Bebob B90CineHS User manual

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
July 2021
Features
A high capacity, Dual-Native-Voltage high load battery, which is compact and lightweight
Direct fitting to a camera or device via B-Mount
Enabling flight carry-on luggage transportation with a capacity of 86Wh
Dual-Native-Voltage 14,4V/4s and 28,8V/8s
400W continuous power drain
20A continuous discharge current
14,4V/4s and 28,8V/8s Hotswap
Five-step LED power indicator (100% - 80% - 60% - 40% - 20%)
Full capacity status LED (green over 80%; yellow between 60% and 80%; red under 60%)
Enhanced data communication (B-Mount protocol)
B90CineHS
Dual-Native-Voltage 14,4V/28,8V - 86Wh
rechargeable Li-Ion stackable Battery - 20A/400W
USER MANUAL
WE STRONGLY RECOMMEND THAT YOU READ THIS
INSTRUCTION BEFORE USING YOUR BEBOB
B90HSCINE BATTERY! PLEASE KEEP THIS MANUAL
FOR FUTURE REFERENCE

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
July 2021
Safety instructions
Only for professional use!
Keep batteries out of reach of children and personnel that has not been instructed in the
use of high capacity Lithium-ion batteries!
Use only with recommended charger.
Keep the battery dry and do not immerse in water.
Never open the case of the battery.
Do not expose to temperature over 60°C.
Do not expose the battery to fire! May explode if thrown into fire!
The maximum discharge current shall not be exceeded (see Specifications).
The maximum charge voltage shall not be exceeded (see Specifications).
Do not put the battery on a device when the red charging LED flashes.
Handle with care! Do not throw! Do not drop!
Charging
Never charge unattended
Remove flammable material from the charging area and avoid high external thermal Ioads.
Wait 30 Minutes after discharge before you put the battery on a charger.
The bebob battery can be charged with an external bebob charger (or equivalent using the
CC-CV method 16,8 V / 33,6V DC).
The maximum voltage shall not be exceeded (see Specifications).
Approximate charge time may vary depending on charger and temperature.
Charge the battery only within the specified temperature range. bebob batteries can be
charged in ambient temperature for optimum performance at 10°C - 30°C.
bebob batteries can be recharged in any state of charge condition
Fuel Gauge Flashing LED indicates State of Charge during Charging Process.
Discharging
The maximum discharge current shall not be exceeded (see Specifications).
When using the battery with video or lighting equipment, power consumption of the
equipment must be below specifications. For the protection of the battery, a load over or
equal to the max discharge current may activate the internal protection circuit and stop
supply of power. In this case the fuse will self-rest after a couple of minute.
Remove flammable material from the discharging area. Avoid high external thermal Ioads.
The end of discharge voltage shall not fall below the allowed Input Voltage (see
Specifications).
Charge the battery only within the specified temperature range. The battery can be used in
ambient temperature of - 20°C - + 55°C.
Do not use more than two batteries when a B90CineHS!
Never connect several B-Mount batteries in series!

