Belkin TUNECAST F8J055 User manual

TUNECAST®AUTO LIVE
For iPhone and iPod
User Manual
TUNECAST®AUTO LIVE
Pour Phone et iPod
Guide d'utilisation
TUNECAST®AUTO LIVE
Para iPhone y iPod
Manual del usuario

TuneCast®Auto LIVE i
SECTIONS 1 2 3 6 754 8 Table of Contents
TABLE OF CONTENTS
1 Introduction ..................................................1
2 Get the ClearScan LIVE App ....................................2
3 Connect your TuneCast Auto ....................................3
4 Find an Open FM Station .......................................4
Use ClearScan to find the best station (recommended) ..................4
Find a station manually ............................................5
Store and select stations ..........................................6
5 Use the PRO Button to Boost Sound .............................7
6 Get the Most Out of TuneCast Auto ..............................8
Charge your iPhone or iPod ........................................8
Optimize the sound quality of your TuneCast Auto ......................8
7 Safety Warnings ...............................................9
8 Information ..................................................10

TuneCast®Auto LIVE 1
SECTIONS 2 3 6 754Table of Contents 8 1
INTRODUCTION
TuneCast Auto charges your iPod while you play your music over your car’s FM radio. Now
you can use your iPhone or iPod touch to control your TuneCast Auto. Just download the free
ClearScan LIVE app from the App Store (see instructions on the next page).

TuneCast®Auto LIVE 2
SECTIONS 1 3 6 754Table of Contents 8 2
GET THE CLEARSCAN LIVE APP
ClearScan LIVE lets you control your TuneCast Auto LIVE directly from your iPhone or iPod
touch. ClearScan LIVE also provides improved ClearScan results by:
• UsingyourGPSlocationtofindthebestFMstationinyourarea
• Recommendingopenstationsbasedonwhatotherpeopleinyourareaareusing
Look for ClearScan LIVE in the App Store on iTunes. See instructions in the app’s Help section
for more information.

TuneCast®Auto LIVE 3
SECTIONS 1 2 6 754Table of Contents 8 3
CONNECT YOUR TUNECAST AUTO
1. Turn down your stereo’s volume.
2. Connect your TuneCast Auto to the cigarette lighter or power outlet in your vehicle.
3. Connect your iPhone or iPod to your TuneCast Auto.
Note: In order to comply with government regulations, European versions of TuneCast Auto will
automatically turn off if there is no audio for approximately 60 seconds. It will automatically turn
on when it detects audio from your iPhone or iPod. You can also press the “m1” or “m2” button
to turn on your TuneCast Auto.

TuneCast®Auto LIVE 4
SECTIONS 1 2 3 6 75Table of Contents 8 4
FIND AN OPEN FM STATION
There are two ways to find an open FM station: by using ClearScan or selecting an
FM station manually.
Use ClearScan to find the best station (recommended)
Your TuneCast Auto uses ClearScan technology to constantly scan for the clearest FM
frequency in your area.
1. Press the “ClearScan” button. Your TuneCast Auto will display the best frequency.
2. Tune your stereo to the frequency on your TuneCast Auto display.

TuneCast®Auto LIVE 5
SECTIONS 1 2 3 6 75Table of Contents 8 4
FIND AN OPEN FM STATION
Find a station manually
If you want to transmit on a specific frequency, you can manually select it on your TuneCast Auto:
1. First, tune your car radio to an open station, one that plays only static or has a very weak
radio signal.
2. Press the + or - button on your TuneCast Auto to select the same station.

TuneCast®Auto LIVE 6
SECTIONS 1 2 3 6 75Table of Contents 8 4
FIND AN OPEN FM STATION
Save and select stations
You can save two stations using the “m1” and “m2” buttons.
1. To save a station, select the desired frequency on your TuneCast Auto using the + or - buttons.
2. Press and hold the “m1” or “m2” button for two seconds. The “m1” or “m2” icon will flash on
the screen when the station is saved.
3. To recall a saved station, press the “m1” or “m2” button. Your TuneCast Auto will change to the
saved station.

