Black Box CAT5 ClassWork Plus Multiloop User manual

CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
DECEMBER 2000
AC840A-R2
AC841C-R2
AC842A
AC842AE
CAT5 ClassWork Plus
Instructor and Student Unit Kits
123
0
456
789
Help Enter Prog Clear
Master
All
Group
Audio
Print
KB
Dark
From
F1 F2 F3 F4
Help
CAT5 Classworks Plus
Instructor Unit
CAT5 Classworks Plus

1
FCC STATEMENT
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from d
igital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.

2
CAT5 CLASSWORK PLUS
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.

3
NOM STATEMENT
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4
CAT5 CLASSWORK PLUS
TRADEMARKS USED IN THIS MANUAL
AT®and PS/2®are registered trademarks of IBM Corporation.
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.

5
CONTENTS
CONTENTS
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Advance Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 The Stages of the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Operating CAT5 ClassWork Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4. CAT5 ClassWork Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1 About the CAT5 ClassWork Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 The Instructor Unit (AC840A-R2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3 The Student Unit (AC841C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5. Installing the Student Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 Setting the Student Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Installing Each Student Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6. Installing the Student Interface Standalone Unit . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1 Student Interface Standalone Unit Connections . . . . . . . . . . . . . . . . . . . . . . 21
6.2 The Keyboard/Mouse In/Out Cable for PS/2. . . . . . . . . . . . . . . . . . . . . . . . 22
6.3 The Screen In/Out Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4 The Power Adapter and Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7. Connecting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.1 Connecting CAT5 ClassWork Plus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.2 Connecting the Instructor/Student Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.2.1 Connecting the System Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.2.2 Connecting the Screen Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2.3 Connecting the Keyboard/Mouse Cable. . . . . . . . . . . . . . . . . . . . . . . . 28
7.2.4 Connecting the Control Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2.5 Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.3 Connecting the System to the Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8. Operating the Instructor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.1.1 Screen Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.1.2 Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.1.3 Darkening Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1.4 Keyboard and Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1.5 Audio/Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6
CAT5 CLASSWORK PLUS
8.2 About the Instructor Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.3 Instructor Control Unit Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.3.1 Screen Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.3.2 Keyboard and Mouse Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.3.3 Scan Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.3.4 Dark Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8.3.5 Macro Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8.3.6 Help Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.3.7 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.4 Instructor Option: Projector Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

7
1. Specifications
Maximum Number of Student PCs — 31
Resolution — Up to 1600 x 1200 75 Hz
Connectors — Instructor Interface Unit and Student Interface Card: (2) RJ-45
system ports, (1) HD15 F screen in/out, (1) 8-pin mini-DIN F for keyboard
and mouse; Instructor Interface Unit also has (1) 5-pin DIN for control and
(1) 4-pin DIN for power; Instructor Control Unit has (1) 5-pin DIN
Transmission Distance — Total cable length should not exceed 360 ft. (110 m).
System Requirements —
CPU with PS/2 style keyboard and mouse connectors
Video: SVGA, VGA, or XGA
Temperature: 0 to 40°C
Humidity: Up to 85% non-condensing
System Cable Specification — RJ-45 male/RJ-45 male connector, Ethernet
100BASE-T4 CAT5 UTP/STP cable (we recommend Black Box cable part
number EVMSL05)
Power — Instructor Interface Unit: 110 VAC; 230 VAC;
Student Unit: Power from the PCI bus
Size — Instructor Control Unit: 3.6"H x 8.6"W x 9"D (5.1 x 21.8 x 22.9 cm);
Instructor Interface Unit: 2"H x 8.9"W x 9"D (5.1 x 22.6 x 22.9 cm);
Student Interface Card: 1⁄4Card
CHAPTER 1: Specifications

8
CAT5 CLASSWORK PLUS
2. Introduction
CAT5 ClassWork Plus uses UTP (Unshielded Twisted Pair) technology.
Replacing the cumbersome coaxial cable with the more aesthetic and thin
single 4-pair 100 BASE-T4 CAT5 UTP cable saves valuable resources—including
time and money.
Using coaxial cabling often meant allowing for extra cabling inside the plastic
duct installed around doorway frames and classroom walls.
With CAT5 ClassWork Plus, you can:
• Use the standard preset network cables commonly arranged in new buildings.
• Prevent hazardous and untidy cable-clutter in the classroom.
• Purchase the exact quantity of Student units for the number of Student
positions that you require, with the opportunity to add new Student units at
your convenience.
CAT5 ClassWork Plus supports:
• IBM compatible computers with PS/2 style keyboard and mouse connectors.
• VGA, SVGA, or XGA video standards.
• Up to 31 Student units in a loop.
• A transmission range of at least 360 ft. (110 m).
CAT5 CLASSWORK PLUS

