Bittel UNOMedia 77 User manual

BITTEL Page 1 of 20 HA9888(77)TSD
Uno Media 5 Serisi
HA9888(77)TSD
Asagida ki tanim ve tarifler,
Gercek urunden az da olsa farkilik gosterebilir
Lutfen kullanimda gercek urunu esas aliniz.
Telefon, bir not verilmeden degisebilir.
Cihazi dogru kullanmak ve kullanima hazir duruma getirmek icin
lutfen bu klavuzu okuyun.
Otel / Moteller icin iyi seyler yapiyoruz ! ..

BITTEL Page 2 of 20 HA9888(77)TSD
TELEFON BOLUMU -ANA ISLEVLER
●9 adet Hizli Arama Tusu
●R.P master cloner ve el cloner’i ile Program Hafiza Tuslari
●Otel logosu, kontakt bilgileri, v.s. oldugu kartonun girdigi cekmece
●Hemen hemen butun Santrallara es uyumlu Mesaj Uyari Isigi
●HAC, Duyma Ozurlu aletinde parazit yapmayan Ahize
●3 seviye Ses Siddet Ayarli, hoparlor ve ahize
●2 seviye Ses Siddet Ayarli, zil
●Telefon mesgul’de kalsa bile, caldirilabilir. Bittel Patenti
●Aranmis numara bilgisi, 5 san. sonra silinir. Bittel Patenti
●Olan Cagri, TUT ta beleyebilir HOLD tusu
●Kesme, MUTE
●Ahizesiz konusma imkanı, Eller Serbest …
●Hat, 2 adet olabilir ve Konferans gorusme
●Medya katlari, Alarm Saat, Radyo, Ses Muzik Calma, Bluetooth, Sarj
●Hemen hemen tum akilli telefon ve tabletlere kolayca baglanir
●Bu aygitlara SARJ imkani
●Stereo HI - FI ses imkanı
●Four USB Charging ports for portable type iPod and mobile device
●Saatin Zaman Clone’lama aleti ile kolay sekilde ayari
KURULUS
1. Dongusel kablonun bir ucunu ahizeye,
diğer ucunu govdenin solunda ki kablo soketine takin
2. AC Akimi baglamak
Adaptor fisini, AC prize ve diger DC ucunu, setin arkasida ki prize takin
3. Telefon Kablosu
RJ11 veya RJ4 duvar uclu Telefon kablosunun TO TEL yazan ucunu
Telefonun arkasinda ki prize, diger ucunu duvar prizine takin.

BITTEL Page 3 of 20 HA9888(77)TSD
4. Dikkat Edilecekler
●Setin uzerinde mekanik degil, manyetik switch vardır,
Set etrafinda MANYETIK alan olmasın.
●Asiri sicak uygulamayin
●Telefon modifiye etmek icin acmayin
●Setin uzeirne Sert cisim mudahalesi uygulamayin
●Sette bir ariza varsa, Yetkili Merkeze lutfen haber verin
SET ÜZERİNDE KİMODULLER
1. Fonksiyon Tuslari ve “Mesajiniz Var”Uyari Ikaz Iisigi
2. Dijital tuslar
3. HAC uyumlu ahize ve prizi.
4. Ekran ——Alarm, Saat, Radyo Kanali,
Ses seviyesi, Bluetooth ID, v.s. gosterir
5. Infrared Alim Alani ----- Zaman kontrol yukleme icin
6. Otel Kartonu —— Otel logosu, Iletisim ve Kullanim Bilgileri.
7. Hizli Arama tuslari
8. Ses ve Ayar tuslari.
9. Zil Sesi Seviye Tusu——Yuksek veya Alcak, 2 ayar ..
10. To Tel port’u
11. Adaptor DC prizi
12. Pil Kutusu——Dis akim gelmedigi zaman devreye girer.
NASIL KULLANILIR
Telefon nasil kullanilir ?
1. Gorusmede SES ayari
Gorusmede, tuslarina basar Ses seviyesini ayarlayabilirsiniz.
Seviye, son birakildigi yerde kalir.
Muzik aninda bu tuslar, Ses ayari icin de kullanilir.
2. Gorusmede Ahize ve “Eller Serbest”gecisi
1) Ahize’den, “Eller Serbest”e :
SPKR tusuna basin ve ahizeyi yerine koyun
2) “Eller Serbest”ten, Ahize’ye :
Sadece ahizeyi kaldirin

