Bike-Lift Master 504 Gate User manual

Operating manual number 057-2-6-0001-R0 Page 1
Version 2021
EN
European Communities
Use and Maintenance Manual
Scissor lifting platform




Master 504 ate
Model
MA504-002
MA504-003
MA504-004
Version
COMPRESSED A R PUMP
ELECTRO-HYDRAUL C PUMP
ELECTRON C W TH REMOTE
CONTROL
MAX
516
ate
Model
Version

MG516
-
001
FOOT
PUMP

MG516
-
002
COMPRESSED
A R
PUMP

MG516
-
003
ELECTRO
-
HYDRAUL C
PUMP

MG516
-
004
ELECTRON C
W TH
REMOTE
CONTROL
MAX 516
Model
Version

M516
-
001
FOOT
PUMP

M516
-
002
COMPRESSED
A R
PUMP

M516
-
003
ELECTRO
-
HYDRAUL C
PUMP

M516
-
004/R
ELECTRON C
W TH
REMOTE
CONTROL
SPORT 500
Model
Version

SG500
-
001
FOOT
PUMP

SG500
-
002
COMPRESSED
A R
PUMP

SG500
-
003
ELECTRO
-
HYDRAUL C
PUMP

SG500
-
004/R
ELECTRON C
W TH
REMOTE
CONTROL
Bike-Lift Europe s.r.l.
via Don Milani, 40/42
43012 Sanguinaro i Fontanellato (PARMA) – Italy
Website: www.bikelifteurope.it
E-mail: [e-mail]

Operating manual number 057-2-6-0001-R0 Page 2
Version 2021
EN
Summary
1 nformation section ................................................................................................................... 4
Preface ................................................................................................................................................. 4
Prohibitions ......................................................................................................................................... 5
Warranty ............................................................................................................................................. 5
Warranty conditions ........................................................................................................................ 5
nsurance ......................................................................................................................................... 5
Manufacturer identification ................................................................................................................ 6
Technical assistance and spare parts .................................................................................................. 6
EC Declaration of conformity .............................................................................................................. 7
Normative references ......................................................................................................................... 8
Legend key ........................................................................................................................................... 9
2-Machine description .............................................................................................................. 10
2.1 Machine name ............................................................................................................................. 10
2.2 Machine identification .......................................................................................................... 10
2.3 Machine description .............................................................................................................. 11
2.4 ntended use ................................................................................................................................ 12
2.5 Technical specifications ............................................................................................................... 13
2.5.1 MASTER 506 GATE ......................................................................................................... 13
2.5.2 MAX 516 GATE ............................................................................................................... 14
2.5.3 MAX 516 ........................................................................................................................ 15
2.5.4 SPORT 500 ..................................................................................................................... 16
3. Safety section ............................................................................................................................... 17
3.1 Environmental working values .............................................................................................. 17
3.2 Sound level ............................................................................................................................ 17
3.3 Residual risks ......................................................................................................................... 17
3.4 Operator protections............................................................................................................. 18
3.5 Safety systems ....................................................................................................................... 18
3.6 Pictograms ............................................................................................................................. 20
3.7 Additional safety systems for the built-in version ................................................................ 21
4 Transport and handling section ................................................................................................ 22
4.1 Transport, handling and storage ........................................................................................... 22
Packaging and Transport ................................................................................................................... 22
4.2 Unloading and handling ........................................................................................................ 22
4.4 Receipt and check .................................................................................................................. 23
4.5 Storage .................................................................................................................................. 23

