BEYES DuraMax X1 User manual

X1
Instruction for Use
Leading aerosol control
system to protect dental
professionals from COVID19

2
CONTENT
SAFETY PRECAUTIONS............................................ 3
PACKING LIST ........................................................... 3
FEATURES ................................................................. 4
SPECIFICATIONS....................................................... 4
PARTS NUMBER ....................................................... 5
OPERATION ............................................................... 6-7
INSTALLATION INSTRUCTIONS .............................. 7
FILTERS REPLACEMENT.......................................... 8
TROUBLESHOOTING ................................................ 9
WARRANTY ............................................................... 10-11

3
MPORTANT SAFETY PRECAUTIONS
Before operating the system, please read this manual thoroughly, and retain it for future
reference.
WARNING-To reduces the risk of electrical shock, re or injury:
• Use only as described in this manual.
• Use only a 120 volt outlet
• When removing the power plug, always hold the plug and never pull by the
cord. Do not handle plug or appliance with wet hands. Electrical shock or re
from short circuit may occur.
• Remove the power plug from the wall outlet before cleaning the unit and when
not using the unit. Turn off all controls before unplugging.
• Do not insert ngers or foreign objects into the intake or air outlet.
• The batteries must be removed from the remote control before disposal, and
the batteries must be disposed of safely.
• Do not operate the unit without lters.
• Do noT wash or reuse the activated carbon lter or clean the activated carbon
lter with liquid, especially alcohol, gasoline, paint thinner, etc. It may cause re!
PACKING LIST
Description QTY
Main machine 1 set
Power cord 1 piece
Arm 1 piece
S1 1 set
S2 1 set
S3 1 set
S4 1 set
Note: The lter element is placed inside the machine

4
FEATURES
Efcient Filtration
4 layer ltration system including HEPA (0.3 μm 99.97%) ltration plus germicidal UV-C
Powerful
10 levels of power control with up to 265 CFM capacity
Sleek
Compact and portable design
Convenient
Unit comes with a handy remote control for smooth operation
SPECIFICATIONS
Model DuraMax X1
Voltage AC110V, 60Hz
Power 350W
Suction 8.2 Kpa
Speed options 10
Ultraviolet C (UV-C) 254nm Spectrum, 10W
Maximum volume 7500L/Min, 265 CFM
Filtration Four layers HEPA 0.3μm 99.97%
Noise Level ≤55dB
Head Diameter 75mm
Arm Reach 1.4m
Unit Weight 28Kg
Shipping Weight 33Kg
Shipping Dimension(mm) L500 x W370 x H595
Unit Dimension(mm) L400 x W255 x H595
Warranty 30 months

5
PARTS NUMbER

6
OPERATION
ON/OFF FLOW + TIME SETFLOW
1 2 3 4
Set Time
1. Press 1 to turn on the unit
2. Press 4 to set the timer, the display will show HXXX
3. Press 2 to increase time
4. Press 3 to decrease time
5. Press 4 to conrm
XXX represents the number of hours the machine is running during timing, the maximum
is 300 hours, the minimum is 1 hour. After setting, press the time button to queue the
remaining time. The display shows HXXX. For instance H005 means 5 hours later, it will
automatically shut down. The time is set to H000 to cancel the timing

7
ON/OFF
Time set
Flow +
Flow
REMOTE CONTROL
Set Time
1. Press 1 to turn on the unit
2. Press 4 to set the timer,
the display will show HXXX
3. Press 2 to increase time
4. Press 3 to decrease time
5. Press 4 to conrm
INSTALLATION INSTRUCTIONS
1. Place the main body of the unit at a convenient spot, connect the arm onto
the main body
2. Connect the power cord to the three in one switch of the machine, insert
the other end into the electric socket
3. Turn on the machine via the start button
1
3
1
2
2
3
4

8
FILTERS REPLACEMENT
1. Turn off the unit
2. Open door to the lter
3. Remove the used lter within
4. Place new lter into the same slot
5. Close the door
Stage 1:
Primary Filter
Eliminate droplet, aerosol, and dust
(Replace every month)
Stage 2:
Secondary Filter
Eliminate blood and aerosol
(Replace 3 month)
Stage 3:
HEPA Filter
Eliminate virus, bacteria size ≥0.3μm 99.97%
(Replace 3 month)
Stage 4:
Activated Carbon Filter
Eliminate Odor
(Replace twice a year)
Stage 5:
Germicidal Lamp UV-C
Kills viruses and bacteria
(Replace every 8000 hrs)

