Bartscher TBST200 User manual

TBST200
A300111

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 1.0
Date of preparation: 2022-10-19
Original instruction manual
EN

A300111 3 / 8
EN
Technical Data
Name:
Cutlery trolley TBST200
Art. No.:
A300111
Material:
stainless steel, plastic
Number of shelves:
1
Shelves dimensions (W x D), in mm:
590 x 310
Number of cutlery boxes:
2
Cutlery box dimensions (W x D x H), in
mm:
511 x 286 x 110
Total load-bearing capacity, max. in kg:
60
Load-bearing capacity per level, max. in
kg.:
30
Clearance between levels, in mm:
330
Number of swivel casters:
4
Locking swivel casters:
2
Diameter of swivel casters, in mm:
80
Number of caster dampers:
4
Material of caster dampers:
plastic
Dimensions (W x D x H), in mm:
594 x 305 x 1.205
Weight, in kg:
10,6
We reserve the right to implement technical modifications.

4 / 8 A300111
EN
Version / Characteristics
•Delivery form: self-assembly set, simple assembly
•Application areas:
–cleaning
–storage
–serving
–transportation
•Version of cutlery boxes:
–4 partitions
–removable
–plastic
•With handles
<Endergebnis>
Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–cleaning, storage and transportation of cutlery.

A300111 5 / 8
EN
Scope of Delivery / Part Name
•Unpack the cutlery trolley and remove the packing material pursuant to
environmental regulations.
•Check completeness of delivery according to the list below:

6 / 8 A300111
EN
Assembly

A300111 7 / 8
EN
1. First, using washers (E) and bolts (F), fix the bottom shelf (D) and both frames
of the cutlery box (B) to one of the lateral sections (A). Use Allen wrench (G)
and tighten bolts. (Fig. 1)
2. As described above, fix the bottom shelf (D) and both frames of the cutlery box
(B) to the second lateral section (A). (Fig. 1)
3. Place the cutlery trolley on its side.
4. Mount swivel casters (K, L) onto square tubing of lateral sections. Between each
swivel caster and the square tubing of the lateral section, place one washer (J)
and one damper.
5. Finally, screw swivel casters into square tubing of lateral sections. (Fig. 3)
6. Set the cutlery trolley on swivel casters. (Fig. 4)
7. Place cutlery boxes (C) in frames (B) provided to this frame.
Installation
1. Check the stability of the cutlery trolley.
2. Level the cutlery trolley through screwing in and out swivel casters.
3. After setting the cutlery trolley in a designated place, lock 2 swivel casters with
lockings to prevent accidental relocation or overturn of the tray trolley.
Using Cutlery Trolley
1. After assembly, thoroughly clean the cutlery trolley observing instructions in
section 'Cleaning'.
2. Fill the cutlery boxes with cutlery.
Cutlery may be stored in a space-saving
manner and well sorted out.
The cutlery trolley facilitates work in various
sections of kitchen. Besides that, it is practical
for users and prevents back from straining in
service area.
Owing to the mobile cutlery trolley it is faster
and easier to make tables and clean them.
Owing to the mobile cutl erytr olleyi t is faster and easier t o maketa bles and clean them:

8 / 8 A300111
EN
Cleaning
ATTENTION!
Scrubbing agents, washing agents with solvents or caustic substances
may damage the surface of the cutlery trolley.
For cleaning, use suitable cleaning agents only.
1. In order to facilitate cleaning, you may remove cutlery boxes.
2. Wash cutlery boxes with warm water with a mild washing agent and a soft cloth.
3. Clean the cutlery trolley and the shelf regularly with warm water and a soft,
damp cloth. Use a mild cleaning agent when required.
4. Finally, thoroughly dry all cleaned parts and surfaces with a soft cloth.
