Baumer AMG 11 D13 User manual

Baumer Hübner GmbH
Max-Dohrn-Str. 2+4
D-10589 Berlin
Phone [phone] - 0
Fax [phone]
[email protected]
www.baumer.com
Manual
Absolute Encoder with
Firmware version from 1.01

BUDE_Manual_DeviceNet_EN.doc 2/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
Content
Page
1Introduction.....................................................................................................................................4
1.1 Scope of delivery..............................................................................................................................4
1.2 Product assignment..........................................................................................................................4
2Safety and operating instructions................................................................................................5
3Operating mode of the encoder....................................................................................................6
3.1 Poll Mode..........................................................................................................................................6
3.2 Change of state Mode (COS)...........................................................................................................6
3.3 Cyclic Mode......................................................................................................................................6
4Encoder operating parameters .....................................................................................................6
5Object model...................................................................................................................................7
6I/O assembly instances..................................................................................................................8
7Configuration of the encoder........................................................................................................9
8Encoder position object ..............................................................................................................10
9Terminal assignment and commissioning.................................................................................13
9.1 Electrical connection ......................................................................................................................13
9.1.1 Setting the user address ................................................................................................................13
9.1.2 Setting the baud rate......................................................................................................................13
9.1.3 Terminating resistor........................................................................................................................13
9.1.4 Bus cover connection.....................................................................................................................14
9.2 Display elements (status display)...................................................................................................15

BUDE_Manual_DeviceNet_EN.doc 3/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
Disclaimer of liability
The present manual was compiled with utmost care, errors and omissions reserved. For this reason Baumer
Huebner GmbH rejects any liability for the information compiled in the present manual. Baumer Huebner
GmbH nor the author will accept any liability for direct or indirect damages resulting from the use of the
present information.
At any time we should be pleased receiving your comments and proposals for further improvement of the
present document.

BUDE_Manual_DeviceNet_EN.doc 4/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
1 Introduction
1.1 Scope of delivery
Please check the delivery upon completeness prior to commissioning.
Depending on encoder configuration and part number delivery is including:
Basic encoder with DeviceNet bus cover
CD with EDS file and manual (also available as download in the Internet).
1.2 Product assignment
Shaft encoders
Produkt Produkt-Code Eds-Datei Produktfamilie
AMG 11 D13 0x0B AMG11D13.eds AMG 11 - Singleturn
AMG 11 D29 0x0A AMG11D29.eds AMG 11 - Multiturn
AMG 81 D13 0x0B AMG81D13.eds AMG 81 - Singleturn
AMG 81 D29 0x0A AMG81D29.eds AMG 81 - Multiturn
Hollow shaft encoders
Produkt Produkt-Code Eds-Datei Produktfamilie
HMG 11 D13 0x0B HMG11D13.eds HMG 11 - Singleturn
HMG 11 D29 0x0A HMG11D29.eds HMG 11 - Multiturn

