Bestway 58230 User manual

#58230
S-S-003343
220-240V~50Hz, 80W, IPX8
Hmax 2.2m Hmin 0.02m
Pool+Drain Pump
OWNER’S MANUAL
1.22m
Bestway Global Holding Inc.
No.3065 Cao An Road,
Shanghai, 201812, China
Tel:
86 21 6913 5588
Fax: [phone]
E-mail: [email protected]
Shanghai
Bestway (Hong Kong) International Ltd.
Suite 713, 7/Floor, East Wing, Tsim Sha Tsui Centre,
66 Mody Road, Kowloon, Hong Kong
Tel:
852 2997 7169
Fax: [phone]
E-mail: [email protected]
Hong Kong
Bestway Central & South America Ltda
Salar Ascotan 1282, Parque Enea,
Pudahuel, Santiago, Chile
Tel:
562 3203 6438
Fax: [phone]
E-mail: [email protected]
Central & South America
Bestway (USA) Inc.
3249 E. Harbour Drive, Phoenix, Arizona 85034,
United States of America
Tel:
1 480 838 3888
Fax: [phone]
E-mail: [email protected]
U.S.A.
Bestway Australia Pty Limited
Unit 10/71-83 Asquith Street,
Silverwater, NSW 2128, Australia
Tel:
61 2 9037 1388
Fax: [phone]
E-mail: [email protected]
Australia
Bestway (Europe) S.r.l.
Via Resistenza 5,
20098 San Giuliano M.se (Mi) - Italy
Tel:
39 02 9884 881
Fax: [phone]
E-mail: [email protected]
Europe
www.bestway-global.com
www.bestway-service.com

S-S-003343
2
WARNING
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
WARNING – The pump is to be supplied by an isolating transformer or
supplied through a residual current device (RCD)having a rated residual
operating current not exceeding 30 mA.
WARNING – The power source on the wall of building should keep
more than 4m away from pool and at a height of 1.2m at least.
WARNING – The appliance must be supplied by earthed power source.
WARNING – RISK OF ELECTRICK SHOCK –The pump cannot be
used while people are inside the pool.
DO NOT BURY CORD. Locate cord to minimize abuse from lawn
mower, hedge trimmers, and other equipment.
WARNING – TO REDUCE THE RISK OF ELECTRIC SHOCK –
The supply cord cannot be replaced. If the cord is damaged the appli-
ance should be scrapped.
WARNING – Extension cords can’t be used.
CAUTION – This pump is for use with storable pools only. Do not use
with permanently-installed pools. A storable pool is constructed so that it
is capable of being readily disassembled for storage and reassembled to
its original integrity. A permanently-installed pool is constructed in or on
the ground or in a building such that it cannot be readily disassembled for
storage.
IMPORTANT – Using the pump with an unmatched electrical supply is
dangerous and will result in catastrophic failure of pump.
RISK OF ELECTRIC SHOCK – When working with electricity, turn the
electrical power off at the circuit breaker and lock breaker door. Failure to
do so will result in increased risk of shock, injury and possibly death.
DO NOT REMOVE THE GROUNDING PRONG OR MODIFY THE
PLUG IN ANY WAY. DO NOT USE ADAPTOR PLUGS. Consult a
qualified electrician for any questions related to the validity of your plugs
grounding.
Handle the pump with care. Do not pull or carry the pump by the power
cord. Never pull a plug from the outlet by yanking the power cord. Keep
cord free from abrasions. Sharp objects, oil, moving parts, and heat
should never be exposed to the pump.
WARNING – This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance by a person responsi-
ble for their safety. Children should be supervised to ensure that they do
not play with the appliance.
Cleaning and user maintenance must be performed by an adult above18
years old who is familiar with the risk of electric shock.
Caution: Read the instruction before using the appliance and
installation/reassemble each time.
WARNING – RISK OF ELECTRIC SHOCK – Do not put the plug into the water.
NOTE: Please examine equipment before use. Notify Bestway at the
customer service address listed on this manual for any manufacturing
defect or missing parts at the time of purchase. Verify that the equipment
components represent the pump model that you had intended to
purchase.
NOTE: The plug of pump shall be at least 3.50m away from the pool.
NOTE: Atmospheric conditions may affect the performance and life span
of your pump. Unnecessary wear and tear may occur during periods of
cold, heat and exposure to sun. Whenever possible shelter the pump
from these conditions.
It is imperative to change as soon as possible all the deteriorated parts.
Only use the parts approved by the manufacturer.
IMPORTANT: Always remember to unplug the drain pump after each
using.
NOTE: Assembly and disassembly by adults only.
NOTE: The pump is used for cleaning and other maintenance of
swimming pools.
Don’t plug or unplug the appliance if hand is wet.
Always unplug the appliance:
• On raining days
• Before cleaning or other maintenance
• Leave it unattended on holidays
When the appliance will be not used for long time, such as in the winter,
the pump should be disassembled and stored indoor.
Safekeeping the instruction. For reconstruction the pool set every time,
please always refer to the instructions.
If instruction is missed, please contact with Bestway or search it in
website: www.bestway-service.com
NOTE: This product is not intended for commercial use.
SAVE THESE INSTRUCTIONS.

