Bauhn HE215027 User manual

INSTRUCTION MANUAL
Model Number: HE215027
auricle
BLUETOOTH®
HEADPHONES

Warranty Note
If you experience any issues with this product, or it’s
performance is not what you had expected, please
contact us at Winplus before returning the item to
the store.
It is likely that we can resolve any problems for you
via phone or email.
We can be reached on:
Phone: [phone] (8:30am - 6:00pm EST)
Email: customercar[email protected]

Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE215027 PRODUCT CODE: 49427 06/2015
[e-mail]
1300 663 907
AUS
BLUETOOTH® HEADPHONES

5
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period
of 12 monthsfrom the date of purchase. Defects that occur within this warranty period,
under normal use and care, will be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage.You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE215027 PRODUCT CODE: 49427 06/2015
[e-mail]
1300 663 907
AUS
BLUETOOTH® HEADPHONES
Safety Instructions
Read this manual thoroughly before rst use and keep it in a safe place for future reference, along with
the warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk
of re, electric shock and injury when correctly adhered to. Follow all instructions and take notice of all
warnings to reduce the risk of re or electric shock.
• Do not expose this product to water, rain, moisture or dust. Electronic products of this kind should
never be subjected to moisture or extreme temperatures.
• Do not attempt to open the product housing. There are no user-serviceable parts inside this product.
• Do not repair the unit yourself. If your device is not functioning correctly, disconnect the product from
power, and contact after sales support.
• Supervise young children to ensure they do not play with the product.
• Do not expose device to chemicals, oils, or other liquids.
• Do not expose device to naked ames or other heat sources.
• Do not drop or subject the device to undue shock.
• Keep device away from magnets at all times.
• Keep away from direct sunlight. Indoor use only.
• Unplug this device during lightning storms or when unused for long periods of time.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks is under license

6
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Contents
Warranty Details 4
Safety Instructions 5
Parts List 7
Technical Specications 7
Product Overview 8
Instructions 9
Charging 9
Power On/O 9
Pairing 10
Pairing Via NFC (Near Field Communication) 11
Audio Playback 11
Phone Calls 12
Connecting via Aux-in 12
FAQs 13
Repair and Refurbished Goods or Parts Notice 14

7
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Parts List
Technical Specications
1x Bauhn Bluetooth Headphones
1x 3.5mm Audio Cable
1x Micro USB Cable
1x Instruction Manual
1x Getting Started Guide
1x Warranty Card
Driver Unit: 50mm
Impedance: 32Ω ± 15%
Frequency Range: 20Hz-20KHz
Rated Power: 10mW
Max. Power: 30mW
Bluetooth Version: 4.0 backwards compatible to 2.0+EDR
Transmission Range: Up to 10m
Standby Time: Up to 250hrs
Playback / Talk Time: Up to 15hrs
Battery: 500mAh Lithium Battery
Power Input: 5V, 500mA

8
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Product Overview
1. Play/Pause Button
2. Previous Track Button
3. Next Track Button
4. Volume Up Button
5. Volume Down Button
6. Audio Jack
7. Status Indicator
8. Charging Port
9. Microphone
10. NFC Contact Point
3
4
5
1
2
6
7
9
8
10

9
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Charging
When fully charged, the Bauhn Bluetooth Headphones will last up to 15hrs depending on usage. To charge,
simply connect your headphones to a USB outlet on your PC or laptop.
1. Insert the included Micro USB plug into Bluetooth Headphones. The charging port is located on the
bottom of right ear pad.
2. Connect the USB plug to a spare USB port on your PC or laptop.
3. The LED light will show a solid red colour to indicate charging is active.
4. The light will turn o when fully charged.
Tip: When your Bluetooth Headphones are running low on battery, the LED on the bottom of the right ear pad
will slowly ash red.
Power On/O
Before rst use, it is recommended you charge the Bauhn Bluetooth Headphones for at least 1 hour.
To turn on your Bauhn Bluetooth Headphones:
1. Hold down the button on the side of the right ear pad for 3 seconds.
2. The headset will state “power on” when you turn on the headphones.
3. The LED on the bottom of the ear pad will quickly ash blue while powered on.
To turn o your Bauhn Bluetooth Headphones:
1. Hold down the button on the side of the right ear pad for 3 seconds.
2. The headset will state “power o” when you turn o the headphones.
3. The LED on the bottom of the ear pad will ash red once when powering o.
Instructions