BUDE_Manual_DeviceNet_EN.doc 5/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
2 Safety and operating instructions
Supplementary information
This manual is intended as a supplement to already existing documentation (catalogues, data sheets and
assembly instructions).
The manual must be read without fail before initial commissioning of the equipment.
Intended purpose of the equipment
The encoder is a precision measurement device. It is used to determine angular positions and revolutions,
and to prepare and supply measured values in the form of electrical output signals for the follow-on device
systems. The encoder may only be used for this purpose.
Commissioning
The encoder may only be installed and assembled by suitably qualified experts.
Observe the operating instructions of the machine manufacturer.
Safety remarks
Prior to commissioning the equipment, check all electrical connections.
If installation, electrical connection or any other work performed at the encoder or at the equipment is not
correctly executed, this can result in a malfunction or failure of the encoder.
Steps must be taken to exclude any risk of personal injury, damage to the plant or to the operating
equipment as a result of encoder failure or malfunction by providing suitable safety precautions.
Encoders must not be operated outside the specified limited values (see detailed product documentation).
Failure to comply with the safety remarks can result in malfunctions, personal injury or damage to property.
Transport and storage
Only ever transport or store encoders in their original packaging.
Never drop encoders or expose them to major vibrations.
Assembly
Avoid impacts or shocks on the housing and shaft.
Avoid any twist or torsion on the housing.
Do not open the encoder or make any mechanical changes to it.
The shaft, ball bearings, glass pane or electronic components can be damaged. In this case, safe and reliable
operation cannot be guaranteed.
Electrical commissioning
Do not make any electrical changes at the encoder.
Do not carry out any wiring work when the encoder is live.
Never plug or unplug the electrical connection when the encoder is live.
Ensure that the entire plant is installed in line with EMC requirements. The installation environment and
wiring affect the electromagnetic compatibility of the encoder. Install the encoder and supply cables
separately or at a long distance from cables with high interference emissions (frequency converters,
contactors etc.)
Where working with consumers which have high interference emissions, make available a separate power
supply for the encoder.
Connect the encoder to the protective earth (PE) conductor
Use shielded cable. Ideally, aim a single side connection to protective earth (PE) at the plc side.
The braided screen, the shield film and the drain wire of the cable must not touch the housing.
Failure to observe these instructions can result in malfunctions, material damage or personal injury.
Disposal
Dispose of encoder components in accordance with locally applicable legislation.

BUDE_Manual_DeviceNet_EN.doc 6/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
3 Operating mode of the encoder
3.1 Poll Mode
In the Poll mode, the encoder transmits at the request of a different user. The transmitted data can be either
position data or additionally to the position data, also contain a warning flag and an alarm flag.
3.2 Change of state Mode (COS)
The encoder transmits position data without a request from a different user, when the current process actual
value has changed by a certain amount (adjustable COS delta).
3.3 Cyclic Mode
The encoder transmits position data without a request from a different user after expiry of a programmed time
interval (adjustable between 1 and 65535 ms)
4 Encoder operating parameters
Description of operating parameters
Parameter Description Value range Default value Product
decimal hex Bit (decimal)
Sense of
rotation Behaviour of the output code depending on the sense of
rotation of the shaft seen
looking at the flange
CW = Increasing values with
clockwise rotation
CCW = Increasing values with
counterclockwise rotation
CW = 0
CCW = 1 CW = 0h CCW = 1h CW = 0 All
Resolution Number of steps per
revolution, input in integral
steps
1..8192 1..2000h 1..13 8192 All
Measurement
range
(overall
resolution) *
Total resolution = number of
steps per revolution x number
of revolutions.
1..536870912 1..20000000h 1..29 536870912 All
Preset value A certain output value is
assigned to the current
position value
0.. set overall resolution -1 0 All
* In the case of singleturn encoders, the measurement range = the resolution

BUDE_Manual_DeviceNet_EN.doc 7/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
5 Object model
The object model describes the object classes used by the encoder.
The encoder feature a predefined master slave connection set. It is a group 2 only server.
The table below indicates the object classes and the number of entities available in each class.
Object class No. of instances
01h: Identity 1
02h: Message Router 1
03h: DeviceNet 1
05h: Connection 1 explicit, 2 I/O
04h: Assembly 2
0Fh: Parameter 19
2Bh: Acknowledge Handler 1
2Fh: Encoder Position 1
The diagram indicates the relationship between the individual object classes

BUDE_Manual_DeviceNet_EN.doc 8/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
6 I/O assembly instances
The encoder supports 2 I/O assembly instances. The instance is determined by instance attribute 14
(produced_connection_path) of the connection object. The programmed value is automatically saved in the
non-volatile memory ("Save" service not necessary here).
The default value is instance 1.
The encoder supplies the following data. From the viewpoint of the master, this is input data.
Instance Type Name
1 Input Position value
2 Input Position value & Warning flag & Alarm flag
Format of I/O assembly data attributes
The I/O assembly data attributes have the following format:
Instance Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
1 0 Position value LSB
1 Position value
2 Position value
3 Position value MSB
2 0 Position value LSB
1 Position value
2 Position value
3 Position value MSB
4 Reserved Warning
flag Alarm flag
Examples:
Path for instance 1 (in hex): "20 04 24 01"
Path for instance 2 (in hex): "20 04 24 02"