BITTEL Page 4 of 20 HA9888(77)TSD
3. Aramayi cevaplama
a. Telefon caliginda, ahizeyi kaldirin veya SPKR tusuna basin.
b. Bir gorusme aninda, (telefon 2 hatli ise) ve 2. hattan da arama geliyor ise;
2. aramanin geldigi tusa bastiginizda, gelen arama ile gorusemeye
gecersiniz.
ilk gorusme devre disi kalir.
Hangi hattin devre disi kalmamasini istiyor iseniz, HOLD'da basin, ve
ardindan hangi hatti askiya almak istiyor isenin o hattin tusuna basin, o
arama askida kalacaktir.
4. 3 yollu konferans gorusme
a. Gorustugunuz anda, HOLD'a basin, telefonun diger hattindan 2.
gorusmeye gecebilirsiniz. Gectikten sonra CONF tusuna bastiginizda 3 kisi
ayni anda karslikli gorusebilir.
b. bu durumda sadece hangi hat ile gorusmek istiyor iseniz, o hattin tusuna
basin, sadece o hat ile gorusmeye baslarsiniz. Veyahut konferans aninda,
HOLD tusuna basip, karsinizda ki 2 kisiyi aski'ya alabilir ve istediginiz hat
tusuna basip, sadece o hat ile gorusebilirsiniz. Bundan sonra CONF tusuna
tekrar bastiginizda, konfrans moduna tekrar donebilirsiniz.
5. Son arana numarayi tekrar cevirme
Son aradiginiz numarayi tekrar cevirmek icin sadece REDiAL tusuna basin.
Ancak gizlilik icin, bu ozellikte saklanan numralar 5 dakika sonra kaybolur,
daha acik deyisle bu ozelik 5 dakika sonra yoktur.
6. HOLD (TUT) tusunu kullanmak
Ahize elde iken, HOLD tusuna basin ve ahizeyi govdeye birakin.
Gorusme yaptiginiz kisi, askida kalacaktir (LED gosterge isigi yanacaktir)
Tekrar ahizeyi kaldirdiginizda, karsinizda ki kisi aski'dan cikacaktir.
Paralel yapida telefon ikinci bir aramayi alir ise,
telefon otomatik HOLD moduna girebilir.
7. Mute (Kesme)
Bu tusa bastiginizda, sizden karsiya herhangi bir ses gitmez.
Tekrar bastiginiz ses gider.
8. Zil sesini ayarlamak

BITTEL Page 5 of 20 HA9888(77)TSD
Govdinin arkasinda ki Low ve Hi (Alcak - Yuksek) seceneklerinden birini
secerek zil ses siddetini ayarliyabilirsiniz.
9. Mesgul durumundan otomatik cikma
Bazi kereler, ahize govdedin uzerine tam olarak oturmayabilir.
Bu durumda telefon devamli mesgul konumdadir.
Tanimlanan belli bir sure sonunda telefon devamli mesgul durumunda
calmaya zorlanirsa, mesgul konumda cikar ve calmaya baslar.
10. CALLER iD ozelligi
Telefon, ilk olarak o hatta calismaya basladiginda, gelen aramanin DTMF mi
veya FSK (darbeli) mi oldugunu otomatik olarak anlar ve bunu hafizaya atar.
Bu anlama ozelligini degistirmek icin (baska bir hatta kullanilacak ise),
telefon hattan cikarilmali ve akim tekrar verilmelidir.
Bu telefonlarda, “gizlilik”icin, gelen arama bilgisi belirli bir zaman sonra
kaybolur.
11. Hizli arama tuslarini kullanmak
“Ahize elde”durumda, hizli arama tuslarindan birine bastiginizda,
o tus hangi dahili numara kaydi yapilmis ise, o numarayi arar.
Hafiza tusuna kayit :
Ahize yerinde modunda, HOLD tusuna basin+giris yapmak istediginiz
dahili no.yu+HOLD tusuna+hangi tusa atanacak ise o tusa basin.
12. Mesaj isigi
Ahize govde'de modunda, mesaj isigi tusuna basin, telefon otomatik
olarak,
programlanmis mesaj servisini arayacak ve o odanin mesajini, sistemin
ozelligine gore okuyacaktir.
Ahize govde'de modunda, Mesaj isigi tusuna basin, telefon otomatik
olarak,
programlanmis mesaj servisini arayacak ve o odanin mesajini, sistemin
ozelligine gore okuyacaktir.
Mesaj isiginin hafiza tusuna kayit :
HOLD tusuna basin+giris yapmak istediginiz dahili no.yu+HOLD
tusuna+mesaj isigi tusuna basin.

