Belkin AirCast Auto F4U037cw User manual

AirCast Auto
User Manual
F4U037cw 8820ek00529
English
Français
Deutsch
Nederlands
Español
Italiano
Português
Русский
Suomi
Norsk
Dansk
Svenska
ČeSky
Polski
Magyar

i
AirCast Auto
SECTIONS 1 2 3 654 7Table of Contents
TABLE OF CONTENTS
4 Troubleshooting. ....................................... 9
5 Safety Warnings ....................................... 10
6 Information ........................................... 11
7 Tip Sheet for the Button ................................ 15
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Initial Setup. ........................................... 3
3 Daily Use .............................................. 6
Connecting ...............................................6
Managing Phone Calls ......................................6
Managing Multiple Calls/Call-Waiting ..........................7
Managing Music ...........................................7
Online Audio Services.......................................8
Disconnecting .............................................8

1
AirCast Auto
SECTIONSTable of Contents 2 3 654 71
INTRODUCTION
Features
• Talk hands-free on your iPhone or other Bluetooth-enabled phone
• Listen to your iTunes music or other audio files, including Internet
radio, from your Bluetooth-enabled device wirelessly through your
car stereo

2
AirCast Auto
SECTIONSTable of Contents 2 3 654 71
INTRODUCTION
What’s in the Box
Optimal
Acceptable
Avoid
Mount Button Power Aux 3.5mm
Audio Cable
Aux 3.5mm Audio
Extension cable
Mount Button Power Aux 3,5mm
Audio Cable Aux 3,5mm Audio Extension cable

3
AirCast Auto
SECTIONSTable of Contents 1 3 654 7
INITIAL SETUP
2
Connect to power and AUX:
1. Insert the power plug into your car’s 12V power outlet (also known
as the cigarette lighter). 2. Insert the audio cable into your car’s AUX port. If the cable is too
short, use the extension cable included in the package.
3. Turn on your car stereo and set the input source to AUX.
Optimal
Acceptable
Avoid
Mount Button Power Aux 3.5mm
Audio Cable
Aux 3.5mm Audio
Extension cable

4
AirCast Auto
SECTIONSTable of Contents 1 3 654 72
INITIAL SETUP
Place the Button:
1. Find a smooth and flat surface on the dashboard in front of you
that is within easy reach but will not interfere with driving. The built-
in microphone is housed in the button so it should be as close to
your mouth and as directly in front of you as possible. See image
for some recommended areas:
2. Make sure the surface is dry and free of dirt.
3. Peel away the back of the mounting disc to expose the adhesive
and stick it to the dashboard.
4. The button will magnetically attach to the mounting disc. The
button can be easily removed and stored when not in use.
Optimal
Acceptable
Avoid
Mount Button Power Aux 3.5mm
Audio Cable
Aux 3.5mm Audio
Extension cable

5
AirCast Auto
SECTIONSTable of Contents 1 3 654 72
INITIAL SETUP
Pair your phone:
1. Press and hold the button until the light ring starts flashing. The
button light will briefly turn off before it starts flashing. Do not
release the button until it starts flashing.
2. On your phone, go to the Bluetooth settings menu.
3. Make sure Bluetooth is turned on.
4. On some phones, set your Bluetooth to search for
new connections.
5. Select the AirCast Auto from the list of accessories.
6. If asked for a pass code, type in “0000”.
7. When paired successfully, the light ring will turn solid blue.
8. Some phones may ask if you want to connect. Select “Yes”.
Pairing with a different phone:
Only one phone can be paired to the AirCast Auto at any one time. To
pair a different phone:
1. Put the AirCast Auto into sleep mode by pressing and holding
the button until the light ring turns off, and then immediately let
go of the button.
2. Repeat the pairing instructions listed previously.

