Bennett Read MULTI-FORCE User manual

USER GUIDE
MULTI-FORCE
THE PREMIUM CYLINDER VACUUM
WITH 13 CYCLONES FOR NO LOSS OF SUCTION*

*Provided the dirt container does not contain dirt past the “Full” line
& all lters are properly maintained (see pages 6 - 10 for details).

1
Thank you for purchasing a BENNETT READ
MULTI-FORCE vacuum.
Your MULTI-FORCE vacuum incorporates the latest technological
advances in home cleaning systems. It imitates the most powerful
forces of nature in a sleek, elegant cleaning system to ensure that
your home is easily and properly cleaned.
It is manufactured to the highest quality and is backed by a one year
guarantee by Tevo. If you register your guarantee online within 14
days of purchase, we will extend the guarantee to 2 years. To activate
your extended guarantee, scan the QR code on the front cover of this
user guide, tap on the link and complete the online form. Alternatively,
visit www.tevo.co.za, click the “Register guarantee” tab at the top of
the page, then complete the form provided. We also stand behind it
with a knowledgeable, dedicated Customer Care department, so
should you ever have a problem, you'll receive fast, considerate
assistance.
Should you need any support from us, please visit: www.tevo.co.za or
call 0861 77 88 88.
PLEASE KEEP THIS USER GUIDE IN A SAFE PLACE AND
READ IT CAREFULLY BEFORE USING YOUR BENNETT READ
MULTI-FORCE VACUUM FOR THE FIRST TIME.

2
• Your MULTI-FORCE is for household use
only
• Use only indoors on dry surfaces
• Do not immerse any part of the system in
water or any other liquids
• Do not operate the system if the appliance
or any other part of the system has been
dropped or damaged
• Do not disassemble or attempt to repair
your MULTI-FORCE. Return the unit for
examination and repair
• Do not use the vacuum to pick up
flammable or combustible liquids such as
gasoline and do not use it in areas where
they may be present
• Do not use the vacuum to pick up anything
that is burning or smoking such as
cigarettes, matches or hot ashes
• Use extra care when cleaning on stairs
• Do not use your MULTI-FORCE without
the filters in place
• Do not leave your MULTI-FORCE
plugged in when unattended
• Unplug the electrical cord when not in
use and before cleaning or servicing
• Keep loose clothing, hair & all body parts
away from openings & moving parts
• Not intended for use by persons (including
children) with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge
• Keep out of reach of children
• Do not allow your MULTI-FORCE to be
used as a toy
• Extra care is necessary when using your
MULTI-FORCE vacuum near children,
animals or plants
• Do not pull the electrical cord or use the
cord as a handle
• Take care to not close doors on the
electrical cord and do not pull the cord
around sharp edges or corners
• Do not run the vacuum over it’s own
electrical cord
• Do not allow the cord to touch hot surfaces
• Turn off all controls before unplugging
from the electrical outlet
• To unplug your MULTI-FORCE, grasp the
plug. Do not unplug by pulling on the
electrical cord
• Do not handle the plug or vacuum with
wet hands
• Do not operate your MULTI-FORCE while
barefoot
• Do not put any objects into the vacuum
openings
• Do not use your MULTI-FORCE while any
opening is blocked
•Keep your MULTI-FORCE free of dust, lint,
hair or anything else which may reduce
airflow
• Keep your work area well lit
• Using improper voltage may result in
damage to the motor and possible injury
to the user. The correct voltage is listed
on the rating label. For operation on
220-240V, 50/60Hz power supply only
• Only use the accessories supplied with
your MULTI-FORCE vacuum
• Only use spare parts recommended by
Tevo
• Store your MULTI-FORCE indoors in a
cool, dry area
IMPORTANT SAFETY INSTRUCTIONS
BASIC SAFETY PRECAUTIONS
SHOULD BE OBSERVED WHEN
USING YOUR MULTI-FORCE,
INCLUDING THE FOLLOWING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY:
!WARNING
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
FOR HOUSEHOLD USE ONLY