Operating manual number 057-2-6-0001-R0 Page 3
Version 2021
EN
5 nstallation section .................................................................................................................... 24
5.1 Power .................................................................................................................................... 24
5.2 Commissioning ...................................................................................................................... 25
6 Dismantling/scrapping section .............................................................................................. 26
6.1 Dismantling ............................................................................................................................ 26
6.2 Mechanical dismantling ........................................................................................................ 26
6.3 Scrapping ............................................................................................................................... 26
7. Operation section ................................................................................................................... 27
7.1 Loading operations ................................................................................................................ 27
7.2 Unloading operations ............................................................................................................ 28
7.3 Lifting types ........................................................................................................................... 28
7.3.1. HYDRAUL C FOOT PUMP - element code - 001 ............................................................. 28
7.3.2 COMPRESSED A R PUMP - element code - 002 ............................................................. 29
7.3.3 ELECTRO-HYDRAUL C PUMP - element code - 003 ....................................................... 29
7.3.4 ELECTRON C W TH REMOTE CONTROL - element code 004/R ..................................... 30
7.3.5. ELECTRO-HYDRAUL C PUMP built-in system - element code - 003/F ........................... 30
8 Maintenance section .................................................................................................................. 31
8.1 Lubrication ............................................................................................................................. 31
8.2 Bleeding of the hydraulic circuit ............................................................................................ 31
8.3 Piston replacement ............................................................................................................... 32
8.4 Cleaning ................................................................................................................................. 33
8.4.1 nitial cleaning ............................................................................................................... 33
8.4.2 General cleaning of the machine .................................................................................. 33
8.4.3 Cleaning the work areas ................................................................................................ 34
8.5 Problems and remedies ......................................................................................................... 34
8.5.1 FOOT PUMP ................................................................................................................... 35
8.5.2 A R PUMP ...................................................................................................................... 37
8.5.3. ELECTR C PUMP ............................................................................................................. 39
9 Accessories ................................................................................................................................. 41
SPARES / TECHN CAL DES GNS ……………………………………………………………………………………………………… 45
MASTER 506 GATE ……………………………………………………………………………………………………………… ...... 42
MAX 516 GATE ................................................................................................................................. 43
MAX 516 .......................................................................................................................................... 44
SPORT 500........................................................................................................................................ 45

Operating manual number 057-2-6-0001-R0 Page 4
Version 2021
EN
I
1 Information section
1.1 Preface
The European Communities (EC) Use and Maintenance Manual is a document issued by Bike-
Lift Europe s.r.l. as an integral part of the machine.
The purpose of this publication is to provide the operator with efficient and safe instructions
regarding the use and maintenance.
This Manual must be read entirely before starting any operation concerning the
installation, use, maintenance and putting out of service of the machine.
Therefore, it is necessary to be kept intact over time.
n order to properly store the Manual, it is recommended to:
 Use the Manual without deteriorating it;
 Do not remove, add, change or rewrite any part of the Manual; any modifications must
be made only by Bike-Lift Europe s.r.l.;
 Keep the Manual in areas protected against humidity in order not to compromise its
durability over time;
 Deliver the Manual to any other user or subsequent owner of the machine.
Workers in charge of using this machine must have all the necessary information
and must receive proper training.
The Manual and relative documentation are confidential by law with the prohibition of
reproduction or transmission to third parties without receiving the explicit authorisation of
the Manufacturer.
As a partial exception to the above mentioned, a copy of this Manual kept in the vicinity of
the machine is allowed for prompt reference, in case the original document is stored in a
different place, in order to guarantee better keeping over time.
Drawings, data and specifications contained in this Manual can be modified at any time by the
company, without prior notice.
n case of significant changes of the machine due to the installation of new parts, Bike-Lift
Europe s.r.l. will compile an updated Manual which will be sent to the Customer together with
the purchased part.

Operating manual number 057-2-6-0001-R0 Page 5
Version 2021
EN
1.2 Prohibitions
The installation, use, maintenance and putting out of service of the device with means,
objects, actions and anything else not provided for in this Manual is considered improper
and therefore the Manufacturer declines all responsibility for the consequences which may
occur regarding people, animals and objects.
t is expressly FORB DDEN the use of the machine by operators who do not
know the regulation and procedures described in the Manual and by
unauthorised people (hereinafter referred to as ‘non-operators’).
t is also forbidden the use of the machine by children and the non-operators or children
must not stand near the machine during all phases of the machine's life.
The putting out of service of the protection systems or anything else provided by the
Manufacturer to protect the operators is the sole responsibility of the Purchaser or the
machine's User.
Any mechanical, electrical or functional change of the machine (not provided for in this
Manual) regarding the control systems, the logic of controls, the circuits present, and the
safety systems is prohibited without the prior written authorisation of the Manufacturer.
1.3 Warranty
Bike-Lift Europe s.r.l. will not be held responsible for inconveniences, breakages, accidents,
etc. due to lack of knowledge or failure to apply the procedures specified in this Manual. The
same applies to the execution of modifications, changes or for the installation of accessories
not previously authorised.
1.3.1 Warranty conditions
Bike-Lift guarantees its products for 12 months, except for the commercial components
which are guaranteed by the manufacturers.
All worn parts are excluded from the warranty.
The warranty is limited to the replacement, ex-works Bike-Lift Europe, of those parts which
are recognised as defective by Bike-Lift Europe due to a material or manufacturing defect
and do not include labour or travel expenses required for their replacement.
The recognition of the warranty is void if the anomaly is due to an inappropriate use of the
product, if the installation was not carried out according to the provisions of the company or
if non-genuine parts were installed.
t also becomes void if the product has been submitted to performances exceeding those
indicated by Bike-Lift Europe s.r.l.
1.3.2 Insurance
All Bike-Lift products are insured with a Recurring Card Payment (RCP) policy with a price
ceiling of €3,000,000. Damages caused by negligence or tampering are excluded.

