Introduction
1
BEC 6500 Series User Manual
CHAPTER 1: INTRODUCTION
Introduction to your Router
Congratulations on your purchase of the BEC 6500 series router (4G/LTE Enterprise Multi-Service
Router). The BEC 6500 series is a 4G/LTE Multi-Service with 11ac High Power Router – featuring a
Dual-WAN interface (4G/LTE and GigaConnect® Ethernet WAN), 4-port Gigabit Ethernet Switch,
USB 2.0, 802.11ac dual-band Wi-Fi access point, Hotspot, Voice ports, dynamic routing and a robust
Firewall security. The BEC 6500 series offers mobile 4G/LTE service with multiple speed rate from
100Mbps up to 600Mbps in downlink and 50Mbps to 150Mbps in uplink and also support a variety of
fixed broadband connections types, including ADSL2+ / VDSL2 / FTTH / Cable modems, with data
rates reaching up to 1Gbps.
A well-designed GUI offers administrators / home owners a simple and easy way to secure and mange
networks through many advanced features. Equipped with11ac and dual bands technologies with
high transmit RF power on both frequency bands, the BEC 6500 series is capable to provide
simultaneous dual band connections with dedicated Wi-Fi streams for specific network applications
and extend Wi-Fi signal providing outstanding range and coverage throughout the home or office.
4G/LTE and Fixed Broadband Service Ready
The BEC 6500 series provides 4G/LTE mobile and gigabit wired Ethernet WAN interfaces and is
featuring an auto-failover to ensure maximum Internet accessibility with minimum service interruption.
This seamless automatic failover with traffic prioritization in the event of an Internet connectivity failure
of the primary WAN interface, traffic is automatically redirected to the secondary WAN interface within
seconds. This functionality operates regardless of whether the primary connection is LTE or a wired
connection.
New Experience with Wi-Fi Speed and Coverage
BEC 6500 support a link rate up to 300Mbps in 2.4GHz frequency range & 866Mbps in 5GHz range
and is also backward compatible with existing 802.11 a / b / g / n wireless equipment in the network.
The Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol (WEP)
features enhance the level of transmission security and access control over Wireless LAN. The BEC
6500 also supports the Wi-Fi Protected Setup (WPS) standard for easy and secure establishment of a
wireless home network. If the user’s network requires wider coverage, the built-in Wireless Distribution
System (WDS) repeater function expands the wireless network without needing any external wires or
cables.
Wi-Fi Hotspot with Captive Portal
BEC 6500 offer Wi-Fi hotspot to share the Internet connection via mobile (4G/LTE) or a wired
connection, an existing FTTH, cable, DSL network or modem, with any wireless-enabled devices
which is completed separate from the private Wi-Fi network. The captive portal enables highly secure
connectivity with multiple authentication options and extensive controls for access and bandwidth
management. Customization options allow for operator logos, branding or advertisement placement.

Introduction
2
BEC 6500 Series User Manual
Cost Saving
Making VoIP calls is extremely simple; just connect the router with your existing analog telephones.
BEC 6500 series complies with the most popularly adopted VoIP standard and SIP protocol to ensure
interoperability with SIP devices and major VoIP Gateways. This router also supports a wider range of
telephony features, such as Call Waiting, Conference, Speed Dial, Return Call, Redial, etc.
4G/LTE Management Center
The Mobile Management Center visually displays its current 4G/LTE signal status also calculates the
total amount of hours or data traffic used per month, allowing you to manage your 4G/LTE monthly
subscriptions.
IPv6 Supported
Internet Protocol version 6 (IPv6) is a version of the Internet Protocol that is designed to succeed IPv4.
IPv6 has a vastly larger address space than IPv4. The router is already supporting IPv6, you can use it
in IPv6 environment no need to change device. The dual-stack protocol implementation in an
operating system is a fundamental IPv4-to-IPv6 transition technology. It implements IPv4 and IPv6
protocol stacks either independently or in a hybrid form. The hybrid form is commonly implemented in
modern operating systems supporting IPv6.
Quick Start Wizard
Support a WEB GUI page to install this device quickly. With this wizard, simple steps will get you
connected to the Internet immediately.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.