3
PRODUCT VIEW
1. Multi-surface floor nozzle
2. Brush switch
3. 2-Piece extension wand
4. Dusting brush/Crevice tool
5. Airflow regulator
6. Handle
7. Hose
8. Carry handle
9. Dirt container release button
10. Hose connector
11. Suction inlet
12. Power button
13. Multi-Cyclonic dirt separator
14. Dirt container
15. Dirt container emptying
catch (at back)
16. Auto-cord rewind button
17. Post-motor filter door
18. Post-motor Microparticle filter
19. Power cord and plug
20. Floor nozzle storage slot
21. Dirt container filter (inside lid)
22. Dirt container filter latch
Do not plug in your vacuum cleaner
until you are familiar with all
instructions and operating
procedures.
!CAUTION:
1
3
6
7
8
10
13
11
14
5
2
16
9
20
21
17
19
12
4
15
22
18

4
ASSEMBLY
1. Connect the hose (7) to the vacuum by
inserting the hose connector (10) into
the suction inlet (11) until it clicks into
place
2. Connect the 2-Piece extension wand by
pushing the small end of one piece into
the large end of the other piece. Then
twist slightly to fasten
3. Connect the hose handle (6) to the end
of the extension wand and twist slightly
to tighten
4. Connect the floor nozzle (1) to the other
end of the extension wand and twist
slightly to tighten
5. Once assembled, you can store your
vacuum by inserting the storage clip
(located on the back of the floor nozzle)
into the storage slot (20) on the rear of
the vacuum
OPERATIONS
POWER CORD
The power cord (19) is located at the rear
of the vacuum. Gently pull the power cord
out. Stop pulling the cord when the yellow
line is visible. There is also a red line which
indicates the end of the usable cord. Do
not pull the power cord out beyond the red
line.
AUTO-CORD REWIND
Your vacuum is equipped with an
automatic cord rewind. When cleaning is
finished, press the power button to switch
the vacuum OFF and grasp the plug to
disconnect from the electrical outlet. Hold
the plug and press the auto cord rewind
button to rewind the cord automatically.
POWER BUTTON
Turn the power ON or OFF by pressing
lightly downward on the power button.
1.
2.
3.
4.
The power cord retracts very quickly.
Take care to avoid injury.
!CAUTION:
AUTO
CORD
REWIND
POWER
BUTTON

Before cleaning under low furniture, check the
area first for objects that might harm the unit or
block the hose.
TIP:
AIRFLOW REGULATOR
Open the airflow regulator by sliding the
regulator down towards the extension
wand to an open position. This will reduce
the suction power for vacuuming delicate
fabrics. For full suction power, close the
air-flow regulator by sliding the regulator
up to the closed position.
5
OPERATIONS
SPECIAL TOOLS
Your MULTI-FORCE vacuum is not only a
powerful carpet and rug cleaner, it’s also a
versatile bare floor and above floor vacuum
cleaner when you select one of the special
tools.
FLOOR NOZZLE
Use to vacuum carpets, rugs and bare
floors. The swivel head turns to get into
tight spaces and fits under cabinets
1. To vacuum carpets and rugs, push the
brush switch to the carpet position
[ ]. This will pull the brushes up
into the floor nozzle
2. To vacuum bare floors, push the brush
switch to the bare floor position
[ ]. This will extend the brushes
down from the floor nozzle
DUSTING BRUSH/CREVICE TOOL
Use the dusting brush to clean blinds,
curtains, draperies, cushions and fabrics.
Use the crevice tool in narrow spaces.
Brush up
1.
Brush down
2.
Airflow regulator
Dusting brush/Crevice tool

To avoid injury, turn the vacuum OFF and
unplug the cord from the wall when not in use.
!WARNING:
Hair, string and small objects can block the
hose and tools. Check them occasionally for
obstructions.
TIP:
MAINTENANCE AND CARE
To reduce the risk of injury from moving parts
and/or electrical shock, turn the Power Switch
OFF and disconnect the plug from the electrical
outlet before performing maintenance checks.
!WARNING:
EMPTYING THE DIRT CONTAINER
Empty the dirt container as soon as the dirt
reaches the “FULL” line on the sides of the
dirt container.
1. Unplug the vacuum from the electrical
outlet
2. Remove hose by pressing the release
button and pulling the hose connector
out from the suction inlet. Set hose aside
3. Press the dirt container release button (9)
and lift up to remove the dirt container
4. Choose an emptying method (method
#2 is recommended for allergy sufferers).
Method #1 - Hold the dirt container
over a rubbish bin and push the
emptying button to open the bottom.
Close the bottom after the dirt empties.
Method #2 - Place a plastic bag over
the bottom of the dirt container. Push
the emptying button through the plastic
bag to open the bottom. After the dust
settles, close the bottom and remove the
plastic bag to discard
5. Replace the dirt container by sliding it
back into the vacuum from the top. Then
push down gently on the dirt container
until it clicks back into place.
Make sure that the locking clasp is
properly fastened.
TO MAINTAIN MAXIMUM
PERFORMANCE FROM YOUR
MULTI-FORCE VACUUM,
PERFORM THESE SIMPLE
MAINTENANCE CHECKS:
2.
3.
4.
5.
6