10
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Instructions
Pairing
The Bauhn Bluetooth Headphones can be paired to a Bluetooth enabled device such as your
smartphone or MP3 player.
Pairing for the rst time:
1. While the headphones are o, press and hold the button on the headphones for 6 seconds to
turn on the Bluetooth Headphones and enter pairing mode.
2. The headset will state “power on” and then “pairing”. The LED will quickly ash blue & red while in
pairing mode.
3. Search on your MP3 Player or smartphone for the device “HE215027” and pair as per your MP3
player or smartphone’s instructions (Refer to your devices manual for further details).
4. When the Bluetooth Headphones are successfully paired with your device, the headphones will
state “your headset is connected”.
5. The LED on the bottom of the ear pad will turn blue when connected via Bluetooth.
Reconnecting to a device
The Bauhn Bluetooth Headphones will automatically reconnect to a device you have previously paired
to, when the device is within range.
1. Press and hold the button for 3 seconds to turn on the Bluetooth Headphones.
2. The Bluetooth Headphones will state “power on” when you turn on the headphones. The LED on
the bottom of the ear pad will quickly ash blue while powered on.
3. The Bluetooth Headphones will begin to automatically search for any previously connected devices
within range. This may take up to 15 seconds.
4. When the Bluetooth Headphones are successfully paired with your device, the headphones will
state “your headset is connected”
5. The LED on the bottom of the ear pad will turn blue when connected via Bluetooth.
Note: The headphones can store up to 10 paired devices and will automatically connect to the last
paired device when in range.

11
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Instructions
Pairing Via NFC (Near Field Communication)
The Bauhn Bluetooth Headphones also feature NFC (Near Field Communication).
This feature lets you pair your Bluetooth Headphones to any NFC enabled Bluetooth device quickly
and easily. The below instructions assume NFC is activated on your device. Refer to the manufacturer’s
instructions if you are unsure how to do this.
1. Turn the headphones on by pressing the button for 3 seconds.
2. To pair your Bluetooth Headphones to an NFC enabled device, hold the headphones against the
device at the bottom of the right ear pad. There is a icon to indicate the best position.
3. Your NFC enabled device may prompt you to conrm pairing to the Bluetooth Headphones.
4. When the Bluetooth Headphones are successfully paired with your device, the headphones will
state “your headset is connected”.
Note: For more information on NFC refer to your device’s instruction manual.
Audio Playback
The Bauhn Bluetooth Headphones features audio playback controls located on the side of the right ear
pad. You can control volume and track playback quickly and easily from your Bluetooth Headphones.
1 – Play / Pause
2 – Track Back
3 – Track Forward
4 – Volume Up
5 – Volume Down
1
2
3
4
5

12
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
Phone Calls
When connected to your Bluetooth enabled phone, you can accept incoming calls through your Bauhn
Bluetooth Headphones.
Answering a Call
1. When you receive an incoming call, the ringtone will be heard through your Bluetooth Headphones.
2. Press the button located on the right ear pad to answer the call.
3. The built-in microphone on the Bluetooth Headphones will pick up your voice as you speak.
Ending a Call
1. When you wish to end a call, press the button located on the right ear pad.
Rejecting a call
1. If you receive a call and do not wish to answer it, you can reject the call by holding the button
located on the right ear pad for 2 seconds.
Connecting via Aux-in
The Bauhn Bluetooth Headphones can be directly connected via the aux-in port located on the bottom
of the left ear pad.
1. Connect the included 3.5mm audio cable to the aux-in jack located on the left ear pad.
2. Connect the other end of the audio cable to the audio out jack on your audio device.
Note: When connected via audio cable, the Bluetooth function and controls are disabled. You cannot
control playback using the control when connected via aux-in. The headphones will not be discoverable
on Bluetooth.
Instructions

