INSTRUCTION MANUAL
STEAM MOP wiTh hAnd hEld STEAM ClEAnEr
Thank you for choosing Black & Decker! To register your new product go to
www.BlackandDecker.com/NewOwner
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
If you have a question or experience a problem with your Black & Decker purchase, go
to http://www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet,
call 1-800-544-6986 from 8 a.m. to 5 p.m. EST Mon. - Fri. to speak with an agent.
Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
VEA EL ESPANOL EN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.
ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
CATALOG NUMBER
BDH1850SM
More info and discount on Black & Decker steam mops,
visit http://www.steammopguides.com
2
INTENDED USE
Your Black & Decker steam mop has been designed for sanitizing and cleaning sealed
hardwood, sealed laminate, linoleum, vinyl, ceramic tile, stone and marble floors. Upright unit is
for floor use only, hand held can be used on all surfaces; do not use the unit upside down. This
appliance is intended for indoor household use only.
SAFETY INSTRUCTIONS
WARNING:
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions listed below may result in electric shock, fire and/or serious injury.
WARNING: When using electrical appliances, basic safety precautions, including
the following, should always be followed to reduce the risk of fire, electric shock,
personal injury and material damage.
SAFETY WARNINGS AND INSTRUCTIONS: POLARIZED PLUGS
To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider
than the other). This equipment must be used with a suitable polarized 2 wire or 3 wire
extension cord. Polarized connections will fit together only one way. Make sure that the
receptacle end of the extension cord has large and small blade slot widths. If the plug does not
fit fully into the extension cord, reverse the plug. If it still does not fit, obtain a suitable extension
cord. If the extension cord does not fit fully into the outlet, contact a qualified electrician to install
the proper outlet. Do not change the tool plug or extension cord in any way.
or the performance of any operation with this appliance other than those recommended
in this instruction manual may present a risk of personal injury.
USING YOUR APPLIANCE
Minimum Gauge for Cord Sets
Volts Total Length of Cord in Feet
120V 0-25 26-50 51-100 101-150
(0-7,6m) (7,6-15,2m) (15,2-30,4m) (30,4-45,7m)
240V 0-50 51-100 101-200 201-300
(0-15,2m) (15,2-30,4m) (30,4-60,9m) (60,9-91,4m)
Ampere Rating
More Not more American Wire Gauge
Than Than
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Not Recommended
SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual. The information it contains
relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols
below are used to help you recognize this information.
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE: Used without the safety alert symbol indicates potentially hazardous
situation which, if not avoided, may result in property damage.
appliance cord away from heat, oil and sharp edges.
sharp corners or expose cord to heated surfaces.
Do not use appliance in an enclosed space filled with vapor given off by oil-base paint
thinner, some moth-proofing substances, flammable dust, or other explosive or toxic vapors.
delicate, steam-sensitive materials.
treated with wax or some no-wax floors, the sheen may be removed by the heat and
steam action. It is always recommended to test an isolated area of the surface to be
cleaned before proceeding. We also recommend that you check the use and care
instructions from the floor manufacturer.
this may damage it or make it unsafe for use.
If the circuit breaker activates while using the steam function, discontinue product use
immediately and contact the customer support center. (Beware of the risk of electrical shock.)
steam head and cleaning pads get very hot during use.
CAUTION:
Always wear suitable shoes when using your steam mop and when
changing the accessories on your steam mop. Do not wear slippers or open-toed footwear.
become hot during use.
AFTER USE
INSPECTION AND REPAIRS
maintenance or repairs.
parts, damage to switches and any other conditions that may affect its operation.
SAFETY OF OTHERS
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance by
a person responsible for their safety.
RESIDUAL RISKS
Additional residual risks may arise when using the tool which may not be included in the
enclosed safety warnings. These risks can arise from misuse, prolonged use, etc.
