Becker B-Tronic EasyControl EC5401B User manual

B-Tronic EasyControl
EC5401B
en Assembly and Operating Instructions
Wall/hand-held transmitter, 1-channel,
bidirectional
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
4035 630 003 0f05/12/2018

Table of contents
General ................................................................................................... 3
Warranty ................................................................................................. 3
Safety instructions ................................................................................... 4
Intended use ........................................................................................... 5
Explanation of displays and buttons........................................................... 6
Normal/master mode ............................................................................... 8
Programming the first transmitter.............................................................. 9
Querying/Changing the receiver mode .....................................................10
Programming more transmitters ..............................................................12
Deleting transmitters...............................................................................14
Changing the direction of rotation of B-Tronic products .............................16
Setting the limit positions of B-Tronic tubular drives...................................17
Upper stop to lower stop ...................................................................17
Upper point to lower point .................................................................18
Upper stop to lower point ..................................................................19
Upper point to lower stop ..................................................................19
Deleting the limit positions of B-Tronic tubular drives .................................20
Performing the programming run on B-Tronic radio receivers.....................21
Deleting the programming run on B-Tronic radio receivers.........................22
Intermediate positions/tilt positions ..........................................................23
Memory function.....................................................................................25
Upper anti-freeze mechanism ..................................................................26
Activating/Deactivating upper anti-freeze mechanism .........................27
Fly screen protection function ..................................................................27
Activating/deactivating repeater mode .....................................................28
Reset the transmitter to the factory setting................................................29
Clean-up function for B-Tronic products...................................................30
Changing batteries..................................................................................31
Wall bracket............................................................................................32
Cleaning.................................................................................................32
Technical data ........................................................................................33
What to do if...?.......................................................................................33
Simplified EU declaration of conformity.....................................................34
2

General
You can operate drives and control units with bidirectional KNX radio with this
transmitter.
This device is exceptionally easy to use.
Please observe these Assembly and Operating Instructions when installing
and setting up the equipment.
Explanation of pictograms
CAUTION CAUTION indicates a hazardous situation
which, if not avoided, could result in in-
jury.
ATTENTION ATTENTION indicates measures that must
be taken to avoid damage to property.
Denotes user tips and other useful in-
formation.
You will find the current status on the type plate according to the following
symbol:
The description of the acknowledgement can be found in the relevant instruc-
tions for the receiver.
Warranty
Structural modifications and incorrect installation which are not in accordance
with these and our other instructions can result in serious injuries, e.g., crush-
ing of limbs. Therefore, structural modifications may only be carried out with
our prior approval and strictly in accordance with our instructions, particularly
the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their inten-
ded use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant
current statutory, official and, in particular, EMC regulations are adhered to
during utilisation of our products, especially with regard to end product manu-
facture, installation and customer advice.
3

Safety instructions
General information
•Please keep the instructions safe!
•Only use in dry rooms.
•Only use unmodified original parts from the control unit manufacturer.
•Keep children away from control units.
•Observe all pertinent country-specific regulations.
•Dispose of exhausted batteries properly. Only replace batteries with the
identical type (see Technical data).
Caution
•Keep people out of the system’s range of travel.
•If the system is controlled by one or more transmitters,
the system’s range of travel must always be visible during
operation.
•Device contains small parts that can be swallowed.
4

Intended use
The transmitter described in these instructions may only be used for operating
suitable drives and control units with bidirectional KNX radio. You can operate
either one group or a number of groups of devices with this transmitter.
•Please note that radio-controlled systems may not be used in areas with
a high risk of interference (e.g. hospitals, airports).
•The remote control is intended solely for use with equipment and sys-
tems in which malfunctions in the transmitter or receiver would not pose
any risk to persons, animals or property, or which contain safety devices
to eliminate such risks.
•The operator is not protected from interference from other telecommu-
nications systems and terminal equipment (e.g. even from radio-con-
trolled systems which are properly operated in the same frequency
range).
•Only connect radio receivers to devices and systems approved by the
manufacturer.
•Ensure that the control unit is not installed or operated
close to metal surfaces or magnetic fields.
•Radio-controlled systems transmitting on the same fre-
quency may cause reception interference.
•Note that the range of the radio signal is limited by legis-
lation as well as by design.
5

Explanation of displays and buttons
2
4
5
1
11
10
9
8
7
6
3
1 Wall bracket receptacle
2 Master button
3 Type plate
4 Batteries
5 Battery compartment cover
6 Programming button (behind
the logo)
7 Changeover switch
8 DOWN button
9 STOP button
10 UP button
11 Status LED
6

Functional overview of the control buttons UP ( ), STOP
( ), DOWN ( )
Function
Button actuation
UP
STOP
DOWN
Touch mode UP
Touch mode DOWN
ON
OFF
Intermediate position I*1
Intermediate position II*1
Tilt position I*1
Tilt position II*1
STOP/STEP*2
Roller shutter <1s
>1s
Screen <1s
>1s
Blind <1s
>1s
Roof window <1s
>1s
ON/OFF <1s
>1s
Pulse <1s
>1s
*1) If present.
*2) With a STOP command, the STEP is always made in the UP direction
7

