Birlea Faro Bed User manual

Vendor: S000053
Page 1 of 5
ASSEMBLY INSTRUCTIONS
FARO 4’ BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR FARO
4’ BED FRAME
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
lways use on a level, even surface.
WARNING: If this ed is placed on a non-carpeted floor you must place some protection under all legs to stop
the ed frame from moving. If this is not adhered to there is no guarantee if the ed frame collapses.
CARE & MAINTENANCE:
ssemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
lways lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com

Vendor: S000053
Page 2 of 5
Parts List Hardware List (found in ox 1)
Part Description Box Qty Part Description Qty
1 Headend 1 1 A 50 mm Black Round Stopper 4
2 Footend 1 1 B M6 x 16 mm JCBC Screw 8
3 Side Support 2 2 C M6 x 50 mm JCBC Screw 4
4 Side Frame 2 2 D M6 Nut 10
5 Mid Support 2 1 E M8 x 50 mm JCBC Screw 2
6 Base Leg 1 3 F M8 Nut 2
7 Slat 3 22 G M6 x 35 mm JCBC Screw 6
** M4 Allen Key and M5 Allen Key provided H Double Slat Cap 11
I Single Slat Cap 22

Vendor: S000053
Page 3 of 5
Step 1: Insert hardware part to the headend (1) and footend (2).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 2: Fix the side supports (3) to the headend (1) and footend (2) using hardware part but do not fully
tighten yet.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 3: Place the side frames (4) underneath the side supports (3) and tightly secure using hardware parts C
and D.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.

Vendor: S000053
Page 4 of 5
Step 4: Place the mid support (5) on top of the side frames (4) and tightly secure using hardware parts E and
F.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 5: Fit the base legs (6) to the mid support (5) according to the holes at the side, then tightly secure
using hardware parts D and G.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 6: Fit hardware part H to the mid support (5) then place hardware part I onto the end of each slat (7).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.

Vendor: S000053
Page 5 of 5
Step 7: Slide the slats (7) into hardware part H on the mid support (5) then push the ends into the side
supports (3) firmly.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
