Bebob VS4 User manual

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
August 2017
VS4 Portable simultaneous li-ion battery
charger
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB VS4 CHARGER! PLEASE
KEEP THIS MANUAL FOR FUTURE
REFERENCE
Features
 4 Channel V-Mount simultaneous Li-Ion Charger.
 Built-in AC Adapter. 15,0V – 5.0A DC XLR4 Output
 Powerbase Mode.
Charging
 All Channel Status indicator show green when the charger is turned on with no battery
connected
 The Channel Status indicator turns red when a battery is placed on the corresponding channel
and the charging process has begun
 The Channel Status indicator turns back green when the battery is fully charged
 The Channel Status indicator turns Yellow when a battery is placed on the corresponding
channel and the charging process fails for damage or safety reason.
 Cooling fan will be activated during the charging process
AC Adapter
 You can use your VS4 simultaneously as a 2 Channel Charger and an AC Adapter. Use
the rear Channels for charging
 The charging functions of the 2 front channels always has priority over the AC function
 The AC adapter delivers up to 5,0A under15,0V

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
August 2017
Powerbase
 Plug off the AC Cord from the charger
 Place one or two full batteries on the front channels of the charger
 Battery Power will be available over the XLR 4 DC Output.
 Maximum Load depends on the batteries
Safety instructions
 Only for professional use! Keep Charger out of reach of children and personnel that has
not been instructed in the use!
 Use only with recommended batteries.
 Keep the charger dry and do not immerse in water.
 Do not cover the charger under use
 A standard three-pin AC plug must be used and earth pole must be connected to the earth line.
 Do not keep in contact with any part of the body while the charger is in working status.
 Do not use or store the charger in unstable, dusty or damp environments.
 Remove the battery from the charger after the charging process is complete.
 Do not attempt to open or repair the charger. Contact your dealer for help if it becomes
defective.
 Handle with care! Do not throw! Do not drop!
Warranty
 The VS4 is covered by a 2 years unconditional warranty on all parts.
 For warranty issues or if you have any additional questions, please contact the appropriate
bebob distributor listed at www.bebob.de.
Specifications
Model VS4
Mount V-Mount
Channel 4 simultaneous
Charging current 16,8V 2.5A
DC Output 15.0V 5.0A
DC Port XLR4 1 minus 4 plus
AC In 90-264V/47-63Hz
Weight 1,9 Kg
Dimensions (WXHXD) 145 x 225x 270mm
Batteries bebob, idx, sony
Charging time depends on the battery capacity
Operating Temp. Range - 10°C ~ + 35°C