Operating manual number 057-2-6-0001-R0 Page 6
Version 2021
EN
1.4 Manufacturer identification
Bike-Lift Europe s.r.l. via Don Milani, 40/42, 43012 Sanguinaro di Fontanellato (PARMA) –
taly
Website: www.bikelifteurope.it
E-mail: [email protected]
Tel:. [phone]
Fax: [phone]
1.5 Technical assistance and spare parts
To order spare parts, it is recommended to specify exactly the following data:
 Model and serial number of the machine;
 Code number and part name;
 Required quantity;
 Shipping means, address and telephone number;
For replacements use only genuine spare parts.
Do not wait until the components are completely worn before replacing them.
CAUT ON: THE REC P ENT W LL BE CHARGED FOR THE REPLACEMENT TOGETHER
W TH THE SH PP NG COSTS.
We recommend that you always contact Bike-Lift Europe s.r.l. for all those assistance and
maintenance operations which are not described or indicated in this Manual.

Operating manual number 057-2-6-0001-R0 Page 7
Version 2021
EN
1.6 EC Declaration of conformity
(Annex II, part 1, section A of directive 2006/42/EC)
Manufacturer:
Company: ike-Lift EUROPE S.r.l.
Address: Via Don Milani, 40/42 - 43012 Sanguinaro di Fontanellato (PR) - Italy
Declares under its sole responsibility that the machines:
Designation: MAX 516//MAX 516 GATE/MASTER 506 GATE/SPORT 500 GATE
Liftingplatforms
Model: M516-001/M516-002/MG516-001/MG516-002/MA506-002/SG500-
001/SG500-002
Serial number:
Year:
Function: Lifting of motorcycles for vehicle maintenance operations
Complies with the essential safety requirements of the following Directive:
 2006/ 2/EC – Machineries Directive
Complies with the requirements of the following Harmonized Standards:
 UNI EN ISO 12100:2010 - Safety of machinery - General principles of design - Risk
assessment and risk reduction
 UNI EN 1 93:2010 – Lifts for vehicles
Person authorized to prepare the Technical Sheet:
Name: Alessandro Tozzi
Address: Via Don Milani, 40/42 - 43012 Sanguinaro di Fontanellato (PR) - Italy
Alessandro Tozzi
Legal Representative

Operating manual number 057-2-6-0001-R0 Page 8
Version 2021
EN
1.7 Normative references
The machine is identified by the European Communities (CE) marking drawn up according to
the specifications of the Machinery Directive 2006/42/EC and subsequent updates.
Reference Title
2006/42/EC Machinery Safety Directive
2014/30/EC Electromagnetic Compatibility Directive (EMC)
2014/35/EU Low-Voltage Directive (LVD)
EN SO 12100 (2010) Safety of machinery - General principles of design - Risk
Assessment and risk reduction
UN EN 349 (1993+A1:
2008)
Safety of machinery - Minimum spaces to avoid the
crushing of body parts
UN EN SO 13850 (2008) Safety of machinery - Emergency shutdown - Design
principles
EN 1493 (2010) European standard on vehicle lifting platforms
EN 60204-1 (2016)
Directive on the state of the art for the design and
construction of the electrical equipment of machines,
including the switchboard connected to the machines
EN 982 (2009)
Safety of machinery - Safety requirements related to
systems and their components for hydraulic fluid and
pneumatic transmissions - Hydraulic fluid
CNR UN 10011-88 Standard on steel constructions
UN 1285-68 Calculation of metal pipes resistance subject to internal
pressure