9
TROUbLEShOOTING
1: The system is still working, but the air volume is weak and the suction force is greatly
reduced
Reason: The air inlet is blocked or there is foreign matter in the tube, and the lter reach-
es saturation and lose efcacy then forms a blockage alarm Check： Turn off the power,
open the top cover, check if there is any foreign matter blocking the air inlet; then check
if the air outlet is blocked. If the suction of the empty machine is normal, the lter element
needs to be replaced.
2: The machine automatically shut down immediately after starting the machine, turn it on
again and repeat the above issue
Reason: The internal airow is not smooth, the lter resistance is too big, causing the
fan starting current to be too big, the machine will shutdown to automatically protect the
machine
Check: Turn off the power, open the upper cover, check if there is any foreign matter
blocking the air inlet; if it is checked, after the treatment is normal, adjust the air volume to
the minimum, then turn it on again, and adjust the air volume to the appropriate position.
3: Turn on the power switch, the indicator light is off
Check if the socket is in poor contact. If the power socket is intact, check if the fuse in the
power box is burnt. If it is damaged, please replace the fuse
Be sure to cut off the power before checking and repairing the equipment!

10
Beyes Limited Warranty Statement
1. SCOPE OF WARRANTY
BEYES Dental Canada Inc. (‘BEYES’) warrants to the original retail purchaser that it will
be at BEYES option to repair or replace components of the dental products manufactured
by BEYES (except for components not warranted under ‘Exclusions’) that are defective
in material or workmanship under normal use and service. BEYES’ obligation under this
limited warranty is limited to the repair or replacement of the applicable components.
This limited warranty shall only apply to defects that are reported to BEYES within the
applicable warranty period and which, upon examination by Beyes, prove to be defective.
This warranty extends only to the rst retail purchaser of a product and is not transferable
or assignable. Replacement components or products may be used and/or refurbished
components or products, provided they are of like quality and specications as new
components or products.
2. APPLICABLE WARRANTY PERIOD
The applicable warranty period, measured from the date of invoice to the original user,
shall be 30 months
3. EXCLUSIONS
This limited warranty does not cover and BEYES shall not be liable for the following;
(1) defects, damage or other conditions caused, in whole or in part, by misuse, abuse,
negligence, alteration, accident, freight damage, negligent storage, tampering or failure to
seek and obtain repair or replacement in a timely manner;
(2) products which are not installed, used, and properly cleaned and maintained as
required or recommended in the BEYES ‘Installation’ and/or ‘Installation/Operation
Manual’ for the applicable product, including the specied structural and operational
environment conditions and electrical power requirements;
(3) products considered to be of a consumable or sterile nature;
(4) accessories or parts not manufactured by BEYES;
(5) charges by anyone for adjustments, repairs, replacement parts, installation or other
work performed upon or in connection with such products which are not expressly
authorized in writing in advance by BEYES;
(6) costs and expenses of routine maintenance and cleaning;
(7) representations and warranties made by any person or entity other than BEYES;
(8) matching of color, grain or texture except to commercially acceptable standards;
(9) changes in color caused by natural or articial light;
(10) custom manufactured products;

11
(11) alterations or modications to the product by any person or entity other than BEYES;
(12) Products that would otherwise by covered under Sections 1 and 2 of this limited
warranty, but are acquired: (i) from a person or entity that is not BEYES or one of its
authorized dealers; or (ii) from a BEYES dealer that is not authorized to sell the product at
issue in the geographic territory where the purchaser is located, or is not authorized to sell
the product at issue within the medical, animal health or dental market, as the case may
be, in which purchaser intends to use the product.
4. EXCLUSIVE REMEDY; CONSEQUENTIAL DAMAGES DISCLAIMER
Beyes’ obligation under this limited warranty is the repair or replacement of defective
parts. Beyes shall not be liable for and hereby disclaims any direct, special, indirect,
incidental, exemplary or consequential damages or delays, including, but not limited to,
damages for loss of prots or income, loss of use, downtime, cover and employee or
independent contractor wages, payments and benets.
5. WARRANTY DISCLAIMER
This limited warranty is Beyes only warranty and is in lieu of all other warranties,
express or implied. Beyes makes no implied warranties of any kind including any implied
warranties of merchantability or tness for a particular purpose. This warranty is limited to
the repair or replacement of defective parts.
6. STATUE OF LIMITATIONS
No actions may be brought against BEYES for breach of this limited warranty, or implied
warranty, if any, or for any other claims arising out of or relating to the products, more than
ninety (90) days following expiration of the limited warranty period.

Beyes Dental Canada Inc.
23-595 Middleeld Road
Toronto, Ontario, M1V 3S2
Canada
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.beyes.ca
Printed in Canada
File #: ENI026
Rev1/30.04.20