TuneCast®Auto LIVE 7
SECTIONS 1 2 3 6 74Table of Contents 8 5
USE THE PRO BUTTON TO BOOST SOUND
Ifyoufindthesoundistooweak,press“PRO”toboostthesoundcomingfromyouriPod.PRO
will cycle through the following settings:
PRO Setting Use for… Description
Normal All types of audio No change to audio
PRO1 Most types of music Increases the average
volume of the audio
PRO2 Quieter music Increases the average
volumemorethanPRO1;
may cause distortion of
louder music
Audio books, mono
recordings, podcasts
Increases the average
volume and transmits in
mono
Try this if you do not receive
a clear signal

TuneCast®Auto LIVE 8
SECTIONS 1 2 3 754Table of Contents 8 6
GET THE MOST OUT OF TUNECAST AUTO
Charge your iPhone or iPod
Your TuneCast Auto will charge your iPhone or iPod while it is connected to a power outlet
and receiving power. If your iPhone or iPod is not charging, make sure your TuneCast Auto is
correctly connected to the power outlet and that your iPhone or iPod is securely connected to
your TuneCast Auto. The indicator light on the cigarette lighter adapter should be lit.
Note: Some vehicles do not provide power to the power outlet unless the vehicle is in ignition
mode or the engine is running.
Optimize the sound quality of your TuneCast Auto
A variety of car radio and antenna configurations are available and you may optimize the sound
quality in your car based on the location of your TuneCast Auto (for example, placing the
TuneCast Auto on the center console may yield better performance than other locations within
your vehicle).

TuneCast®Auto LIVE 9
SECTIONS 1 2 3 654Table of Contents 8 7
SAFETY WARNINGS
Do not attempt to connect your TuneCast Auto while driving. Make sure your TuneCast
Auto fits securely and firmly into the power outlet before driving.
Do not attempt to adjust or retrieve an unsecured TuneCast Auto or iPhone or iPod while
driving. Position the TuneCast Auto so that both the TuneCast Auto and the iPhone or iPod do
not interfere with any of the operating controls of the car.
Do not insert any objects other than the cigarette lighter adapter into the power outlet
without disconnecting the battery of the car first. Failure to observe this safety warning
can result in injury or property damage.
Belkin does not assume any responsibility for personal injury or property damage incurred due
to hazardous driving as a result of interaction with the TuneCast Auto, the iPhone or iPod, or the
vehicle’s power outlet.

TuneCast®Auto LIVE 10
SECTIONS 1 2 3 6 754Table of Contents
INFORMATION
8
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC
COMPATIBILITY
We, Belkin International, Inc., of 12045 E. Waterfront Drive, Playa Vista, CA 90094, declare
under our sole responsibility that the product, SKU No: F8J055, to which this declaration
relates,complieswithPart15oftheFCCRules.Operationissubjecttothefollowing
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of the following measures:
•Reorientorrelocatethereceivingantenna.
•Increasethedistancebetweentheequipmentandthereceiver.
•Connecttheequipmenttoanoutletonacircuitdifferentfromthattowhichthereceiver
is connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

TuneCast®Auto LIVE 11
SECTIONS 1 2 3 6 754Table of Contents 8
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
IMPORTANT NOTE:
Industry Canada Statement
ThisdevicecomplieswithICES-003oftheIndustryCanadaRules.Operationissubjectto
the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
CedispositifestconformealanormeCNR-standardsd’IndustrieCanadaapplicableaux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux
conditions suivantes:
(1) le dispositif ne doit pas produire de brouillage prejudiciable, et
(2) ce dispositif doit accepter tout brouillage recu, y compris un brouillage susceptible de
provoquer un fonctionnement indesirable.
IC Statement:
ThisdigitalapparatuscomplieswithCANICES-3(B)/NMB-3(B)
CE Declaration of Conformity
We, Belkin International, Inc., declare under our sole responsibility that the F8J055, to which
thisdeclarationrelates,isinconformitywithEMCDirective2004/108/EC,LowVoltage
Directive2006/95/ECEnergyDirective2005/32/EC&2009/125/ECRoHSDirective2011/65/
EU(Recast).
INFORMATION

TuneCast®Auto LIVE 12
SECTIONS 1 2 3 6 754Table of Contents 8
We further declare that the product meets the essential requirement of the above
Directives. The limits contain in these articles are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
-Reorientorrelocatethereceivingantenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
INFORMATION

TuneCast®Auto LIVE 13
SECTIONS 1 2 3 6 754Table of Contents 8
INFORMATION
Belkin International, Inc., Limited 1-Year Product Warranty
What this warranty covers.
Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this Belkin product
that the product shall be free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin warrants the Belkin product for one year.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except
for shipping charges for the product). Belkin reserves the right to discontinue any of its
products without notice, and disclaims any limited warranty to repair or replace any such
discontinued products. In the event that Belkin is unable to repair or replace the product
(for example, because it has been discontinued), Belkin will offer either a refund or a
credit toward the purchase of another product from Belkin.com in an amount equal to the
purchase price of the product as evidenced on the original purchase receipt as discounted
by its natural use.

