Bartec MC 92NOex-IS User manual

Mobile Computer MC 92NOex-IS
Quick Start Guide

BARTEC GmbH
Max-Eyth-Straße 16
Fon: [phone]
Support:
em[email protected]
97980 Bad Mergentheim
Fax: [phone]
Download:
http://automation.bartec.de
GERMANY
Internet:
www.bartec.com
Quick Start Guide - Translation
MC 92N0ex-IS
Mobile Computer
Type 17-A1A*-****/********
ATEX/IECEx Zone 1
UL Class I, II Division 1 and Class III
Document No.: 11-A1A2-7E0001
Status: January 2022
Proviso: Subject to technical changes. Changes, mistakes and printing errors do
not substantiate any claim to damages.
Content
Pages
English
1-36

Table of content
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Subject to technical changes.
January 2022
1Basic safety information ...................................................................................................................... 1
1.1 Information on this Quick Start Guide............................................................................... 1
Languages........................................................................................................................ 2
Changes in the document................................................................................................. 2
Registered trademarks ..................................................................................................... 2
1.2 Handling the product ........................................................................................................ 2
1.3 Intended use..................................................................................................................... 3
Exclusive purpose ............................................................................................................ 3
Unintended use ................................................................................................................ 3
1.4 Duties of the operator....................................................................................................... 3
1.5 Safety information............................................................................................................. 3
1.6 Maintenance..................................................................................................................... 4
Servicing........................................................................................................................... 4
Inspection......................................................................................................................... 4
Repairs............................................................................................................................. 4
Commissioning................................................................................................................. 4
1.7 Labelling, test certificate, and standards .......................................................................... 4
1.8 Warranty........................................................................................................................... 5
1.9 Co-applicable documents................................................................................................. 6
1.10 Definition of terms............................................................................................................. 6
1.11 Configuration.................................................................................................................... 7
2Product description.............................................................................................................................. 8
2.1 MC 92N0ex-IS ................................................................................................................... 8
2.2 Purpose of use ................................................................................................................. 8
3Structure................................................................................................................................................ 9
4Technical data..................................................................................................................................... 10
4.1 Explosion protection....................................................................................................... 10
4.2 Features ......................................................................................................................... 11
Performance features..................................................................................................... 11
Physical features............................................................................................................ 11
User environment........................................................................................................... 13
Barcode capture options................................................................................................. 13
Reading range................................................................................................................ 14
Application development ................................................................................................ 15
Voice and data transmission Wireless LAN.................................................................... 16
Voice and data transmission Wireless PAN ................................................................... 17
Headset.......................................................................................................................... 17
4.3 Battery............................................................................................................................ 18
4.4 Product labelling............................................................................................................. 19
Mobile Computer............................................................................................................ 19
Battery............................................................................................................................ 20
Laser Labels................................................................................................................... 20
5Transport and storage........................................................................................................................ 21
5.1 Transport........................................................................................................................ 21
5.2 Storage........................................................................................................................... 21

Table of content
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Subject to technical changes.
January 2022
6Commissioning................................................................................................................................... 22
6.1 Requirements in potentially explosive atmosphere ........................................................ 22
6.2 First steps....................................................................................................................... 24
7Operation............................................................................................................................................. 25
7.1 Final inspection............................................................................................................... 25
7.2 Handling ......................................................................................................................... 25
7.3 Handling accessories ..................................................................................................... 26
Insert/change battery...................................................................................................... 26
Change keypad .............................................................................................................. 28
Leather holster ............................................................................................................... 30
7.4 Scanning ........................................................................................................................ 31
8Service, Inspection, Repair................................................................................................................ 32
8.1 Service intervals............................................................................................................. 32
8.2 Inspection....................................................................................................................... 32
8.3 Service and repair work.................................................................................................. 32
Information on sending in for repairs.............................................................................. 33
9Disposal............................................................................................................................................... 34
10 Declaration of Conformity.................................................................................................................. 35
10.1 EU Declaration of Conformity......................................................................................... 35
11 Note...................................................................................................................................................... 36