Even with the application of the relevant safety regulations and the implementation of
safety devices, certain residual risks can not be avoided. These include:
prolonged periods ensure you take regular breaks.
3
FUNCTIONAL DESCRIPTION
1. ON/Off switch
2. SmartSelectTM button
3. Hand Held Steam Cleaner
4. Handle Tube
5. Steam Head
6. Micro-Fiber
Cleaning Pad
7. Resting Mat
8. Carpet Glider
9. Lift and Reach
Head Cleaning Pad
ACCESSORIES
This appliance includes some or all of the following accessories. The performance of your
appliance depends on the accessory used. Black & Decker accessories are engineered
to high quality standards and designed to enhance the performance of your appliance. By
using these accessories you will get the very best from your appliance.
A
4
Flexible hose and
handle
For convenient use of
all accessories.
Variable steam jet
nozzle
For higher pressure
steam bursts, twist
to change the spray
pattern of the steam
burst.
cleaning small hard
surfaces.
For cleaning glass
doors and windows.
WARNING:
Do not use the
window squeegee on
cold glass. It may cause
the glass to break.
Mini pivot mop
For cleaning tiles and
large flat surfaces.
Detail grout cleaner
For cleaning grouted
areas between tiles.
Large scrub brush
cleaner with scraper
For cleaning heavily
soiled object such as
BBQ’s.
ASSEMBLY
NOTICE: Each steam mop is 100% tested in the factory to ensure product performance
and safety. When assembling your new steam mop for the first time you may notice water
residue inside of the unit.
WARNING: Before attempting any of the following operations, make sure that the
appliance is switched off and unplugged and that the appliance is cold and contains
minimal or no water.
ATTACHING THE HANDLE - Fig. B
end of the steam mop body (11) until it clicks into place.
ATTACHING THE STEAM HEAD - Fig. C
onto the steam head (5) until it clicks into place.
mop body by pressing the steam head release
button (12) and pulling the steam mop body off the
steam head.
ATTACHING THE HAND HELD
STEAM CLEANER - Fig. D
steam mop body (11) until it clicks into place.
REMOVING THE HAND HELD STEAM
CLEANER - Fig. E
Push the release button (13) down and pull the hand held
steam cleaner (3) away from the steam mop body.
5
D
B
C
E
6
ATTACHING A CLEANING PAD - Fig. F
Replacement cleaning pads are available from your Black
the ‘hook & loop’ side facing up.
press it down onto the cleaning pad. You are now
ready to steam clean and sanitize your floor.
NOTICE: Always place the steam mop on the resting
mat with the handle tube (4) in the upright position
when stationary and make sure the steam mop is
turned off when not in use.
REMOVING A CLEANING PAD - Fig. G
CAUTION: Always wear suitable shoes when
changing the cleaning pad on your steam mop. Do not
wear slippers or open-toed footwear.
until it cools down. (approximately five minutes)
Place the front of your shoe onto the cleaning pad
removal tab (14) and press down firmly.
NOTICE:
Always place the steam mop on the resting
mat (7) with the handle (4) in the upright position when stationary and make sure the steam
mop is turned off when not in use.
ATTACHING THE CARPET GLIDER - Fig. H
Place carpet glider on the floor.
Lightly press the steam mop down onto the carpet
glider (8) until it clicks into place.
NOTICE: Always place the steam mop on the resting
mat (7) with the handle tube (4) in the upright position
when stationary and make sure the steam mop is
turned off when not in use.
REMOVING THE CARPET GLIDER
CAUTION: Always wear suitable shoes when
changing the carpet glider on your steam mop. Do not
wear slippers or open-toed footwear.
Return the handle tube to the upright position and
five minutes)
Lift the steam mop up off the carpet glider.
NOTICE: Always place the steam mop on the resting mat with the handle in the upright
position when stationary and make sure the steam mop is turned off when not in use.
HAND HELD STEAM CLEANER ATTACHMENTS
NOTICE:
First remove the hand held steam cleaner
from the steam body.