Operating manual number 057-2-6-0001-R0 Page 9
Version 2021
EN
1.8 Legend key
LIFTIN PLATFORM: hydraulic/electric/pneumatic scissor handling system for the
maintenance and repair of motorcycles and scooters. The specific identification of the lifting
platform is indicated on the cover.
OPERATOR: n compliance with Directive 2006/42/EC and subsequent updates, it is specified
that the term ‘operator’ means the person(s) in charge of installing, operating, adjusting and
cleaning the lifting platform. The maintenance and repair operations of the lifting platform
are the responsibility of competent personnel.
SYMBOLS MEANIN
Yellow triangle pictogram generally indicates a Warning /Risk, e.g. risk of high
temperatures, risk of crushing the hands, etc.
BLUE round pictogram generally indicates an obligation, for example the obligation to
wear certain Person Protective Equipment (PPE), e.g. goggles ... or the obligation to read
the User Manual.
Round red Prohibition pictogram indicates in general a Prohibition, for example, person
access prohibition, prohibition of hand access while the vehicle is moving.
ndicates that the operation can be performed by specialised personnel authorised by
the Employer.
Particular importance indication which requires attention.
Specifies an operation which can only be performed by trained personnel, or after
having read and consulted specific operating instructions.

Operating manual number 057-2-6-0001-R0 Page 10
Version 2021
EN
2- Machine description
2.1 Machine name
Scissor lifting platform for the maintenance and repair of motorcycles and scooters with a
maximum capacity of 500 kg.
The handling of the Bike-Lift lifting platforms can be done through one of the following
systems:
- hydraulic pedal system;
- compressed air system;
- electro-hydraulic system;
- electronic system with remote control.
This Manual refers to the model of lifting platform indicated on the cover
2.2 Machine identification
The identification data of the machine are indicated on the plate placed on the structure and
shown in the attached declaration of conformity.
Refer to these details for ordering spare parts and for any kind of contact with the
Manufacturer
t is absolutely forbidden for the user to remove or alter this plate. Any modification or
removal of the plate will void any warranty.
The machines can be subject to updates or small aesthetic changes and therefore have
different details than those shown, without prejudice to the descriptions and procedures
contained by this Manual.
Figure 1 – Example of a plate affixed to the machine

Operating manual number 057-2-6-0001-R0 Page 11
Version 2021
EN
2.3 Machine description
The machine known as Motorbike Lifting Platform is a suitable equipment to support
motorcycles during the maintenance and repair phase in a comfortable and safe way.
The basic parts of the lifting platform (see Figure 2) are:
Figure 2 – Model of a lifting platform
- an elevating work platform (red);
- a base which can be anchored to the ground (blue);
- a scissor lift system consisting of two crossed X-shaped legs (green) handled by a
hydraulic cylinder equipped with a parachute valve.
The fall protection system (shown in yellow in the following figure) consists of:
a mobile anchoring bar with automatic coupling which
prevents the accidental descent of the mobile surface.
a mechanical safety system consisting of two toothed
bars firmly welded to the base

Operating manual number 057-2-6-0001-R0 Page 12
Version 2021
EN
2.4 Intended use
Disseminate the instructions described in this chapter to all personnel
involved in the preparation and use of the machine.
The machine is intended for lifting motorcycles for maintenance purposes.
The machine has been designed and built for the specified use; a different use
and non-compliance with the technical parameters set by the Manufacturer may
be dangerous for the operators.
t can be used in the mechanical motorcycles repair shops both for the mechanical part and
for the bodywork.
Any other use different from the one indicated is to be considered as not planned
and may cause damage to the machine and operators. t is therefore FORBIDDEN.
The machine must always be operated by only one operator.
The operator must always work in proper lighting conditions and wear clothes and protections
appropriate to the task performed (typical activity of mechanical workshop)
The working position of the operator during the ascent and descent phases is in the area
around the machine at the safety distance allowed by the cable length of the control panel.
t is absolutely forbidden to lift motorcycles while leaning on the side
kickstand.
Do not try to lift motor vehicles weighing more than the maximum capacity
of the platform.
Do not try to lift four-wheeled vehicles, using two lifting platforms placed
side by side.
Do not stand under the motorcycle in case of the ‘gate’ version.

Operating manual number 057-2-6-0001-R0 Page 13
Version 2021
EN
2.5 Technical specifications
2.5.1 MASTER 506 ATE
(see exploded diagram attached to this Manual)
VERT CAL SC SSOR L FT NG PLATFORM - MASTER 506
GATE
PARAMETER VALUE
Maximum load capacity 500 kg
Maximum height 130 cm
Minimum height 19 cm
Safety locking positions 8
Lifting tabletop size 220x75 cm
Side wings size 212x8.5 cm
Overall dimensions of the lifting
platform 220x92 cm
GATE size 60x36 cm
Run-up ramp size 82x51 cm
Total space of the lift 230x92 cm
Weight 250 kg
The following additional data are available depending on the type of handling:
2.5.1.1 MASTER 506 GATE – MA506-002
AIR PUMP (AIR-HYDRAULIC)
PARAMETER VALUE
Air pressure 7-10 Bar
Air consumption 300 Lt/Min.
2.5.1.2 MASTER 506 GATE – MA506-00
ELECTRO-HYDRAULIC CONTROL UNIT
PARAMETER VALUE
Available power supplies
230Volt- 50Hz Europe
200Volt-50/60Hz Japan
110Volt-60Hz USA
Power 1,1 kW
Available controls Series button panel

