Beko BA 310 AC User manual

conditioner
Instruction Manual
BA BA 312 C BA 312 H
EN FR DE IT RO
310 AC
02M-8500063200-4920-01
Local air

This product has been produced in environmentally friendly, modern facilities
Complies with the WEEE Regulation. Does not contain PCB.
Please read this user manual rst!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user
manual as well. Follow all warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
Warning to actions that must
never perform.
B
Warning for electric shock.
Warning for hot surfaces.
Do not cover it.
This symbol shows that the
operation manual should be
read carefully.
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
This symbol
shows that this
appliance used
a flammable
refrigerant. If
the refrigerant
is leaked and
exposed to
an external
ignition source,
there is a risk of
fire.

3 / 224 EN
Contents
1 4
2 10
3 22
4 24
4.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Tools needed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5 30
5.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.2 Other features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6 38
6.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
7 40
8 41
9 42
10 43
10.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
11 44
Local air conditioner

4 / 224 EN
1 Safety precautons
Warning
To prevent death or injury to the user or other people and property
damage, the following instructions must be followed. Incorrect
operation due to ignoring of instructions may cause death, harm or
damage.
t Installation must be performed according to the installation
instructions. Improper installation can cause water leakage,
electrical shock, or fire.
t Use only the included accessories and parts, and specified tools for
the installation. Using non-standard parts can cause water leakage,
electrical shock, fire, and injury or property damage.
t Make sure that the outlet you are using is grounded and has the
appropriate voltage. The power cord is equipped with a three-prong
grounding plug to protect against shock. Voltage information can be
found on the nameplate of the unit.
t Your unit must be used in a properly grounded wall receptacle. If
the wall receptacle you intend to use is not adequately grounded or
protected by a time delay fuse or circuit breaker (the fuse or circuit
breaker needed is determined by the maximum current of the unit.
The maximum current is indicated on the nameplate located on
unit), have a qualified electrician install the proper receptacle.
t Install the unit on a flat, sturdy surface. Failure to do so could result
in damage or excessive noise and vibration.
t The unit must be kept free from obstruction to ensure proper
function and to mitigate safety hazards.
Local air conditioner

5 / 224 EN
t Do not modify the length of the power cord or use an extension
cord to power the unit.
t Do not share a single outlet with other electrical appliances.
Improper power supply can cause fire or electrical shock.
t Do not install your air conditioner in a wet room such as a bathroom
or laundry room. Too much exposure to water can cause electrical
components to short circuit.
t Do not install the unit in a location that may be exposed to
combustible gas, as this could cause fire.
t The unit has wheels to facilitate moving. Make sure not to use the
wheels on thick carpet or to roll over objects, as these could cause
tipping.
t Do not operate a unit that it has been dropped or damaged.
t The appliance with electric heater shall have at least 1 meter space
to the combustible materials.
t Do not touch the unit with wet or damp hands or when barefoot.
t If the air conditioner is knocked over during use, turn off the unit
and unplug it from the main power supply immediately. Visually
inspect the unit to ensure there is no damage. If you suspect the
unit has been damaged, contact a technician or customer service for
assistance.
t In a thunderstorm, the power must be cut off to avoid damage to
the machine due to lightning.
t Your air conditioner should be used in such a way that it is protected
from moisture. e.g. condensation, splashed water, etc. Do not place
1 Safety precautions
Local air conditioner

6 / 224 EN
or store your air conditioner where it can fall or be pulled into water
or any other liquid. Unplug immediately if it occurs.
t All wiring must be performed strictly in accordance with the wiring
diagram located inside of the unit.
t The unit’s circuit board (PCB) is designed with a fuse to provide
overcurrent protection. The specifications of the fuse are printed
on the circuit board, such as: T 3.15A/250V, etc.
t This appliance can be used by children aged from 8 years and above
if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved.
Cleaning and user maintenance shall not be made by children
unless they are aged from 8 years and above and supervised. Keep
the appliance and its cord out of reach of children aged less than
8 years. (be applicable for the European Countries).
t This appliance is not intended for use by persons (including
childern) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. (be applicable for other
countries except the European Countries)
t Children should be supervised to ensure that they do not play with
the appliance. Children must be supervised around the unit at all
times.
t If the supply cord is damaged, it must be replaced by the
manufacturer,its service agent or similarly qualified persons in order
to avoid a hazard.
1 Safety precautions
Local air conditioner