ATTACHING THE HOSE - Fig. I
Press in the clips (17) on either side of the hose (16).
Press the hose onto the steam nozzle (18) and
release the clips.
H
17
16
I
F
G
WARNING: Inspect the seal on the steam
nozzle and hose before each use (Figure J). If the
seal is missing or damaged contact your nearest
authorized repair agent. Do not use the appliance.
CAUTION: Ensure that the hose is securely
fastenedbefore using the hand held steam cleaner.
ATTACHING AN ACCESSORY - Fig. K
Align the lugs (19) on the hose with the recesses on
the accessory.
Press the accessory onto the hose and twist
counterclockwise until the accessory clicks into place.
REMOVING AN ACCESSORY
Twist the accessory clockwise then pull away from
the hose.
REMOVING THE HOSE
away from the steam nozzle.
FILLING THE WATER TANK - Fig. L
help prolong the life of the system.
WARNING:
Your water tank has a 10.1oz
capacity. Do not over fill the tank.
NOTICE:
Fill the water tank with regular tap water.
NOTICE:
In areas of very hard water, the use of
de-ionized water is recommended.
Ensure that the appliance is switched off and the
power cord is disconnected from the power supply.
handle tube (4) in the upright position.
Using the supplied jug (22), fill the water tank (3) with water.
NOTICE: Always empty the steam mop after use.
OPERATION
SWITCHING ON AND OFF - Fig. M
CAUTION: FOR FLOOR USE ONLY; DO
NOT USE THE UNIT UPSIDE DOWN.
NOTICE:
When the steam mop is first turned on the
ready to use the water reservoir will glow blue. It takes
approximately 15 seconds for the steam mop to heat up.
button (1).
button.
NOTICE:
Never leave the steam mop in one spot on any surface for any period of time.
Always place the steam mop on the resting mat (7) with the handle tube (4) in the upright
position when stationary and make sure the steam mop is turned off when not in use.
NOTICE: Always empty the steam mop after use.
7
19
K
3
21
22
L
M
Seal
J
8
SmartSelectTM Dial - Fig. N
TM dial (2) which shows various hard floor
surface cleaning applications. They are used to select the correct operating mode for
your particular hard floor surface.
WARNING: Do not use on any unsealed hard floor surfaces. Additionally, on
surfaces that have been treated with wax or some no wax floors, the sheen may be
removed by the heat and steam action. It is always recommended to test an isolated
area of the surface to be cleaned before proceeding. We also recommend that you
check the use and care instructions from the floor manufacturer.
Using the SmartSelectTM dial (2), choose from one of the following applications:
The steam mop will select the correct volume of
steam required for your particular cleaning operation.
NOTICE: The SmartSelectTM Dial
on will recall the previously used setting.
STEAM BURST BUTTON
The steam burst button is built in feature that aides in the removal of stubborn floor marks or
stuck on grime.
NOTICE: The steam burst will last for 10 seconds then the steam mop will return to
the chosen setting.
NOTICE: This unit will kill 99.9% of bacteria and germs when used in accordance with
this manual and with the micro fiber pad fitted and a continuous run time of 90 seconds
HINTS FOR OPTIMUM USE
GENERAL USE
CAUTION: Never use the steam mop without first attaching a cleaning pad.
CAUTION: It is important to monitor the water level in the water tank. To refill the
water tank and continue to sanitise/ clean, return the handle tube (4) to the upright
refill the water tank with supplied water jug.
CAUTION:
Never leave the steam mop in one spot on any surface for any period of
time. Always place the steam mop on the resting mat (7) with the handle tube in the upright
position when stationary and make sure the steam mop is turned off when not in use.
• Alwaysvacuumorsweepthefloorbeforeusingthesteammop.
slowly, covering a small area at a time.
Do not use chemical cleaners with your steam mop. To remove stubborn stains
from vinyl or linoleum floors, you can pre-treat them with a mild detergent and some
water before using the steam mop.