WARNING
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
WARNING – The pump is to be supplied by an isolating transformer or
supplied through a residual current device (RCD)having a rated residual
operating current not exceeding 30 mA.
WARNING – The power source on the wall of building should keep
more than 4m away from pool and at a height of 1.2m at least.
WARNING – The appliance must be supplied by earthed power source.
WARNING – RISK OF ELECTRICK SHOCK –The pump cannot be
used while people are inside the pool.
DO NOT BURY CORD. Locate cord to minimize abuse from lawn
mower, hedge trimmers, and other equipment.
WARNING – TO REDUCE THE RISK OF ELECTRIC SHOCK –
The supply cord cannot be replaced. If the cord is damaged the appli-
ance should be scrapped.
WARNING – Extension cords can’t be used.
CAUTION – This pump is for use with storable pools only. Do not use
with permanently-installed pools. A storable pool is constructed so that it
is capable of being readily disassembled for storage and reassembled to
its original integrity. A permanently-installed pool is constructed in or on
the ground or in a building such that it cannot be readily disassembled for
storage.
IMPORTANT – Using the pump with an unmatched electrical supply is
dangerous and will result in catastrophic failure of pump.
RISK OF ELECTRIC SHOCK – When working with electricity, turn the
electrical power off at the circuit breaker and lock breaker door. Failure to
do so will result in increased risk of shock, injury and possibly death.
DO NOT REMOVE THE GROUNDING PRONG OR MODIFY THE
PLUG IN ANY WAY. DO NOT USE ADAPTOR PLUGS. Consult a
qualified electrician for any questions related to the validity of your plugs
grounding.
Handle the pump with care. Do not pull or carry the pump by the power
cord. Never pull a plug from the outlet by yanking the power cord. Keep
cord free from abrasions. Sharp objects, oil, moving parts, and heat
should never be exposed to the pump.
WARNING – This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance by a person responsi-
ble for their safety. Children should be supervised to ensure that they do
not play with the appliance.
S-S-003343
3
Cleaning and user maintenance must be performed by an adult above18
years old who is familiar with the risk of electric shock.
Caution: Read the instruction before using the appliance and
installation/reassemble each time.
WARNING – RISK OF ELECTRIC SHOCK – Do not put the plug into the water.
NOTE: Please examine equipment before use. Notify Bestway at the
customer service address listed on this manual for any manufacturing
defect or missing parts at the time of purchase. Verify that the equipment
components represent the pump model that you had intended to
purchase.
NOTE: The plug of pump shall be at least 3.50m away from the pool.
NOTE: Atmospheric conditions may affect the performance and life span
of your pump. Unnecessary wear and tear may occur during periods of
cold, heat and exposure to sun. Whenever possible shelter the pump
from these conditions.
It is imperative to change as soon as possible all the deteriorated parts.
Only use the parts approved by the manufacturer.
IMPORTANT: Always remember to unplug the drain pump after each
using.
NOTE: Assembly and disassembly by adults only.
NOTE: The pump is used for cleaning and other maintenance of
swimming pools.
Don’t plug or unplug the appliance if hand is wet.
Always unplug the appliance:
• On raining days
• Before cleaning or other maintenance
• Leave it unattended on holidays
When the appliance will be not used for long time, such as in the winter,
the pump should be disassembled and stored indoor.
Safekeeping the instruction. For reconstruction the pool set every time,
please always refer to the instructions.
If instruction is missed, please contact with Bestway or search it in
website: www.bestway-service.com
NOTE: This product is not intended for commercial use.
SAVE THESE INSTRUCTIONS.
Hose Seal Ring
P6005 P6124 P6556 P6555 P6H565
Hose Clamp Hose Adaptor Hose Adaptor
NOTE: To order spare parts for the drain pump, list the part No.
Parts Reference Overview
Before assembling the drain pump, become familiar with all parts.
(See Fig.1)

S-S-003343
4
Pump Installation and Operation
1. Connect the provided hose to the
drain pump by fastening the hose
clamp. (See Fig.2)
NOTE: Two types of hose adaptors
are provided to be used with differ-
ent garden hoses, see Fig.3 & Fig.4
for assembly.
2. Vertically place the drain pump into
the pool with the other end of hose
to the drain area.(Check local
regulations for drainage by-laws)
NOTE: Do not put the plug into the
pool.
3. To turn on the pump, insert the plug
into a proper socket.
NOTE: When the water level of the
pool is less than 2cm, do not use the
drain pump.
NOTE: Keep the drain pump vertical
at all times.
NOTE: Do not dry run the pump.
Pump Maintenance and Storage
CAUTION: YOU MUST ENSURE THE
DRAIN PUMP IS UNPLUGGED
BEFORE PERFORMING MAINTE-
NANCE OR SEVERE RISK OF
INJURY OR DEATH EXISTS.
1. Unplug the pump.
2. Loosen the hose clamps, and
remove the hose from the drain
pump.
3. Dry the pump with a cloth and store
in a dry location out of reach from
children.
P6555
P6556
P6124
P6005
P6H565
Fig.1
Fig.2
Fig.3
Fig.4
P6556
P6124
P6555
P6H565
European
garden hose
g
P6555
Ametican
arden hose