7 / 224 EN
t Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
t Do not remove any fixed covers. Never use this appliance if it is not
working properly, or if it has been dropped or damaged.
t Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from traffic area and where it will not
be tripped over.
t Do not operate unit with a damaged cord, plug, power fuse or circuit
breaker. Discard unit or return to an authorized service facility for
examination and/or repair.
t To reduce the risk of fire or electric shock, do not use this appliance
with any solid-state speed control device.
t The appliance shall be installed in accordance with national wiring
regulations.
t Contact the authorised service technician for repair or maintenance
of this unit.
t Contact the authorised installer for installation of this unit.
t Do not cover or obstruct the inlet or outlet grilles.
t Do not use this product for functions other than those described in
this instruction manual.
t Before cleaning, turn off the power and unplug the unit.
t Disconnect the power if strange sounds, smell, or smoke comes
from it.
1 Safety precautions
Local air conditioner

8 / 224 EN
t Do not press the buttons on the control panel with anything other
than your fingers.
t Do not remove any fixed covers. Never use this appliance if it is not
working properly, or if it has been dropped or damaged.
t Do not operate or stop the unit by inserting or pulling out the power
cord plug.
t Do not use hazardous chemicals to clean or come into contact
with the unit. Do not use the unit in the presence of inflammable
substances or vapour such as alcohol, insecticides, petrol,etc.
t Always transport your air conditioner in a vertical position and stand
on a stable, level surface during use.
t Always contact a qualified person to carry out repairs. If the
damaged power supply cord must be replaced with a new power
supply cord obtained from the product manufacturer and not
repaired.
t Hold the plug by the head of the power plug when taking it out.
t Turn off the product when not in use.
t Warning Do not use manuals to accelerate the defrosting process or
to clean, other than those recommended by the manufacturer. The
appliance shall be stored in a room without Continuously operation
ignition sources (for example: open flames, an operation gas
appliance or an operating electric heater.) Do not pierce or burn. Be
aware that refrigerants may not contain an odour.
t The appliance shall state the insulation of a residual current device
(RCD) having rated residual operating current not exceeding 30mA.
1 Safety precautions
Local air conditioner

9 / 224 EN
t This appliance is intended to be used in household and similar
applications such as
- Staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
1 Safety precautions
Local air conditioner

10 / 224 EN
t Do not use means to accelerate the defrosting process or to clean,
other than those recommended by the manufacturer.
t The appliance shall be stored in a room without continuously
operating ignition sources (for example: open flames, an operating
gas appliance or an operating electric heater).
t Do not pierce or burn.
t Be aware that the refrigerants may not contain an odour.
t Appliance BA 3 09 C / BA 3 10 AC , should be installed, operated and
stored in a room with a floor area larger than 10 m2.
t Appliance BA 3 12 C / BA 3 12 H , should be installed, operated and
stored in a room with a floor area larger than 12 m2.
t Compliance with national gas regulations shall be observed.
t Keep ventilation openings clear of obstruction.
t The appliance shall be stored so as to prevent mechanical damage
from occurring.
t A warning that the appliance shall be stored in a well-ventilated
area where the room size corresponds to the room area as specified
for operation.
t Any person who is involved with working on or breaking into a
refrigerant circuit should hold a current valid certificate from an
industry-accredited assessment authority, which authorises their
competence to handle refrigerants safely in accordance with an
industry recognised assessment specification.
2 Warnings (for using R290 refrigerant only)
Local air conditioner