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Basic safety information
Subject to technical changes.
January 2022
1/36
1Basic safety information
1.1 Information on this Quick Start Guide
Read carefully before putting the devices into operation.
The Quick Start Guide is a fixed part of the product. It must be kept in the direct vicinity of
the device and the installation, operating and service staff must have access to it at all
times.
The Quick Start Guide contains important information, safety instructions and test
certificates which are necessary for the perfect function of the device in operation.
The Quick Start Guide is directed at all individuals concerned with the commissioning,
handling and servicing of the product. The applicable guidelines and standards for areas
with gas and dust atmosphere (EN/IEC 60079-17, EN/IEC 60079-19) must be observed
when conducting this work.
Knowledge of the safety and warning information in this Quick Start Guide and the strict
compliance with it is essential for safe installation and commissioning. Accidents, injuries
and material damage can be avoided by circumspect handling and systematically
following the instructions.
The examples, tables, and figures provided in this Quick Start Guide are for illustration
purposes. Due to the different requirements of the respective application, the BARTEC
company cannot assume responsibility or liability for actual use based on the examples
and figures.
The BARTEC company reserves the right to carry out technical changes at any time.
In no event will BARTEC company be responsible or liable for indirect or consequential
damages resulting from the use or application of this Quick Start Guide.
Safety and warning information is particularly emphasised in this Quick Start Guide and
marked by symbols.
DANGER
DANGER describes a directly imminent danger. If not avoided, death or severe injury
will be the consequence.
WARNING
WARNING describes a possibly imminent danger. If not avoided, death or severe injury
may be the consequence.
CAUTION
CAUTION describes a possibly imminent danger. If not avoided, mild or slight injury may
be the consequence.
ATTENTION
ATTENTION describes a possibly damaging situation. If not avoided, the plant or
objects in its vicinity may be damaged.
Important information on effective, economical & environmentally compliant handling.

Basic safety information
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
2/36
Subject to technical changes.
January 2022
Languages
The original Quick Start Guide is written in German. All other available languages are
translations of the original Quick Start Guide.
The Quick Start Guide is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
Changes in the document
BARTEC reserves the right to change the content of this document without notification. No
warranty is assumed for the correctness of the information. In cases of doubt, the German
safety instructions apply because it is not possible to rule out errors of translation or printing.
In the case of legal disputes, the “General Terms and Conditions of Business” of the
BARTEC Group also apply.
The current versions of the datasheets, certificates and Declarations of conformity can be
downloaded from www.bartec.com or may be requested directly from BARTEC GmbH.
Registered trademarks
Bluetooth® is a registered trademark of Bluetooth Special Interest Group
Android The "Android" name, the Android logo, the Google Play trademark and
other Google trademarks are the property of Google LLC.
WiFi is a registered trademark of Wi-Fi-Alliance, an association of
manufacturers founded in 1999.
1.2 Handling the product
The product described in this Quick Start Guide left the factory in a perfect and tested state
in terms of safety. To maintain this state and to achieve a perfect and safe operation of this
product, it may only be operated in the manner described by the manufacturer. In addition,
the perfect and safe operation of this product requires correct transportation, proper storage
and careful operation.
The safe and perfect handling of the Mobile Computer is a prerequisite for its perfect and
correct functioning.

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Basic safety information
Subject to technical changes.
January 2022
3/36
1.3 Intended use
Exclusive purpose
The Mobile Computer is a handheld piece of electrical equipment. It serves the purpose of
the mobile recording, processing and/or radio transmission of data within potentially
explosive atmospheres.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The admissible operating data of the device used must be considered.
Unintended use
Any other use is unintended and may lead to damage and accidents. The manufacturer
shall not be liable for any use extending beyond the exclusive purpose.
1.4 Duties of the operator
The operator undertakes to only permit persons to work with the Mobile Computer who
are acquainted with the basic regulations on safety and accident prevention, and
who have been inducted in the use of the Mobile Computer,
have read and understood the documentation, the safety chapter and the
warnings.
The operator checks that the safety and accident prevention regulations applicable to the
respective case of use have been observed.
1.5 Safety information
Do not dry wipe or clean devices in potentially explosive atmospheres!
Do not open devices in potentially explosive atmospheres.
Do not replace or charge battery in potentially explosive atmospheres.
General statutory provisions or guidelines on occupational health and safety,
accident prevention provisions and environmental protection laws must be
heeded, e.g. Operational Safety Ordinance (BetrSichV) and nationally applicable
ordinances.
Use suitable clothing and shoes with respect to the danger of hazardous
electrostatic charges.
Avoid heat influences outside the specified temperature range.
Protect device from external influences! Do not expose device to
caustic/aggressive liquids, vapours or spray. In the case of malfunction or
damaged enclosure, remove the device immediately from the potentially explosive
atmosphere and bring it to a safe place.

