Black Box LBH2001A-H User manual

©Copyright 2009. Black Box Corporation. All rights reserved.
1000 PARK DRIVE • LAWRENCE, PA 15055-1018 • 724-746-5500 • FAX [phone]
Gigabit Media Converter Switch December 2009
LBH2001A-H
LBH2001A-P
CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
i
BLACK BOX®
Gigabit Converter Switch
Installation and User Guide
Trademarks
UL is a registered trademark of Underwriters Laboratories
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
Important: BLACK BOX®Gigabit Converter Switches contain no user serviceable
parts. Attempted service by unauthorized personnel shall render any and all warranties
null and void. If problems are experienced with a Gigabit Converter Switch, consult
Section 5, Troubleshooting, of this User Guide.
©2009 BLACK BOX®Corporation
Printed in the United States of America. 84-01061Z, Rev A

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
ii
Contacting Black Box Corporation
Please use these mailing address and phone and fax numbers:
Black Box Corporation
1000 Park Drive
Pittsburgh, PA 15055
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
__________________________________________________________

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
iii
FEDERAL COMMUNICATIONS COMMISSION
AND
CANADIAN DEPARTMENT OF COMMUNICATIONS
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if
not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication. It
has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC
rules, which are designed to provide reasonable protection against such
interference when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference,
in which case the user at his own expense will be required to take whatever
measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
iv
This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de la classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato
eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberan ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser
respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
v
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño,
lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean
reconnendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recommendado por el
fabricante.
8. Servicio—El usuario no debe intentar dar sercicio al equipo eléctrico más allá a lo descrito en
las instrucciones de operatión. Todo otro servicio deberá ser referido a personal de servicio
calificado.
9. El aparato eléctrico debe ser situado de tal mannera que su posición no interfiera su uso. La
colocación del aparato eléctrico sobre una cama, sofá, alfombra o superficie similar puede
bloquea la ventilación, no se debe colocar en libreros o gabinetes que impidan el flujo de aire
por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance du fuentes de calor como radiadores,
registros de calor, estufas u otros aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado una fuente de poder sólo del tipo descrito en el
instrucivo de operación, o como se indique en el aparato.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
vi
12. Precaución debe ser tomada de mal manera que la tierra fisica y la polarización del equipo no
sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni
pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los
contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recommendaciones del
fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo
periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la
cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño;;o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
vii
Certification Notice for
Equipment Used in Canada
The Canadian Department of Communications label identifies certified equipment. This
certification means that the equipment meets certain telecommunications-network
protective, operation, and safety requirements. The Department does not guarantee the
equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The equipment
must also be installed using an acceptable method of connection. In some cases, the
company’s inside wiring associated with a single-line individual service may be extended
by means of a certified connector assembly (extension cord). The customer should be
aware that compliance with the above conditions may not prevent degradation of service
in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance
facility—in this case, your supplier. Any repairs or alterations made by the user to this

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
viii
equipment, or equipment malfunctions, may give the telecommunications company cause
to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the
power utility, telephone lines, and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas.
CAUTION:
Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority, or
electrician, as appropriate.
The LOAD NUMBER (LN) assigned to each terminal device denotes the percentage of
the total load to be connected to a telephone loop which is used by the device, to prevent
overloading. The termination on a loop may consist of any combination of devices,
subject only to the requirement that the total of the load numbers of all the devices does
not exceed 100.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
ix
Electrical Safety requirements:
1. This product is to be installed Only in Restricted Access Areas
(Dedicated Equipment Rooms, Electrical Closets, or the like).
2. 48VDC products shall be installed with a readily accessible disconnect
device in the building installation supply circuit to the product.
3. This product shall be provided with a maximum 5A DC Listed fuse or
circuit breaker in the supply circuit when connected to a 48V
centralized source.
4. The external power supply for DC units shall be Listed, Direct Plug In
power unit, marked Class 2, or listed ITE Power Supply, marked LPS,
which has suitably rated output voltage (i.e. 24VDC or 48VDC) and suitable
rated output current.
5. Product does not contain user replaceable fuses. Any internal fuses can
ONLY be replaced by Black Box personnel through the RMA process.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
x
TABLE OF CONTENTS Page
1.0SPECIFICATIONS ............................................................................... 1
1.1Technical Specifications...................................................................... 1
1.2Summary of models and descriptions:............................................... 10
2.0INTRODUCTION ............................................................................... 14
2.1Inspecting the Package and the Product............................................. 14
2.2Product Description ........................................................................... 15
2.2.1LBH2001A-H/P Product Description........................................ 15
2.3Frame Buffering and Latency............................................................ 21
2.4Features and Benefits......................................................................... 24
2.5Applications for LBH2001A Series Converter Switches................... 27
3.0INSTALLATION................................................................................. 35
3.1Locating the Converter Switch Unit ................................................ 35
3.2LE1505-RACK for Rack Mounting of LBH2001A Series Switches 37
3.3LH1505P-RACK for Rack Mounting, includes Power supply.......... 38
3.4 DIN-Rail mounting option................................................................. 40
3.5Power Requirements for LBH2001A Series Switches....................... 41