9
CHAPTER 3: Overview
3. Overview
This chapter discusses configuring the CAT5 ClassWork Plus classroom which
involves combining both:
• Basic computer equipment, and
• Specialized ClassWork equipment
The basic computer equipment for the Instructor and each Student is a computer,
a keyboard, a screen, and a mouse, and whatever else is installed
in the computer.
The specialized CAT5 ClassWork Plus equipment for the Instructor Unit Kit
(AC840A-R2) includes:
• (1) keypad/LCD control unit and control cable,
• (1) Instructor Interface Unit that links the instructor’s computer to the first
student’s computer in a daisychain,
• (1) power supply,
• Monitor, keyboard, and mouse cables, and
• this users’ manual.
The specialized CAT5 ClassWork Plus equipment for the Student Unit Card
(AC841C-R2) or Student Interface Standalone Unit (AC841A) includes:
• (1) Student Interface Card or Student Interface Standalone Unit to link
one student’s computer to the next student’s computer in a daisychain,
• Monitor, keyboard, and mouse cables (all necessary cables are included), and
• this users’ manual.
The CAT5 Classworks Plus Starter Kit (AC842A or AC842AE) includes:
• (1) keypad/LCD control unit and control cable,
• (1) Instructor Interface Unit that links the instructor’s computer to the
student’s computer in a daisychain,
• (1) power suppply,

10
CAT5 CLASSWORK PLUS
• Monitor, keyboard, and mouse cables for instructor units,
• (3) Student Interface Cards to link one student’s computer to the next
student’s computer in a daisychain,
• Monitor, keyboard, and mouse cables for student units (all necessary cables
are included), and
• this users’ manual.
3.1 Advance Planning
Thorough planning is the key to successful configuration of your CAT5 ClassWork
Plus classroom. Time spent prior to the actual installation—in preparation and
planning—will prove itself time well invested. You should draw a sketch of your
proposed CAT5 ClassWork Plus classroom taking into account the positioning of
the computers and the Instructor’s position.
Make provision for electrical wall sockets—if necessary, a certified electrician
should prepare enough outlets before you install the CAT5 ClassWork Plus
classroom. Each outlet should have the same phase and a common ground.
3.2 The Stages of the Installation
The order in which you install your CAT5 ClassWork Plus classroom is a question
of common sense and convenience. Every person has his or her way of doing the
same thing. Nevertheless, we do recommend the following guidelines:
• Before the day of the actual installation, check the classroom’s layout: the
positioning of the furniture, the lighting and electrical outlets. This will allow
time for the classroom’s administrators to carry out any rearrangements before
the day of the actual installation.
• On the day of the actual installation, the first stage is to ensure that the basic
computer equipment is installed and operates correctly. To do this, switch on
all the computers to confirm that each workstation functions. Once you’ve
tested them, switch off all the computers.
• Determine where in the classroom you are going to place the Instructor
Position. Usually the Instructor sits at the front of the class, but not always.
•Figure 3-1 illustrates the CAT5 ClassWork Plus configuration in a block
diagram.
CAT5 CLASSWORK PLUS

11
CHAPTER 3: Overview
Figure 3-1. CAT5 ClassWork Plus Configuration.
Instructor position
Instructor
Interface
Unit
Instructor Control
unit
Instructor computer First student computer Last student computer

12
CAT5 CLASSWORK PLUS
3.3 Operating CAT5 ClassWork Plus
For instructions on how to operate the Instructor Unit hardware, see Chapter 8.
CAT5 CLASSWORK PLUS