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
July 2021
Storage
The battery shall be stored within the specified ranges for temperature, relative humidity
and state of charge (see Specifications)
Storage temperature range is - 20°C ~ + 35°C (<85% humidity).
To store the battery for a long period (longer than 4 Weeks), the battery should be charged
between 50% and 75%. The battery should be recharged every 4 Weeks.
After storage some self-discharge will occur. Before re-use it is advisable to recharge the
battery full.
Stack able Hotswap
It is not recommended to stack more than two batteries in total together - a 3rd
battery might not be identified by the system (in other words: Use only one
B90CineHS).
If a B-Mount battery with more than 5% capacity (apprx. 24,1V/@100W) is stacked to the
back of a B90CineHS, the B90CineHS will behave as a Hotswap adapter, passing through
the power of the back battery, without discharging itself.
Note: The B90CineHS is not recharged by the battery in the back!
B90CineHS normal battery operation:
oThe status LED is green when the B90CineHS is used as a single battery.
oLED flushes red when the B90CineHS is below 10% state of charge.
B90CineHS during active hotswap operation:
oIf the back battery turns under 5% of capacity for 5sec (apprx. 24.1V@100W) the
B90CineHS will switch on without any interruption and will power the device.
oIf the back battery gets removed, the B90CineHS provides the power without any
interruption and will power the consumer device.
The status LED of the B90CineHS
oflushes orange when the B90CineHS is above 10% state of charge.
oflushes red when the B90CineHS is below 10% state of charge.
Disposal
The B90CineHS battery has to be disposed within a dedicated collection container for used
device batteries. Please be aware that only empty batteries are allowed for disposal in
collection containers. In case the battery is not completely discharged, precautions against
a potential short-circuit have to be taken.
Warranty
The B90CineHS is covered by a 2 years unconditional warranty on all parts, except the
cells.
The cells are covered by a 2-year warranty, 80% of the original capacity.
For warranty issues or if you have any additional questions, please contact the appropriate
bebob distributor listed at www.bebob.de.

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
July 2021
Specifications
Model
B90CineHS
Mount
B-Mount
Energy/Capacity
86Wh
Voltage (native nominal voltage)
14,4V/4s and 28,8V/8s DC (native)
Max. Continuous Discharge Current
20,0A
Continuous Power Drain
400W
Max. Charge/Output Voltage
16,8 V / 33,6V DC
End Voltage (discharge cut-off)
10,0 V / 20,0V DC
Cells
Lithium-Ion
Twist D-Tap
13,2V; 2,5A
USB-C Port
5,0V; 1,0A
Fuel Gauge
5-Step LED
Status
Green: Full Capacity over 80%
Yellow: Full Capacity between 60 and 80%
Red: Full Capacity under 60%
Weight
0,66 kg
Dimensions (WxHxD)
94x144x47mm
Chargers
Bebob B-Mount or Equivalent
Charging time (bebob BS2/BS4)
1 hour / 80% @5A/16,8V
apprx. 1,9 hours / 100% @5A/16,8V
Operating Temp. Range
Charge: + 10°C ~ + 30°C recommended
Discharge:- 20°C ~ + 55°C
Storage:- 20°C ~ + 35°C (<85% RH )
Certification Conformity
Product Safety: IEC 62133-2
Transport Safety: UN38.3

bebob factory GmbH –Höglwörtherstr. 350 –D-81379 München –Tel.: [phone]
www.bebob.de
July 2021
Transport as of October 1st 2020
This Summary reflects our current Knowledge.
1. Transport by Commercial Airline / Carry-on Luggage
You can transport in your carry-on luggage a battery <100 Wh attached to the
camera or equipment it powers.
You can transport in your carry-on luggage an unspecified number of spare batteries
<100 Wh:
Put tape over the contacts.
Put each single battery in a plastic bag before packing it in your carry-on
luggage.
Batteries <100 Wh do not need to be discharged to 30% SoC for transport as
personal luggage, this is only a requirement of cargo shipments.
Carry a copy of the bebob UN Transport Documentation (www.bebob.de)
We recommend that you confirm with your carrier of choice, to determine any further
restriction or local policies, before travelling.
2. Transport by Commercial Airline / Checked-in Luggage
Batteries <100 Wh are forbidden in your checked-in luggage
3. Transport as air-, road- and sea-freight
Li-Ion batteries, and so bebob batteries <100 Wh, when shipped by air, road or sea are
classified as dangerous goods class 9 and subject to special UN certified packaging.
Air transport authority training and authorisation are required for packing batteries <100
Wh, for an air cargo shipment.
Li-Ion batteries for air cargo must have a state-of-charge of no more than 30% for
shipping, means only one out of the five-fuel gauge led lights up.
We recommend that you confirm with your carrier of choice, to determine any further
restriction or local policies, before travelling.
