USER GUIDE
COMPACT CYLINDER VACUUM
8
MODEL EV-505-S16

2
Thank you for purchasing a BENNETT READ
FORCE 8 vacuum.
Your FORCE 8 vacuum incorporates the latest technological
advances in home cleaning systems. It imitates the most powerful
forces of nature in a sleek, elegant cleaning system to ensure that
your home is easily and properly cleaned.
Your new vacuum is manufactured to a high standard of quality and
is backed up by a 12 month guarantee by Tevo.
Should you need any support from us, please visit
www.tevo.co.za or call 0861 77 88 88.
PLEASE KEEP THIS USER GUIDE IN A SAFE PLACE AND
READ IT CAREFULLY BEFORE USING YOUR BENNETT READ
FORCE 8 VACUUM FOR THE FIRST TIME.

3
•Your FORCE 8 is for household use only
•Use only indoors on dry surfaces
•Do not immerse any part of the system in
water or any other liquids
•Do not operate the system if the appliance
or any other part of the system has been
dropped or damaged
•Do not disassemble or attempt to repair
your FORCE 8. Return the unit for
examination and repair
•Do not use the vacuum to pick up
flammable or combustible liquids such as
gasoline and do not use it in areas where
they may be present
•Do not use the vacuum to pick up anything
that is burning or smoking such as
cigarettes, matches or hot ashes
• Use extra care when cleaning on stairs
•Do not use your FORCE 8 without the
filters in place
•Do not leave your FORCE 8 plugged in
when unattended
•Unplug the electrical cord when not in
use and before cleaning or servicing
•Keep loose clothing, hair and all parts of
body away from openings and moving
parts
• Not intended for use by persons (including
children) with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge
• Keep out of reach of children
•Do not allow your FORCE 8 to be used
as a toy
•Extra care is necessary when using your
FORCE 8 vacuum near children,
animals or plants
• Do not pull the electrical cord or use the
cord as a handle
• Take care to not close doors on the
electrical cord and do not pull the cord
around sharp edges or corners
•Do not run the vacuum over it’s own
electrical cord
•Do not allow the cord to touch hot surfaces
•Turn off all controls as applicable before
unplugging from the electrical outlet
• To unplug your FORCE 8, grasp the
plug, do not unplug by pulling on the
electrical cord
•Do not handle the plug or vacuum with
wet hands
•Do not operate your FORCE 8 while
barefoot
• Do not put any objects into the vacuum
openings
• Do not use your FORCE 8 while any
opening is blocked
•Keep your FORCE 8 free of dust, lint, hair
or anything else which may reduce airflow
•Keep your work area well lit
•Using improper voltage may result in
damage to the motor and possible injury
to the user. The correct voltage is listed
on the rating label. For operation on
220-240V, 50/60Hz power supply only
•Only use the accessories supplied with
your FORCE 8 vacuum
•Only use spare parts recommended by
Tevo
• Store your FORCE 8 indoors in a cool,
dry area
IMPORTANT SAFETY INSTRUCTIONS
BASIC SAFETY PRECAUTIONS
SHOULD BE OBSERVED WHEN
USING YOUR FORCE 8,
INCLUDING THE FOLLOWING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY:
!WARNING
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
FOR HOUSEHOLD USE ONLY

4
PRODUCT VIEW
1. Multi-surface floor nozzle
2. Brush switch
3. Extension wand (x2)
4. Tool clip holder
5. Dusting brush
6. Crevice tool
7. Air flow regulator
8. Handle
9. Hose
10.Carry handle
11.Dirt container release button
12.Hose connector
13.Suction inlet
14.Power button
15.Dirt container filter
16.Dirt container
17.Dirt container emptying
button (at the back)
18.Auto - cord rewind button
19.Post-motor filter
20.Floor nozzle storage slot
21.Power cord and plug
Do not plug in your vacuum
cleaner until you are familiar
with all instructions and
operating procedures.
!CAUTION:
1
2
3
4
5
7
8
9
11
21
19
6
14
13
12
15
17
16
18
20 10

5
ASSEMBLY
1. Connect the hose (9) to the
vacuum by inserting the hose
connector (12) into the suction
inlet (13). You will hear a ‘click’ when
it is securely in place
2. Attach the extension wands (3)
together by inserting one into the
other. Twist slightly to tighten the
connection
3. Connect the hose handle (8) to the
end of the extension wand and twist
slightly to tighten
4. Connect the floor nozzle (1) to the
other end of the extension wand and
twist slightly to tighten
5. Once assembled, you can store
your vacuum by inserting the
storage clip (located on the back of
the floor nozzle) into the storage
slot (20) on the rear of the vacuum
OPERATIONS
POWER CORD
The power cord (21) is located at the rear of
the vacuum. Gently pull out the power cord.
Stop pulling the cord when the yellow line is
visible. There is also a red line which
indicates the end of the usable cord. Do not
pull the power cord out beyond the red line.
AUTO-CORD REWIND
Your vacuum is equipped with an automatic
cord rewind. When cleaning is finished,
press the power button OFF and grasp the
plug to disconnect from the electrical outlet.
Hold the plug and press the auto-cord rewind
button to rewind the cord automatically.
POWER BUTTON
Turn the power ON or OFF by pressing
lightly downward on the power button.
1.
2.
3.
4.
The power cord retracts very quickly.
Take care to avoid injury.
!CAUTION:
Auto cord
rewind