MAINTENANCE OF WASHABLE FILTERS
1.Remove the dirt container by pressing
the dirt container release button (9) and
lifting up on the handle
2.Open the lid of the dirt container by
lifting the dirt container filter catch
3. Lift the Dirt Container Filter (21) out from
above the Multi-Cyclonic Dirt Separator
(13). Once the filter has been removed,
gently wash it in luke-warm water. A mild
detergent may be used. Ensure that the
filter is well rinsed and COMPLETELY DRY
before placing it back into the machine
Never operate your MULTI-FORCE vacuum
without all the filters in place. Doing so may
damage the motor and void the guarantee.
!CAUTION:
7
Never operate your MULTI-FORCE
vacuum with damp or wet filters.
!WARNING:
For maximum cleaning performance, check the
filters often and clean or replace if necessary.
TIP:
Do not use any appliances such as electric
hair dryers, to dry the filters. Filters may only
be AIR DRIED.
!WARNING:
2.
3.
1.

8
Before cleaning under low furniture check the
area first for objects that might harm the unit or
block the hose.
TIP:
Hair, string and small objects can block the hose
and tools. Check the unit occasionally for these
obstructions.
TIP:
Leave the Separator and Dirt Container outside
with top and bottom lid open to speed up the
drying process
TIP:
MAINTENANCE OF THE CYCLONIC
DIRT SEPARATOR
3. Reinstall the Dirt Container Filter (21)
and reassemble the Multi-Cyclonic
Separator and Dirt Container before
inserting back into the machine
1. The Multi-Cyclonic Separator (13) can
be removed from the Dirt Container
(14). Follow the diagram ( )
on the Dirt Container to unlock, then
pull apart from the Multi-Cyclonic
Separator. Follow the diagram to lock
when replacing again.
2. The Separator and Dirt Container can
be washed/rinsed under running tap
water (Figure 2A and 2B).
ENSURE THAT THE SEPARATOR AND
DIRT CONTAINER ARE COMPLETELY
DRY BEFORE RETURING THEM TO
THE MACHINE
2A.
1.
2B.
Never operate your MULTI-FORCE vacuum
without all the filters in place. Doing so may
damage the motor and void the guarantee.
!CAUTION:

9
MAINTENANCE AND CARE
CLEANING THE POST-MOTOR
MICROPARTICLE FILTER
THE POST-MOTOR FILTER ASSISTS IN THE
FILTRATION PROCESS TO RETURN CLEANER
AIR INTO THE ROOM
1.Unplug the vacuum from the electrical
outlet
2.Remove the filter door (17) (located at
the back of the vacuum) by
pressing the tab down. Take care when
removing the filter door
3. Remove the post-motor filter from
the filter door
4. The post-motor filter can be hand
washed in cold water with a mild
detergent. Rinse well and air dry
COMPLETELY before placing back
into the vacuum
5. Replace the post-motor filter into the
filter door. Then replace the assembly
into the machine by placing the two
tabs on the bottom of the filter door into
the notches on the bottom of the
post-motor filter compartment and push
into the vacuum until it clicks into place.
Ensure that the tabs are properly
inserted into the housing
Never operate your MULTI-FORCE
vacuum with damp or wet lters, or
without all lters in place.
!WARNING:
This product is intended for household use only
and not for commercial or industrial use.
Vacuuming of dust from products like plaster,
concrete or ashes will damage the motor and
void the guarantee.
NOTICE:
2.
For maximum cleaning performance check the
filters often and clean or replace them regularly.
TIP:
3.