STEAM MOP CLEANING
Raise the steam mop off the resting mat and lightly press it down onto the cleaning pad.
23
2
N
9
SmartSelectTM button (2) until the required setting is reached.
will start to come out of the steam head.
NOTICE: If the system has been run dry it may take up to 30 seconds to prime the
system on first use.
glide easily over the surface to be sanitized/cleaned.
Push and pull the steam mop slowly across the floor to thoroughly steam clean each section.
NOTICE: During use you may turn off the steam pump by returning the handle to
the upright position, this convenient feature will allow you to place the steam mop on
the resting mat for a short time so that you may move items or furniture, then continue
cleaning without the need to switch the appliance off.
down. (approximately five minutes)
HAND HELD STEAM CLEANING - Fig O
NOTICE:
To effectively sanitize an area, the lift and reach
head with microfiber pad must be used.
steam mop body (10).
approximately 15 seconds for the hand held steam
cleaner to heat up.
to activate the steam pump. After a few seconds
steam will start to come out of the accessory.
NOTICE: During use you may turn off the steam pump by releasing the trigger switch,
this convenient feature will allow you to place the hand held steam cleaner down for a
short time so that you may move items or furniture, then continue cleaning without the
need to switch the appliance off.
(approximately five minutes)
CARPET REFRESHING
CAUTION:
I
t is important to monitor the water level in the water tank. To refill the
water tank and continue to sanitize/ clean, return the handle tube (4) to the upright position
with supplied water jug.
CAUTION: Never leave the steam mop in one spot on any surface for any period
of time. Always place the steam mop on the resting mat (7) with the handle tube in the upright
position when stationary and make sure the steam mop is turned off when not in use.
SmartSelectTM button (2) to the Wood/Laminate setting.
will start to come out of the steam head.
Push and pull the steam mop slowly across the carpet to thoroughly refresh each section.
NOTICE: During use you may turn off the steam pump by returning the handle tube to the
upright position, this convenient feature will allow you to place the steam mop on the resting
mat so that you may move items of furniture with out the need to switch the appliance off.
down. (approximately five minutes)
25
24
1
O
10
AFTER USE - Fig. P
and wait until the steam mop cools down.
(approximately five minutes)
Remove the cleaning pad (6) and wash it so that it is
ready for the next use. (Take care to follow the wash
care instructions printed on the cleaning pad).
Wrap the electric cord around the cord hooks (26 & 27).
NOTICE: The top cord hook rotates to easily release the cord ready for next use.
NOTICE: With the handle tube in the upright position, the cord neatly wrapped
around the cord hooks your steam mop will stand on its own for storage. Alternatively
there is a hanging bracket built into the hand grip which will allow your steam mop to be
hung from a suitable hook on the wall. Always ensure that your wall hook is capable of
supporting the weight of the steam mop safely.
MAINTENANCE AND CLEANING
Your Black & Decker corded appliance has been designed to operate over a long period
upon proper appliance care and regular cleaning.
WARNING: Before performing any maintenance or cleaning on corded appliances
switch off and unplug the appliance.
appliance; never immerse any part of the appliance into a liquid. IMPORTANT: To
should be performed by authorized service centers or other qualified service
organizations, always using identical replacement parts.
For stubborn marks you can use a mild solution of soap and water to dampen your cloth.
CARE OF THE CLEANING PADS
NOTICE: Follow the cleaning instructions printed on the label of your cleaning pad.
Wash care instructions
softener - Air dry only - Allow to dry fully before re-use.
ACCESSORIES
Recommended accessories for use with your appliance are available from your local
dealer or authorized service center. If you need assistance regarding accessories, please
call: 1-800-544-6986.