Operating manual number 057-2-6-0001-R0 Page 14
Version 2021
EN
2.5.2 MAX 516 ATE
(see exploded diagram attached to this Manual)
VERTICAL SCISSOR LIFTIN PLATFORM – MAX 516 ATE
PARAMETER VALUE
Maximum bearing 500 kg
Maximum height 120 cm
Minimum height 19 cm
Safety positions number 8
Lifting surface size 210x75 cm
Side wings size 210x12 cm
Total space of the lifting platform 210x99 cm
GATE size 60x36 cm
Ascent ramp size 83x51 cm
Total space of the lift 220x99 cm
Weight 250 kg
The following additional data are available depending on the type of handling:
2.5.2.1 MAX 516 GATE – MG516-002
AIR PUMP (AIR-HYDRAULIC)
PARAMETER VALUE
Air pressure 7-10 Bar
Air consumption 300 Lt/Min.
2.5.2.2 MAX 516 GATE – MG516-00
ELECTRO-HYDRAULIC CONTROL UNIT
PARAMETER VALUE
Available power supplies
230Volt- -50Hz Europe
200Volt-50/60Hz Japan
110Volt-60Hz USA
Power 1,1 kW
Available controls Series button panel

Operating manual number 057-2-6-0001-R0 Page 15
Version 2021
EN
2.5.3 MAX 516
(see exploded diagram attached to this Manual)
VERT CAL SC SSOR L FT NG PLATFORM – MAX 516
PARAMETER VALUE
Maximum bearing 500 kg
Maximum height 120 cm
Minimum height 19 cm
Safety positions number 8
Lifting surface size 210x75 cm
Side wings size 210x12 cm
Total space of the lifting platform 210x99 cm
GATE size 60x36 cm
Ascent ramp size 82x51 cm
Total space of the lift 220x99 cm
Weight 250 kg
The following additional data are available depending on the type of handling:
2.5. .1 MAX 516 – M516-002
A R PUMP (A R-HYDRAUL C)
PARAMETER VALUE
Air pressure 7-10 Bar
Air consumption 300 Lt/Min.
2.5. .2 MAX 516 – M516-00
ELECTRO-HYDRAUL C CONTROL UN T
PARAMETER VALUE
Available power supplies
230Volt- -50Hz Europe
200Volt-50/60Hz Japan
110Volt-60Hz USA
Power 1,1 kW
Available controls Series button panel

Operating manual number 057-2-6-0001-R0 Page 16
Version 2021
EN
2.5.4 SPORT 500
(see exploded diagram attached to this Manual)
VERT CAL SC SSOR L FT NG PLATFORM – SPORT 500
PARAMETER VALUE
Maximum bearing 500 kg
Maximum height 120 cm
Minimum height 19 cm
Safety positions number 8
Lifting surface size 210x60 cm
Side wings size 210x12 cm
Total space of the lifting
platform
210x84 cm
GATE size 60x36 cm
Ascent ramp size 62x44 cm
Total space of the lift 220x84 cm
Weight 190 kg
The following additional data are available depending on the type of handling:
2.5.4.1 SPORT 500 – SG500-002
A R PUMP (A R-HYDRAUL C)
PARAMETER VALUE
Air pressure 7-10 Bar
Air consumption 300 Lt/Min.
2.5.4.2 SPORT 500 – SG500-00
ELECTRO-HYDRAUL C CONTROL UN T
PARAMETER VALUE
Available power supplies
230Volt- -50Hz Europe
200Volt-50/60Hz Japan
110Volt-60Hz USA
Power 1,1 kW
Available controls Series button panel