13
After Sales Support
1300 663 907
Model Number HE215027
customercar[email protected]
FAQs
Question Solution
There is no audio through the
headphones when paired to a device
• Remove any cables connected to the aux-in jack
on the headphones and device.
• Turn up the volume on the headphones using the
control pad.
• Turn up the volume on the paired device (above
80%).
• Ensure the “HE215027” is selected as the audio
output on your device.
• Try re-pairing your device. Only one audio device
can be paired at once.
The headphones won’t turn on • Charge the device for 1 hour using the included
Micro USB cable before trying again.
I can’t pair to my Bluetooth enabled
device
• Check that you are within range of the
headphones.
• Ensure that Bluetooth is enabled on your phone
or MP3 player.
• Ensure the headphones are in pairing mode, with
LED ashing blue and red rapidly.
I can’t hear anything when I dial
someone/someone dials me
• Turn up the volume on the headphones using the
control pad.
• Turn up the volume on the paired device.
• Ensure you have not muted the phone.
The NFC function isn’t working • Check your device features NFC. Refer to the
device manufacturers instructions for details.
• Check you have activated NFC on your NFC
enabled device.
• Ensure you are holding the NFC enabled device
to the logo located on the bottom of the right
ear pad.
Can I use a power adaptor to charge the
headphones?
• The Bauhn Bluetooth Headphones do not
include a power adaptor; however, you can
charge the device using any USB power Adaptor
with 5V, 500mA output. Contact your local
electronics store to purchase an adaptor.
I lost my USB cable • Micro USB cables can be purchased from most
electronics retailers.
Where can I get an auxiliary cable from? • Auxiliary cables are available from most
electronics retailers.
How do I pair the Bluetooth Headphones
to my laptop/PC?
• Ensure your laptop/PC has Bluetooth
capabilities.
• Refer to your laptop/PC manual for pairing
instructions

Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be returned
to the Supplier for repair.
Please be aware that if your product iscapable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored onamobile telephone, songs
stored on a portable media player, games saved onagames console or files stored ona USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending theproduct for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 663 907 or write to us at:
Winplus Australasia
PO BOX 537
Bayswater Business Centre
Bayswater, VIC 3153
Winplus Help Desk 1300 663 907
(Operating Hours: Mon-Fri 08:30AM to 6:00PM)
[email protected]
www.winplus.com.au
AFTER SALES SUPPORT
1300 663 907
AUS
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE215027 PRODUCT CODE: 49427 06/2015
[e-mail]
1300 663 907
AUS
BLUETOOTH® HEADPHONES

Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be returned
to the Supplier for repair.
Please be aware that if your product iscapable of retaining user-generated data (such as files
stored on a computer hard drive, telephone numbers stored onamobile telephone, songs
stored on a portable media player, games saved onagames console or files stored ona USB
memory stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending theproduct for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on 1300 663 907 or write to us at:
Winplus Australasia
PO BOX 537
Bayswater Business Centre
Bayswater, VIC 3153
Winplus Help Desk 1300 663 907
(Operating Hours: Mon-Fri 08:30AM to 6:00PM)
[email protected]
www.winplus.com.au
AFTER SALES SUPPORT
1300 663 907
AUS
AFTER SALES SUPPORT
YEAR WARRANTY
1
MODEL: HE215027 PRODUCT CODE: 49427 06/2015
[e-mail]
1300 663 907
AUS
BLUETOOTH® HEADPHONES
