Bien Air MC2 Series User manual

REF 2100017-ENG/09.11 1/2
REF 2100017-ENG/09.11
Hoses
MC2 & Isolite
0120
fi . 1 fi . 2
➇
➈
fi . 3
fi . 5
fi . 4
REF 1300414-010
fi . 6
REF 212.65.01-001
fi . 7
REF 212.65.01-001
MC2 IR & MC2 GTAV
fi . 8
MC2 IR & MC2 GTAV
fi . 9
Isolite
fi . 10
Isolite
fi . 11
fi . 13
A
B
Instruction
English
Medical devices entirely made in Switzerland
by Bien-Air Dental SA.
Type
Electric micromotor hose with revolving connector
for use with the MC2, the solite 100 and 300, with
or without light. Quality hoses straight or coiled, in
black, grey or white. Standard length 1.7 m or spe-
cial lengths up to 3 m.
Intended use
Product intended for professional use only. Use in
dentistry for prophylaxis, general dentistry and en-
dodontic work.
Technical data and assembly
Classification
Class a, «active medical devices», as per section
«Classification», Rule 2 of Annex X to Euro-
pean Directive 93/42/EEC, namely: «Non-invasive
devices intended for channelling liquids or gases for
the purpose of administration into the body, which
may be connected to an active medical device in
Class a».
Fitting
Keep the initial alignment of the leads and conduits
unchanged. Place the back-up ring ➇in the lock-
ing area fig. 1 . Tie the security string ➈ fig. 2 .
Description fig. 3 - 4
➀Ø 1.5/2.5 mm air spray (small white)
with “A” or (blue)
➁Ø 1.5/2.5 mm water spray (small white)
with “W” or (green)
➂Ø 1.5/2.5 mm motor cooling (small white)
or (transparent) Ø 2.8/4.1 mm
➃(+) red: motor
➄black: motor
➅(+) brown: bulb
➆(0V) blue: bulb
➇back-up ring
➈security string (if existing)
Accessories
O-Ring joint REF 1300414-010. Changing the O-
ring joint fig. 5 . The split ring REF 212.65.01 fig. 6
is required only for connection to an MC2 R or
GTAV motor fig. 7-8 .
Connection (without the split ring) to an solite
electric motor fig. 9-10 .
The conical piece fig. 11 can be useful for connect-
ing the cooling tube to the Unit tube ➆ fig. 12 .
Maintenance
Non-sterilisable
Cleaning
Carefully clean all surfaces with a cloth impreg-
nated with Spraynet, fig. 13 .
Disinfection
Disinfect using a clean cloth soaked in a suitable
product.Products containing acetone,chlorine and
bleaches are not recommended as disinfectants.
To keep the surface of the hose in good condition, it
is advisable to periodically wipe the complete length
of it with a cloth dusted with talcum powder.
Never immerse in disinfectant solutions.
Not suitable for ultrasonic bath.
Transport
Temperature between -40°C (-40°F) and 70°C
(158°F), relative humidity between 10% and 100%,
atmospheric pressure 50 kPa to 106 kPa (7.3 to
15.3 psi).
Information
The technical specifications, illustrations and di-
mensions contained in these instructions are given
only as a guide. They may not be the subject of any
claim. The manufacturer reserves the right to make
technical improvements to its equipment, without
amending these instructions. For all additional in-
formation, please contact Bien-Air Dental SA at the
address indicated on the back cover.
Other precautions for use
The device must be used by a qualified person in
accordance with the current legal provisions con-
cerning industrial safety, health and accident pre-
vention measures, and these working instructions.
n accordance with these requirements, the opera-
tors:
• must only use operating devices that are in per-
fect working order; in the event of irregular
functioning, excessive vibration, abnormal
heating or other signs indicating malfunction
of the device, the work must be stopped imme-
diately; in this case, contact a repair centre that
is approved by Bien-Air Dental;
• must ensure that the device is used only for the
purpose for which it is intended, must protect
themselves, their patients and third parties from
any danger, and must avoid contamination
through the use of the product.
The device is intended for medical treatment only;
any use other than that for which this product is in-
tended is unauthorised and may be dangerous.The
medical device meets all the current legal require-
ments.
The device is not authorised for use in an explosive
atmosphere (anaesthetic gas).
ecommendations
t is essential to use dry, purified compressed air in
order to ensure the long working life of the device.
Maintain the quality of the air and the water by reg-
ular maintenance of the compressor and the filtra-
tion systems. The use of unfiltered hard water will
lead to early blockage of the tubes, connectors and
spray cones.
Rest the device on a suitable support to avoid risks
of infection for yourself,the patient or third parties.
Only use maintenance products and components
from Bien-Air Dental. The use of other products and
components can void the guarantee.
Do not sterilise

REF 2100017-ENG/09.11 2/2
This product may be covered by one or more of the following patents:
EP Europe: 745358 / 688539 / 948294 / 1145688 / 1563800 / 1563801 / 1675523 / 1753360 DE Germany: 29616023.7
DK Denmark: 9600315 F France: 2722972 CH Switzerland: 693922 CN China: 100528099 / 100522100 / 100522099 /
100553584 JP Japan: 3892485 / 4298933 / 7000419 US United-States: 5453008 / 6033220 / 6319003 / 7214060 / 7448870
U ussia: 2361540 / 2361541 / 2372046
REF 1600120-001 HOSE SOL TE/MC2 GREY / REF 1600297-001 HOSE SOL TE/MC2 BLACK / REF 1600314-001 HOSE
SOL TE/MC2 WH TE / REF 1600315-001 HOSE SOL TE/MC2 CO LED BLACK / REF 1600298-001 HOSE SOL TE/MC2 SW VEL
GREY / REF 1600299-001 HOSE SOL TE/MC2 SW VEL BLACK / REF 1600316-001 HOSE SOL TE/MC2 SW VEL WH TE
Bien-Air Dental SA
Länggasse 60
Case postale
2500 Bienne 6, Switzerland
Tel. [phone]
Fax [phone]
[e-mail]
Bien-Air
Deutschland GmbH
Jechtinger Strasse 11
79111 Freiburg, Deutschland
Tel. [phone]
Fax [phone]
[e-mail]
Bien-Air España, SA
Entença, 169 Bajos
08029 Barcelona, España
Tel. [phone]
Fax [phone]
[e-mail]
Bien-Air USA, Inc.