BITTEL Page 6 of 20 HA9888(77)TSD
13. Tuslarin hizli bir sekilde hafiza programlanmasi
Bu islem icin ana merkezi ve el programlama cihazlari kallanilacaktir ve bu
unitelerin ayri kullanim klavuzlari vardir.
Lutfen bunlari okuyun.
MEDYA BOLUMU -ANA ISLEVLER
UnoMedia (77) serisi telefonlar, Elektronik Tasarim ve Govde tipi
bakimindan cesitli patentlere sahip olup otellerin odalarinda telefon
gorusmesi ve
diger medya imkanlari icin uretilmistir.
İki ana bolumu mevcuttur, 1.si, bilinen telefon gorusmeleri icin tasarlanmistir,
diger bolum; iPod / iPhone ve diger Gsm’lerde Muzik, Alarm saat, FM
radyo , Gsm ler sarj imkani gibi bir takim yan işlevlere de sahiptir.
Bunun yaninda, unite üzerinde Bluetooth, NFC (akilli baglanma), Ustun ve
Kaliteli Ses ve Sub Bass Arka Tema imkani gibi ek ozellikler mevcuttur.
Asagida belirtildigi gibi bazi ozellikler:
1. Keskin ve Kolay Görülür LCD ekran ve parlaklik ayarlanabilir
2. Alarm, FM Radyo, NFC ve Bluetooth Hoparlor
3. Bluetooth 2.1 + EDR destekler, Sifresiz ve aninda cift Baglanti
4. NFC
5. USB Sarj imkani, Apple, Samsung, HTC, Sony, LG, vs.
6. Audio giris kablosu
7. Apple, Samsung, HTC, Sony, LG, vs. destekleyen, Multi Fonksiyonel
kablo
8. Yaz Saati Uygulamasi (DST) auto degisim
9. Back-up batarya - Saat ve Alarm icin dis DC akim kesildiginde

BITTEL Page 7 of 20 HA9888(77)TSD
SET ÜZERİNDE KİMODULLER
1.
2.
3. ALARM SET
4. ALARM ON/OFF
5. EKRAN PARLAKLIK
6. LCD
7. Bluetooth
8. LINE IN
9. RADYO
10. RADYO KANAL +
11. RADYO KANAL -
12. NFC
13. RADYO Anten cikisi
14. DC Adaptor Girisi
15. USB Sarj Portu
17. Infrared Alim Anteni
18. Audio Giris Portu
19. Multi-Fonksiyon Kablo
20. Multi-Fonksiyon Kablo Baglantisi
21. Pil Kutusu
22. BL-5C Lithium Pil
Lithium Pili Takmak
1. Adaptoru fisten cekin ve cihazin arkasinda ki Pil Kutusunu acin
2. Duzgun sekilde Pili takin.
3. Pil Kapagini takin ve vidalayin. Duzgun sekilde takildi ise, LCD
yanacaktir.

BITTEL Page 8 of 20 HA9888(77)TSD
NASIL KULLANILIR ?
Ses Kısmi
Apple’lar, diger mobil telefonlar ve MP3 Calicilardan gelen MUZIK burada
calar.
1) Bluetooth: Bluetooth tusuna basin, LCD ekranda ID numarasi
belirecektir. Mobil Aygit (Gsm telefon) Bluetooth bolumu Aygit
aramasindan sonra bu ID numarasini gosterecektir. Ve NFC destekli
Gsm lerde, bir sifreleme yapmadan, 2 unite hemen eslenir. LDC ekranda
ON goreceksiniz.
2) LINE IN moduna girmek icin LINE IN tusuna basin, sonra Apple veya
herhangi diger bir aygiti Apple Dock veya 3.5 mm audio kablo ile
baglayin.
3) Mobile cihazin NFC ozelligini aktive edin ve NFC alaninin icinde olsun,
otomatik olarak Bluetooth uzerinden baglanacaktir. alandan cikildiginda
kapanacaktir.
Not: 5 dakika herhangi bir muzik gelmez ise, 2 baglantida da i/f kesilir.
2. FM Radyo
Radyoya gecmek icon RADIO tusuna basin, TUNING+/- tuslari ile Kanal
Aramasi yapabilirsiniz.
3. Akustik ses
tuslari lie Volum artirilabilir veya azaltilabilir.
4. Otel Mod’u Acmak veya Kapamak (odada cok gurulti olmamasi icin)
tusunu bir sure basili tutun; LCD ekran ON veya OFF gostecektir
ON ‘da: volum, 0—20, OFF’ta: volum, 0-30 ye fikslenir…