6
AirCast Auto
SECTIONSTable of Contents 1 2 654 7
DAILY USE
3
Managing Phone Calls
Make a call:
• Place calls as you normally do on your phone and the call audio
will be heard through your car stereo.
Make a call using voice-dialing:
• If your phone supports voice-dialing, press and hold the button
until you hear your phone prompt for a command (about one
second).
Answer a call:
• When an incoming call is detected, the light ring will flash blue.
• Tap the button to answer the call and the light ring will return to
solid blue.
Connecting
To connect to the AirCast Auto:
1. If you’re already on a call or listening to music via a Bluetooth®
headset, turn the headset off so that your phone is free to connect
to the AirCast Auto.
2. Turn your car stereo on and set the input source to AUX.
3. Make sure there’s power to the AirCast Auto—the light ring will be
solid orange.
4. Tap the button and the AirCast Auto will attempt to re-connect with
the same phone it last connected to.
5. When successfully connected, the light ring will turn solid blue.
6. If you’re already on a call or listening to music, the audio will
transfer to your car speakers.
Note: After 10 minutes of inactivity, the AirCast Auto will go into
sleep mode and the light ring will turn off. When that happens, tap
the button to wake it and it will immediately attempt to connect to
the same phone it last connected to.

7
AirCast Auto
SECTIONSTable of Contents 1 2 654 73
DAILY USE
Managing Music
Play:
• Tap the button and your phone will play whatever music was
last playing.
• To change the music selection, use the controls on the phone.
To pause/un-pause the music:
• Tap the button and the music will pause.
• If the music is already paused, tapping the button will un-pause it.
• If a call comes in while listening to music, the music will
automatically pause.
Skip songs:
• To skip to the next song, double-tap the button.
• This may not work for all phones.
Managing Multiple Calls/Call-Waiting
Answer a second incoming call:
• Tapthebutton.
Switch between two calls:
• Tapthebutton.
End the second call:
• Double-tapthebutton.

8
AirCast Auto
SECTIONSTable of Contents 1 2 654 73
DAILY USE
Disconnecting
To disconnect from the AirCast Auto, press and hold the button until the
light ring goes off, and then immediately release the button.
Note: If you’re on a call, the audio will transfer back to the phone after a few
seconds. If you’re listening to music, depending on the phone, the music will
pause or continue playing with the sound coming out of your phone.
Online Audio Services
If you use audio-streaming services or apps such as Pandora®or
iheartradio®, you might be able to use AirCast Auto to enjoy streaming
audio through your car stereo. If the sound comes out of your phone
instead of the car speakers:
1. Check to make sure the phone is connected to the AirCast Auto.
2. Check the service or app setting to make sure the Bluetooth option
is enabled and the sound output is set to Bluetooth.

9
AirCast Auto
SECTIONSTable of Contents 1 2 3 5 74
TROUBLESHOOTING
6
You can quickly solve most problems with your AirCast Auto by
following the advice in this section.
The audio is not coming out of the stereo speakers.
Solutions:
• MakesureboththecarstereoandtheAirCastAutoarepoweredon.
• Makesuretheaudiocableiscorrectlyandfirmlyconnectedtothe
aux-in jack of your vehicle.
• MakesureyourcarstereoissettotheAUXinputsetting.
• Makesurethestereovolumeissettoacomfortablelisteninglevel.
• MakesurethatyouriPhone,iPodtouch,orotherBluetooth-enabled
device is connected via Bluetooth to the AirCast Auto.

10
AirCast Auto
SECTIONSTable of Contents 1 2 3 64 75
SAFETY WARNINGS
Your AirCast Auto requires full concentration and both hands to install.
Do not attempt to connect your AirCast Auto while driving. Do
not attempt to adjust or retrieve an unsecured AirCast Auto while
driving. Adjust the position of your AirCast Auto so that it does not
interfere with any of the operating controls of the vehicle or your view of
the road.
Do not use this apparatus near water (for example, a bath tub, wash
bowl, kitchen sink, laundry tub, wet basement, swimming pool, or other
areas located near water).
Unplug this product from the cigarette lighter or power outlet before
cleaning. Clean only with a dry cloth.
Unplug this apparatus when unused for long periods of time.
Only use attachments/accessories specified by the manufacturer.
Belkin does not assume any responsibility for personal injury or property
damage incurred due to hazardous driving as a result of interaction with
the AirCast Auto, iPhone, iPod, or other Bluetooth-enabled device.

