USER GUIDE
MODEL CJTG00499B-120
Multi-Cyclonic Vacuum

Thank you for purchasing a BENNETT READ
POWER UP PET vacuum.
Your POWER UP PET vacuum incorporates the latest technological
advances in home cleaning systems. It imitates the most powerful
forces of nature in a sleek, elegant cleaning system to ensure that
your home is easily and properly cleaned.
Your new vacuum is manufactured to a high standard of quality and
is backed up by a 12 month guarantee by Tevo.
Should you need any support from us, please visit
www.tevo.co.za or call 0861 77 88 88.
PLEASE KEEP THIS USER GUIDE IN A SAFE PLACE AND
READ IT CAREFULLY BEFORE USING YOUR BENNETT READ
POWER UP PET VACUUM FOR THE FIRST TIME.
1

IMPORTANT SAFETY INSTRUCTIONS
2
When using an electrical appliance, basic precautions should be observed,
including the following:
To reduce the risk of fire, electric shock, or injury follow these instructions.
WARNING:
!
• Use indoors only
• For dry pick-up only
• Do not use with damaged cord or plug
• If appliance is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, return it to a service agent
• Do not pull or carry by cord, use cord as a handle, close door on cord, pull cord around
sharp corners or edges, run appliance over cord, or expose cord to heated surfaces
• Do not unplug by pulling on cord. Unplug by grasping plug
• Do not handle plug or appliance with wet hands
• Do not expose hair, loose clothing, fingers or body parts to openings or moving parts
• Do not pick up hot or burning objects such as cigarettes, matches, or hot ashes
• Do not pick up flammable or combustible materials (lighter fluid, petrol, kerosene, etc.) or
use in the presence of explosive liquids or vapour
• Do not use appliance in an enclosed space filled with vapours given off by oil based
paints, paint thinners, some moth proofing substances, flammable dust, or other explosive
or toxic vapours
• Not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for
their safety
• Young children should be supervised to ensure that they do not play with the appliance
• Unplug from outlet when not in use
• Do not put any object into opening
• Remove plug from electrical outlet before cleaning or maintaining the appliance
• If the supply electric cord is damaged, it must be replaced by the manufacturer or its
service agent in order to avoid danger

3
For operation on a 220-240 volt A.C. 50/60 Hz Power supply only.
SAVE THESE INSTRUCTIONS. THIS MODEL IS FOR HOUSEHOLD USE ONLY.
IMPORTANT:
!
• Do not pick up toxic materials (chlorine, bleach, ammonia, drain cleaner, petrol, etc.)
• Do not use for any purpose other than described in this User Guide
• Use only manufacturer’s recommended attachments
• Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may
reduce air flow
• Keep appliance on a level surface
• Turn off all controls before unplugging
• Be extra careful when cleaning stairs
• This appliance is provided with double insulation. Use only identical replacement parts
• Do not use without the filters in place
• Pay close attention when working around children and animals

PRODUCT VIEW
4
1. Handle
2. Hand-Held Pet Turbobrush
3. Crevice Tool
4. Extension Pipe
5. Extension Pipe Holder
6. HEPA Filter inside
7. Height Adjustment Control
8. High Speed Turbobrush
9. Carry Handle
10. Dirt Tank Release
11. Pre-motor Filter Release Catch
12. Multi-cyclonic Filter
13. Dirt Tank
14. Headlight
15. Handle-Release Pedal
1
9
10
11
12
13
14
15
2
4
5
6
7
8
3

5
16. Quick-Release
Cord Reel
17. Power Cord
18. Variable Suction
Control Valve
19. Dusting Brush
20. On/Off Power
Switch
21. Hose Wand
22. Flex Hose
16
17
18
19
20
21
22