BITTEL Page 9 of 20 HA9888(77)TSD
5. AUDIO OFF mod’unda:
1) SNOOZE ‘u bir sure basili tutun; LCD Ay ve Gunu gosterir;
2) SNOOZE ‘u bir sure daha basili tutun; LCD Yili gosterir;
3) SNOOZE ‘u bir sure daha tekrar basili tutun;, LCD,
DST Zone ‘u ve
Set Parametrelerini
gosterir.
6. Akilli Aktive Olma imkanı
Telefon geldiginde, calan muzik azalan bir şekilde susar ve gorusme
bittiginde takrar aktive olur.
Zaman Ayari
AUDIO OFF mod’unda ( LINE IN olmayacak ve Radyo calismayacak) zaman
ayari yapilabilir.
1) 6 saniye ALARM SET’e basin，Saat Digit’i yanip sonecek, ile
ayari yapin.
2) 6 saniye ALARM SET’e tekrar basin，Dakika Digit’i yanip sonecek,
ile ayari yapin.
3) Bitirmek icin, ALARM SET’e basin.
4) 12 saat ve 24 hour formatı, tuslari ile yapilir.
Alarm Ayari
1) ALARM SET’e basin，Saat ayarini tuslarla yapin.
ALARM SET’e tekrar basin，Dakika ayarini tuslarla yapin.
Bitirmek icin, ALARM SET’e basin.
2. Alarm’ı!aktive etmek
ALARM ON/OFF tusuna basarak bunu aktive eder veya sonlandirirsiniz
Aktive oldugunda ekranda alarm isareti, saat ve dakika, LCD ekranda
gorunur. Sonlandiginda gorunmez.

BITTEL Page 10 of 20 HA9888(77)TSD
3. Alarm Erteleme
1) Harhangi bir tusa basin (ALARM tusu harici) veya ahizeyi kaldırın
Erteleme baslar. 10 dakika sonra tekrar calar.
2) Calan alarm, UM77 ‘ye yaklasinca da susar, ertelenir.
3) Muzik caliyor ise, alarm basladiginda susar.
LCD Lumen (Isik Gucu) ayar Degisikligi
Off-alarm modunda, SNOOZE ‘a basarsanız LCD isik gucu ayarlanir,
Orta, Yuksek ve Alcak olmak uzere 3 seviye vardir.
Sarj port’lari
1. 4 adet USB charging port’u vardir
1) 2 akilli USB Charging port’u —Apple’lar icin.
2) 2 standart USB Charging port’u —diger Mobil cihazlar icin.
2. LINE IN audio giris port’u --- 3.5mm cift track audio kablosu iPod/MP3’leri
baglar.
3. Multi-media Sarj Kablosu: iPod/iPad/Mini Pad/iPhone5 gibi Apple’lar icin
, Apple Dock & Lighting Connector..
4. Multi-Funksiyonel Sarj port’lari:Apple’lar icin , Apple Dock & Lighting
Connector; micro USB port’lu mobil telefonlar sarji icin Micro USB port.
Bluetooth ile Gelen Mobil Telefon Aramalarini Dinlemek
Bluetooth baglantidan sonra, misafir gelen gorusmeleri tuslari ile
yapabilir. Ses ayari da buradan yapilir. LCD nin sagini sinyallesme icin
kapatmayin
Saat icin Pil Sarj’lanmasi
Yedekleme pili, …BL-5C Lithium Battery, 1000mAH and 3.7V.
Orta lumende, her hangi bir akim kesilirse, bu pil Saat ve Alarm icin
Yedekleme’ye girer.
Monte ve de montesi arkada ki Pil kapakciginin acilmasi le olur.
Istenmediginde standart uretimde bu pil verilmez.