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
xi
3.6Powering the LBH2001A with 12V, 24V or –48VDC power input.. 42
3.7LBH2001A Series, DC-powered, -48, 24 and 12VDC Installation.. 44
3.8Connecting Ethernet Media ............................................................... 46
3.8.1Connecting Twisted Pair (RJ-45, CAT 3, CAT 5 or CAT 6, .......
Unshielded or Shielded)............................................................. 47
3.8.2Connecting Fiber Optic LC-type, “Small Form factor (SFF)”... 48
3.8.3Connecting Fiber Optic SC-type, "Snap-In".............................. 49
3.8.4Installing LC-type SFP module,“Small Form Pluggable (SFP)”49
3.8.5Connecting Single-Mode Fiber Optic........................................ 49
3.8.6Power Budget Calculations for LBH2001A, Fiber Media......... 50
3.8.7Connections to NICs which support Auto-Negotiation............. 51
4.0OPERATION....................................................................................... 53
4.1Triple-Speed Functionality, and Switching ....................................... 53
4.2Auto-cross (MDIX), Auto-negotiation and Speed-sensing................ 55
4.3Dual LEDs, Top-front and in End with ports .................................... 56
5.0TROUBLESHOOTING...................................................................... 57
5.1Before Calling for Assistance............................................................ 58
5.2When Calling for Assistance ............................................................. 59

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
xii
5.3Shipping and Packaging Information................................................. 60
Revisions:
Rev A 12/09: Initial Release

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
1
1.0 SPECIFICATIONS
1.1 Technical Specifications
Ports Performance
Data Rate: 10Mbps, 100Mbps, 1000Mbps
Network Standards
1000Mb: Ethernet IEEE 802.3ab and 802.3z
1000Base-T, -SX, -LX
100Mb: Ethernet IEEE 802.3u, 100BASE-TX, 100BASE-FX
10 Mb: Ethernet IEEE 802.3, 10BASE-T
Auto-sensing for speed: IEEE 802.3z
Packet-Processing Between Domains
Filter and Forward Rate from 1000Mbps ports: 1,488,000 pps max.
Filter and Forward Rate from 100Mbps ports: 148,800 pps max.
Filtering and Forwarding Rate from 10 Mbps ports: 14,880 pps max.
Processing type: Store and Forward, non-blocking
Auto-learning: 1K-address table
Address buffer age-out time: 300 sec.
Packet buffers memory: 64KB, dynamically shared on all domains

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
2
Latency (not including packet time): 1000 to 1000Mbps: <3μs
100 to 100Mbps: <5μs 10 to 10Mbps: <18μs
100 to 10 Mbps: <5μs 10 to 100Mbps: <15μs
Path Delay Value: 50 BT on all ports
Maximum Ethernet Segment (or Domain) Lengths
10BASE-T (Unshielded twisted pair) 100 m (328 ft)
10BASE-FL, Fiber optic 2 km (6,562 ft)
10BASE-FL, Single-mode Fiber optic 10 km (32,810ft)
100BASE-TX (CAT 5 UTP) 100 m (328 ft)
100BASE-FX, half-duplex: (multi-mode) 412 m (1350 ft)
100BASE-FX, full duplex: (multi-mode) 2 km (6,562 ft)
100BASE-FX, half-duplex: (single-mode) 412 m (1350 ft)
100BASE-FX, full duplex: (single-mode) 20 km (65,620 ft)
100BASE-FX, full duplex: (single-mode, long reach) 40 km (131,240 ft)
1000BASE-T (CAT5E OR CAT6 recommended) 100 m (328 ft)
1000BASE-SX, full duplex, multi-mode (62.5um) 220 m (722 ft)
1000BASE-SX, full duplex, multi-mode (50um) 550 m (1804 ft)
1000BASE-LX, full duplex, single-mode (9um) 5 km (16404 ft)

