on green.
5Input signal : R-Y, Y and B-Y with separate Tri
level sync or with composite Tri-level sync.
PROJECTOR WARM UP
AFULLWHITEPATTERN
WILLBEGENERATEDFOR
20MINUTES;
FORINMEDIATEUSEOF
THEPROJECTOR,PRESS
<EXIT>;
WARNING:SKIPPINGTHIS
PROCEDURE CAN REDUCE
THEINITIALPICTURE
QUALITYOFTHEPROJECTED
IMAGE;
THISOPTIONCANBE
DISABLEDINTHESERVICE
MENU
REMAINING
PROJECTOR
WARM UP
TIME
18.5 MIN
PLEASEUSE
<EXIT>TO
LEAVE THIS
PROCEDURE
ONOFF
PO WE R / MAIN S
800 peripherals RGB
Comp-/H-SyncV-Sync
COMM. PORT PORT 3 PORT 4/5
V-nom
I-nom
Freq
See installat ion i nstructi ons before connecting to the suppl y.
Voi r l a noti ced’installation avant de raccorder au rØseau.
120/230 V
7/5 Amp
50/60 Hz
DEFOCUS OFF - ON
75 Ohm X-POS Y-POS green : operation
red : standby
PORT 2 PORT 1
OFF - ON
75 Ohm
PROJECTOR MODE
123 4 5
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1). This
device may not cause harmful inter-
ference, and (2) this device must
accept any interference receiv ed
including interference that may cause
undesir ed operati on"
All manuals and user guides at all-guides.com

Connections
3-3
5976283 BARCOGRAPHICS 808s 160403
Connecting a RGB Analog source to port 3.
Connect your RGB source via an interface to Port 3.
Always use an interface when a computer and local monitor have
to be connected to the projector.
Available Barco interfaces :
Universal analog interface R9826100
RGB 120 MHz analog interface R9826570
VGA interface 120V R9828079
230V R9828070
MAC interface 120V R9828059
230V R9828050
MAGIK interface 120V R9828129 & R9828128
230V R9828120 & R9828121
RGB analog input with automatic sync detection. (Separate H and
V sync inputs, with composite sync input or with sync signals on
green)
Pin configuration D9 connector of the Analog input.
1 Not connected
2 Ground RGBS
3 RED
4 GREEN
5 BLUE
6 Ground RGBS
7 Ground RGBS
8 Hor/comp. sync
9 Vert. sync
Analog Input Selection :
Press digit button 3 on the RCU or the local keypad.
Connecting a RGB Analog source to port 4/5.
RGB analog input terminals with separate H and V sync inputs,
composite sync input or sync signals on green (automatic sync
detection).
Always use an interface when a computer and local monitor have
to be connected to the projector. See 'Connecting a RGB Analog
source to port 3' for a list of BARCO interfaces which can be applied.
RGB input selection :
(RGB : R, G, B signals with automatic sync detection)
Press digit button 4 or 5 on the RCU or the local keypad.
212))
32:(50$,16
SHULSKHUDOV
5* %
&RPS +6 \QF 96 \QF
&2 003257 32 57
3257
9QRP
,QRP
)UH T
6HHLQVWDOODWLRQLQVWUXFWLRQVEHIRUHFRQQHFWLQJWRWKHVXSSO\
9RLUODQRWLFHGLQVWDOODWLRQDYDQWGHUDFFRUGHUDXUpVHDX
9
$PS
+]
69,'(2 2))21
2KP
9,'(2 JUHHQRSHUD WLRQ
UHGVWDQGE\
3257  
325 7
2))21
2KP
352-( &72502'(
