Bebob VS2-RL User manual

bebob factoryGmbH – Höglwörtherstr. 350 – D-81379München – Tel.: [phone]
www.bebob.de
April2016
VS2-RLPortablesimultaneousli-ion battery
charger
User Manual
WE STRONGLYRECOMMEND THATYOU
READTHIS INSTRUCTIONBEFORE USING
YOUR BEBOBVS2-RLCHARGER!PLEASE
KEEP THIS MANUALFORFUTURE
REFERENCE
Features
·2 ChannelV-Mount simultaneousLi-Ion Charger.
·Built-in AC Adapter. 15,0V– 5.0ADCXLR4 Output
·PowerbaseMode.
Charging
·All ChannelStatusindicatorshow green when the chargeris turned on with no battery
connected
·The ChannelStatusindicatorturnsred when a batteryis placed on the corresponding channel
and the charging process hasbegun
·The ChannelStatusindicatorturnsback green when the batteryis fullycharged
·The ChannelStatusindicatorturnsYellow when a batteryis placed on the corresponding
channeland the charging process fails fordamage orsafetyreason.
·Cooling fan willbe activated during the charging process
ACAdapter
·You can useyourVS2-RLeitherasanACAdapterorasa charger.Both functionsaren´t
possible simultaneously
·The chargingfunctionsalwayshaspriority
·The AC adapterdelivers up to 5,0Aunder15,0V

bebob factoryGmbH – Höglwörtherstr. 350 – D-81379München – Tel.: [phone]
www.bebob.de
April2016
Powerbase
·Plug oftheACCord fromthe charger
·Placeone ortwo fullbatterieson the charger
·BatteryPowerwill be availableovertheXLR 4 DC Output.
·MaximumLoad dependson thebatteries
Safetyinstructions
·Onlyforprofessionaluse!Keep Chargerout ofreachofchildren and personnelthat has
not beeninstructed in the use!
·Use onlywith recommended batteries.
·Keep the chargerdryand do notimmerse in water.
·Do not coverthechargerunderuse
·Astandard three-pin AC plug must be used and earth pole must be connected to the earth line.
·Do not keep in contact with anypart ofthe bodywhile the chargeris in working status.
·Do not use orstore the chargerin unstable, dustyordamp environments.
·Remove the batteryfromthechargerafterthe charging process is complete.
·Do not attempt to open orrepairthe charger. Contact yourdealerforhelp ifit becomes
defective.
·Handlewithcare!Do not throw!Do not drop!
Warranty
·The VS2RL iscovered bya2 years unconditionalwarrantyonallparts.
·Forwarrantyissuesorif you haveanyadditionalquestions,please contact the appropriate
bebob distributorlisted at www.bebob.de.
Specifications
Model VS2-RL
Mount V-Mount
Channel 2 simultaneous
Charging current 16,8V2.5A
DC Output 15.0V5.0A
DC Port XLR4 1 minus4 plus
AC In 90-264V/47-63Hz
Weight 1,0 Kg
Dimensions(WXHXD) 110 x231x141mm
Batteries bebob, idx, sony
Charging time (bebobVS2/VS4) dependson the batterycapacity
Operating Temp. Range -10°C~+35°C