BITTEL Page 11 of 20 HA9888(77)TSD
Zamani Degistirmek
Uzaktan Zaman Yukleyici’ye pil takin,Arti ve Eksi’ye dikkat edin.
Uzaktan Zaman Yukleyici
Uzaktan Zaman Yukleyici ile Zaman Ayari
●TIME SET tusuna basin, hour digits flas edecek, UP/DOWN tuslari ile ayar,
●TIME SET tusuna basin, UP/DOWN tuslari ile dakikayi ayarlayin
●TIME SET tusuna basin, UP/DOWN tuslari ile ayi ayarlayin
●TIME SET tusuna basin, UP/DOWN tuslari ile gunu ayarlayin
●TIME SET tusuna basin, UP/DOWN tuslari ile dakikayi ayarlayin
●TIME SET tusuna basin, UP/DOWN tuslari ile yili ayarlayin
●TIME SET tusuna basin, LCD son tumunu gosterir..
DST alani (Bolgesel Zaman Dilimi) kodunun
Uzaktan Zaman Yukleyici’ye tanimi
DST SET tusuna, UP/DOWN tusu ile Alan Koduna git:
00= DST KAPALI 01=ABD/Kanada, 02=Avrupa / Rusya / Isvec
03= Meksika 04=Yeni Zelanda
1. LCD
2. DST SET tusu —— Bolge/saat zamani.
3. TIME SET tusu —— zaman ve tarih.
4. TIME PROG tusu —— zaman ve tarih ayari .
5. DST PROG tusu —— DST ayari.
6. UP tusu —— Yukari tusu.
7. DOWN tusu —— Asagi tusu.

BITTEL Page 12 of 20 HA9888(77)TSD
Zaman Ayari
1) DST PROG tusu ile Bolge Kodunu Girin
2) LCD saati gosterdiginde, 12- Saat Format’ı ve 24- Saat Format’ı icin
TIME SET tusuna 2 saniyden fazla basin.
Sorun Bulmak
1. Ses Yok
Akim Kablosu takilmis mi ?
.
2. Radyo calismiyor veya ses parazitli
Arkada ki anten kablosunu ayarlayin.
No the selected channel in local
FCC APPROVAL
FCC, Part 68 (ABD) kurallarina tamamen uymaktadir.
FCC 'ye uyumlu oldugu, model cikartmasinda kayit numarasi ile belirtilmekte
ayrica (REN) (ringer equivalence number) belirtilmektedir. Bu bilgiler,
ulkeninizin telefon sirketine verilmesi icin urun uzerinde belirtilmektedir.
CE APPROVAL
CE onay ve sartlarina tamamen uymakTadir..
Fisler
RJ11C USOC standarti.

BITTEL Page 13 of 20 HA9888(77)TSD
GARANTI
Urun, alindigi tarihten 12 ay sure icinde tamamen uretim ve
imalat hatalarina karsi garanti kapsamindadir.
Asagida ki durumlar disinda Bİttel urunu onarma veya bir yenisi ile
degistirmek sorumlulugundadir.
1) Normal kullanim disi,
2) Yetki verilmemis kisi veya kurumlarca onarim veya modifikasyon.
3) Bu urun, rutubetli, kirli, tozlu ortamlarda kullanilmaz.
4) Tasima veya depolama aninda islanma veya darbe
BU LiMiTED GARANTİALiCiYA oZEL HUKUSAL HAKLAR VERİR.
ALiCiNiN BUNUN YANiNDA BoLGELESEL BAKiM HAKLARi DA VARDiR.
Garanti, urunun Bittel veya onun kabul edilmis distributor'unden
alindiginda gecerlidir.
BITTEL ve ASTRO A.S. (BITTEL TURKIYE) ile KONTAKT
Bittel
Telefon : (86)
633-2212119 / 2212113 / 2212103
internet : www.bittelcom.com
Email : [email protected]
Adres : Shandong Bittel Electronics Co.;Ltd
No. 1 Rizhao North Road, Rizhao,
Shandong, 276800, Cin
Astro A.S.
Telefon : [phone]
internet : www.bittelturkey.com
Email : [e-mail]
Adres : 2. cad. Plato Sitesi
Amber Cicegi sok. # 19-A
34450, Zekeriyakoy, İstanbul
Copyright © 2010 Bittel inc. Her hakki mahvuzdur.

