Baumatic BO905SS User manual

1
BO905SS 60 cm Built in
electric double oven

User Manual for your Baumatic
BO905SS 60 cm Built in double electric
oven
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 02/09/10
2

3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 – 11
Product and aperture dimensions 8
Product specifications 8 – 9
Electricaldetails 9
Coolingfans 9
Controlpanel 10
Ovenprogrammer/timer 11
Initial set up of your oven 11 - 12
Setting the time of day 11
Before first use 11 - 12
Timerfunctions 12 – 17
The minute minder function (main oven and top oven) 12 - 13
The semi-automatic cooking function (main oven only) 13 - 14
The end of cooking function (main oven only) 14 - 15
The automatic cooking function (main oven only) 15 – 16
Cancelling the semi-automatic and automatic function 16
Cancelling the minute minder function 16
Adjusting the volume of the audible signal 16 - 17
Changingthetimeofday 17
Using your oven 17-22
Selecting an oven function 17
Mainovenfunctions 17-18
Thermostat control knob (main and top oven) 19
Oven operating light (main and top oven) 19
Cooking guidelines 19 – 21
Usingthegrill 21
Warnings 22
Cleaning and maintenance 23 – 26
Removing the side racks 24
Replacing the oven bulb (main oven) 24 - 25
Replacing the oven bulb (secondary oven) 25
Removing the oven door for cleaning 26
Installation 27 - 33
Electrical connection 27 – 28
Connecting the mains supply cable 29
Replacing the mains supply cable 30
Positioning the appliance 31
Ventilation requirements 32
Installing the oven into the housing unit 33
My appliance isn’t working correctly 33 - 35
Contact details 36

Environmental note
4
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Information
oThis appliance is designed for domestic household use and can
be built into a standard kitchen cabinet or housing unit.
oIMPORTANT: The adjacent furniture or housing and all
materials used in the installation must be able to withstand a
minimum temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
oRepairs may only be carried out by Baumatic service
engineers or their authorised service agent.
Warning and safety instructions
oThis appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compliance
does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.
5

6
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowed
to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
General Safety
oDo not place heavy objects on the oven door or lean on the
oven door when it is open, as this can cause damage to the oven
door hinges.
oDo not leave heated oil or fat unattended, as this is a fire risk.
oDo not place pans or baking trays directly on the base of the
oven cavity, or line it with aluminium foil.
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to
dry clothing.
oDo not install the appliance next to curtains or soft furnishings.
oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.

Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity.
oIn the parts destined to come into contact with foodstuffs, this
appliance is in accordance with the requirements of the EC
directive 89/109 transposed in the Italian Legislative Decree No.
108 of 25/01/92.
oCE: Appliance conforming to the European directives
89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions
and “RoHS” directive 2002/95/CE.*
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
*The RoHS directive stands for “the restriction of the use of
certain hazardous substances in electrical and electronic
equipment”. This directive bans the placing on the EU market of
new electrical and electronic equipment containing more than
the agreed levels of lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyl (PBB) and polybrominated
diphenyl ether (PBDE) flame retardants.
7

Specifications
Product and aperture dimensions
Product Dimensions
Height: 885 mm
Width: 598 mm
Depth: 566 mm
(incl. 22 mm front fascia depth)
Aperture Dimensions
Height: 800 - 882 mm
Width: 562 - 565 mm
Depth: 560 mm (min)
Product specifications
oEnergy efficiency class: A/A
oLED full programmer
o2 x cooling fans
oTriple-glazed removable doors
oThermostatically controlled grills
oWipeClean enamelled cavities
oMain oven:
o9 functions
oGross oven capacity: 68 litres
8

9
oNet oven capacity: 61 litres
oSecondary oven:
o4 functions
oGross oven capacity: 38 litres
oNet oven capacity: 30 litres
Standard accessories
o2 x Enamelled baking trays with handle
o3 x Safety shelves
o2 x Trivets
oRemovable chrome side racks
oRemovable roof liner (main oven only)
oBPS2 Pizza stone
Optional extras
oSCL1KIT Stayclean liners (main oven only)
Electrical details
Rated Voltage: 220 - 240 V~ 50/60 Hz
Supply Connection: 20 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 4.40 kW
Mains Supply Lead: 3 x 2.5 mm²
Oven Light Bulb: 25 W/300°C screw type pigmy
Cooling fans
oTwo tangential cooling fans are fitted inside of these appliances,
to make the internal temperature of the oven stable and the
external surface temperature lower.
oAfter you have finished cooking and switched off the oven, the
cooling fan will continue to run for a period of time afterwards.
The length of time will depend on how long the oven has been
switched on for and at how high a temperature.

For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening the main oven door and looking on the right hand
side of the oven chassis.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….
Control Panel
1) Top oven thermostat control knob
2) Top oven operating light
3) Top oven power indicator light
4) Top oven function selector knob
5) Oven programmer/timer
6) Main oven function selector knob
7) Main oven power indicator light
8) Main oven operating light
9) Main oven thermostat control knob
