Black Box KV9604A User manual

!
!
KV9604A
!
!
!
!
!
!
!
4-Port ServSwitch DT Series
USB/DVI/Audio KVM Switch
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
CUSTOMER
SUPPORT
INFORMATION
!
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]

!

1
!
FCC AND IC RFI STATEMENTS
!
!
FEDERAL COMMUNICATIONS COMMISSION
and INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
!
!
Class B Digital Device. This equipment has been tested and found to comply with
the limits for a Class B computing device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. However, there is no guarantee that
interference will not occur in a particular installation. This equipment generates,
uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. If this equipment does cause harmful interference to radio or
telephone reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following
measures:
!
•Reorient or relocate the receiving antenna.
!
•Increase the separation between the equipment and receiver.
!
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
!
•Consult an experienced radio/TV technician for help.
!
CAUTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
!
!
To meet FCC requirements, shielded cables and power cords are required
to connect this device to a personal computer or other Class B certified
device.
!
This digital apparatus does not exceed the Class B limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
!
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe B prescrites dans le Règlement sur le brouillage
radioélectrique publié par Industrie Canada.

2
!
!
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
!
!
!
INSTRUCCIONES DE SEGURIDAD
!
!
!
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
!
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
!
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
!
4. Todas las instrucciones de operación y uso deben ser seguidas.
!
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
!
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
!
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
!
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
!
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
!
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
!
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.

3
4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
!
!
NOM STATEMENT
!
!
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
!
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
!
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
!
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
!
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
!
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
!
18. Servicio por personal calificado deberá ser provisto cuando:
!
A: El cable de poder o el contacto ha sido dañado; u
!
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
!
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
4
!
!
!
!
TRADEMARKS USED IN THIS MANUAL
!
BLACK BOX, the Double Diamond logo, and ServSwitch are trademarks or
registered trademarks of BB Technologies, Inc.
!
IntelliMouse, Microsoft, Windows, Windows NT, and Windows Vista are either
registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
!
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
5
!
!
!
!
!
Contents
CONTENTS
!
!
Chapter Page
1. Specifications .......................................................................................................... 6
2. Overview .................................................................................................................. 7
2.1 Introduction .................................................................................................... 7
2.2 Components.................................................................................................... 8
2.2.1 Front Panel ............................................................................................ 8
2.2.2 Rear Panel.............................................................................................. 9
2.3 What’s Included ............................................................................................ 10
2.4 Cables That You’ll Need to Supply ............................................................. 10
3. Installation ............................................................................................................ 11
3.1 ServSwitch Placement................................................................................... 11
3.2 Hardware Installation................................................................................... 11
3.2.1 Connecting the Console Keyboard, Mouse, and Monitor ............. 11
3.2.2 Connecting the Computers................................................................ 13
3.2.3 Initial Power On .................................................................................. 13
4. Operation.............................................................................................................. 14
4.1 Powering Up the System .............................................................................. 14
4.2 Selecting Computers Using Front-Panel Buttons ...................................... 14
4.3 Function Button............................................................................................ 14
Appendix. Troubleshooting ....................................................................................... 16
A.1 Calling Black Box.......................................................................................... 16
A.2 Shipping and Packaging .............................................................................. 16

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
6
!
!
1. Specifications
!
Hotkeys: No
!
Resolution: 1600 x 1200 @ 60 Hz
!
Supported Operating Systems: Windows® 98 SE/Me/2000/XP, and
Windows Vista™
!
User Controls: (4) port buttons (labeled 1–4) also used for Scan time buttons and
AutoScan, (1) function button
!
Connectors: (1) Power;
Console end: (1) DVI-I, (4) USB Type A, (2) 3.5-mm jacks for audio (speaker
and microphone);
Computer end: (4) DVI-I, (4) USB Type B, (8) 3.5-mm jacks for audio
(speaker and microphone)
!
Indicators: (4) Port
!
Temperature Tolerance: Operating: 32 to 104°F (0 to 40°C);
Storage: -4 to +140°F (-20 to +60°C)
!
Power: From the interface or via a 5-VDC, 2-A power supply (included)
!
Size: 1.7"H x 8.7"W x 5.1"D (4.4 x 2.2 x 13 cm)
!
Weight: 2.2 lb. (1 kg)
NOTE: The KV9604A does not support hotkeys.

CHAPTER 2: Overview
7
!
!
!
2. Overview
!
!
2.1 Introduction
!
The 4-Port ServSwitch USB/DVI/Audio KVM Switch allows you to control up to
four computers from a single IBM® console (USB keyboard, USB mouse, and DVI
[Digital Visual Interface] monitor, plus audio). Supported mice include Microsoft®
IntelliMouse® and other mice.
!
Setup is fast and simple, and there’s no software to configure. Its small desktop
footprint is ideal for on or under your desktop. Use front-panel buttons on the
ServSwitch to select ports or start AutoScan. The front-panel LEDs will light with
the corresponding active port when switching between the computers. The
AutoScan function allows you to automatically scan and monitor all computers,
one by one, that are connected to the ServSwitch.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
8
!
!
!
2.2 Components
!
2.2.1 FRONT PANEL
!
Figure 2-1 shows the 4-Port ServSwitch front view. Table 2-1 describes
the components numbered in the illustration.
!
!
 