11 / 224 EN
t Servicing shall only be performed as recommended by the
equipment manufacturer. Maintenance and repair requiring the
assistance of other skilled personnel shall be carried out under
the supervision of the person competent in the use of flammable
refrigerants.
1. Transport of equipment containing flammable refrigerants.
See transport regulations.
2. Marking of equipment using signs.
See local regulations.
3. Disposal of equipment using flammable refrigerants.
See national regulations.
4. Storage of equipment/appliances
The storage of equipment should be in accordance with the
manufacturer’s instructions.
5. Storage of packed (unsold) equipment
Storage package protection should be constructed such that
mechanical damage to the equipment inside the package will not
cause a leak of the refrigerant charge. The maximum number
of pieces of equipment permitted to be stored together will be
determined by local regulations.
6. Information on servicing
1) Checks to the area
Prior to beginning work on systems containing flammable
refrigerants, safety checks are necessary to ensure that the risk
of ignition is minimised. For repair to the refrigerating system, the
2 Warnings (for using R290 refrigerant only)
Local air conditioner

12 / 224 EN
following precautions shall be complied with prior to conducting work
on the system.
2) Work procedure
Work shall be undertaken under a controlled procedure so as to
minimise the risk of a flammable gas or vapour being present while
the work is being performed.
3) General work area
All maintenance staff and others working in the local area shall be
instructed on the nature of work being carried out. Work in confined
spaces shall be avoided. The area around the workspace shall be
sectioned off. Ensure that the conditions within the area have been
made safe by control of flammable material.
4) Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant
detector prior to and during work, to ensure the technician is
aware of potentially flammable atmospheres. Ensure that the leak
detection equipment being used is suitable for use with flammable
refrigerants, i.e. non-sparking, adequately sealed or intrinsically
safe.
5) Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or
any associated parts, appropriate fire extinguishing equipment shall
be available to hand. Have a dry powder or CO2 fire extinguisher
adjacent to the charging area.
2 Warnings (for using R290 refrigerant only)
Local air conditioner

13 / 224 EN
6) No ignition sources
No person carrying out work in relation to a refrigeration system
which involves exposing any pipe work that contains or has
contained flammable refrigerant shall use any sources of ignition
in such a manner that it may lead to the risk of fire or explosion. All
possible ignition sources, including cigarette smoking, should be
kept sufficiently far away from the site of installation, repairing,
removing and disposal, during which flammable refrigerant can
possibly be released to the surrounding space. Prior to work taking
place, the area around the equipment is to be surveyed to make
sure that there are no flammable hazards or ignition risks. No
Smoking signs shall be displayed.
7) Ventilated area
Ensure that the area is in the open or that it is adequately ventilated
before breaking into the system or conducting any hot work. A
degree of ventilation shall continue during the period that the work
is carried out. The ventilation should safely disperse any released
refrigerant and preferably expel it externally into the atmosphere.
8) Checks to the refrigeration equipment
Where electrical components are being changed, they shall be
fit for the purpose and to the correct specification. At all times
the manufacturer’s maintenance and service guidelines shall
be followed. If in doubt consult the manufacturer’s technical
department for assistance. The following checks shall be applied to
installations using flammable refrigerants:
2 Warnings (for using R290 refrigerant only)
Local air conditioner

14 / 224 EN
t The charge size is in accordance with the room size within which
the refrigerant containing parts are installed;
t The ventilation machinery and outlets are operating adequately and
are not obstructed;
t If an indirect refrigerating circuit is being used, the secondary circuit
shall be checked for the presence of refrigerant; Marking to the
equipment continues to be visible and legible. Markings and signs
that are illegible shall be corrected;
t Refrigeration pipe or components are installed in a position where
they are unlikely to be exposed to any substance which may corrode
refrigerant containing components, unless the components are
constructed of materials which are inherently resistant to being
corroded or are suitably protected against being so corroded.
9) Checks to electrical devices
Repair and maintenance to electrical components shall include
initial safety checks and component inspection procedures. If a
fault exists that could compromise safety, then no electrical supply
shall be connected to the circuit until it is satisfactorily dealt with.
If the fault cannot be corrected immediately but it is necessary to
continue operation, an adequate temporary solution shall be used.
This shall be reported to the owner of the equipment so all parties
are advised.
Initial safety checks shall include:
t That capacitors are discharged: this shall be done in a safe manner
to avoid possibility of sparking;
2 Warnings (for using R290 refrigerant only)
Local air conditioner