Introduction
Features & Specifications
3
BEC 6500 Series User Manual
Features & Specifications
• 4G/LTE for high speed mobile broadband connectivity
• Gigabit Ethernet WAN (GbE WAN) for Cable/Fiber/xDSL high WAN throughput
• Gigabit Ethernet LAN
• IPv6 ready (IPv4/IPv6 dual stack)
• Multiple wireless SSIDs with wireless guest access and client isolation
• IEEE 802.11 a/ac/b/g/n compliant Wireless Access Point with Wi-Fi Protected Setup (WPS)
• Wi-Fi Protected Access (WPA-PSK/ WPA2-PSK) and Wired Equivalent Privacy (WEP)
• SOHO Firewall Security with DoS Preventing and Packet Filtering
• Quality of Service Control for traffic prioritization management
• Universal Plug and Play (UPnP) Compliance
• Voice over IP compliant with SIP standard (BEC 6500VAL)
• Two FXS ports for connecting to regular analog telephones (BEC 6500VAL)
• Call Waiting, Conference Call (BEC 6500VAL)
• Speed Dial, Return Call, Redial (BEC 6500VAL)
• Don’t Disturb (BEC 6500VAL)
• Ease of Use with Quick Installation Wizard
• One USB port for NAS (FTP/ SAMBA server)
• Ideal for SOHO, office, and home users
Network Protocols and Features
• IPv4, IPv6 or IPv4 / IPv6 Dual Stack
• NAT, static (v4/v6) routing and RIP-1 / 2
• DHCPv4 / v6
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS proxy
• IGMP snooping and IGMP proxy
• MLD snooping and MLD proxy

Introduction
Features & Specifications
4
BEC 6500 Series User Manual
Firewall
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• DoS attack prevention including Land Attack, Ping of Death, etc.
• Access control
• IP&MAC filter, URL Content Filter
• Password protection for system management
• VPN pass-through
Quality of Service Control
•Traffic prioritization management based-on Protocol, Port Number and IP Address (IPv4/ IPv6)
Wireless LAN
• Compliant with IEEE 802.11 a/b/g/n/ac standards
• 2.4GHz & 5GHz frequency range
•20/40-MHz channel bandwidth
•Up to 300Mbps (2.4GHz) & 866Mbps (5GHz) wireless data phy rate
•64/128 bits WEP supported for encryption
•Wireless security with WPA-PSK, WPA2-PSK, Mixed WPA/WAP2-PSK, (TKIP/AES),
802.1x/Radius
•AP, Client Bridge and WDS Operational Modes
•Multiple SSID (4 SSIDs), BSSID
•Wireless MAC filtering
•Wireless Client Isolation
•Wi-Fi Hotspot with Captive Portal
•Dynamic, Wi-Fi client rate-limiting
USB Application Server
• Storage/NAS: SAMBA Server, FTP Server
• 4G/LTE Mobile Internet Connection
VoIP (6500VAL & 6500X Only)
• Compliant with SIP standard (RFC3261)
• Codec: G.729, G.726, G.711 A-Law, G.711 u-Law
• DTMF Method: Inband, RFC 2833, SIP Info

Introduction
Features & Specifications
5
BEC 6500 Series User Manual
• Caller ID Generation: DTMF, FSK
• Silence Suppression (VAD), Echo Cancellation
• Call Waiting, Conference Call
• Speed Dial, Return Call, Redial
• Don't Disturb
• FAX Relay: T.38
• Call Detailed Records (CDR)
Management
• Quick Installation wizard
• Web-based GUI for remote and local management (IPv4/IPv6)
• Firmware upgrades and configuration data upload and download via web-based GUI
• Supports DHCP server / client / relay
• Supports SNMP v1, v2, v3, MIB-I and MIB-II
• TR-069 supports remote management
• BECentral® Remote Management

Introduction
Hardware Specifications
6
BEC 6500 Series User Manual
Hardware Specifications
Physical interface
• 4G LTE antenna: 2 external female SMA connectors (up to 4 connectors – 6500 R18/R20)
• 5G Wi-Fi antenna: 2 external female RP-SMA connectors
• SIM card slot: Mini SIM card (2FF) slot for mobile broadband connectivity
• VoIP phone port: 2 RJ-11 FXS phone ports to connect with 2 regular analog phones. (6500VAL &
6500VL only)
• Wireless on/off and WPS push button
• Factory default reset button
• Ethernet: 4-port 10 / 100 / 1000Mbps auto-crossover (MDI / MDI-X) Switch
- 1 x Versatile Port : LAN 4 / WAN
• USB: USB 2.0 port for storage service
• Power DC Jack
• Power Button On/Off
• LED Indicators
Physical Specifications
• Dimensions (W*H*D): 9.04" x 6.10" x 1.69"(229.5mm x 155mm x 43mm)
Power Requirement
• Input: 15V DC, 1.6A

Introduction
Application Diagrams
7
BEC 6500 Series User Manual
Application Diagrams
BEC 6500 series (4G/LTE Multi-Service 11ac Broadband Router) is an all-in-one router,
supporting multiple WAN connection options (4/LTE, Fixed Broadband and Auto WAN Failover) to
connect to the Internet.
4G/LTE Router Mode
With an embedded 4G/LTE module, the router can be used to connect to high speed mobile fixed
wireless connection.
FTTH / Broadband Router Mode
This router also has a Gigabits Ethernet WAN port (EWAN) to connect with your Fiber / Cable/ xDSL
modem.