TuneCast®Auto LIVE 14
SECTIONS 1 2 3 6 754Table of Contents
INFORMATION
8
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to Belkin
for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin
determines that the Belkin product has been improperly installed, altered in any way, or
tamperedwith.TheBelkinProductWarrantydoesnotprotectagainstactsofGodsuch
as flood, lightning, earthquake, war, vandalism, theft, normal-use wear and tear, erosion,
depletion, obsolescence, abuse, damage due to low voltage disturbances (i.e. brownouts or
sags), non-authorized program, or system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin International, Inc., at 12045 E. Waterfront Drive, Playa Vista, CA 90094,
Attn: Customer Service, or call (800)-223-5546, within 15 days of the Occurrence. Be
prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. YourBelkinCustomerServiceRepresentativewilltheninstructyouonhowtoforward
your receipt and Belkin product and how to proceed with your claim.

TuneCast®Auto LIVE 15
SECTIONS 1 2 3 6 754Table of Contents
INFORMATION
8
Belkin reserves the right to review the damaged Belkin product. All costs of shipping the
Belkin product to Belkin for inspection shall be borne solely by the purchaser. If Belkin
determines, in its sole discretion, that it is impractical to ship the damaged equipment to
Belkin, Belkin may designate, in its sole discretion, an equipment repair facility to inspect
and estimate the cost to repair such equipment. The cost, if any, of shipping the equipment
to and from such repair facility and of such estimate shall be borne solely by the purchaser.
Damaged equipment must remain available for inspection until the claim is finalized.
Whenever claims are settled, Belkin reserves the right to be subrogated under any existing
insurance policies the purchaser may have.
How state law relates to the warranty.
THISWARRANTYCONTAINSTHESOLEWARRANTYOFBELKIN.THEREARENOOTHER
WARRANTIES,EXPRESSEDOR,EXCEPTASREQUIREDBYLAW,IMPLIED,INCLUDING
THEIMPLIEDWARRANTYORCONDITIONOFQUALITY,MERCHANTABILITYORFITNESS
FORAPARTICULARPURPOSE,ANDSUCHIMPLIEDWARRANTIES,IFANY,ARELIMITED
INDURATIONTOTHETERMOFTHISWARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above
limitations may not apply to you.
INNOEVENTSHALLBELKINBELIABLEFORINCIDENTAL,SPECIAL,DIRECT,INDIRECT,
CONSEQUENTIALORMULTIPLEDAMAGESSUCHAS,BUTNOTLIMITEDTO,LOST
BUSINESSORPROFITSARISINGOUTOFTHESALEORUSEOFANYBELKINPRODUCT,
EVENIFADVISEDOFTHEPOSSIBILITYOFSUCHDAMAGES.
This warranty gives you specific legal rights, and you may also have other rights, which may
vary from state to state. Some states do not allow the exclusion or limitation of incidental,
consequential, or other damages, so the above limitations may not apply to you.

TuneCast®Auto LIVE ii
SECTIONS 1 2 3 6 754 8
Table des matières
TABLE DES MATIÈRES
1 Introduction .................................................16
2 Téléchargement de l'application ClearScan LIVE .................17
3 Branchement de votre TuneCast Auto ...........................18
4 Recherche d'une station FM ouverte ............................19
Utilisation de ClearScan pour trouver la meilleure fréquence
(recommandée) .................................................19
Recherchemanuelled'unestation ................................. 20
Mémorisation et sélection de stations ...............................21
5 Utilisez du bouton PRO pour amplifier le son .................... 22
6 Comment tirer le maximum de votre TuneCast Auto.............. 23
Chargement de votre iPhone ou iPod .............................. 23
Optimisation de la qualité sonore de votre TuneCast Auto.............. 23
7 Consignes de sécurité ....................................... 24
8 Information ................................................. 25

TuneCast®Auto LIVE 16
SECTIONS
Table des matières 1 2 3 6 754 8
1
INTRODUCTION
TuneCast Auto charge votre iPod pendant que vous écoutez votre musique sur la radio FM de
votre voiture. Dorénavant, vous pouvez utiliser votre iPhone ou iPod touch pour contrôler votre
TuneCast Auto. Il suffit de télécharger gratuitement l'application ClearScan LIVE à partir de
iTunes Store (voir les instructions à la page suivante).

TuneCast®Auto LIVE 17
SECTIONS
Table des matières 123 6 754 8
TÉLÉCHARGEMENT DE L'APPLICATION CLEARSCAN LIVE
ClearScan LIVE vous permet d'utiliser les commandes de votre TuneCast Auto LIVE
directement à partir de votre iPhone ou iPod touch. ClearScan LIVE donne également de
meilleurs résultats en :
• UtilisantvotreemplacementGPSpourtrouverlameilleurestationFMdansvotresecteur
• Recommandantdesstationsouvertesqued'autrespersonnesutilisentdansvotresecteur
Téléchargez ClearScan LIVE à partir du site iTunes Store. Pour de plus amples renseignements
à ce sujet, suivez les instructions de la section Aide de l'application.