10
To reduce the risk of electric shock, turn the
Power Switch OFF and disconnect the plug
from the electrical outlet before performing
troubleshooting checks.
!WARNING:
TROUBLESHOOTING
Vacuum cleaner
won't run
PROBLEM POSSIBLE CAUSES REMEDIES
1. Power cord not firmly plugged in 1. Check electrical plug
2. Power button not pressed down 2. Press power button
Vacuum cleaner
doesn't vacuum
effectively 2. Filters are dirty 2. Follow instructions
for cleaning filters
on pages 7 - 9
1. Tools, hose or extension wands
are blocked
1. Remove each part
and check for
blockages
3. Follow instructions
for emptying the dirt
container on page 6
3. Dirt container is full
4. Check that hose
connector is locked
into suction inlet
4. Hose connector not securely
attached to suction inlet
5. Check hose and
replace if necessary
5. Crack or hole in hose
6. Change to closed
6. Air-flow regulator is set to open
7. Clear blockage from
the dirt container
following steps 1 to
7 at the top of this
page.
7. Blocked dirt container
Dust blows out
of the air vents
1. Dirt container is full 1. Empty the dirt
container
2. Filters missing or installed
incorrectly
2. Check all filters for
correct installation
3. Filters are dirty 3. Check and clean or
replace all filters
4. Hose connector is blocked 4. Remove hose and
check for blockages
5. Hose connector is not securely
attached to the suction inlet
5. Make sure the hose
connector is locked
into the suction inlet
6. Crack or hole in hose 6. Check hose and
replace if necessary
Other maintenance or service not included
in the manual must be performed by an
authorized Tevo service representative. For
any questions or concerns, contact customer
care on 0861 77 88 88.

11
REPLACEMENT PARTS HVC125
The items below are available for purchase as accessories for your MULTI-FORCE vacuum.
To purchase, contact Tevo customer care in your area. Contact details on page 12.
ITEM PART NAME
PART NO.
1. ZHVC12801 Dirt Container Filter
2. ZHVC12802 Post-motor Microparticle Filter
3. ZHVC12803 Floor Nozzle
4. ZHVC12804 Flex Hose
5. ZHVC12805 2-Piece Extension Wand
6. ZHVC12806 Dusting Brush/Crevice Tool
3.
4. 5.
1.
6.
2.

12
CONSUMER GUARANTEE
Your BENNETT READ MULTI-FORCE is guaranteed against manufacture faults
for a period of 1 year. If you register your gurantee online at www.tevo.co.za
within 14 days of purchase, then your gurantee will be extended to 2 years.
Tevo undertakes to repair or replace this product at no charge if found to be
defective due to a manufacturing fault during the gurantee period. This
gurantee excludes damage caused by misuse, neglect, shipping accident,
commercial use, incorrect installation, or unauthorized repair. This guarantee
does not apply to routine maintenance components such as, but not limited to,
filters and brushes. Tevo is not liable for incidental or consequential damages
of any nature associated with the use of this product. Tevo’s liability will not
exceed the purchase price of this product.
PLEASE KEEP YOUR RECEIPT TO VERIFY YOUR GUARANTEE.
Guarantee and service enquiries can be made by contacting:
Tevo (Pty) Ltd
Gauteng 086 111 8386 or 012 740 5000
Durban [phone]
Cape Town [phone]/9
Customer Service Help Line 0861 77 88 88
www.tevo.co.za
TECHNICAL SPECIFICATIONS:
Nominal voltage: 220-240 V AC
Nominal frequency: 50/60 Hz
Rated Power Output : 1800 W
Model: SL158

ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances with general municipal waste. Hazardous
substances can leak and contaminate the groundwater, affecting the food chain
and ultimately damaging the environment and your health. Contact your local
municipality for information on safe disposal in your area.
Please think of the environment and recycle all plastic and paper in accordance
with your local recycling program.
PLEASE RECYCLE

Brought to you by:
www.tevo.co.za | [e-mail]
0861 77 88 88
MULTI-FORCE
THE PREMIUM CYLINDER VACUUM
WITH 13 CYCLONES FOR NO LOSS OF SUCTION*
