Belkin F5U101 User manual

P73153 F5U101
4 Port Hub
User Manual
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 1

P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 2

The Belkin USB 4 Port Hub is a full-featured Universal Serial
Bus (USB) hub. USB 4 Port Hub provides one upstream port
and four downstream ports to the user. It supports both full
speed (12Mbps) and low speed (1.5Mbps) devices such as
keyboards, mice, joysticks and speakers. The USB 4 Port Hub
allows users to attach and use computer peripherals to their
computers without the need to reboot or run setup. Unlike
many other hubs, the USB 4 Port Hub is both bus- and self-
powered. The self-powered feature allows for the cascading
of devices with additional hubs allowing up to 127 different
devices to be connected to a single USB port. The USB 4
Port Hub also includes per-port power ready LEDs for the
user. For detailed specifications please refer to the section
entitled "Technical Specifications". Also included is a 6 ft.
(1.8m) USB Device Cable for immediate connection.
Introduction
1
Please read this manual thoroughly and follow the
procedures to prevent any damage to the 4 Port
Hub and/or to the connected devices.
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 1

Features
2
• Supports both OHCI (Open Host Controller Interface)
and UHCI (Universal Host Controller Interface)
• Provides four downstream ports
• Both self-powered and bus-powered mode are
automatically detected
• Per-port overcurrent detection and protection
• Per-port power LED indicators
• Hot insertion capabilities
• Universal Serial Bus (USB) Compliant
• Can be used as a module to the Belkin BusStation™
Package Contents
(1) USB 4 Port Hub: F5U101
(1) USB Device Cable 6 ft. (1.8m): F3U133-06
(1) Universal Power Adapter:
Input: 120V AC
Output: DC 5V, 2.6A Min.
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 2

Technical Specifications
3
Upstream Ports: (1)
Downstream Ports: (4)
LED: (1) Powered
(4) Downstream Power
Per-Port Voltage: DC +5V
Per-Port Current: 500mA (max)
Power Mode (Autodetect): Self-powered or Bus-powered
Operation Temperature: 41ºF~104ºF (5°C~40°C)
Stock Temperature: -4ºF~219ºF (-20°C~60°C)
Humidity: 0%~80%RH noncondensing
Enclosure: Plastic
Weight: 5.57oz. (158g)
Dimension (LxWxH): 4.25" x 3.75" x 1.25"
(108mm x 95mm x 32mm)
Power Supply: DC 5V 2.6A
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 3

Product Detail
4
Figure-1
Per-port power LED
Powered LED
Sleeve
DC 5V 2.6A
Power Jack
Root Port Downstream
Ports
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 4

Hardware Installation
5
USB Cable
There are two types of USB connectors; one is the USB-A, the
other USB-B. The included USB cable is 6 ft. (1.8m) in length.
Power Mode Setting
The Belkin USB 4 Port Hub can operate either with or
without the included AC adapter. When used in bus-powered
mode, without the AC adapter, the hub will supply each
device attached to it a maximum of DC +5V, 100mA power.
This should be sufficient for most mice, joysticks and other
low-power devices. In self-powered mode, using the AC
adapter, the USB 4 Port Hub provides a maximum DC +5V,
500mA to each downstream port, allowing for connection to
other hubs or power-hungry devices.
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 5

Hardware Installation (continued)
6
1. Attach the AC adapter to the power jack on the hub and
power source. While the AC adapter is optional in most
situations, it is recommended that it be used when installing
the USB hub. Once it is determined that the devices are
working properly unplug the AC adapter. If the devices
continue to work properly you will not need the AC adapter.
If they cease to function you will need the AC adapter.
2. Connect the USB-A connector (please refer to Figure-2) of
the USB cable into the downstream port of the PC or one
downstream port of another hub.
3. Connect the USB-B connector (please refer to Figure-3) of
the USB cable into the upstream port of the USB 4 Port Hub
4. Connect the USB-A connector of the USB device, such as a
mouse, keyboard, etc. into any of the downstream ports of
the USB 4 Port Hub.
Note: This can also be used as a module
to the Belkin BusStation™. Simply
remove the attached sleeve and
slide the hub into one of the
BusStation™bays.
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 6

Hardware Installation (continued)
7
PORT 1 PORT 2
PORT 3
ROOT PORT
PORT 4
No software is needed for Windows®98; however, for some
versions of Windows®95 release 2 you will need to use the
software provided by the manufacturer of the device you
want to connect.
Software Installation
Figure-2
USB-A connector Figure-3
USB-B connector
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 7

Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton CA 90220,
declare under our sole responsibility that the product:
F5U101
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility that the F5U101, to which this
declaration relates, is in conformity with Generic Emissions Standard EN50081-1 and with
Generic Immunity Standard EN50082-1 1992.
Belkin Components Limited Lifetime Product Warranty
Belkin Components warrants this product against defects in materials and workmanship for
its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at
no charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse,
or misapplication; if the product has been modified without the written permission of Belkin;
or if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension, or
addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER
LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME,
GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM
OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential damages
or exclusions of implied warranties, so the above limitations of exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also have other rights that
vary from state to state.
P73153/F5U101/US/man.qxd 1/7/00 5:16 PM Page 8