BITTEL Page 14 of 20 HA9888(77)TSD
Shandong Bittel Electronics Co.,Ltd
No.1 Rizhao North Road,Rizhao,
Shandong,China
Declaration of Conformity
Declaration Number: DOC150518 Date: 8th May, 2015
We: Shandong Bittel Electronics Co., Ltd.
No.1 Rizhao North Road, Rizhao Shandong, 276800, China
Certify that the product described is in conformity with the EC Directive 2006/95/EC,
2004/108/EC, 1999/5/EC and RoHS/65/EC.
Model number:
HCD9888TSD HCD9888TS HA9888TSD HCD9888(38)TSD HA9888(38)TS
HA9888(38)TD HA9888(38)TSD HCD9888(40)TSD HA9888(32)TS HA9888(32)TSD
HA9888(12)TSD HA9888(12)TS HA9888(49)TSD HCD9888(49)TSDHA9888(48)TS
HA9888(48)TSD HA9888(58)TS HCD9888(58)TSD HA9888(58)TSD
HA9888(67)TSD HCD9888(67)TSD HA9888(67)TS HCD9888(68)TSD HA9888(68)TSD
HA9888(68)TS HA9888(69)TSD HA9888(69)TS HCD9888(69)TSD HA9888(66)T
HA9888(66)T-T
HA9888(41)T-18 HA9888(41)T-5+ HA9888(41)T HA9888(41)T-0HA9888(41)T-0+
HA9888(41)T HA9888(41)T-5 HA9888(41)T-T HA9888(41)T-T+ HA9888(25)T
HA9888(25)T(E) HA9888(41)T-25
HWD9888(67)TSD HWD9888(68)TSD HWD9888(38)TSD HWD9888(69)TSD
HWD9888(48)TSD HWD9888TS HWD9888TSD HWDCD9888(68)TSD
HWDCD9888TS HWDCD9888TSD
HWDCD9888(67)TSD HWDCD9888(38)TSD HA9888(58)TSD-IP HA9888(66)TSD-IP
HA9888(67)TSD-IP HA9888(68)TSD-IP HA9888(69)TSD-IP HA9888(77)TSD-IP
HCD9888(58)TSD-IP HCD9888(67)TSD-IP HCD9888(68)TSD-IP HWD9888(58)TSD-IP
HWD9888(66)TSD-IP HWD9888(67)TSD-IP HWD9888(68)TSD-IP HWD9888(69)TSD-IP
HWDCD9888(67)TSD-IP HWDCD9888(68)TSD-IP HA9888TSD-IP
HWD9888TSD-IP HWDCD9888TSD-IP HCD9888TSD-IP
HT20 HT60 HA9888(62)TSD HA9888(77)TSD
Are in conformity with the following essential requirements and harmonized standards.
The product has been assessed by the application of the following standards:
LVD EN 60950-1:2006+A11 :2009+A1:2010+A12:2011+A2:2003
EMC EN 55022:2010+AC:2011
EN 55024:2010
Authorized Signatory: Name: Jiangwen Tian
Title: Chief Engineer

BITTEL Page 15 of 20 HA9888(77)TSD
MAIN FEATURES
UNOMedia 77 (shorted for UM 77) is a kind of Multi-Media device, which is
specially designed to meet the need of hotel guestroom. UM 77 is made of
first class electrical materials, awarded several patents, which give UM 77 a
variety of functions and magnificent appearance. Further more it also own
special multi-media features, such as Bluetooth, NFC, Alarm, FM
radio, HiFi acoustics, charging and playing Apple and other portable
devices.
Some features as below:
Clear and Striking LCD display and the brightness can be adjusted
2. Alarm, FM Radio, NFC and Bluetooth Speaker
3. Supporting Bluetooth 2.1 + EDR, paired connection without password
4. NFC
5. USB Charging Ports for portable type mobile devices, such as Apple,
Samsung, HTC, etc
6. Audio input cable
7. Multi-Function Cable, supporting portable type mobile device, such as
Apple, Samsung, HTC, etc
8. Daylight Saving Time (DST) auto change
9. Back-up battery - Time and Alarm can also well work without external
power
LOCATION AND CONTROL
ALARM SET 4. ALARM ON/OFF 5. SNOOZE
LCD Display 7. Bluetooth 8. LINE INN 9. RADIO 10. TUNING
TUNING+ 12. NFC 13. RADIO Antenna Output 14. DC Jack
15(16). USB Charging Port 17. Infrared Receiving Area
Audio Inputting Port 19. Multi-Function Cable
Multi-Function Cable connector
Battery box 22. BL-5C Lithium Battery
Install Lithium Battery
Firstly please disconnect the power adaptor and open the battery box, which
is on the back side of the device
Please correctly install the battery.
Put the battery cover back and install the screw. If the battery is successfully
installed, the LCD will be light.