Basic safety information
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
4/36
Subject to technical changes.
January 2022
1.6 Maintenance
The pertinent erection and operating provisions for electrical systems must be observed!
(e.g. Directive 2014/34/EU, BetrSichV and nationally applicable ordinances
EN/IEC 60079-14 and the series DIN VDE 0100)!
Observe the national waste disposal regulations when disposing of the devices.
Servicing
No constant servicing will be necessary if operated correctly under consideration of the
assembly instructions and environmental conditions. See chapter: Service, inspection,
repair in this respect.
Inspection
According to EN/IEC 60079-17 and EN/IEC 60079-19 the operator of electrical systems in
potentially explosive atmospheres is obliged to have these inspected by an electrician to
ensure correct condition.
Repairs
Repairs to explosion-protected devices may only be performed by authorised personnel
with original spare parts and according to the state of the art.
Therfore all repairs to the Mobile Computer have to conducted by BARTEC.
Contact information and instructions for repair requests and processing can be found at:
https://www.bartec.de/en/products/automation-enterprise-mobility/
Procedure guide
RMA Form
Commissioning
It must be checked that all components and documents are available before commissioning.
1.7 Labelling, test certificate, and standards
Labels on explosion protection and the test certificate are attached to the Mobile Computer.
Labelling see chapter: Technical Data.
The guidelines and standards applicable to the Mobile Computer for devices and protected
systems for intended use in potentially explosive atmospheres see chapter: Declaration of
Conformity.

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Basic safety information
Subject to technical changes.
January 2022
5/36
1.8 Warranty
WARNING
No changes or retrofits may be made without the written consent of the
manufacturer.
If non-specified components are used, the explosion protection will no longer be
guaranteed. In the case of externally procured parts, it is not guaranteed that these have
been designed and manufactured in accordance with their load and requisite safety.
Contact the manufacturer before any changes or retrofits to receive a release.
Only use original spare and wearing parts.
The manufacturer shall exclusively assume the complete warranty only for spare parts
ordered from him.
Our “General Terms and Conditions of Sale and Delivery” shall apply in principle. These
shall be made available to the operator on signing of contract at the latest. Warranty and
liability claims in the case of injury and damage to property shall be excluded if they are
attributable to one or several of the following causes:
Unintended use of the Mobile Computer.
Incorrect handling
Failure to observe the information in the Quick Start Guide and the User Manual
with respect to transport, storage, commissioning, operation and service.
Independent structural changes
Faulty monitoring of parts subject to wear and tear.
Incorrectly performed repairs.
Cases of disaster through the impact of foreign bodies and force majeure.
We grant a warranty period of one year starting from the date of delivery from the Bad
Mergentheim factory on the Mobile Computer (exception: battery 6 months). The warranty
period for accessories is one year starting from the date of delivery from the Bad
Mergentheim factory. This warranty covers all parts of the delivery and shall be restricted
to the free replacement or repair of the defective parts in our Bad Mergentheim factory. For
this purpose, any packaging supplied must be kept where possible. In the case of warranty,
the goods must be returned to us after written agreement using an RMA form. There shall
be no claim to repair at the sight of erection.
The information contained herein refers to the explosion-protected version of the Mobile
Computer MC 92N0ex-IS.
This Quick Start Guide contains all important information on the subject of explosion
protection.
Further product information on handling and commissioning can be found on the BARTEC
support page: https://automation.bartec.de/mobileE.htm

Basic safety information
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
6/36
Subject to technical changes.
January 2022
1.9 Co-applicable documents
All documents are available online from the following websites:
BARTEC: www.bartec.com or http://automation.bartec.de
ZEBRA: www.zebra.com
In the event of an overlaps with Zebra, the instructions of BARTEC apply.
Document BARTEC
Explanation
User manual
Mobile Computer MC 92N0ex
This user manual describes the use of the
explosion-protected version of the Mobile
Computer MC 92N0ex
Quick Start Guide
Mobile Computer MC 92N0ex-IS
The safety relevant information, initial use
and further data of the Mobile Computer
MC 92N0ex-IS are described in this Quick
Start Guide.
Data sheet
Mobile Computer MC 92N0ex-IS
This technical data sheet contains the most
important explosion-relevant technical data
as well as general technical data.
Document ZEBRA
Explanation
For MC9200
MC92 Mobile Computer
Quick Start Guide
MC92 Mobile Computer
Integrator Guide
MC92 Mobile Computer
User Guide
Instructions for commissioning, operating,
configuring, programming and maintaining of
the Mobile Computer.
1.10 Definition of terms
A few abbreviations are used in the documentation.
IS
=
Intrinsically Safe =>
is used as generic term Zone 1 and Division 1 versions
MC
=
stands for the entire product series of Mobile Computer