WARNING: The use of any accessory not recommended for use with this
appliance could be hazardous.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
outlet.
fitted. attached.
correctly - LED’s do not
light up.
product repeatedly causes the
circuit fuse to blow, discontinue
26
27
P
11
SERVICE INFORMATION
customers with efficient and reliable power tool service. Whether you need technical
advice, repair, or genuine factory replacement parts, contact the Black & Decker location
nearest you. To find your local service location, refer to the yellow page directory under
“Tools—Electric” or call: 1-800-544-6986 or visit www.blackanddecker.com
LIMITED TWO-YEAR HOME USE WARRANTY
material or workmanship. The defective product will be replaced or repaired at no charge
in either of two ways.
The first, which will result in exchanges only, is to return the product to the retailer from
whom it was purchased (provided that the store is a participating retailer). Returns should
be made within the time period of the retailer’s policy for exchanges (usually 30 to 90 days
after the sale). Proof of purchase may be required. Please check with the retailer for their
specific return policy regarding returns that are beyond the time set for exchanges.
The second option is to take or send the product (prepaid) to a Black & Decker owned
“Tools-Electric” in the yellow pages of the phone directory.
This warranty does not apply to accessories. This warranty gives you specific legal rights
and you may have other rights which vary from state to state or province to province.
LATIN AMERICA: This warranty does not apply to products sold in Latin America. For
products sold in Latin America, check country specific warranty information contained in
the packaging, call the local company or see the website for warranty information.
FREE WARNING LABEL REPLACEMENT:If your warning labels become illegible or are
missing, call 1-800-544-6986 for a free replacement.
See ‘Tools-Electric’
– Yellow Pages –
for Service & Sales
Imported by
701 E. Joppa Rd.
use immediately and have it
serviced at a Black & Decker
service center or authorized
servicer.)
product repeatedly causes the
circuit breaker to trip,
discontinue use immediately
and have it serviced at a Black &
Decker service center or
authorized servicer.)
and change the micro-fiber
cleaning pad.
long. the floor with a damp or wet
cleaning pad still attached when
not in use.
For assistance with your product, visit our website www.blackanddecker.com for the
1-800-544-6986.
12
MODE D’EMPLOI
BAlAi A VAPEUr AVEC ACCESSOirE POrTATiF
Merci d’avoir choisi Black & Decker! Consulter le site Web
www.BlackandDecker.com/NewOwner pour enregistrer votre nouveau produit.
À LIRE AVANT DE RETOURNER CE PRODUIT POUR QUELQUE
RAISON QUE CE SOIT :
Si des questions ou des problèmes surgissent après l’achat d’un produit Black &
Decker, consulter le site Web www.blackanddecker.com/instantanswers
pour obtenir des réponses instantanément 24 heures par jour. Si la réponse est
introuvable ou en l’absence d’accès à l’Internet, composer le 1 800 544-6986 de 8 h à
17 h HNE, du lundi au vendredi, pour parler avec un agent. Prière d’avoir le numéro de
catalogue sous la main lors de l’appel.
Pour l´achat d´un filtre de rechange composer le 1-888-678-7278
CONSERVER CE MODE D’EMPLOI POUR UN USAGE ULTÉRIEUR.
pour usage domestique seulement.
N° DE CATALOGUE
BDH1850SM
13
lignes directrices en matière de sécurité - définitions
Il est important que vous lisiez et compreniez ce mode d’emploi. Les informations qu’il
danger : Indique une situation dangereuse imminente qui, si elle n’est pas évitée,
causera la mort ou des graves blessures.
aVertissement : Indique une situation potentiellement
dangereuse qui, si elle n’est pas évitée, pourrait causer la mort ou de graves
blessures.
mise en garde: Indique une situation potentiellement dangereuse qui, si elle
n’est pas évitée, pourrait causer des blessures mineures ou modérées.
aVis:
potentiellement dangereuse qui, si elle n’est pas évitée, peut résulter en des
UTILISATION PRÉVUE
de bois dur scellé, de bois lamellés scellés, de linoléum, de vinyle, de carreaux de
céramique, en pierre et en marbre. Utilisation pour le plancher seulement; ne pas
intérieure seulement.