6
To avoid injury, turn cleaner
OFF and unplug cord from wall
when not in use.
!WARNING:
Before cleaning under low furniture, check
area first for objects that might harm the unit
or block the hose.
TIP:
Hair, string and small objects can block the
hose and tools. Check them occasionally for
obstructions.
TIP:
AIR FLOW REGULATOR
Open the air flow regulator by sliding the
regulator down towards the extension wand
to an open position. This will reduce the
suction power for vacuuming delicate fabrics.
For full suction power, close the air flow
regulator by sliding the regulator up to the
closed position.
OPERATIONS
SPECIAL TOOLS
Your BENNETT READ FORCE 8 vacuum is not
only a powerful carpet and rug cleaner,
it’s also a versatile bare floor and above floor
vacuum cleaner when you select one of the
special tools.
FLOOR NOZZLE
Use to vacuum carpets, rugs and bare floors.
The swivel head turns to get into tight spaces
and fits under cabinets
1. To vacuum carpets and rugs, push the
brush switch to the carpet position
[ ]. This will pull the brushes up
into the floor nozzle.
2. To vacuum bare floors, push the brush
switch to the bare floor position [ ].
This will extend the brushes
down from the floor nozzle.
CREVICE TOOL
Use the crevice tool in narrow spaces.
DUSTING BRUSH
Use the dusting brush to clean curtains,
draperies, cushions and fabrics.
TOOL CLIP
The tool clip provides convenient storage for
your crevice tool and dusting brush when
clipped onto the extension wand.
Brush up Brush down
1. 2.
Dusting
brush
Crevice
tool
Tool clip
Air flow regulator

7
MAINTENANCE AND CARE
To reduce the risk of injury from moving parts
and/or electrical shock, turn Power Switch
OFF and disconnect plug from electrical outlet
before performing maintenance checks.
!WARNING:
EMPTYING THE DIRT CONTAINER
Empty the dirt container as soon as the dirt
reaches the “FULL” line on the sides of the
dirt container.
1. Unplug the vacuum from the
electrical outlet.
2. Remove the hose by pressing the
securing clips inward and pulling
the hose connector out from the
suction inlet. Set the hose aside.
3. Press the dirt container release
button under the carry handle and
lift up to remove the dirt container.
4. Choose an emptying method.
Method #2 is recommended for
allergy sufferers.
Method #1 - Hold the dirt container
over a rubbish bin and push the
emptying button to open the
bottom. Close the bottom after the
dirt empties.
Method #2 - Place a plastic bag
over the bottom of the dirt
container. Push the emptying
button through the plastic bag to open
the bottom. After the dust settles,
close the bottom and remove the
plastic bag to discard.
5. Replace the dirt container by
placing it back into the vacuum and
pushing down on the dirt container
until it clicks back into place.
To maintain maximum performance from your BENNETT READ FORCE 8 vacuum, perform
these simple maintenance checks:
2.
3.
4.
5.

8
MAINTENANCE AND CARE
CLEANING THE DIRT
CONTAINER FILTER
The key to maximum performance is a
clean filter. Cleaning the filter after each
use will help your FORCE 8 vacuum
operate at peak efficiency.
1. Follow the steps 1 to 4 on page 7
to remove and open the dirt
container.
2. Unlock the dirt container filter
from the vacuum by turning it
anticlockwise. Pull the filter straight
down to remove it.
3. Remove the dirt container filter
screen by grasping the bottom of
the filter frame base and pulling the
screen straight up. Parts separate
by slowly pulling vertically upwards
on the filter screen. Do not use
excessive force.
4. The dirt container filter screen and
dirt container filter can be hand
washed in cold water with a mild
detergent. Rinse well and air dry
thoroughly before placing back
together.
5. Attach the dirt container filter
screen back onto the dirt container
filter by sliding it down over the dirt
container filter, making sure that
the three tabs on the top of the dirt
container filter screen line up with
the notches on the dirt container
filter.
6. Insert the dirt container filter
assembly back into the dirt
container by lining up the three
tabs on the top of the dirt container
filter assembly with the three
notches inside the top of the dirt
container and turning the dirt
container filter assembly clockwise
to lock it into place.
Never operate your FORCE 8 vacuum without all
the filters in place. Doing so may damage the motor
and void the guarantee.
!CAUTION:
2.
3.
Dirt container
filter
Filter frame
base
Dirt container
filter screen
Never operate your FORCE 8
vacuum with damp or wet filters.
!WARNING:

