bintec elmeg elmeg IP130 – More than just a telephone
elmeg IP130 – More than just a telephone
Your elmeg IP130is an IP phone designed for professional use.
uEasy to set up
Use automatic configuration together with a phone system of the elmeg hybird product
family.
uWeb user interfaces for telephony and configuration
Operate and configure your telephone from your PC with ease.
uHigh Definition Sound Performance – HDSP
Make phone calls with brilliant sound quality.
uPhone functions for the professional user
Use the call divert, conference call, call reject and Do Not Disturb (DND) functions.
uMultiple directories
Manage your personal directory with up to 500 vCards (caller pictures are possible) or use an
corporate directory (LDAP).
uNetwork connection
Connect your telephone to the local network via Ethernet. Connect a PC using your tele-
phone as a gigabit Ethernet switch.
uProtect the environment
Reduce environmental pollution with the power-saving power adapter .
uIndividual settings
Load your own pictures and ringers, subscribe to Internet services and choose how you want
the display to look.
Assign functions or frequently used numbers to the keys.
Further information about your phone can be found at
www.bintec-elmeg.com

elmeg IP130 / en / elmegIP130_v1_April-2014 / overview.fm / 09.04.2014
Version 2, 27.05.2010
4elmeg IP130
bintec elmegPhone overview
Phone overview
1Mute key Activate/deactivate microphone (mute) £Page 36
2Speaker key Activate/deactivate speaker £Page 36
3Headset key Make call via headset £Page 34
4Volume key Depending on the operating mode: Adjust the volume of the
speaker, receiver, headset or ringer £Page 35
5Display keys Control of display functions £Page 22
6Information Centre Open the Information Centre £Page 64
7Do Not Disturb key Do Not Disturb (DND) function £Page 36
8Call records key Record a call £Page 37
9Message Centre Open call and message lists £Page 58
10 End call/back key End/reject call; cancel function;
go back one menu level (press briefly);
return to idle status (press and hold)
£Page 26
£Page 24
11 Navigation key Scroll through lists and entries. In idle status: £Page 24
È
Open redial list. £Page 43
‰
Confirm or start action, select entry £Page 24
Z
Open directory £Page 47
12 Consultation key Initiate/end consultation call £Page 39
13 Conference key Initiate conference call £Page 40
14 Transfer key Transfer call to another party £Page 41
15 Function keys Programmable keys £Page 120
Understanding the keys
21 3 4 5
6 7 8 9 10 11 12 13 14 15

elmeg IP130 / en / elmegIP130_v1_April-2014 / overview.fm / 09.04.2014
Version 2, 27.05.2010
5elmeg IP130
bintec elmeg Phone overview
Understanding Light Emitting Diodes (LEDs)
Understanding the display
Understanding the display symbols
A
Flashes Incoming call. £Page 34
Lights up Call is being made via the speaker. £Page 36
B
Flashes Incoming call (a headset must be connected). £Page 34
Lights up Call is being made via the headset. £Page 34
C
Lights up The microphone is muted. £Page 36
E
Flashes New message in the Message Centre. £Page 58
F
Lights up Call is being recorded. £Page 37
G
Lights up "Do Not Disturb" function is activated. £Page 36
J
Lights up One or more callers on hold. £Page 39
K
Lights up Conference call is activated. £Page 40
S
Flashes Incoming call on the number programmed to this key. £Page 33
Lights up Call is being made on the number programmed to this key.
ó
Ringer deactivated. £Page 67
Ã
New messages on the network mailbox. The number
is displayed to the
right.
£Page 53
™
Missed calls. £Page 43
Ë
New e-mails. £Page 55
·
Alarm clock function activated. The wake-up time is displayed to the right. £Page 61
Other icons may appear depending on the function. These are displayed alongside the corresponding
description.
Call Select Line
Current time
Area of application
Adjustable display, e.g.,
time zone, time, calendar,
picture £Page 70
Display functions
(Page 22)
T
T
T
Display icons
T
Display icons
Date and Time
U
U
You set the time and date
format using the Web
configurator
£Page 125.
Currently used
account £Page 31
U