15 / 224 EN
t That there no live electrical components and wiring are exposed
while charging, recovering or purging the system;
t That there is continuity of earth bonding.
7. Repairs to sealed components
1) During repairs to sealed components, all electrical supplies shall be
disconnected from the equipment being worked upon prior to any
removal of sealed covers, etc. If it isabsolutely necessary to have an
electrical supply to equipment during servicing, then a permanently
operating form of leak detection shall be located at the most critical
point to warn of a potentially hazardous situation.
2) Particular attention shall be paid to the following to ensure that
by working on electrical components, the casing is not altered in
such a way that the level of protection is affected. This shall include
damage to cables, excessive number of connections, terminals not
made to original specification, damage to seals, incorrect fitting of
glands, etc.
Ensure that apparatus is mounted securely.
Ensure that seals or sealing materials have not degraded such
that they no longer serve the purpose of preventing the ingress of
flammable atmospheres. Replacement parts shall be in accordance
with the manufacturer’s specifications.
C
Note:
The use of silicon sealant may inhibit the effectiveness of
some types of leak detection equipment. Intrinsically safe
components do not have to be isolated prior to working
on them.
2 Warnings (for using R290 refrigerant only)
Local air conditioner

16 / 224 EN
8. Repair to intrinsically safe components
Do not apply any permanent inductive or capacitance loads to the
circuit without ensuring that this will not exceed the permissible
voltage and current permitted for the equipment in use. Intrinsically
safe components are the only types that can be worked on while
live in the presence of a flammable atmosphere. The test apparatus
shall be at the correct rating. Replace components only with parts
specified by the manufacturer. Other parts may result in the ignition
of refrigerant in the atmosphere from a leak.
9. Cabling
Check that cabling will not be subject to wear, corrosion, excessive
pressure, vibration, sharp edges or any other adverse environmental
effects. The check shall also take into account the effects of aging
or continual vibration from sources such as compressors or fans.
10. Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used
in the searching for or detection of refrigerant leaks. A halide torch
(or any other detector using a naked flame) shall not be used.
11. Leak detection methods
The following leak detection methods are deemed acceptable
for systems containing flammable refrigerants. Electronic leak
detectors shall be used to detect flammable refrigerants, but
the sensitivity may not be adequate, or may need re-calibration.
(Detection equipment shall be calibrated in a refrigerant-free
area.) Ensure that the detector is not a potential source of ignition
2 Warnings (for using R290 refrigerant only)
Local air conditioner

17 / 224 EN
2 Warnings (for using R290 refrigerant only)
and is suitable for the refrigerant used. Leak detection equipment
shall be set at a percentage of the LFL of the refrigerant and shall
be calibrated to the refrigerant employed and the appropriate
percentage of gas (25 % maximum) is confirmed. Leak detection
fluids are suitable for use with most refrigerants but the use of
detergents containing chlorine shall be avoided as the chlorine may
react with the refrigerant and corrode the copper pipe-work. If a
leak is suspected, all naked flames shall be removed/ extinguished.
If a leakage of refrigerant is found which requires brazing, all of
the refrigerant shall be recovered from the system, or isolated (by
means of shut off valves) in a part of the system remote from the
leak. Oxygen free nitrogen (OFN) shall then be purged through the
system both before and during the brazing process.
12. Removal and evacuation
When breaking into the refrigerant circuit to make repairs or for any
other purpose conventional procedures shall be used. However, it
is important that best practice is followed since flammability is a
consideration. The following procedure shall be adhered to:
t Remove refrigerant;
t Purge the circuit with inert gas;
t Evacuate;
t Purge again with inert gas;
t Open the circuit by cutting or brazing.
The refrigerant charge shall be recovered into the correct recovery
cylinders. The system shall be flushed with OFN to render the
Local air conditioner