9
MAINTENANCE AND CARE
CLEANING THE POST-
MOTOR FILTER
The post-motor filter assists in the
filtration process to return cleaner
air into the room
1. Unplug the vacuum from the
electrical outlet.
2. Remove the filter door (located at
the back of the vacuum) by
pushing down on the tab and
pulling out and away from the
vacuum.
3. Remove the post-motor filter from
the vacuum by grasping the two
tabs and pulling gently outwards.
4. Separate the post-motor filter
from the post-motor filter frame.
5. The post-motor filter can be hand
washed in cold water with a mild
detergent. Rinse well and air dry
thoroughly before placing back
into the vacuum.
6. Replace the filter door by placing
the two tabs on the bottom of the
filter door into the notches on the
bottom of the post-motor filter
compartment and pushing the tab
forward into the vacuum to lock
into place.
For maximum cleaning performance check the
filters often and clean or replace them regularly.
TIP:
Never operate your FORCE 8 vacuum with
damp or wet filters, or without all filters in place.
!WARNING:
This product is intended for household use only
and not for commercial or industrial use.
Vacuuming of dust from products like plaster,
concrete or ashes will damage the motor and
void the guarantee.
NOTICE:
2.
3.
4.

TROUBLESHOOTING
10
MAINTENANCE AND CARE
CLEARING BLOCKAGES
FROM THE DIRT CONTAINER
1. Unplug the vacuum from the
electrical outlet.
2.Follow steps 1 to 3 on page 7 to
remove and open the dirt container.
3. Follow steps 2 to 3 on page 8 to
remove the dirt container filter.
4.Tap the dirt container filter
assembly over a garbage bin to
remove any dirt or debris from the
dirt container filter screen that
surrounds the dirt container.
5. Reach up into the dirt container to
clear any dirt or debris.
6. Check if there are any blockages in
the suction inlet.
7. After clearing any dirt or debris
from the dirt container, replace the
dirt container assembly into the dirt
container following step 7 on page 8.
Vacuum cleaner
won't run
Problem Possible causes Remedies
1. Power cord not firmly plugged in 1. Check electrical plug
2. Power button not pressed down 2. Press power button
Vacuum cleaner
doesn't vacuum
effectively 2. Filters are dirty 2. Follow instructions
for cleaning filters
on pages 8 and 9
1. Tools, hose or extension wands
are blocked
1. Remove each part
and check for
blockages
3. Follow instructions
for emptying the dirt
container on page 7
3. Dirt container is full
4. Check that hose
connector is locked
into suction inlet
4. Hose connector not securely
attached to suction inlet
5. Check hose and
replace if necessary
5. Crack or hole in hose
6. Change to closed or
maximum setting
6. Air flow regulator is set to open
or minimum setting
7. Clear blockage from
the dirt container
following steps 1 to
7 at the top of this
page.
7. Blocked dirt container
To reduce the risk of electric shock, turn Power
Switch OFF and disconnect plug from electrical
outlet before performing troubleshooting checks.
!WARNING:

11
REPLACEMENT PARTS
The items below are available for purchase as accessories for your BENNETT READ FORCE 8
vacuum. To purchase contact Tevo customer care in your area. Details on page 12.
Item Part name
TROUBLESHOOTING CONTINUED
Problem Possible causes Remedies
Dust blows out
of the air vents
1. Dirt container is full 1. Empty the dirt
container
2. Filters missing or installed
incorrectly
2. Check all filters for
correct installation
3. Filters are dirty 3. Check and clean or
replace all filters
4. Hose connector is blocked 4. Remove hose and
check for blockages
5. Hose connector is not securely
attached to the suction inlet
5. Make sure the hose
connector is locked
into the suction inlet
6. Crack or hole in hose 6. Check hose and
replace if necessary
Other maintenance or service not included in the manual must be performed by an authorized Tevo service
representative. For any questions or concerns, contact customer care on 0861 77 88 88.
Part #
1. ZHVC119CO1 Dirt container filter screen
2. HVC119CO2 Dirt container filter
3. ZHVC119CO3 Post-motor filter
4. ZHVC119CO4 Floor nozzle
5. ZHVC119CO5 Hose with handle
6. ZHVC119CO6 Extension wands (2)
7. ZHVC119CO7 Tool clip holder
8. ZHVC119CO8 Crevice tool
9. ZHVC119CO9 Dusting brush
2. 3. 4. 5.1.
7. 8. 9.6.

12
CONSUMER GUARANTEE
Brought to you by:
www.tevo.co.za | [e-mail]
0861 77 88 88
The BENNETT READ FORCE 8 has a one year product guarantee from Tevo
(Pty) Ltd.
Tevo will replace or repair,at Tevo’s option, any defective or malfunctioning
part due to manufacturing defect, free of charge from the date of purchase by
the original purchaser for one year.
This guarantee applies to product used for personal or domestic use only, and
specifically excludes any malfunction or defect arising from commercial use.
This guarantee does not apply to routine maintenance components such as
filters and brushes. Damage or malfunction caused by negligence, abuse,
unauthorized repair, or use not in accordance with the User Guide is not
covered.
Tevo is not liable for incidental or consequential damages of any nature
associated with the use of this product. Tevo’s liability will not exceed the
purchase price of this product.
Guarantee and Service enquiries can be made by contacting:
Tevo (Pty) Ltd
Gauteng 086 111 8386
Durban [phone]
Cape Town [phone]/9
Customer Service Help Line 0861 77 88 88
www.tevo.co.za