BUDE_Manual_DeviceNet_EN.doc 9/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
7 Configuration of the encoder
The encoder-specific parameters can be programmed using the parameter object 0Fh. Each instance of the
relevant object refers to a certain attribute of the encoder position object. Changed parameters are initially
saved in the non-volatile memory by the "Save" service.
Instances of the parameter object
The table below shows the instances of parameter object OFh which are supported by the encoder.
Instance no. Name Reference to attribute no. of the
encoder position object 2Fhex
1 Sense of rotation 3
2 Internal diagnostic function (not used) 4
3 Scaling function 5
4 Position format 6
5 Steps per turn 7
6 Total resolution in steps 8
7 Measurement steps (not used) 9
8 Preset value 10
9 Position value 12
10 Operating status 80
11 Singleturn resolution 81
12 Number of revolutions 82
13 Alarm flag 85
14 Alarm signals 83
15 Supported alarm signals 84
16 Warning flag 88
17 Warning messages 86
18 Supported warning messages 87
19 Profile / software version 89
General services
The parameter object supports the following services:
Code Service Description
0Eh Get_Attribute_Single Supplies the content of a selected attribute
10h Set_Attribute_Single
Changes the value of a selected attribute. The new
value is not yet (!) stored in the non-volatile
memory.
05h Reset Resets all parameters to the default values.
15h Restore
Reloads all parameters from the non-volatile
memory.
16h Save
Saves all parameters in the non-volatile memory so
that they are applicable again after power off/on.

BUDE_Manual_DeviceNet_EN.doc 10/15 Baumer Hübner GmbH
22.10.2010/bja Berlin, Germany
8 Encoder position object
The encoder position object is a manufacturer-specific object. The class code is 2Fh.
Instance attributes
Due to their differing functionality, the instance attributes are subdivided into two groups.
The first group, attribute I to 12, contains the parameters for position calculation.
The second group, attribute 80 to 95, contains the diagnostic functions.
Changed parameters are only saved in the non-volatile memory by the "save" service.
Table: Parameters for position calculation
Attribute ID Access Name Data type Description Values
1 read No. of attributes USINT Number of supported attributes
2 read Attributes Array of
USINT List of supported attributes
3 read/
write Sense of rotation BOOL Setting the sense of rotation 0 = CW
1 = CCW
4 read Internal diagnostic
function BOOL Not used 0 = OFF
5 read Scaling function BOOL Activation of the scaling
function 1 = ON
6 read Position format USINT Format of the position value 0 = Steps
7 read/
write Steps per turn UDINT Number of required steps per turn See op. parameters
8 read/
write Total resolution UDINT Number of required steps over the measurement range See operating
parameters
9 read Reserved UDINT Reserved = 0
10 read/
write Preset value UDINT The position value is set to the preset value See op. parameters
11 read/
write COS delta DINT Minimal position change value in the COS mode 1 to overall resolution
12 read Position value DINT Current position value 1 to overall
resolution
Steps per turn
The parameter "Steps per turn" defines the number of steps per revolution. If this parameter is set, the overall
resolution is changed according to the following formula:
Total resolution = Steps per turn x turns
Sense of rotation
The sense of rotation defines whether the position values of the encoder increase when rotation takes place
clockwise (CW) or counter clockwise (CCW) when looking at the shaft.
Total resolution in steps
The parameter "Total resolution in steps" defines the total number of steps over the entire measurement
range.
Example: Steps per turn = 3600; Turns = 256; Total resolution = 3600 x 256 = 921600
If the number of turns is programmed as a value not equal to 2n(1, 2, 4,...65536), parameterizing will have to
be done anew as soon as the encoder's zero point has been exceeded in powerless state.
