Decon wheel Action 5 User manual

2020-01-07
Assembly instructions for Action 5 with e-Drive
MED3183
1. Remove wheels on both sides.
2. Check the correct placement for the stop pin and remove Battery Box and anti-tip
devices.

2020-01-07
3. Assembly the plate (right side) according to picture.
4. Parts pair mountingset:
ITEM PART NUMBER QTY DESCRIPTION
1 405239 1 Nordlock Washer M16
2 XSM8ML 1 Nut Self-Locking M8
3 XSM16M 1 Nut M16 Low
4 100 400 007 2 Spacer
5 HW069 1 Sleeve
6 100 400 001 1 Spacer
7 100 400 005 1 Spacer
8 XSM8BR 1 Washer Plain M8
9 XSM8X45 1 Screw Rounded M8 x 45
10 MED2000 1 Bracket
11 100 400 017 1 Spacer
5. Adjust the parking brake.

2020-01-07
Assembly of the joystick
6. Assemble the joystick on the right side, see the pictures above.
Item No. Part Number Qty Description
1 XOC-46295-00 1 Sheet Metal Bracket
2 XSM6X16 2 Screw - Round - M6 x 16
3 XSM6ML 2 Locknut M6
4 XOC-48160-B0 1 Upper holder assembly 2
5 MED1500 1 Bracket
6 XSM6BR 4 Plain Washer M6
7 Screw Original Not Included 2 Screw Original Not Included
Note! If the assemble is on the left side use MED1300 instead of MED1500.

2020-01-07
Item No. Part Number Qty Description
1 XSM6TG 1 Washer
2 Xklamma3 1 Clamp
3 XSM6X20 1 Screw M6 x 20
4 XSM6BR 1 Plain Washer 6,4
5 MED1200 1 Attendant control (Not included)
Assembly of the joystick as an attendant control (both sides)
MED1436
Item No. Part Number Qty Description
1 MED1317 1 Bracket
2 XSM6X35 1 Screw M6 x 35
3 XSM6X16 2 Screw M6 x 16
4 XSM6BR 3 Plain Washer M6
5 XSM6ML 3 Lock Nut M6
6 MED1316 1 Plate with Pin
7 Xklamma3 1 Clamp
8 100 400 044 1 Spacer
If the Joystick
is placed on
the Left side
turn it around
to the other
side.

2020-01-07
Brake adjustment
7. Move the spacer to the outside and adjust parking brake.