Introduction
Application Diagrams
8
BEC 6500 Series User Manual
Automatic WAN Failover
The automatic failover ensures uninterrupted operation and 24/7 Internet availability. When Primary
WAN connection fails, the Secondary connection will back up the Internet connection seamlessly.

Product Overview
9
BEC 6500 Series User Manual
CHAPTER 2: PRODUCT OVERVIEW
Important Note for Using This Router
What’s in the Box
✓ BEC 6500 series 4G/LTE 11ac Broadband Router x 1
✓ This Quick Start Guide x 1
✓ Wi-Fi Antenna x 2
✓ RJ-45 Ethernet Cable x 1
✓ DC Power Adapter x 1
✓ 4G/LTE Antenna x 2 ( BEC 6500 R18/R21: 4 LTE antennas)
✓Place the router on a stable surface.
✓Only use the power adapter that comes with the package. Using
a different voltage rating power adaptor may damage the router.
Attention
✓Do not use the router in high humidity or high temperature.
✓Do not use the same power source for the BEC 6500 on other
equipment.
✓Do not open or repair the case yourself. If the device becomes
too hot, turn off the power immediately and have it repaired at
a qualified service center.
✓Avoid using this product and all accessories outdoors.
Warning

Product Overview
Device Description / Front Panel LEDs (6500AEL & 6500AT)
10
BEC 6500 Series User Manual
Device Description
Front Panel LEDs (BEC 6500AEL & BEC 6500AT)
PORT
MEANING
1
LTE Antenna
Connectors
Screw the supplied mobile LTE antennas onto the antenna connectors on both sides.
(6500 R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas)
LED
STATUS
DESCRIPTION
Power
Green
System is up and ready
Red
Boot failure
Ethernet
Port
LAN 1 - 4
Green
Transmission speed is at Gigabit speed (1000Mbps)
Orange
Transmission speed is at 10/100Mbps
Blinking
Data being transmitted/received
USB
Green
Connecting to a USB dongle or a hard drive.
Wi-Fi 2.4G /
5G
Green
Wireless connection to 2.4G or 5G network is established
Blinking
Data being transmitted / received
WPS
Green
Wireless device(s) being connected successfully via WPS mode
Blinking
WPS is enabled and trying to establish a WPS connection
LTE
(Received
Signal
Strength
Indicator)
Green
RSSI greater than -69 dBm. Excellent signal condition
Green
Flashing
Quickly
RSSI from -81 to -69 dBm. Good signal condition
Orange
Flashing
Quickly
RSSI from -99 to -81 dBm. Fair signal condition.
Orange
Flashing
Slowly
RSSI less than -99 dBm. Poor signal condition.
Orange
No signal and the 4G_LTE module is in service
Off
No LTE module or LTE module fails
Internet
Green
WAN IP is received, and traffic is passing thru the device.
Red
Cannot get a WAN/public IP address
Off
The device is either in bridged mode or WAN connection not ready.

Product Overview
Device Description / Front Panel LEDs (6500VAL & 6500X)
11
BEC 6500 Series User Manual
Front Panel LEDs (BEC 6500VAL & BEC 6500X)
PORT
MEANING
1
LTE Antenna
Connectors
Screw the supplied mobile LTE antennas onto the antenna connectors on both sides.
(6500 R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas)
LED
STATUS
DESCRIPTION
Power
Green
System is up and ready
Red
Boot failure
Ethernet
Port
LAN 1 - 4
Green
Transmission speed is at Gigabit speed (1000Mbps)
Orange
Transmission speed is at 10/100Mbps
Blinking
Data being transmitted/received
USB
Green
Connecting to a USB dongle or a hard drive.
Wi-Fi 2.4G /
5G
Green
Wireless connection to 2.4G or 5G network is established
Blinking
Data being transmitted / received
WPS
Green
Wireless device(s) being connected successfully via WPS mode
Blinking
WPS is enabled and trying to establish a WPS connection
Phone
Green
Successfully registered and ready to be used.
Orange
Phone is off-hook, in-use.
LTE
(Received
Signal
Strength
Indicator)
Green
RSSI greater than -69 dBm. Excellent signal condition
Green
Flashing
Quickly
RSSI from -81 to -69 dBm. Good signal condition
Orange
Flashing
Quickly
RSSI from -99 to -81 dBm. Fair signal condition.
Orange
Flashing
Slowly
RSSI less than -99 dBm. Poor signal condition.
Orange
No signal and the 4G_LTE module is in service
Off
No LTE module or LTE module fails
Internet
Green
WAN IP is received, and traffic is passing thru the device.
Red
Cannot get a WAN/public IP address
Off
The device is either in bridged mode or WAN connection not ready.