Directives de sécurité
AVERTISSEMENT : Lire tous les avertissements de sécurité et toutes les
consignes. Le non-respect des avertissements et des directives figurant ci-dessous peut
AVERTISSEMENT : Lorsque des outils électriques sont utilisés, des
précautions de base en matière de sécurité, notamment les suivantes, doivent toujours
être observées afin de réduire le risque d’incendie, de décharge électrique, de
blessures corporelles et de dommages matériels.
AVERTISSEMENTS DE SÉCURITÉ ET DIRECTIVES : FICHES
POLARISÉES
Pour réduire le risque de décharge électrique, le présent appareil comporte une fiche
la prise, communiquer avec un électricien professionnel pour qu’il installe une prise
Calibre minimal des cordons de rallonge
Tension Longueur totale du cordon en pieds
120V 0-25 26-50 51-100 101-150
(0-7,6m) (7,6-15,2m) (15,2-30,4m) (30,4-45,7m)
240V 0-50 51-100 101-200 201-300
(0-15,2m) (15,2-30,4m) (30,4-60,9m) (60,9-91,4m)
Intensité (A)
moins plus
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10 - 12 16 16 14 12
12 - 16 14 12 Non recommandé
accessoire ou pièce ou encore toute opération réalisée avec cet appareil autre que
celles recommandées dans le présent mode d’emploi peut présenter un risque de
blessures corporelles.
Utilisation de l’appareil
prises de courant.
lorsqu’il fonctionne.
éloigné de la chaleur, de l’huile et des bords tranchants.
comme poignée, ni fermer une porte dessus, ni tirer le cordon contre des bords
inflammables ou d’autres vapeurs explosives ou toxiques.
l’humidité provenant de la vapeur pourrait causer des dommages. En outre, sur les
par la chaleur et l’action de la vapeur. Il est toujours recommandé de tester un endroit
consulter le mode d’emploi et d’entretien fourni par le fabricant de planchers.
(Attention au risque de décharge électrique.)
MISE EN GARDE :
Le couvercle peut devenir chaud durant l’utilisation de l’appareil.
De la vapeur peut s’échapper de l’appareil durant son utilisation.
devenir chaudes durant l’utilisation de l’appareil.
réservoir d’eau.
Après usage
14
15
Inspection et réparations
entretien ou des réparations.
défectueuses. Vérifier si des pièces sont brisées, si des interrupteurs sont endommagés
et s’il y a d’autres problèmes pouvant compromettre le fonctionnement de l’appareil.
réparation autorisé.
ce mode d’emploi.
Sécurité d’autrui
des capacités physiques, sensorielles ou mentales réduites ou ayant un manque
Risques résiduels
Des risques résiduels supplémentaires peuvent survenir au moment d’utiliser l’outil et
peuvent se poser en cas d’utilisation inadéquate, d’utilisation prolongée, etc.
Il est impossible d’éviter certains risques résiduels malgré le respect de toutes les règles
est utilisé durant de longues périodes, s’assurer de prendre régulièrement une pause.
DESCRIPTION FONCTIONNELLE
1. Interrupteur MARCHE/
ARRÊT
2. Bouton SmartSelectMC
3. Balai à vapeur portatif
4. Poignée
5. Tête à vapeur
6. Tampon nettoyant en
microfibres
7. Tapis de repos
8. Patin à tapis
9. Tampon nettoyant pour tête
Lift and Reach
A
16
ASSEMBLAGE
REMARQUE :
le rendement et la sécurité du produit. Au moment d’assembler pour la première fois le
AVERTISSEMENT : :Avant de réaliser les opérations suivantes, s’assurer que
l’appareil est éteint et débranché, qu’il est froid et qu’il
renferme peu ou pas d’eau.
FIXATION DE LA POIGNÉE — Fig. B
fasse entendre.