6
The only tool you’ll need to assemble your vacuum cleaner is a medium
sized flat-head screwdriver.
Do not plug in your vacuum cleaner until you are familiar with all
instructions and operating procedures.
Before using your vacuum, make sure that the dirt container is in the
locked position and that all filters (pre-motor and HEPA post- motor) are
in place. Do not operate your vacuum without these filters.
CAUTION:
CAUTION:
!
!
1. Locate the handle inside the box.
Remove the screw packet taped
to the handle
2. Stand the vacuum upright and from
the top of the unit, slide the base of
the handle firmly into the opening at
the top of the vacuum body
3. Push the handle all the way into the
opening and ensure that the handle
fits firmly to the vacuum body and is
unable to turn
4. Insert the provided screw into the
existing hole, attaching the handle
to the body of the vacuum. Tighten
securely with a screwdriver
1. Slide the extension wand and
crevice tool into the storage clip
on side of vacuum
2. Slide the dusting brush into the
storage clip on back of vacuum
3. Store the Pet TurboBrush on the
back of the handle by lining up
the TurboBrush with the hook on
the base of the holder then push
forward to snap into place
Attach handle to vacuum
Attach tools and accessories
ASSEMBLY:
2
3
3

OPERATIONS
7
The Power Switch is located at the back of the vacuum. Gently press the Power switch with
your foot to switch the machine on and press again to switch off. For the exact location of
the Power Switch please refer to page 5 of this guide.
Press the handle-release pedal (located on the lower left side of the vacuum)
with your foot to place your vacuum into the cleaning position.
The rotating floor brush on your vacuum can be adjusted to clean several floor surfaces.
Bare Floors - For non-carpeted, indoor surfaces
Lowest Setting - For flat pile carpets
Medium Setting - For short and medium pile carpets
High Setting - For Medium to high pile carpets
Max Setting - For plush pile carpet
For above-floor cleaning, the floor brush will continue to rotate but
is raised off the floor. To prevent carpet damage, do not lean on the
vacuum or let the powerfoot tilt forward.
To avoid personal injury and to prevent the cleaner from falling when
cleaning stairs, always place it at the bottom of the stairs.
For optimal cleaning performance, adjust to the lowest practical setting.
If your cleaner is difficult to push or if the rotating brush is grinding into
the carpet too heavily, adjust to the next higher setting. Always ensure
the machine is in the Upright position before adjusting the height setting.
Before cleaning under low
furniture, check area first for
objects that might harm the unit
or block the vacuum hose.
NOTICE:
CAUTION:
NOTE:
TIP
!
!
!
1. Upright – For storage and above-floor
cleaning with tools
2. Normal Cleaning – Press handle-release
pedal once. Position used for most household
floor cleaning tasks
3. Low Cleaning – Use for reaching under low
furniture such as tables, chairs or beds. Avoid
dropping the handle too low, always ensure
the front Turbo-brush stays in contact with the
surface you are vacuuming
1. Turn height adjustment knob to desired setting:
POWER SWITCH
HANDLE POSITIONS
HEIGHT ADJUSTMENT

8
Your vacuum is not only a powerful carpet and rug cleaner, it’s also a versatile above-floor
vacuum cleaner when you select one of the special tools.
Dusting Brush:
Use the dusting brush to dust furniture,
blinds, books, lamps, shelves
and baseboards
Crevice Tool:
Use in tight narrow spaces
Extension Wand:
Use with desired attachment
for a longer reach
Hose Wand:
Use with desired attachment for a longer
reach or for cleaning hard to reach places
TurboBrush Pet:
Use rotating brush action for small flat
areas such as cushions and beds
Press gently down and pull towards you in a raking motion.
Too much pressure will cause the brush to stop rotating.
Hair, string and small objects can block
the vacuum hose or tools. Check them
occasionally for obstructions.
These tools are designed to remove pet hair
from upholstered or carpeted surfaces. They
should not be used on pets.
NOTICE:
NOTICE:
TIP
!
!
1. To move your vacuum cleaner
from room to room, put the handle
in the upright position, tilt the
cleaner back on its rear wheels
and push forward
2. The cleaner can also be moved
by using the carry handle
1. Raise the handle to the
upright position
2. Grasp the hose wand handle to
separate from hose wand base
3. Attach tools by firmly pushing
onto vacuum hose, hose wand or
extension wand. Be sure the hose
and tool fit snuggly together by
twisting tightly
TRANSPORTING CLEANER
SPECIAL ON-BOARD TOOLS
2
12