11
AirCast Auto
SECTIONSTable of Contents 1 2 3 54 76
INFORMATION
FCC Statement
Belkin International, Inc., is not responsible for any interference caused
by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate this equipment.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
ICES
This Class B digital apparatus complies with Canadian ICES-003.
IC
This Class B digital apparatus complies with Canada RSS-210.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the
R&TTE Directive 1999/5/EC, the EMC Directive 2004/108/EC, and the
low-voltage Directive 2006/95/EC. A copy of the European Union CE
marking “Declaration of Conformity” may be obtained at the website:
www.belkin.com/doc
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfrom
that which the receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

12
AirCast Auto
SECTIONSTable of Contents 1 2 3 54 76
INFORMATION
Belkin International, Inc., Limited 3-Year Product Warranty
The Belkin Product Warranty does not protect against acts of God such
as flood, lightning, earthquake, war, vandalism, theft, normal-use wear
and tear, erosion, depletion, obsolescence, abuse, damage due to low
voltage disturbances (i.e. brownouts or sags), non-authorized program,
or system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin Ltd Express Business Park, Shipton Way, Rushden,
NN106GL, United Kingdom, Attn: Customer Service, call +44 (0)
1933 35 2000 or 0845 607 77 87, within 15 days of the Occurence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you
on how to forward your receipt and Belkin product and how to
proceed with your claim.
What this warranty covers.
Belkin International, Inc. (“Belkin”) warrants to the original purchaser of
this Belkin product that the product shall be free of defects in design,
assembly, material, or workmanship.
What the period of coverage is.
Belkin warrants the Belkin product for three years.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of
charge (except for shipping charges for the product). Belkin reserves the
right to discontinue any of its products without notice, and disclaims any
limited warranty to repair or replace any such discontinued products. In the
event that Belkin is unable to repair or replace the product (for example,
because it has been discontinued), Belkin will offer either a refund or a credit
toward the purchase of another product from Belkin.com in an amount equal
to the purchase price of the product as evidenced on the original purchase
receipt as discounted by its natural use.
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not
provided to Belkin for inspection upon Belkin’s request at the sole
expense of the purchaser, or if Belkin determines that the Belkin product
has been improperly installed, altered in any way, or tampered with.

13
AirCast Auto
SECTIONSTable of Contents 1 2 3 54 76
INFORMATION
Belkin reserves the right to review the damaged Belkin product. All
costs of shipping the Belkin product to Belkin for inspection shall be
borne solely by the purchaser. If Belkin determines, in its sole discretion,
that it is impractical to ship the damaged equipment to Belkin, Belkin
may designate, in its sole discretion, an equipment repair facility to
inspect and estimate the cost to repair such equipment. The cost, if any,
of shipping the equipment to and from such repair facility and of such
estimate shall be borne solely by the purchaser. Damaged equipment
must remain available for inspection until the claim is finalized.
Whenever claims are settled, Belkin reserves the right to be subrogated
under any existing insurance policies the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN.
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS
REQUIRED BY LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY
OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY,
ARE LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty
lasts, so the above limitations may not apply to you.
IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL,
DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH
AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING
OUT OF THE SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have
other rights, which may vary from state to state. Some states do not
allow the exclusion or limitation of incidental, consequential, or other
damages, so the above limitations may not apply to you.