Medical Technologies
5 Corporate Park
Suite 160
rvine, CA 92606 USA
Phone [phone]-B EN
Phone [phone]
Fax [phone]
[e-mail]
Bien-Air France Sàrl
55-57, avenue Jean Lolive
93508 Pantin Cedex, France
Tel. [phone]
Fax [phone]
[e-mail]
Bien-Air Italia s.r.l.
Via Vaina 3
20122 Milano, talia
Tel. [phone]/54
Fax [phone]
[e-mail]
Bien-Air UK Ltd
Arundel House
Unit 1 - Ground Floor
Amberley Court, Whitworth Road
Crawley, West Sussex,
RH11 7XL, England
Telephone [phone]
Fax: [phone]
[e-mail]
Bien-Air Asia Ltd.
Nishi- kebukuro
Daiichi-Seimei Bldg. 10F
2-40-12 kebukuro, Toshimaku
Tokyo, 171-0014, Japan
Tel. [phone]
Fax [phone]
[e-mail]
Beijing Bien-Air
Medical nstrument
Technology Service Co. Ltd.
Room 907, The Exchange Beijing,
No 118 Jian Guo Lu Yi,
Chao Yang District,
Beijing 100022, China
Tel. [phone]
Fax [phone]
[e-mail]
REF 1600036-006
6x
10x
Designation micromotor MC2 40 I MC2 40 GTAV MC2 Isolite 300 MC2 Isolite 100
EF micromotor 1600073-001 1600075-001 1600078-001 1600079-001
Designation hose EF hose
Grey hose with fixed connector 1600120-001 x (x) x x
Black hose with fixed connector 1600297-001 x (x) x x
Grey hose, revolving connector 1600298-001 x x
Black hose, revolving connector 1600299-001 x x
White hose with fixed connector 1600314-001 x (x) x x
Black coiled hose with fixed connector 1600315-001 x (x) x x
White hose, revolving connector 1600316-001 x x
(X) Do not connect supply of water and air spray (risk to damage the micromotor)
EF Legend
1600120-001 Grey hose with fixed connector, for micromotors MC2
and solite
1600297-001 Black hose with fixed connector, for micromotors MC2
and solite
1600298-001 Grey hose, revolving connector for micromotors solite
1600299-001 Black hose, revolving connector for micromotors solite
1600314-001 White hose with fixed connector, for micromotors MC2
and solite
1600315-001 Black coiled hose with fixed connector for micromotors
MC2 and solite
1600316-001 White hose, revolving connector for micromotors solite
1300414-010 O-Ring joint
212.65.01-001 Split ring
1600036-006 Spraynet, cleaning spray 500 ml, box of 6 cans
n these instructions, “Device” corresponds to the product described in the
heading “Type”. For example, turbine, contra-angle, handpiece, micromotor,
tube, electronics, connectors, station etc.
List of Bien-Air Dental SA registered trade mark products ®:
Attention.
Aquilon®
Bora®
Boralina®
ChiroPro®
Eolia®
Gyro®
Gyrolina®
solite®
Lubrifluid®
Lubrimed®
MX®
PowerCare®
Prestilina®
Spraynet®
Manufacturer.
Optional accessories
REF 1300414-010
REF 212.65.01-001
Set supplied
Fixed connector for MC2
REF 1600120-001
REF 1600297-001
REF 1600314-001
REF 1600315-001
Rotatin connector for MC2
REF 1600298-001
REF 1600299-001
REF 1600316-001
Guarantee
Terms of guarantee
Bien-Air Dental grants the user a guarantee cover-
ing all functional defects, material or production
faults. The device is covered by this guarantee for
12 months from the date of invoicing.
Bien-Air Dental offers a 24-month guarantee for the
glass-bar light conductors.
n the event of justified claim,Bien-Air Dental or its
authorised representative will fulfil the company’s
obligations under this guarantee by repairing or re-
placing the product free of charge. Any other claims,
of whatever nature, in particular in the form of a
claim for damages and interest, are excluded.
Bien-Air Dental shall not be held responsible for
damage or injury and the consequences thereof, re-
sulting from:
• excessive wear and tear
• improper use
• non-observance of the instructions for installa-
tion, operation and maintenance
• unusual chemical, electrical or electrolytic
influences
• poor connections, whether of the air, water or
electricity supply.
The guarantee does not cover flexible “fibre optic”
type conductors,or any parts made of synthetic ma-
terials.
The guarantee shall become null and void if the
damage and its consequences are due to improper
manipulation of the product, or modifications to
the product carried out by persons not authorised
by Bien-Air Dental.
Claims under the terms of the guarantee will be
considered only on presentation, together with the
product, of the invoice or the consignment note, on
which the date of purchase, the product reference
and the Serial No. should be clearly indicated.
Symbols
Move fully to the stop, in
the direction indicated.
Move in the direction
indicated.
Wear rubber gloves.
0120
CE Marking with number
of the notified body.