BITTEL Page 16 of 20 HA9888(77)TSD
HOW TO USE
Acoustic Part
1. Apple devices/ mobile phones/ MP3 and other devices can be played by
Bluetooth or LINE IN.
1) Bluetooth: Please press Bluetooth key, an ID Number will be displayed on
the LCD screen. Then open Bluetooth function of the mobile devices to
search that ID No and they will be paired connection without password. It will
show "ON" on the LCD screen if the connection is correct.
2) LINE IN: Please press LINE IN key to select the LINE IN mode, and then
connect the Apple devices/mobile phones/ MP3 and other devices to 3.5mm
audio line or Apple Dock for playing.
3) Please active mobile phone’s NFC feature and move it toward the NFC
area, it will automatically connect with the Bluetooth; move the
mobile phone toward with NFC area again, the Bluetooth feature will be
automatically closed.
Notice: The acoustic will exit Bluetooth mode or LINE IN mode if there is no
music to play for 5 minutes.
2. FM Radio
Please press RADIO key to select the FM-RADIO mode, then press
TUNING+/- to select the needed frequency.
Press TUNING+/-for a while, it will search frequency forward or backward and
will stop automatically after searching certain channel.
Press RADIO for a while, you can choose the channel of 87.5-108.0Mhz or
76-108.0Mhz.
3. Acoustic volume
The acoustic volume can be adjusted by pressing button.
4. Turn on/off Hotel Mode
AUDIO OFF mode, press for a while, LCD display ON or OFF (ON or
OFF the hotel mode), ON: volume 0—20, OFF: volume 0-30.
AUDIO OFF mode:
1) Press SNOOZE for a while, LCD will display Month, Day;

BITTEL Page 17 of 20 HA9888(77)TSD
2) Press Snooze for a while again, LCD will display Year;
3) Press Snooze for a while again, LCD will display DST Zone and easy
to view the setting parameters.
6. Detect the device mode intelligently
If telephone ringing or off-hook under FM-RADIO or LINE IN mode, the
telephone can PAUSE audio playing , after the phone call finished or ringing
stopped it can resume to playing mode again.
Time Setting
Under AUDIO OFF mode (not LINE IN or FM-RADIO working mode) to set
the time
1) Press ALARM SET for 6s，the hour digit will flash, press to adjust
hour.
2) Press ALARM SET again while the hour digit is flashing, the minute digit
will flash, press to adjust minute.
3) Press ALARM SET to finish the setting.
4) Press key to adjust 12 hour format and 24 hour format.
Alarm Setting
1. Set Alarm Time
1) Press ALARM SET key, then press to adjust hour.
2) Press the ALARM SET key again, then press !!to adjust minute.
3) Press the ALARM SET key to finish the setting.
2. Activate the Alarm
Press ALARM ON/OFF key to start and close alarm. The alarm time and its
mark will be displayed on the LCD if the alarm is activated. The alarm and its
mark disappear will disappear if the alarm is closed.
3. Alarm snooze feature
1) When alarm ringing, press any key (except for ALARM button) or pick up
the handset, it will activate the Snooze. After 10 minutes it will ring again.
2) When alarm ringing, it will auto activate Snooze once the guests approach
the phone in 30cm.
3) Alarm ringing during playing mode, it exist playing mode automatically.
Adjust LCD brightness
In off-alarm mode, press SNOOZE to adjust the LCD brightness, there are
three levels for selecting: Mid,Hi and Off.