14
AirCast Auto
SECTIONSTable of Contents 1 2 3 54 76
INFORMATION
COUNTRY NUMBER INTERNET ADRESS
AUSTRIA 0820 200766 www.belkin.com/de/
BELGIUM 07 07 00 073 www.belkin.com/nl/
www.belkin.com/fr/
CZECH REPUBLIC 239 000 406 www.belkin.com/uk/
DENMARK 701 22 403 www.belkin.com/uk/
FINLAND 0972519123 www.belkin.com/uk/
FRANCE 08 - 25 54 00 26 www.belkin.com/fr/
GERMANY 0180 - 500 57 09 www.belkin.com/de/
GREECE 00800 - 44 14 23 90 www.belkin.com/uk/
HUNGARY 06 - 17 77 49 06 www.belkin.com/uk/
ICELAND 800 8534 www.belkin.com/uk/
IRELAND 0818 55 50 06 www.belkin.com/uk/
ITALY 02 - 69 43 02 51 www.belkin.com/it/
LUXEMBOURG 34 20 80 85 60 www.belkin.com/uk/
NETHERLANDS 0900 - 040 07 90 €0.10 per minute www.belkin.com/nl/
NORWAY 81 50 0287 www.belkin.com/uk/
POLAND 00800 - 441 17 37 www.belkin.com/uk/
PORTUGAL 707 200 676 www.belkin.com/uk/
RUSSIA 495 580 9541 www.belkin.com/
SOUTH AFRICA 0800 - 99 15 21 www.belkin.com/uk/
SPAIN 902 - 02 43 66 www.belkin.com/es/
SWEDEN 07 - 71 40 04 53 www.belkin.com/uk/
SWITZERLAND 08 - 48 00 02 19 www.belkin.com/de/
www.belkin.com/fr/
UNITED KINGDOM 0845 - 607 77 87 www.belkin.com/uk/
OTHER COUNTRIES +44 - 1933 35 20 00
You can find additional support information on our website www.belkin.com
through the tech-support area. If you want to contact technical support by
phone, please call the number you need from this list*.
Free Tech Support*
*National call rates may apply www.belkin.com

15
AirCast Auto
SECTIONSTable of Contents 1 2 3 654 7
TIP SHEET FOR THE BUTTON
Pairing Press and hold the button until the light ring flashes
orange. The light will briefly turn off before flashing.
Do not release until the light starts flashing.
Connect/transfer audio to the car Tap the button
Disconnect/transfer audio to phone Press and hold until the light ring turns off
Release the button immediately after the light ring
turns off
Answer a call Tap the button
End a call Tap the button
Answer a 2nd call Tap the button
Switch between 2 calls Tap the button
End 2nd call, resume 1st call Double-tap the button
Initiate voice-dialing Press and hold until voice prompt
Pause/un-pause music Tap the button (may not work on all phones)
Skip songs Double-tap the button (may not work on all phones)
Initiate voice-dialing Press and hold until phone prompts for a
voice command
Orange – Not flashing Powered but not connected
Orange – Flashing In Pairing mode
Blue – Not flashing Paired and connected
Blue – Flashing Incoming call
What the light ring on the button means:
Function Steps
This page can be removed from the manual and placed in your car for easy reference.

© 2010 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
iPod, iPhone, iPod touch, and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries. The Bluetooth name
and the Bluetooth trademarks are owned by Bluetooth SIG, Inc., and are used by Belkin International, Inc., under license.
F4U037cw
8820ek00529
Belkin Ltd.
Express Business Park
Shipton Way, Rushden
NN10 6GL, United Kingdom
Belkin Iberia
Avda de Barajas, 24
Edificio Gamma, 4ªpta
28108 Alcobendas
Madrid - Spain
Belkin SAS
130 Rue de Silly
92100 Boulogne-Billancourt,
France
Belkin Italy & Greece
Via Carducci, 7
Milano 20123
Italy
Belkin GmbH
Otto-Hahn-Straße 20
85609 Aschheim
Germany
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk,
Netherlands

AirCast Auto
Manuel de l'utilisateur
F4U037cw 8820ek00529
English
Français
Deutsch
Nederlands
Español
Italiano
Português
Русский
Suomi
Norsk
Dansk
Svenska
ČeSky
Polski
Magyar

i
AirCast Auto
SECTIONS 1 2 3 654 7Table des matières
TABLE DES MATIÈRES
4 Dépannage............................................. 9
5 Avertissements de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Informations .......................................... 11
7 Conseils d'utilisation du bouton ......................... 15
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Installation initiale. ..................................... 3
3 Utilisation quotidienne .................................. 6
Connexion ................................................6
Appels téléphoniques .......................................6
Appels multiples/en attente ..................................7
Musique ..................................................7
Services audio en ligne......................................8
Déconnexion ..............................................8