ACCESSOIRES
L’appareil comprend l’ensemble ou quelques-uns des accessoires suivants. Le
rendement de l’appareil dépend de l’accessoire utilisé. Les accessoires Black
& Decker sont conçus pour satisfaire à des normes de qualité élevées et pour
améliorer le rendement de votre appareil. L’utilisation de ces accessoires permet
de tirer pleinement avantage de l’appareil.
Flexible et poignée
Pour une utilisation
pratique de tous les
accessoires.
réglable
Pour augmenter la
pression des jets de
vapeur, tourner pour
changer la forme du jet.
Petite brosse (bleue)
Pour nettoyer les petites
surfaces dures.
Pour nettoyer les portes
et les fenêtres de verre
ADVERTISSEMENT:
Ne pas utiliser la
verre froid. Le verre
pourrait se briser.
Mini-serpillière pivotante
Pour nettoyer le
carrelage et les grandes
surfaces planes.
Accessoire de
nettoyage détaillé pour
les rainures
Pour nettoyer le coulis
entre les carreaux.
Grande brosse de
récurage avec grattoir
Pour nettoyer les objets
très sales comme les
barbecues.
B
17
FIXATION DE LA TÊTE À VAPEUR — Fig. C
déclic se fasse entendre.
FIXATION DE L’ACCESSOIRE DE BALAI A VAPEUR PORTATIF - Fig. D
qu’un déclic se fasse entendre.
RETRAIT DE L’ACCESSOIRE DE BALAI A VAPEUR PORTATIF - Fig. E
FIXATION D’UN TAMPON NETTOYANT - Fig. F
Des tampons nettoyants de rechange sont offerts auprès
agrippant’ soit vers le haut.
puis l’appuyer sur le tampon nettoyant. L’appareil
vapeur le plancher.
AVIS :
vapeur est éteint lorsqu’il n’est pas utilisé.
D
E
F
C
18
RETRAIT D’UN TAMPON NETTOYANT - Fig. G
MISE EN GARDE : Toujours porter des
chaussures adéquates au moment de changer le
ARRÊT ».
le laisser refroidir (environ cinq minutes).
languette de dégagement (14) du tampon nettoyant
et l’enfoncer fermement.
AVIS :
lorsqu’il n’est pas utilisé.
FIXATION DU PATIN A TAPIS – Fig. H
déclic se fasse entendre.
DEPOSE DU PATIN A TAPIS
MISE EN GARDE : Toujours porter des chaussures adéquates au moment de
tapis et l’enfoncer fermement.
AVIS :
est éteint lorsqu’il n’est pas utilisé.
ACCESSOIRES DE BALAI A VAPEUR
AVIS :
FIXATION DU TUYAU – Fig. I
relâcher les attaches.
AVERTISSEMENT
:Inspecter le joint
manquant ou endommagé, contacter l’agent de
réparation autorisé le plus proche. Ne pas utiliser
l’appareil.
MISE EN GARDE :
17
16
I
H
G
j
oint d'étanchéité
J
19
INSTALLATION D’UN ACCESSOIRE – Fig. K
sur l’accessoire.
s’enclenche en place.
RETRAIT D’UN ACCESSOIRE
séparer du tuyau.
RETRAIT DU TUYAU
REMPLISSAGE DU RESERVOIR D’EAU - Fig. L
un système contre l’entartrage.
AVERTISSEMENT : Le réservoir a une capacité
de 298 ml (10.1 oz). Ne pas trop remplir le réservoir.
AVIS : Le réservoir d’eau a un mode de dépose
pratique, ce qui facilite l’utilisation.
AVIS : Remplir le réservoir d’eau avec de l’eau du
robinet.
AVIS : Dans les régions où l’eau est très dure, il est
recommandé d’utiliser de l’eau désionisée.
est débranché de l’alimentation.
vers le bas.