Operating manual number 057-2-6-0001-R0 Page 17
Version 2021
EN
3 Safety section
3.1 Environmental working values
The use environment of the machine must be well lit, must not present explosion hazards of
any kind and must be protected from atmospheric precipitations.
The machine works properly within the following values:
 Ambient temperature between 5° and 40° C;
 Ambient humidity between 30% and 90% without condensation;
STORAGE: if the machine has been unpacked, store it in a closed space protected from bad
weather conditions.
3.2 Sound level
During the normal conditions of use some measurements were made at the workplace and
around the machine at a distance of 1 m and at 1.6 m height above the ground.
The survey was carried out with a sound level meter, complying with EC 651 standard, class
1 and the result of the assessment was lower than the minimum limit of action required by
the regulations in force.
3.3 Residual risks
The use of the lifting platform is the absolute prerogative of professional
operators and specialised technicians, in compliance with the
requirements of Machinery Directive 2006/42/ EC and subsequent
updates.
Operators must be in full possession of all physical and mental abilities during the
performance of their tasks on the machine; they must not, for example, be under the influence
of sedatives, drugs or alcohol.
Before carrying out the work, the operators must be perfectly aware of
the position and operation of all the controls and specifications of the
machine indicated in the ‘EC Use and Maintenance Manual’.
t is forbidden to use the lifting platform for a purpose other than those provided by the
Manufacturer.
Always pay attention to the danger and/or warning signs placed on the machine or in adjacent
areas.
The machine must always be operated by only one operator placed at
the safety distance allowed by the cable length of the control panel.
The operators standing areas must always be kept clean and free of any oily residues to allow
an easy and safe passage.
The putting out of service of the protection and safety devices for protecting the operators is
the sole responsibility of the Purchaser or the machine's user.
i

Operating manual number 057-2-6-0001-R0 Page 18
Version 2021
EN
Finally, we remind you that the handling, installation, use, maintenance and putting out of
service of the machine represent a source of danger if these operations are not performed in
compliance with the requirements of this Manual or without the necessary caution and
attention required.
(Further and better details regarding the Risk Assessment to be requested from the
Manufacturer).
3.4 Operator protections
Before starting any type of work on the motorcycle lifting platform,
the operator must wear appropriate PPE, such as gloves and safety
footwear.
Always wear work clothing normally used in the mechanical workshop
activity.
3.5 Safety systems
The machine is equipped with a mechanical safety device (Figure 3) consisting of a mechanical
safety bar for standing at the working height, with the lower stroke limitation made by lock
blocks welded to the lower base.
Figure 3 – Mechanical stop system
mobile anchoring bar with automatic coupling which
prevents the accidental descent of the mobile surface.
mechanical safety system consisting of two toothed
bars firmly welded to the base
The lifting piston has a parachute valve which locks the cylinder in case the oil cable is
In order to make the machine safe during the ascent phase:
1- Allow the anchoring bar to move freely around the perimeter of the toothed bar on the
base;
2- When the selected position is reached, leave the bar uncoupled; this will act as a
mechanical stop in case of an uncontrolled fall of the structure.
In order to make the machine safe during the descent phase:
1- Hook the anchoring bar to the appropriate lock in order not to hinder the correct descent
of the system;
2- f the system is brought to the lower stroke (therefore in a position of minimum height),
the bar will automatically release to allow the ascent; otherwise, select the chosen
position to hook the bar which will act as a mechanical stop in case of an uncontrolled
fall of the structure.

Operating manual number 057-2-6-0001-R0 Page 19
Version 2021
EN
blanked.

Operating manual number 057-2-6-0001-R0 Page 20
Version 2021
EN
ALWAYS keep the mechanical lock hooked during work, in order to weigh down
the weight of the structure and of the vehicle standing on it even on the toothed
bars at the base.
During the use of the lifting platform it is very important to pay the utmost attention to the
ascent and descent manoeuvres. During the ascent/descent phase the operator is required to
distance from the lifting platform according to the length allowed by the control panel cable.
The personnel who are not in charge of using the lift must not pass or stand in the operating
area of the motorcycle lifting platform.
The machine must always be operated by only one operator.
Once the motorcycle is loaded on the lifting platform, place it in a vice or use the
rear kickstand, then fasten it firmly to the openings and the wheel lock by using a
belt.
G VEN THE BEAR NG VALUE ND CATED ON THE PLATE:
Do not exceed the load capacity of the lifting platform;
Use it only to lift objects;
Do not modify the lifting platform;
The load must always remain firm and stable.
3.6 Pictograms
Danger of crushing hands with the lifting platform arms.
When the platform is at the desired height, insert the locking bar to prevent it
from falling down accidentally.
Load the motorcycle only when the platform is completely lowered.
Before lifting it, make sure that nothing is supported by the ramp.
Do not lean the rear wheel of the motorcycle on the ramp during and after
lifting.