Normal/master mode
The transmitter can be operated in two modes:
•Normal mode (normal operation) The commands that are issued apply
to all the receivers of a channel.
•Master mode (Setting mode for all B‑Tronic products) The commands
issued apply exclusively to one selected receiver of a channel.
The normal mode is set at the factory.
Activating master mode
Press the master button until the changeover button flashes
green once per second. This flashing will continue as long as you remain in
master mode.
By pressing the master button again, the programmed receiver is selected, or
the programmed receivers are selected in sequence.
The selected receiver confirms.
You can now make the various settings that are only available in master mode.
When all the desired settings have been made at this receiver, you can press
the master button again to select the next receiver for programming.
Leaving master mode
There are two ways to leave master mode:
1. Press the changeover button
2. Master mode is automatically closed once 2 minutes have gone by
without a button being pushed
8

Programming the first transmitter
The receiver mode must always be set appropriately for the
receiver. Roller shutter/venetian blind is the factory setting.
Putting the receiver into programming mode
Follow the Assembly and Operating Instructions for the re-
ceiver.
•Switch off the power supply to the receiver for 5 seconds, then switch it
back on
or
•Operate the programming button or the radio switch of the receiver.
The receiver is now in programming mode for 3 minutes.
Programming transmitters
Please make sure that only one receiver is in programming
mode at any time. It is not possible to program/clear multiple
receivers at the same time.
Press the transmitter's programming button while programming mode is act-
ive, until the receiver confirms successful programming. The status LED
flashes yellow during the programming process.
The programming process is now complete.
Lights up
green /
red
Action completed successfully (green) or not suc-
cessfully (red).
9

Querying/Changing the receiver mode
The receiver mode must always be set appropriately for the
receiver. Roller shutter/venetian blind is the factory setting.
Querying the current receiver mode
There are different receiver modes. The receiver mode must always be set ap-
propriately for the receiver (e.g. roller shutter/blind, dimmer/switch). Roller
shutter/venetian blind is the factory setting.
Briefly press the programming button, and then
the changeover button for 1 second.
Flashes
yellow
once
Receiver mode roller shutter
Flashes
yellow
twice
Receiver mode dimmer
Flashes
yellow
three
times
Receiver mode switch
Flashes
yellow four
times
Receiver mode venetian blind
Flashes
yellow five
times
Receiver mode screen
Flashes
yellow six
times
Receiver mode roof window
10

Changing to the desired receiver mode
The current receiver mode is first indicated through the dis-
play code.
Briefly press the programming button, and then
the changeover button for 5 seconds.
Flashes
yellow
once
Receiver mode roller shutter
Flashes
yellow
twice
Receiver mode dimmer
Flashes
yellow
three
times
Receiver mode switch
Flashes
yellow four
times
Receiver mode venetian blind
Flashes
yellow five
times
Receiver mode screen
Flashes
yellow six
times
Receiver mode roof window
Repeat this procedure until the desired receiver mode has been selected.
11

Programming more transmitters
The receiver mode must always be set appropriately for the
receiver. Roller shutter/venetian blind is the factory setting.
Programming more B-Tronic transmitters in the B-
Tronic receiver
Put the receiver into programming mode in one of the three possible ways.
Please make sure that only one receiver is in programming
mode at any time. It is not possible to program/clear multiple
receivers at the same time.
Putting the B-Tronic receiver into programming mode with a pro-
grammed B‑Tronic transmitter
Put the transmitter into master mode.
Select the receiver by pressing the button until the desired receiver con-
firms.
All the following settings will then only be executed for this device.
Press the programming button of the pro-
grammed transmitter.
▻The receiver confirms.
►The receiver goes into the programming
mode for 3 minutes
Putting the B-Tronic receiver into program-
ming mode by switching on the power
Switch on the power.
►The receiver goes into the programming
mode for 3 minutes
12

Putting the B-Tronic receiver into program-
ming mode with the radio switch
Switch the radio switch to the inside position. If
the radio switch is already in this position, switch it
to the outside and back to the inside position.
►The tubular drive goes into the programming
mode for 3 minutes
Press the programming button for 3 seconds.
The LED flashes green.
►The receiver goes into the programming
mode for 3 minutes
When the receiver is in programming mode, proceed as follows:
Now press the programming button of the new
transmitter.
▻The receiver confirms.
►The programming process is now complete.
Lights up
green /
red
Action completed successfully (green) or not suc-
cessfully (red).
Programming more B-Tronic transmitters in a KNX RF
compatible receiver from another manufacturer
Please find the appropriate description on our website.
Programming more KNX RF compatible transmitters
from another manufacturer in a B-Tronic receiver
Please find the appropriate description on our website.
13