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
3
Operating Environment
LBH2001A-H: -13ºF to 140ºF (-25ºC to 60ºC) Long term per agency tests (UL)
-40ºF to 185ºF (-40ºC to 85ºC) Short term per IEC Type tests
LBH2001A-P: -40ºF to 167ºF (-40ºC to 75ºC) Long term per agency tests (UL)
-40ºF to 185ºF (-40ºC to 85ºC) Short term per IEC Type tests
Storage Temperature,
All models: -40ºF to 212ºF (-40ºC to 100ºC)
Cold Start:
LBH2001A-H to -20ºC
LBH2001A-P to -40ºC
Ambient Relative Humidity: 5% to 95% (non-condensing)
Altitude (All models): -200 to 50,000ft. (-60 – 15,000 m)
Conformal Coating (optional) for humidity protection
Note: LBH2001A models are designed for NEBS compliance, including, vibration,
shock and altitude.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
4
Packaging:
Enclosure: Rugged sheet metal (Aluminum)
Dimensions of the Switch unit:
3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm)
Weight: LBH2001A-H/P: 9 oz. (255g)
Power supply, for LBH2001A-H: 5.8 oz (165g)
for LBH2001A-P: 7.9 oz (225g)
Cooling Method:
Convection on the LBH2001A Series models. The hardened (H) factory floor and
extreme (P) temperature un-controlled location models have closed cases to withstand
dirt and use special thermal techniques to transfer heat to the outside of the case for
cooling.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
5
POWER SUPPLY
AC POWER SUPPLY (using an external power adapter):
All models have a (8-15) VDC output with 6ft long cord and a 2.5mm center. The power
supplies are temperature rated to match the Converter Switch ratings.
Factory Floor (LBH2001A-H) Ratings (-25 to 60°C)
North America (-Hd) models. Hardened, factory floor temperature rated. Input: 6ft AC
power cord to IEC 320 connector on the 100-240vac 47-63Hz external power adapter.
Output: 12vdc, 1.25Amps
International (LBH2001AE-H) models. Factory floor temperature rated. Input: IEC
320 connector on the 100-240vac 47-63Hz external power adapter.
Output: 12vdc, 1.25Amps.

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
6
Temperature un-controlled Premium (LBH2001A-P) Ratings (-40 to 75°C)
North America (-Pd) models. Outdoor temperature rated.
Input: 6ft AC power cord to IEC 320 connector on the100-
240vac 47-63Hz external power adapters.
Output: 12vdc, 2Amps.
International (LBH2001AE-P) models. Outdoor
temperature rated. Input: IEC 320 connector on the 100-
240vac 47-63Hz external power adapter.
Output: 12vdc, 2Amps.
Direct DC POWER SUPPLY: built-in terminal block for
+, -, ground along with 12VDC jack
12V DC internal (range of 8.0 to 15V DC)
24V DC internal (range of 18 to 36V DC).
-48V DC internal (range of 36 to 60V DC), -, ground

BLACK BOX®Gigabit Media Converter Switch Installation & User Guide
7
Power Consumption: See Section 3.6.
Note 1: the 8-15V DC jack can be used for dual source DC input using an AC adapter
and the DC terminal block. Power supply protection is provided by internal diodes.
Note 2: The Direct DC power floats. The user may ground either “+” or “-” if desired.
Port Connectors (LBH2001A-H/P):
Two RJ-45 Ports: supports 10/100/1000Mbps with auto cross (MDIX).
They are shielded 8-pin female connectors for shielded (STP) and unshielded
(UTP) Cat 3, 4, 5 cables.
One Fiber optic port: The LBH2001A series is 1000Base-SX / -LX with a
“fiber flavor” choice of multimode or singlemode SC, SLC, SFP connectors.
Switches (LBH2001A-H/P)
Fiber port default is FDX (Full-Duplex)
RJ45’s are triple-speed auto-negotiating