9
To maximize your cleaning performance and extend the life of your vacuum, it is very
important that you empty your dirt container and check and clean your filters frequently.
Perform the following maintenance steps:
To reduce the risk of electric shock, turn power switch OFF and
disconnect plug from electrical outlet before performing maintenance
or troubleshooting checks.
To maximize cleaning performance, check and clean or replace
all filters as suggested.
The rotating floor brush continues to rotate while tools are in use. To
reduce the risk of injury from moving parts, always move the cleaner with
the carrying handle. Always place vacuum cleaner on the floor with handle
in upright position when using tools. Never place your fingers under the
cleaner when it is running. Never place vacuum foot on furniture or uneven
surfaces. Do not place vacuum cleaner close enough to objects to pull them
into rotating brush.
WARNING:
TIP
CAUTION:
TIP
!
!
!
1. To use your vacuum, remove the cord and
plug it into an electrical outlet. For your
convenience, there is a quick-release cord
wrap for easy cord removal. There is also
a cord clip that is located at the back of the
upper handle where you can attach the cord
while vacuuming
2. When you are finished cleaning, turn vacuum
cleaner off
3. Unplug power cord by grasping the plug
(NOT the cord) and disconnect from outlet
4. Loop power cord around cord wraps on back
of vacuum cleaner. Be sure to first return the
quick-release cord reel back to its original
position before wrapping the cord
1. Empty the dirt container when the dirt reaches the “Full” line on the container,
or more frequently to prevent overfills. For best performance, empty after each use
2. Check the pre-motor filter and post-motor HEPA filter at least twice a month,
clean or replace as needed
3. Replace the post-motor HEPA filter every three to six months
NOTE: More frequent filter cleaning may be necessary if you are vacuuming new
carpet, fine dust, or have allergy concerns. Follow the instructions on the following
pages to perform these simple maintenance steps
POWER CORD USAGE
MAINTENANCE AND CARE

10
The dirt container should to be emptied before the dirt reaches the “Full” line on the container.
1. Unplug the vacuum
from electrical outlet
2. Lift the Dirt Tank from
the vacuum cleaner
body by lifting the Dirt
Tank Release upwards
and pulling the Dirt
Tank towards you
3. The dirt release catch
is located at the back
of the Dirt Tank. Hold
the dirt tank over a
dust bin and press the
release catch from
the top downwards to
release the bottom lid
4. Shake the Dirt Tank
or gently tap it on the
side to ensure all dirt
and dust is released
into the dust bin
5. Close the bottom lid
and return the Dirt
Tank to the Vacuum
cleaner by inserting
the bottom part first
and then gently clip
the top back in place
1. Unplug the vacuum
from electrical outlet
2. The pre-motor filter
protects the motor
from dirt particles.
It is located in the
top of the Dirt Tank.
Remove the Dirt Tank
as explained in the
previous section. Lift
the front clip (located
underneath the Dirt
Tank Release) to
remove the foam filter
and clean it
3. The post-motor HEPA
filter assists in the
filtration process to
return clean air to the
room. It is located
in the main body of
the vacuum cleaner
underneath the Dirt
Tank. With the Dirt
Tank removed, turn
the dial clockwise
and lift up. Remove
the HEPA filter by
grasping the tab and
pulling upwards. To
clean the HEPA filter
gently tap it on a hard
surface or the side of
the dust bin. DO NOT
WET THE HEPA FILTER
EMPTY DIRT CONTAINER
CLEANING THE PRE-MOTOR
AND POST-MOTOR HEPA FILTER
Emptying the dirt container after every use will help prevent over-filling
and ensure that the vacuum is ready to go the next time you clean.
The pre-motor filter may be hand washed in cold water.
Rinse well and air dry thoroughly before replacing.
The post-motor filter is a white, pleated HEPA filter. THIS FILTER IS NOT
WASHABLE and must be replaced when it becomes dirty.
NOTE:
NOTE:
NOTE:
!
!
!
2
23
3

