Bebob GN4/8 User manual

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
GN4/8 Wall mount simultaneous Li-ion battery
charger
for B-Mount, V-Mount/Vmicro and A-Mount/Amicro
User Manual
WE STRONGLY RECOMMEND THAT YOU READ THIS
INSTRUCTION BEFORE USING YOUR BEBOB VGN4
CHARGER! PLEASE KEEP THIS MANUAL FOR FUTURE
REFERENCE
1
Features
4 / 8 Channel Wall-Mount Simultaneous 16,8V Li-Ion Charger
200W Power –with Fast Charge Option via 2 Channels (2x5A max.)
Cascade Option with other bebob Wall-Mount Chargers via AC Loop-Through Connection
Carrying Handle for Flexible Use also On Set
Safety instructions
Only for professional use! Keep Charger out of reach of children and personnel that has
not been instructed in the use!
Use only with recommended batteries.
Keep the charger dry and do not immerse in water. Do not cover the charger under use.
A standard three-pin AC plug must be used and earth pole must be connected to the
earth line.
Do not keep in contact with any part of the body while the charger is in working status.
Do not use or store the charger in unstable, dusty or damp environments.
Remove the battery from the charger after the charging process is complete.
Do not attempt to open or repair the charger. Contact your dealer for help if it becomes
defective. Handle with care! Do not throw! Do not drop!
1
The charger is available as B-Mount-, Vmicro-, Vmount-, Amicro-, Amount -version.

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
Charging
Never leave batteries unattended while charging
All Channel Status indicator show green when the charger is turned on with no battery
connected
The Channel Status indicator turns red when a battery is placed on the corresponding
channel and the charging process has begun
The Channel Status indicator turns back green when the battery is fully charged
The Channel Status indicator turns Yellow when a battery is placed on the corresponding
channel and the charging process fails for damage or safety reason.
Cooling fan will be activated during the charging process
Fast simultaneous/sequential charging with 5A in case for B-Mount, Vmicro, Vmount,
Amicro and Amount batteries by using only channel 1 and 3.
Warranty
The GN4/8 is covered by a 2 years unconditional warranty on all parts.
For warranty issues or if you have any additional questions, please contact the
appropriate bebob distributor listed at www.bebob.de.
Accessories
1 x AC cable
1 x AC cascade cable
2 x Fixing plate
1 x hexawrench

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
Set up:
Modes: 4x2,5A normal charge mode via all channels or 2x5A max. fast charge option via channels 1 and 3:
Top View
Operating elements
Ch1
1
)
1) In case of micro Wall Mount
charger: In addition slot Aand B.
Ch2
1
)
Ch3
1
)
Ch4
1
)
Channel 1/2 - max. 5A
Channel 3/4 - max. 5A

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
Mounting
The drilling pattern of the wall mount charger is in the annex of this operation manual
Cascading:

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
Specifications
Specifications
Model B-Mount
V-Mount
A-Mount
Vmicro
Amicro
BGN4
VGN4
AGN4
VGN8micro
AGN8micro
Channel
4 Channels / 8 Channels (micro model
simultaneous charger)
Charger (nominal specs)
16,8V // max. 10A
2x5A max. fast charge option ch1 / 3
4x2,5A normal charge all channels
Cascade Option
Yes, capability depends on AC circuit fuse
AC Input ratings
90-264V/47-63Hz 200W
Weight BGN4
VGN4
VGN8micro
AGN4
AGN8micro
3,87kg
3,84 kg
4,30kg
3,87kg
3,87kg
Dimensions (WxHxD)
270 x 67,5 x 410mm (min)
270 x 89,7 x 410mm (max)
Batteries
bebob, idx, sony
Charging time
depends on the battery capacity
Operating Temp. Range
- 10°C ~ + 35°C

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
June 2023
Annex