13
CHAPTER 4: CAT5 ClassWork Plus
4. CAT5 ClassWork Plus
This chapter describes the Instructor Interface Unit and the Student Interface
Card. For information on how to operate the keypad/LCD control unit (Instructor
Control Unit), see Chapter 8.
4.1 About the CAT5 ClassWork Plus
Each CAT5 ClassWork Plus system uses:
• A Instructor Control Unit (described in Chapter 8).
• An Instructor Interface Unit, which is a closed box that you connect to the
Instructor’s position (as Section 7.2 describes), and
• A Student unit, which is a PCI card that you insert in each of the Student
computers (as Chapter 5 describes).
CAT5 ClassWork Plus supports up to 31 student units connected in a loop.
4.2 The Instructor Interface Unit
Figure 4-1 illustrates the Instructor Interface Unit.
Figure 4-1. The Instructor Interface Unit.
The Image Tuning adjustment is located on the Instructor Interface Unit’s
underside. See Chapter 7.
CAT5 Classworks Plus

14
CAT5 CLASSWORK PLUSCAT5 CLASSWORK PLUS
Figure 4-2 illustrates the Instructor Interface Unit’s rear-panel connectors.
Figure 4-2. Connectors on the Rear Panel of the Instructor Interface Unit.
Figure 4-3 shows all the connectors used by the Instructor Interface Unit.
Figure 4-3. The Instructor Interface Unit’s Connectors.
Screen I/O Out InKB/MPower Control
RJ-45F
RJ-45F
HDD15F
MiniDIN8F
DIN5F
DIN4F
Port To connector To Cable
(RJ-45M) System In
System Out
Screen In/Out
PS/2 Mouse/
Keyboard In/Out
Control
Power
(RJ-45M)
(HDD15M)
(MiniDIN8M)
(DIN5M)
(DIN4M)

15
4.3 The Student Interface Card
Each Student unit is a PCI (Peripheral Component Interconnect) card. Figure 4-4
shows the Student Interface Card.
Figure 4-4. The Student Unit.
Figure 4-5 shows the Student unit’s bracket.
Figure 4-5. The Student Unit’s Bracket.
CHAPTER 4: CAT5 ClassWork Plus
ID Number
Screen Image Adjustment
Screen I/O
Screen I/O
KB/M
KB/M
In
In
Out
Out

16
CAT5 CLASSWORK PLUS
Figure 4-6 shows the Student unit’s connectors.
Figure 4-6. The Student Unit’s Connectors.
CAT5 CLASSWORK PLUS
RJ-45F
RJ-45F
HDD15F
MiniDIN8F
Port To connector To Cable
(RJ-45M) System In
System Out
Screen In/Out
PS/2 Mouse/
Keyboard In/Out
(RJ-45M)
(HDD15M)
(MiniDIN8M)

17
CHAPTER 5: Installing the Student Units
5. Installing the Student Cards
This chapter deals with installing the Student Units. This involves:
• Opening up each of the Student computers and inserting each Student unit
card in place.
NOTE
You connect the Instructor Interface Unit to the CAT5 ClassWork Plus
system. Section 6.2 describes how to connect the Instructor Interface
Unit.
Before installing CAT5 ClassWork Plus:
• Switch off all the computers.
• Disconnect the power cord from the computer.
• Beware of any sharp edges that may be present inside your computer.
5.1 Setting the Student Number
1. Switch on all the classroom’s computers.
2. Press the PRINT ALL key on the Instructor Control Unit.
3. Press the Shift key twice on the Student keyboard (within 2 seconds). A
temporary loss of mouse control occurs.
4. Press the F1 key on the keyboard.
5. Type the three digits for that Student position (for example, 007 for Student
position #7).
6. Press the Esc key on the keyboard. This saves the ID number and exits.
7. Test the hotkey functions by pressing the keys on the Instructor Control Unit
in this sequence:
<From><*><Mastr><Enter>
* represents that Student ID number in two-digit format (for example, 07 for
Student position #7).
8. Repeat steps 2–7 to set the Student ID number for each of the other Student
positions separately.

18
CAT5 CLASSWORK PLUS
9. Disable the PRINT ALL function on the Instructor Control Unit by typing
<PRINT>.
NOTE
1. Enter a leading zero where necessary. For example, type 011 for
eleven.
2. Set each Student ID number from that Student position.
3. Each Student position requires its own unique ID number.
Before installing each Student unit, set the ID Number on each Student unit as
follows:
CAT5 CLASSWORK PLUS

19
Figure 5-1. Setting the Student ID Number.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Address Switch Setting
1 2 3 4 5 6
CHAPTER 5: Installing the Student Units