11
You should check your vacuum cleaner’s rotating floor brush and drive belt regularly for wear
or damage. You should also clean the brush and brush ends of string, hair and carpet fibers.
This type of debris can wrap around the brush and hamper its ability to effectively clean your
carpet. Also remove any debris that has accumulated under the brush cover.
1. Unplug the vacuum from
electrical outlet
2. Place handle in low position
and turn vacuum cleaner over
so bottom side is facing up
3. Remove the five screws marked
on the picture to the right and gently
lift the base cover from the machine
4. Grasp rotating floor brush at both
ends and lift
5. Clean string, hair and other debris
from rotating floor brush, paying
particular attention to brush ends
6. Clean string, hair and other
debris from motor pulley and
drive belt areas
7. Check drive belt carefully
for wear, cuts or stressed areas
8. Check air passageway for
obstructions. Remove debris
from this area
9. Insert front edge of the brush
cover and rotate into place.
Fasten the latches and replace
the five screws
CHECK ROTATING FLOOR BRUSH AND DRIVE BELT
This product is intended for household use only and not for commercial
or industrial use. Vacuuming of dust from products like plaster, concrete
or ashes will damage the motor and void the warranty.
Do not operate cleaner with damp or wet filters
or without all filters in place.
Motor Pulley
Air Passageway
To reduce the risk of injury from moving parts, turn vacuum
cleaner off and disconnect power plug from electrical outlet.
NOTICE:
WARNING:
WARNING:
!
!
!
3
4

12
The Pet Turbobrush should be checked regularly for blockages or debris wrapping
around the brush.
1. Unplug the vacuum from electrical outlet
2. Remove rotating floor brush from vacuum
cleaner (Steps 1-4 of check rotating floor
brush and drive belt), remove and discard
old drive belt
3. Place new drive belt over motor pulley and
loop other end over rotating floor brush in
the space between the bristles
4. Pull the rotating floor brush firmly into
position, stretching the drive belt, and
place ends of rotating floor brush down
into the slots on sides as shown. Alignment
of brush ends in slots may be necessary to
fully insert the brush
5. Turn rotating floor brush by hand several
times in the direction of motor pulley. If
properly installed, drive belt will center
itself on rotating brush crown
6. Insert front edge of brush cover and rotate
into place. Snap the front latches in place
and replace the five screws
1. Remove the Pet Turbobrush from hose or
back of vacuum
2. Twist collar anticlockwise to unlock the
top cover. Lift the back end slightly and pull
the top cover backward to release the front
holding pins. Do not use excessive force,
the top cover should slide out easily
3. Remove the brush from the belt and
clean debris
4. Replace the brush inside the belt and
place ends into slots on sides as shown
5. Reposition top cover making sure to line
up inside tabs at the front with the opening
on the cover before closing. Twist collar
clockwise to lock
REPLACE DRIVE BELT
MAINTAINING PET TURBO BRUSH
It is important that you use only genuine Bennett Read replacement belts.
Generic belts may not meet the exact specifications required to keep your
vacuum operating at its peak performance. The use of unbranded belts
could lead to early failure of the vacuum and could void your warranty.
NOTE:
!
Motor Pulley
2
4

13
Low suction or poor pick-up may be due to a clog in the vacuum cleaner.
If you notice a change in the sound of the motor, check for clogs.
1. Unplug the vacuum from electrical outlet
2. Empty Dirt Container
3. Check upper tank for build up or blockages
4. If you notice blockages in the upper tank, remove the inner cyclone
(see section below “Cleaning the upper tank”)
5. Grasp the hose wand and separate it from the hose wand base.
Check for blockages in the base, the wand or in the hose
6. If the clog persists, follow the instructions for “Checking the
rotating floor brush and drive belt” on pages 11 and 12 and
inspect the air passageway for obstructions
1. Remove the lid of the Dirt Tank by twisting the lid to
the “unlock” position. Separate the Dirt Tank and
cyclone assembly
2. Wipe the inside of the upper tank and the cyclone
assembly with a damp cloth moistened with water
or a mild cleaning solution
3. To thoroughly clean the filtration disk and inner cyclone,
turn the entire cyclone assembly upside-down, then turn the
filtration disk anticlockwise to release. Lift the inner cyclone
and filtration disk up to remove
4. The inner cyclone and filtration disk may be washed using
a mild detergent. Be sure it is completely dry before
reassembling or you may damage the unit.
5. Once cleaning is complete, reassemble by aligning
the slots on the inner cyclone with the tabs of the centre
column as shown on the right. Then place the filtration
disk over the centre column and slide it straight down on
the top of the inner cyclone. Line up the tabs with the slots
and turn clockwise to lock
CLEARING CLOGS
CLEANING THE UPPER TANK
2
1
3 4
5
5