AVIS : Toujours vider le réservoir d’eau après l’avoir utilisé.
FONCTIONNEMENT
ALLUMER ET ETEINDRE L’APPAREIL - Fig. M
MISE EN GARDE : UTILISATION POUR LE
PLANCHER SEULEMENT; NE PAS UTILISER
L’APPAREIL A L’ENVERS.
AVIS :
première fois, le témoin du réservoir d’eau passe au
le témoin du réservoir passe au bleu. Il faut environ 15
AVIS :
AVIS :
19
K
3
21
22
L
M
20
Cadran Smart SelectMC
(2) qui indique diverses
applications de nettoyage pour les surfaces de planchers durs. Il permet de choisir le
particulière du plancher dur.
AVERTISSEMENT : Ne pas utiliser sur du bois non scellé ou des planchers
lamellés non scellés, car l’humidité provenant de la vapeur pourrait causer des
cire, le lustre peut être enlevé par la chaleur et l’action de la vapeur. Il est toujours
recommandons également de consulter le mode d’emploi et d’entretien fourni par le
fabricant de planchers.
Utiliser le cadran SmartSelectMC (2) pour choisir l’une des applications suivantes :
nettoyage particulière.
AVIS : a une fonction de mémorisation. À la mise en
BOUTON DE JET DE VAPEUR - Fig. N
Le bouton de jet de vapeur est une fonction intégrée
de vapeur (23).
AVIS : Le jet de vapeur dure 10 secondes, puis le
AVIS :
le présent manuel, il tue 99,9 % des bactéries et des
germes avec le tampon en microfibres en place et un temps d’utilisation continue de 90
secondes.
CONSEILS POUR OPTIMISER L’UTILISATION
USAGE GENERAL
MISE EN GARDE :
tampon nettoyant.
MISE EN GARDE : Il est important de surveiller le niveau d’eau dans le réservoir
d’eau. Pour remplir le réservoir d’eau et continuer de désinfecter/nettoyer la surface,
réservoir d’eau (3).
MISE EN GARDE :
Pierre/marbre
Carreaux/vinyle
Bois dur/bois lamellé
23
2
N
Other manuals for BDH1850SM
1
Table of contents
Languages:
Other Black & Decker Steam Cleaner manuals
Black & Decker
Black & Decker FSMH1621-XE User manual
Black & Decker
Black & Decker FSM1630 User manual
Black & Decker
Black & Decker FSS1600-XE User manual
Black & Decker
Black & Decker FSS1600 User manual
Black & Decker
Black & Decker FSM1630 User manual
Black & Decker
Black & Decker FSMH1621 User manual
Black & Decker
Black & Decker BHSM15FX08 User manual
Black & Decker
Black & Decker BDH1720SM User manual
Black & Decker
Black & Decker BXGS1600E User manual
Black & Decker
Black & Decker FSM1625 User manual
Black & Decker
Black & Decker CARDLESS BROOM NS118 User manual
Black & Decker
Black & Decker FSM1500 User manual
Black & Decker
Black & Decker FSM1630 User manual
Black & Decker
Black & Decker FSM1620S User manual
Black & Decker
Black & Decker FSH10SM Guide
Black & Decker
Black & Decker BDH1760SM User manual
Black & Decker
Black & Decker FSM1605 User manual
Black & Decker
Black & Decker BDH1800SM User manual
Black & Decker
Black & Decker FSM1640 User manual
Black & Decker
Black & Decker FSMH16151 User manual
Popular Steam Cleaner manuals by other brands
Lervia
Lervia STEAM BRUSH KH1270-06/08-V6 operating instructions
Maxwell
Maxwell MW-3707 W instruction manual
Electrolux
Electrolux EGS2103 Instruction book
liebfeld
liebfeld 4742022040133 Instructions for use & safety instructions
Oreck
Oreck STEAM-IT STEAM100LRH user guide
Beautural
Beautural YPZ-146 instruction manual
