Birlea Winchester 3 Door 2 Drawer Sideboard User manual

Assembly Instructions
Thank you for
purchasing a
Birlea product.
Forachancetowina Love 2 Shop voucher
simplypostapictureofyournewproduct
onyourpreferredsocialchannelstagging
Birlea Furniture and using the hashtag
#ShareYourStyle and #Birlea .Onewinner
willbeselectedatrandomeachmonth.
To view our full terms and conditions please visit our website. www.birlea.com
Are you happy with your purchase?
Yes: That’sgreat,wewouldlovetohearmorefromyou.Pleaseleaveusareviewon
oursocialmediachannelsorTrustpilot.Yourfeedbackwillbegreatlyappreciated.
No: Ifforanyreasonthereissomethingmissing,indifferentorincorrectwith
yourorder,pleasecontacttheretaileryoupurchasedtheitemfrom.Wewill
workwiththeretailertoresolveyourissueasquicklyaspossible.
www.birlea.com

IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLING OR USING YOUR WINCHESTER 3 DOOR 2 DRAWER SIDEBOARD.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damage or
worn.
DO NOT use this item unless all fixings are secured.
Please keep small parts out of reach of
children. Always use on a level, even
surface.
It is recommended that two people handle and assemble the item.
Birlea advise you use the wall straps provided to further enhance the safety of this product.
CARE & MAINTENANCE:
Assemble in the room of use.
To avoid damages assemble the item on a soft, clean
surface Periodically check all screws & fixings to ensure
they are secure. DO NOT push the item as this will
damage the base.
Always lift the item with two people to
reposition. Keep any sharp objects away
from the item.
This product is manufactured in pine which is a wood with natural characteristics including knots,
grains, clusters or indentations.
On unpacking the item you may notice an odour due to production processes but this will disappear
after a period of time.
DO NOT place the item next to a radiator or direct sunlight – this item is susceptible to temperature
change. It is recommended an even room temperature be maintained with no sudden fluctuations.
DO NOT place hot or cold items directly onto the surface of the item as marking will occur
For general cleaning use a duster or damp cloth (almost dry) not wet - do not use soap and water ,
detergents, aerosol sprays or any polish as use of these would invalidate any claims.
DO NOT place the item onto wet or damp flooring as staining may occur to the floor.
Page 1 of 8
www.birlea.com
Vendor: S000401
813mm
1119mm
356mm
ASSEMBLY INSTRUCTIONS
WINCHESTER 3 DOOR 2 DRAWER SIDEBOARD

Page 2 of 8
Vendor: S000401
012345678 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6
mm
2X
Hardware List
Part Item Qty
A Wooden Dowel 22
B Cam Bolt 30
C Cam Lock 30
D Tack 60
E Slip Shoe 5
F 40mm Screw 6
G 14mm Screw 44
H Sticker 2
I Handle 5
J Side Slide 2
K Drawer Slide 2
L Safety Strap 1
M 25mm Screw 3
N Hinge 6
O Shelf Support 8
P Back Profile 1
Q Silicone Stop 3
Parts List
Part Item Qty
1 Right Side 1
2 Left Side 1
3 Base 1
4 Top 1
5 Division 1
6 Traverse 2
7 Baseboard 1
8 Right Column 2
9 Left Column 2
10 Back 1
11 Drawer Front 2
12 Drawer Back 2
13 Drawer Side 4
14 Drawer Bottom 2
15 Door 3
16 Shelf 1
17 Larger Back 2
18 Upper Back 1
19 Larger Division 1
20 Smaller Shelf 1
1
2
4
3
16
20
5
19
11
12
13
13
14
8
9
9
8
7
6
6
10
18
17
17
3X
Drawer Door
15

Page 3 of 8
Vendor: S000401
A
A
7
1
G
J
G
G
G
J
6
A
A
2
B
BB
B
B
B
B
B
4
B
B
98
Step 2: Insert the hardware (B) in the right side (1), left side (2), top (4), right column (8), left column
(9), drawer back (12) and drawer front (11). Then attach hardware (J) to the right side (1) and left
side (2) using hardware (G) and fix hardware (O) in the right side (1) and left side (2).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
A
5
A
A
4X
B
B
B
B11
12 2X
2X
B
O
O
BG
G
J
2X
13
A
A
A
19
O
O
Step 1: Insert the hardware (A) into the division (5), traverse (6), drawer side (13), baseboard (7)
and larger division (19). Then attach hardware (J) to the division (5) using hardware (G) and fix
hardware (O) in the larger division (19).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
2X

Page 4 of 8
Vendor: S000401
C
B
1
9
8
3
2
7
19
6
6
C
C
C
C
F
C
C
F
F
C
C
8
9
Step 3: Attach the right column (8), left column (9), traverse (6), and the base (3) to the right side
(1) and left side (2) using hardware (C) Then attach baseboard (7) to the bottom of the base (3),
and attach larger division (19) to the base (3) and traverse (6) using hardware (F), (A) and
screwdriver (not provided).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.

Page 5 of 8
Vendor: S000401
5
F
D
E
9
8
9
F
4
C
C
C
Step 4: Fix the division (5) to the traverse (6) using hardware (F), (A) and screwdriver (not provided).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
6
6
Step 5: Attach the top (4) using hardware (C). Then attach hardware (E) and (D) to the bottom of the
right column (8), left column (9) and baseboard (7).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
C
5
1
2

Page 6 of 8
Vendor: S000401
BC
C
G
K
K
2X 2X
2X
14
13
13
12 11
GG
G
GI
C
Step 7: Attach hardware (N) to the door (15) using hardware (G).
Attach hardware (I) to the door (15) using hardware (M).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
G
N
G
M
N
I
15
3X
Step 6: Attach the drawer side (13) to the drawer back (12) using hardware (C) then insert the
dawer bottom (14).
Attach the drawer front (11) to the drawer side (13) using hardware (C). Then attach hardware (K)
onto the drawer side (13) using hardware (G).
Attach hardware (I) to the drawer front (11) using hardware (G).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.

Page 7 of 8
Vendor: S000401
D
D
D17
P
P17
D
Step 9: Fix the door (15) in the right side (1), larger division (19) and left side (2) using hardware (G)
and (N).
Insert the shelf (16) and smaller shelf (20) inside the product, above the hardware (O).
Insert hardware (Q) in the shelf (16) and smaller shelf (20) to hit the door (15).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
15
15
15 G
N
Step 8: Attach the back (10), larger back (17) and upper back (18) to the back of the assembled
product using hardware (D) and combining them using hardware (P).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
17
10
18
D
17
15
16
20
Q

Page 8 of 8
Vendor: S000401
Additional Information:
• For complete product information, images and dimension diagrams
please visit the website www.birlea.com
• If you have any issues with your item please contact the retailer
directly you purchased it from who will be able to resolve any
issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [e-mail]
to be shared in our #birleahome feature on Instagram.
Step 10: Insert the drawers as shown below.
Insert the hardware (H) into the apparent holes.
Attach the safety strap (L) to the back of the sideboard and wall following the diagram.
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
K
J
H
Inserting the Drawers
L
Safety Strap