Product Overview
Device Description / Rear Panel Connectors (6500AEL & 6500AT)
12
BEC 6500 Series User Manual
Rear Panel Connectors (BEC 6500AEL & BEC 6500AT)
PORT
MEANING
1
Wi-Fi
Antenna
Connectors
Screw the supplied Wi-Fi antennas onto the antenna connectors on both sides.
1
LTE Antenna
Connectors
(6500 R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas)
Screw the supplied mobile LTE antennas onto the antenna connectors on both sides.
2
SIM Card Slot
Insert the mini SIM card (2FF) with the gold contact facing down.
Push the mini SIM card (2FF) inwards to eject it
3
WPS &
Wireless
On/Off
By controlling the pressing time, users can achieve two different effects:
(1) WPS*: Press &hold the button for less than 6 seconds to trigger WPS function.
(2) Wireless ON/OFF button: Press & hold the button for more than 6 seconds to enable
or disable the wireless.
* Refer to the WPS section in the User Manual for more details.
4
Reset
After the device is powered on, press it 6 seconds or above: to restore to factory default
settings (this is used when you cannot login to the router, e.g. forgot your password)
5
Gigabit
LAN Ethernet
(1 - 4)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four LAN ports when
connecting to a PC or an office/home network of 10Mbps /100Mbps /1000Mbps
* EWAN/4
Connect to Fiber/ Cable/ xDSL Modem with a RJ-45 cable, for broadband connectivity.
Note: LAN 4 automatically becomes an EWAN port when EWAN internet interface is being
selected in the GUI
6
USB
The USB can either setup for 4G/LTE internet access or storage/file sharing.
7
DC Power
Jack
Connect the supplied Power Adapter to this jack.
8
Power
ON/OFF
Power ON/OFF switch
1
2
7
1
8
3
5
6
4
*

Product Overview
Device Description / Rear Panel Connectors (6500VAL & 6500X)
13
BEC 6500 Series User Manual
Rear Panel Connectors (BEC 6500VAL & BEC 6500X)
PORT
MEANING
1
Wi-Fi
Antenna
Connectors
Screw the supplied Wi-Fi antennas onto the antenna connectors on both sides.
1
LTE Antenna
Connectors
(6500 R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas)
Screw the supplied mobile LTE antennas onto the antenna connectors on both sides.
2
SIM Card Slot
Insert the mini SIM card (2FF) with the gold contact facing down.
Push the mini SIM card (2FF) inwards to eject it
3
Phone
(1X-2X)
Connect your analog phone to this port with a RJ-11 cable.
4
WPS &
Wireless
On/Off
By controlling the pressing time, users can achieve two different effects:
(1) WPS*: Press &hold the button for less than 6 seconds to trigger WPS function.
(2) Wireless ON/OFF button: Press & hold the button for more than 6 seconds to enable
or disable the wireless.
* Refer to the WPS section in the User Manual for more details.
5
Reset
After the device is powered on, press it 6 seconds or above: to restore to factory default
settings (this is used when you cannot login to the router, e.g. forgot your password)
6
Gigabit
LAN Ethernet
(1 - 4)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four LAN ports when
connecting to a PC or an office/home network of 10Mbps /100Mbps /1000Mbps
* EWAN/4
Connect to Fiber/ Cable/ xDSL Modem with a RJ-45 cable, for broadband connectivity.
Note: LAN 4 automatically becomes an EWAN port when EWAN internet interface is being
selected in the GUI
7
USB
The USB can either setup for 4G/LTE internet access or storage/file sharing.
8
DC Power
Jack
Connect the supplied Power Adapter to this jack.
9
Power
ON/OFF
Power ON/OFF switch
1
2
8
1
9
5
6
7
4
*
3

Product Overview
Hardware Connection
14
BEC 6500 Series User Manual
Hardware Connection
Back Panel Ports & Connectors
Wi-Fi & LTE Antenna Connectors (Standard Version)