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Basic safety information
Subject to technical changes.
January 2022
7/36
1.11 Configuration
The devices are only supplied with preinstalled operating system.
Customer software or further applications are not contained in the delivery.
This Quick Start Guide refers to the following configurations:
Configuration
Version
Processor
TI OMAC 4430 Dual-Core/1GHz
Display
3.7" VGA Color Display
Memory
1 GB
Mass storage
2 GB
Operating system
Windows WEH 6.5.3
Windows CE 7.0
Android 4.4.4.
WLAN
WIN CE/WEH:
802.11 a/b/g/n/d/h/i
Android:
802.11 a/b/g/n/d/h/i/k/r
Bluetooth
WIN CE/WEH:
Microsoft-Stack: Bluetooth 2.1 EDR
Stonestreet-Stack: Bluetooth 4.0 plus BLE or WBA
Android:
Bluetooth 4.0 BLE
Scanner Options
SE965-SR:
1D scan engine with standard range
SE1524-ER:
1D scan engine with extended range
SE4500-SR:
Omnidirectional 1D/2D engine for image capture of 1D and 2D
symbols
SE4500-HD:
1D/2D DPM engine for image capture with several DPMs

Product description
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
8/36
Subject to technical changes.
January 2022
2Product description
2.1 MC 92N0ex-IS
The MC 92N0ex-IS is a tough Mobile Computer with 3.7" color display, which has been
designed for use in the industrial environments and especially developed by BARTEC in
close cooperation with ZEBRA for use in potentially explosive atmospheres.
2.2 Purpose of use
The Mobile Computer MC 92N0ex-IS are handheld electrical devices. They serve the
purpose of entry, processing and (radio) transmission of data within potentially explosive
atmospheres.
The Mobile Computer MC 92N0ex-IS are used exclusively in combination with devices
which comply with the requirements placed on the overvoltage category I.
The Mobile Computer MC 92N0ex-IS, Type 17-A1A*-****/******** have been modified for
use in the following potentially explosive atmospheres:
ATEX / IECEx Zone 1
Class I, II Division 1 and Class III

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Structure
Subject to technical changes.
January 2022
9/36
3Structure

Technical data
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
10/36
Subject to technical changes.
January 2022
4Technical data
4.1 Explosion protection
ATEX Zone 1
Type 17-A1A3-****/********
MC 92N0ex-IS
Labelling
II 2G Ex q [ib] IIC T4 Gb
Test certificate
PTB 13 ATEX 2019 X
Standards
See chapter: EU Declaration of Conformity
IECEx Zone 1
Type 17-A1A3-****/********
MC 92N0ex-IS
Labelling
Ex q [ib] IIC T4 Gb
Test certificate
IECEx PTB 13.0043X
Standards
See chapter: EU Declaration of Conformity
Class I, II, III, Division 1
Type 17-A1A2-****/********
MC 92N0ex-IS
Labelling
Class I Division 1 Groups C und D
Class II Division 1 Groups F und G
Class III
Test certificate
USA and Canada
UL E226123
Standards
USA Standard UL 913, 5 Edition.
Canada National Standard C22.2 Nr. 157-92
X - labelling (special conditions of use for secure operation within the potentially
explosive atmosphere)
The ambient temperature range is -20 °C ≤ Ta ≤ +50 °C.*
The device must be protected from impact with high impact energy, from intense UV-
irradiation, and strongly charge generating processes.
It is not allowed to use connectors inside the potentially explosive atmosphere.*
It is not allowed to remove, change and/or charge the battery inside the potentially
explosive atmosphere.*
The battery must be locked within the potentially explosive atmosphere.*
*See individual chapters on the items in this Quick Start Guide.