BITTEL Page 18 of 20 HA9888(77)TSD
Charging ports
1. There are Four USB charging ports, charging for some devices
1) Two intelligent USB Charging ports — Charging for Apple devices.
2) Two standard USB Charging ports —— Charging for mobile phones and
other peripheral products.
2. LINE IN audio input port --- With 3.5mm dual track audio lines connect
iPod/MP3 to acoustics.
3. Multi-media Charging Cable: Apple Dock & Lighting Connector for
connecting Apple devices, such as iPod/iPad/Mini Pad/iPhone5;
4. Multi-Functional Charging ports: Apple Dock & Lighting Connector charging
for all Apple devices; Micro USB port charging for the mobile phones with
micro USB port.
Receive mobile phone calls through Bluetooth
After connect with the Bluetooth, the guest can choose to answer the phone
call by Bluetooth. Please press to adjust the volume. Please don’t cover
the right of the LCD, or it will affect the communication quality.
Clock’s battery Changing
The back-up battery is BL-5C Lithium Battery, 1000mAH and 3.7V. Without
external power, the back-up battery will keep the LCD in middle-light. Further
more, it can make the LCD to show the time and guarantees the Alarm can
well work.
If it needs change new battery, please remove the battery-cabinet cover, take
off the old battery and install new one. Please make sure to install the right
battery.
Note: The Back-up battery isn’t supplied & installed into UM 77 unless there
is special requirement.
Change time
Firstly, please install two pieces of 7# 1.5V batteries into the Remote Time
Controller. Pay attention to the polarity of the battery. Don’t mix the old and
new batteries.
Note: The anode of the battery should be toward outside. The battery should
be changed every two years.

BITTEL Page 19 of 20 HA9888(77)TSD
Remote Time Control
Set time with the Remote Time Control
●Press TIME SET key, hour digits flashing, press UP/DOWN key to adjust,
●Press TIME SET key, press UP/DOWN key to adjust minute,
●Press TIME SET key, press UP/DOWN key to adjust month,
●Press TIME SET key, press UP/DOWN key to adjust day,
●Press TIME SET key, press UP/DOWN key to adjust year,
●Press TIME SET key, LCD display the time, setting finished.
Set DST area code with the Remote Time Control
Press DST SET key, then press UP/DOWN key to set the area code:
00= DST OFF, 01=USA/Canada, 02=Europe/Russia/Swiss;
03= Mexico, 04=New Zealand
Adjust Time
1) After the above setting,press DST PROG at the right upper direction
within 10cm near the LCD to adjust the DST Time. Press Time PROG to
adjust the date and time.
2) When LCD displays time, press TIME SET over 2 seconds to realize the
conversion of 12- Hour Format and 24- Hour Format.
Note: If the attached Remote Time Control is different than above image,
please according to the attached object.
Maintenance and Troubleshooting
Acoustics no sound
Please check if the power is correctly connected.
2. No signal or nersy noise after radio selected the channel
Adjust the direction of the radio antenna
No the selected channel in local
FCC APPROVAL
Complies with Part 68 of the FCC rules. On the bottom of this telephone is a
label that contains, among other information, the FCC registration number
and the ringer equivalence number (REN) for this telephone. If requested, you
must provide this information to the Telephone Company.
CE APPROVAL
Complies with CE approval.

BITTEL Page 20 of 20 HA9888(77)TSD
JACKS
Use RJ11C USOC standard modular jacks.
WARRANTY
This product is warranted for a period of 12 months from the date of purchase
against faulty materials or workmanship. If during this period a defect arises,
we may repair or replace the product, at Bittel’s discretion, provided that:
1) The product has not been used for any purpose other than normal use,
2) Unauthorized product repair or modifications have not been attempted.
3) The product has never been used in a harsh or corrosive environment.
4) No damage in transit
THIS LIMITED WARRANTY GIVES THE BUYER SPECIFIC LEGAL
RIGHTS. THE BUYER MAY ALSO HAVE OTHER RIGHTS WHICH
VARYFROM JURISDICTION TO JURISDICTION.
This warranty is only valid for merchandise purchased directly from Bittel or
dealers or distributors Bittel Co. authorized .
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CONTACTING BITTEL
Telephone: [phone]
Internet: www.bittelgroup.com
Email: [e-mail]
Address: Shandong Bittel Electronics Co.;Ltd.
No. 1 Rizhao North Road, Rizhao,
Shandong, 276800, China
Copyright © 2014 Bittel Inc. All rights reserved. V1