Deleting transmitters
Deleting from B-Tronic receivers with two B-Tronic
transmitters
Put a programmed transmitter, other than the one that is to be de-
leted, into master mode.
Select the device by pressing the button until the desired device confirms.
All the following settings will then only be executed for this device.
While the transmitter is in master mode, the sym-
bols on the changeover button flash green once
per second.
Now press the programming button, until the
status LED changes from green to yellow, and the
receiver confirms.
Changes
from
green to
yellow
Press the programming button, until the status
LED flashes yellow and the receiver confirms.
Flashes
yellow
Now press the programming button of the trans-
mitter to be deleted until the receiver confirms.
►The transmitter is now deleted from the re-
ceiver.
Lights up
green /
red
Action completed successfully (green) or not suc-
cessfully (red).
14

Deleting from B-Tronic receivers with one B-Tronic
transmitter
The last or only transmitter in a receiver can be deleted using
the following deletion sequence. To program new transmit-
ters, the receiver must again be put into programming mode.
Put the transmitter into master mode.
Select the device by pressing the button until the desired device confirms.
All the following settings will then only be executed for this device.
While the transmitter is in master mode, the sym-
bols on the changeover button flash green once
per second.
Now press the programming button, until the
status LED changes from green to yellow, and the
receiver confirms.
Changes
from
green to
yellow
Press the programming button, until the status
LED flashes yellow and the receiver confirms.
Flashes
yellow
Now press the changeover button to leave master
mode.
Now press the programming button until the re-
ceiver confirms.
►The transmitter is now deleted from the re-
ceiver.
Lights up
green /
red
Action completed successfully (green) or not suc-
cessfully (red).
15

Deleting a B-Tronic transmitter from a KNX RF
compatible receiver from another manufacturer
Please find the appropriate description in the instructions for the receiver or
on our website.
Changing the direction of rotation of B-
Tronic products
Check the direction of rotation before setting the limit positions. The shading
solution must move in the correct direction when the UP or DOWN buttons are
pressed.
If this is not the case, please carry out the following steps to change the direc-
tion of rotation:
No limit positions must be programmed. Delete the limit positions if neces-
sary.
Put the transmitter into master mode.
Select the receiver by pressing the button until the desired receiver con-
firms.
First press the programming button and, within
the next 3seconds, press both the UP and DOWN
buttons for 3seconds.
▻The receiver confirms.
Check the running direction again.
16

Setting the limit positions of B-Tronic tubular
drives
Upper stop to lower stop
Put the transmitter into master mode.
Select the tubular drive by pressing the button until the tubular drive con-
firms.
All the following settings will then only be executed for this device.
Open to the permanent upper stop.
▻The tubular drive switches off automat-
ically.
Then close to the permanent lower stop.
▻The tubular drive switches off automat-
ically.
►The limit positions are now set.
17

Upper point to lower point
Put the transmitter into master mode.
Select the tubular drive by pressing the button until the tubular drive con-
firms.
All the following settings will then only be executed for this device.
There is no shading solution length adjustment with this limit
position setting.
Open to the desired upper limit position.
Press the programming button and, within 1
second, also press the UP button and hold the two
buttons down.
▻The receiver confirms.
Then close to the desired lower limit position.
Press the programming button and, within 1
second, also press the DOWN button and hold the
two buttons down.
▻The receiver confirms.
►The limit positions are now set.
18

Upper stop to lower point
Put the transmitter into master mode.
Select the tubular drive by pressing the button until the tubular drive con-
firms.
All the following settings will then only be executed for this device.
Open to the permanent upper stop.
▻The tubular drive switches off automat-
ically.
Then close to the desired lower limit position.
Press the programming button and, within 1
second, also press the DOWN button and hold the
two buttons down.
▻The receiver confirms.
►The limit positions are now set.
Upper point to lower stop
Put the transmitter into master mode.
Select the tubular drive by pressing the button until the tubular drive con-
firms.
All the following settings will then only be executed for this device.
Open to the desired upper limit position.
Press the programming button and, within 1
second, also press the UP button and hold the two
buttons down.
▻The receiver confirms.
Then close to the permanent lower stop.
▻The tubular drive switches off automat-
ically.
►The limit positions are now set.
19

Deleting the limit positions of B-Tronic
tubular drives
Attention
When one or both of the limit positions are deleted, all the
other set functions (e.g. intermediate position) are deleted
as well.
Once set, the limit positions can only be deleted using mas-
ter mode. Deleted limit positions are displayed on the limit
position status indicator.
Deleting individual limit positions
Put the transmitter into master mode.
Select the tubular drive by pressing the button until the tubular drive con-
firms.
All the following settings will then only be executed for this device.
Open/close to the limit position to be deleted.
Press the programming button and, within the
next 1 second, press the STOP button at the same
time and hold the two buttons down for 5 seconds.
▻The receiver confirms.
►The limit position is now deleted.
20