LQYHU
RKPWHUP
7KLVGHYLFHFRPSOLHVZLWKSDUWRI
WKH)&&UXOHV2SHUDWLRQLVVXEMHFWWR
IROORZLQJ WZRFRQGLWLRQ V7KLV
GHYLFHPD\QRWFDXVHKDUPIXOLQWHU
IHUHQFHDQGWKLVGHYLFHPXVW
DFFHSWDQ\LQWHUIHUHQFHUHFHLYHG
LQFOXGLQJLQWHUIHUHQFHWKDWPD\FDXVH
XQGHVLUHGRSHUDWLRQ
212))
32:(50$,16
SHULSKHUDOV
5*%
&RP S + 6\ QF 9 6 \Q F
&2003257 3257
325 7   
9QRP
,QRP
)UHT
6HHLQVWDOODWLRQLQVWUXFWLRQVEHIRUHFRQQHFWLQJWRWKHVXSSO\
9RLUODQRWLFHGLQVWDOODWLRQDY DQWGHUDFFRUGHUDXUpVHDX
9
$PS
+]
69,'(2 2))21
2KP
9,'(2 JUHHQ RSHUDWLRQ
UHG VWDQGE\
3257
3257
2))21
2KP
352-(&72502'(
LQYHU RKPWH UP
7KLVGHYLFHFRPSOLHVZLWKSDUWRI
WKH)&&UXOHV2SHUDWLRQLVVXEMHFWWR
IROORZLQJWZRFRQGLWLRQV7KLV
GHYLFHPD\QRWFDXVHKDUPIXOLQWHU
IHUHQFHDQGWKLVGHYLFHPXVW
DFFHSWDQ\LQWHUIHUHQFHUHFHLYHG
LQFOXGLQJLQWHUIHUHQFHWKDWPD\FDXVH
XQGHVLUHGRSHUDWLRQ
All manuals and user guides at all-guides.com

Connections
3-4 5976283 BARCOGRAPHICS 808s 160403
Connecting a RGB Analog source with Tri-level
sync to port 4/5.
(option)
RGB analog input terminals with Tri level sync input or Tri-
level sync on green. The projector detects automatically
where the sync signal is located.
RGB input selection :
(RG3sB : R, G, B signals with automatic Tri-level sync detection)
Press digit button 7 on the RCU or the local keypad.
Connecting a Component Video source to
port 4/5.
A component video (R-Y, Y, B-Y) with sync signals can be con-
nected to the projector via the Port 4/5. The projector automatically
detects where the sync signal is located.
To select the component video input :
Press digit button 6 on the RCU or the local keypad.
To select the component video input :
Press digit button 8 on the RCU or the local keypad.
Connecting a Component Video source with Tri-
level sync to port 4/5.
(Opion)
A component video (R-Y, Y, B-Y) with Tri-level sync signals can be
connected to the projector via the Port 4/5. The projector automati-
cally detects where the sync signal is located.
212))
32:(50$,16
SHULSKHUDOV
5*%
&RPS+6\QF9 6\QF
&200325 7 3257
3257
9QRP
,QRP
)UHT
6HHLQVWDOODWLRQLQVWUXFWLRQVEHIRUHFRQQHFWLQJWRWKHVXSSO\
9RLUODQRWLFHGLQVWDOODWLRQDY DQWGHUDFFRUGHUDXUpVHDX
9
$PS
+]
69,'(2 2)) 21
2K P
9,'(2 JUHHQ RSHUDWLRQ
UHGV WDQGE\
325 7
3257
2)) 21
2K P
352-(& 72502'(
798
7KLVGHYLFHFRPSOLHVZLWKSDUWRI
WKH)&&UXOHV2SHUDWLRQLVVXEMHFWWR
IROORZLQJWZRFRQGLWLRQV7KLV
GHYLFHPD\QRWFDXVHKDUPIXOLQWHU
IHUHQFHDQGWKLVGHYLFHPXVW
DFFHSWDQ\LQWHUIHUHQFHU HFHLYHG
LQFOXGLQJLQWHUIHU HQFHWKDWPD\FDXVH
XQGHVLUHGRSHUDWLRQ
212))
32:(50$,16
SHULSKHUDOV
5*%
&RPS+6\QF9 6\QF
&200325 7 3257
3257
9QRP
,QRP
)UHT
6HHLQVWDOODWLRQLQVWUXFWLRQVEHIRUHFRQQHFWLQJWRWKHVXSSO\
9RLUODQRWLFHGLQVWDOODWLRQDY DQWGHUDFFRUGHUDXUpVHDX
9
$PS
+]
69,'(2 2)) 21
2K P
9,'(2 JUHHQ RSHUDWLRQ
UHGV WDQGE\
325 7
3257
2)) 21
2K P
352-(& 72502'(
798
7KLVGHYLFHFRPSOLHVZLWKSDUWRI