18 / 224 EN
2 Warnings (for using R290 refrigerant only)
unit safe. This process may need to be repeated several times.
Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking the vacuum in the system
with OFN and continuing to fill until the working pressure is
achieved, then venting to atmosphere, and finally pulling down to a
vacuum. This process shall be repeated until no refrigerant is within
the system. When the final OFN charge is used, the system shall be
vented down to atmospheric pressure to enable work to take place.
This operation is absolutely vital if brazing operations on the pipe-
work are to take place. Ensure that the outlet for the vacuum pump is
not close to any ignition sources and there is ventilation available.
13. Charging procedures
In addition to conventional charging procedures, the following
requirements shall be followed. Ensure that contamination
of different refrigerants does not occur when using charging
equipment. Hoses or lines shall be as short as possible to minimise
the amount of refrigerant contained in them.
Cylinders shall be kept upright.
Ensure that the refrigeration system is earthed prior to charging the
system with refrigerant.
Label the system when charging is complete (if not already).
Extreme care shall be taken not to overfill the refrigeration system.
Prior to recharging the system it shall be pressure tested with OFN.
The system shall be leak tested on completion of charging but prior
to commissioning. A follow up leak test shall be carried out prior to
leaving the site.
Local air conditioner

19 / 224 EN
2 Warnings (for using R290 refrigerant only)
14. Decommissioning
Before carrying out this procedure, it is essential that the technician
is completely familiar with the equipment and all its detail. It is
recommended good practice that all refrigerants are recovered
safely. Prior to the task being carried out, an oil and refrigerant
sample shall be taken in case analysis is required prior to re-use of
reclaimed refrigerant. It is essential that electrical power is available
before the task is commenced.
a. Become familiar with the equipment and its operation.
b. Isolate system electrically.
c. Before attempting the procedure ensure that:
Mechanical handling equipment is available, if required, for
handling refrigerant cylinders;
All personal protective equipment is available and being used
correctly; The recovery process is supervised at all times by a
competent person;
Recovery equipment and cylinders conform to the appropriate
standards.
d. Pump down refrigerant system, if possible.
e. If a vacuum is not possible, make a manifold so that refrigerant can
be removed from various parts of the system.
f. Make sure that cylinder is situated on the scales before recovery
takes place.
g. Start the recovery machine and operate in accordance with
manufacturer’s instructions.
Local air conditioner

20 / 224 EN
2 Warnings (for using R290 refrigerant only)
h. Do not overfill cylinders. (No more than 80 % volume liquid charge).
i. Do not exceed the maximum working pressure of the cylinder, even
temporarily.
j. When the cylinders have been filled correctly and the process
completed, make sure that the cylinders and the equipment
are removed from site promptly and all isolation valves on the
equipment are closed off.
k. Recovered refrigerant shall not be charged into another
refrigeration system unless it has been cleaned and checked.
15. Labelling
Equipment shall be labelled stating that it has been de-
commissioned and emptied of refrigerant. The label shall be dated
and signed. Ensure that there are labels on the equipment stating the
equipment contains flammable refrigerant.
16. Recovery
When removing refrigerant from a system, either for servicing
or decommissioning, it is recommended good practice that all
refrigerants are removed safely.
When transferring refrigerant into cylinders, ensure that only
appropriate refrigerant recovery cylinders are employed.
Ensure that the correct number of cylinders for holding the total
system charge is available. All cylinders to be used are designated for
the recovered refrigerant and labelled for that refrigerant (i.e. special
cylinders for the recovery of refrigerant). Cylinders shall be complete
Local air conditioner