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Technical data
Subject to technical changes.
January 2022
11/36
4.2 Features
Performance features
CPU
Dual-Core 1 GHz OMAP 4430-Prozessor
Operating system
Windows WEH 6.5.3
Windows CE 7.0
Android 4.4.4.
Memory
4 GB RAM; 32 GB Flash
Extension slot
SD card slot
with SDHC support
(up to 32 GB)
Interfaces
RS232
USB
Physical features
Dimensions:
(Length x Width x Height)
MC 92N0ex-G:
231 x 91 x 193 mm (9.1 x 3.6 x 7.6 inch)
MC 92N0ex-K:
231 x 91 x 56 mm (9.1 x 3.6 x 2.3 inch)
Weight
(including battery)
MC 92N0ex-G:
Type 17-A1A3-****/******** (ATEX/IECEx Zone 1)
approx. 1060 g (2.3 lb)
Type 17-A1A2-****/******** (UL Div. 1)
approx. 830 g (1.8 lb)
MC 92N0ex-K:
Type 17-A1A3-****/******** (ATEX/IECEx Zone 1)
approx. 980 g (2.2 lb)
Type 17-A1A2-****/******** (UL Div. 1)
approx. 700 g (1.5 lb)
Display
3.7" VGA-colour display
VGA mode:
480 x 640 pixel (width x height)
QVGA mode (Windows CE only):
240 x 320 pixel (width x height)
Touchscreen
Analogue-resistive touchscreen
Background lighting
LED technology
Network connections
Ethernet (via charge station);
USB 2.0, Host or Client
Interactive sensor technology
Three-axes accelerometer for motion sensor
application for dynamic screen orientation
power monitoring
recognition of free fall

Technical data
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
12/36
Subject to technical changes.
January 2022
Keypad versions
28 Keypad (Numeric keys can be used direct,
Alpha keys and other key functions can be
used via function keys)
43 Keypad (Numeric- and Function keys can
be used direct, Alpha keys and other key
functions can be used via function keys)
53 Keypad (Numeric- and Alpha keys can be
used directly, other key functions can be used
via function keys)
53 Keypad with layout for VT Emulation
No emulation software is installed on the Mobile Computers with the emulation key
version. The customer must order the emulation software separately from ZEBRA and its
distributors and install it himself.
The devices are modified to suit the selected keypad version. The end user can replace
the keypad later himself.
When replacing the keyboard, follow the instructions in this Quick Start Guide.

MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
Technical data
Subject to technical changes.
January 2022
13/36
User environment
Operating temperature
-20 °C to +40 °C ( -4 °F to +104 °F)
Charging temperature
0 °C to +40 °C (+32 °F to +104 °F)
Storage temperature
(without battery)
-40 °C to +70 °C (-40 °F to +158 °F)
Relative humidity
5 % to 95 % (non-condensing)
Class of protection (IEC 60529)
Type 17-A1A3-****/******* (ATEX/IECEx Zone 1)
IP 54
Type 17-A1A2-****/******* (UL Div. 1)
IP 64
Barcode capture options
Barcode capture
Available operating
systems
Form
1D-Barcodes
Windows
CE/WEH
Android
4.4.4
MC92N0
Gun
MC92N0
Brick
SE965-SR
1D Standard Range Scan Engine
Yes
Yes
Yes
Yes
SE1524-ER
1D Extended Range Scan Engine
Yes
Yes
Yes
No
1D-/2D Barcodes
SE4500-SR
1D-/2D Omni-Direktional Imager Engine
Yes
Yes
Yes
Yes
DPM/1D-/2D Barcodes
SE4500-HD
DPM/1D-/2D Imager Engine
Yes
No
Yes
Yes

Technical data
MC 92N0ex-IS - Mobile Computer
Type 17-A1A*-****/********
14/36
Subject to technical changes.
January 2022
Reading range
Barcode capture
Reading range
1D-Barcodes
minimum
maximum
SE965-SR
1D Standard Range Scan Engine
2.5 cm
0.98 inch
130 cm
51.18 inch
SE1524-ER
1D Extended Range Scan Engine
5 cm
1.97 inch
1370 cm
539.37 inch
1D-/2D Barcodes
SE4500-SR
1D-/2D Omni-Directional Imager Engine
5 cm
1.97 inch
60 cm
23.62 inch
DPM/1D-/2D Barcodes
SE4500-HD
DPM/1D-/2D Imager Engine
3.5 cm
1.38 inch
28 cm
11.02 inch
The scanning range of the different scan engines depends on the used barcode type, the
print quality and the module width (in mil).
The scan engines used comply with laser class CDRH Class II / IEC 825 Class 2.
Further detailed information on the used scan engine can be found in the “User Manual“
or “Integrator Guide“ from ZEBRA.