14
USE THIS TROUBLESHOOTING GUIDE AS A FIRST STEP TO RESOLVE ANY
PROBLEMS YOU MAY BE EXPERIENCING.
Any faults not covered in the below table should be resolved by an authorized
service representative.
Other maintenance or service not included in the manual should be performed
by an authorized service representative.
Thank you for selecting a BENNETT READ product.
TROUBLESHOOTING:
To reduce the risk of electric shock, turn power OFF and disconnect plug
from electrical outlet before performing maintenance or troubleshooting.
WARNING:
!
PROBLEM POSSIBLE CAUSES REMEDIES
Vacuum cleaner
won’t run
1. Power cord not plugged in
2. Damaged power cord
1. Check electrical plug
2. Unplug, check for damage, replace if
necessary
Vacuum cleaner
and tools won’t pick
up dirt
1. Incorrect height adjustment
2. Hose not attached to suction
opening
3. Flex Hose not securely attached
4. Crack or hole in hose
5. Broken or worn drive belt
6. Rotating floor brush bristles worn
7. Rotating floor brush jammed
8. Blockage in vacuum
9. Dirt container full
10. Dirt container not installed
properly
11. Filters are dirty
12. Turbobrush is stuck or
debris is wrapped around
the brush roll
1. Adjust Height Adjustment Control to
correct height
2. Firmly push hose wand into hose
wand base
3. Make sure Flex Hose is snapped into
locked position
4. Check hose and replace if needed
5. Replace drive belt, see page 11 & 12
6. Replace brush
7. Remove brush and clean debris from
brush ends
8. Clear clogs, see page 13
9. Empty dirt container
10. Position correctly and lock in place
11. Check pre-motor and post-motor filters
12. See page 12 for maintaining
Turbobrush
Vacuum cleaner is
difficult to push
1. Incorrect height setting 1. Adjust Height Adjustment Control to
correct height setting
Visible dirt escaping
from cleaner
1. Dirt Container full
2. Filters missing or installed
incorrectly
3. Dirt Container installed
incorrectly
1. Empty Dirt Container
2. Check pre-motor and post-motor
filters for correct installation
3. Remove and re-insert dirt
container correctly

15
REPLACEMENTS PARTS
The items below are available for purchase as accessories for your BENNETT READ
POWER UP PET multi-cyclonic vacuum. To purchase, contact TEVO customer care in your area.
ITEM PART NO. PART NAME
1. 32074 Style 7/9/10/12/14 Drive Belt
2. 203-1073 Style 7/8/14 Pre-Motor Foam Filter
3. 3091 Style 8/14 HEPA Media Post-Motor Filter
ITEM PART NO. PART NAME
1. 203-1056 Crevice Tool
2. 203-1059 Dusting Brush
3. 203-1290 Pet Turbobrush
4. 203-1068 Extension Wand
1
1 2 3
2 3
4
ADDITIONAL ACCESSORIES

16
CONSUMER GUARANTEE:
The BENNETT READ Power UP PET multi-cyclonic vacuum has a 12 month
product guarantee from TEVO (PTY) Ltd.
TEVO will replace or repair, at TEVO’s option, any defective or malfunctioning
part due to manufacturing defect, free of charge from the date of purchase by
the original purchaser for 12 months.
This guarantee applies to product used for personal or domestic use only, and
specifically excludes any malfunction or defect arising from commercial use.
This guarantee does not apply to routine maintenance components such as
filters and brushes. Damage or malfunction caused by negligence, abuse,
unauthorized repair, or use not in accordance with the user guide is not
covered.
TEVO is not liable for incidental or consequential damages of any nature
associated with the use of this product. TEVO’s liability will not exceed the
purchase price of this product.
Guarantee and service enquiries can be made by contacting:
TEVO (Pty) Ltd
Gauteng 086 111 8386 or 012 740 5000
Durban [phone]
Cape Town [phone]/9
Customer Service Help Line 0861 77 88 88
www.tevo.co.za

Brought to you by:
0861 77 88 88
www.tevo.co.za | [e-mail]
Multi-Cyclonic Vacuum