!
!
!
!
!
 
!
!
!
Figure 2-1. The 4-Port ServSwitch front-panel view.
!
Table 2-1. Front-panel components.
!
Component
Description

Port selection buttons
Press buttons 1–4 individually to select
a computer.

Scan time buttons
Press buttons 1 and 2 together to
change the Scan time interval. The unit
beeps 1, 2, 3, or 4 times for scan time
of 3, 8, 15, or 30 seconds, respectively.

!
Autoscan buttons
!
Press buttons 3 and 4 together to start
Autoscan.

!
Port LEDs
!
LEDs light when the connected
computer is selected.

Power LED
Lights when power is on.

!
Function button
!
Adjusts video signal strength or selects
audio signal. See Section 4.4.

CHAPTER 2: Overview
9
!
!
!
!
2.2.2 REAR PANEL
!
Figure 2-2 shows the 4-Port ServSwitch rear view. Table 2-2 describes the
components numbered in the illustration.
!
!
!
 12

!
 11
!
 11
!
 11
!
 11
!
!
!
!
!
!
!
!
!
 
!
!
Figure 2-2. The 4-Port ServSwitch back-panel view.
!
Table 2-2. Rear-panel components.
!
Component
Description

Power connector
Connects to a 5-VDC, 2-A power supply.

Console USB Type A
ports
Keyboard and mouse ports for console.

Console DVI port
Attaches to the user monitor.

Computer DVI ports
Connect to a computer’s video cards.

!
Computer USB Type B
ports
!
Keyboard/mouse ports for computers.
11
Computer audio ports
Speakers and microphones connect here.
12
Console audio ports
Speaker and microphone connect here.
!
9

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
10
!
!
!
2.3 What’s Included
!
The package should contain the following items. If anything is missing or
damaged, please contact Black Box.
!
•4-Port ServSwitch DT Series USB/DVI/Audio KVM Switch
!
•(1) universal power supply, output: 5 VDC, 2 A
!
•This user’s manual
!
!
2.4 Cables That You’ll Need to Supply
!
•4-Port ServSwitch DT Series USB/DVI KVM Switch Cable (EHN900024U
-0006, -0009, -0015): These cables connect to PCs that have USB and DVI
connectors. The cables are available in 6-, 9-, and 15-foot (1.8-, 2.8-, and 4.7-m)
versions.
!
•Audio cable (EJ110-0002, -0005, -0010, -0015): These cables connect to audio
and are available in 2-, 5-, 10-, and 15-foot (0.6-, 1.5-, 3.1-, and 4.7-m) versions.

CHAPTER 3: Installation
11
!
!
!
3. Installation
!
!
3.1 ServSwitch Placement
!
The 4-Port ServSwitch DT Series USB/DVI/Audio KVM Switch is small, portable,
and designed to fit on a desktop. Consider the following when deciding where to
place the KVM switch:
!
•How long are the cables attached to your keyboard, mouse, and monitor?
!
•How far away are the computers from the console?
!
•How long are the cables you use to connect your computers to the ServSwitch?
!
CAUTION
Do not place cables near machines that create electrical noise such as
fluorescent lighting, air conditioning equipment, etc.
!
!
3.2 Hardware Installation
!
This section provides instructions for the basic hardware setup of a single
ServSwitch.
!
CAUTION
Before you begin, make sure that power to all the devices that you will
be connecting is turned off.
!
To prevent damage caused by ground potential differences, make sure
that all devices are properly grounded. If you don’t follow these
instructions, your computers and/or the ServSwitch could be damaged.
!
!
3.2.1 CONNECTING THE CONSOLE KEYBOARD, MOUSE, AND MONITOR
!
1. Power off all computers.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
12
!
!
!
!
2. Connect your USB keyboard and USB mouse directly to the USB keyboard
and mouse ports (labeled with keyboard and mouse symbols) on the back of
the ServSwitch as shown in Figure 3-1. Attach your DVI cable from your
monitor directly to the DVI port. Then connect the speakers and microphone
to the console’s audio ports.
!
!
!
Microphone
!
Speakers !
!
Mouse
!
Keyboard
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Monitor
!
!
Figure 3-1. Console keyboard, mouse, monitor, and audio connection.
!
NOTES
The monitor connected to the DVI-I port must be capable of
synchronizing with the computer’s video signal. If you are uncertain
about the monitor type, consult the monitor user’s manual.

CHAPTER 3: Installation
13
!
!
!
!
3.2.2 CONNECTING THE COMPUTERS
!
Using the all-in-one DVI cable (EHN900024U-0006 or -0010), connect a computer
to the ServSwitch. Connect the cable’s USB connectors to the computer’s USB
port. Connect the cable’s DVI-I connector to your computer’s DVI-I monitor port
as shown in Figure 3-2. Connect the USB and DVI-I connectors on the other end of
the cable to the ServSwitch. Follow the same procedure to connect the other
computers.
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
ServSwitch
cable
!
USB
computer
!
!
Figure 3-2. Computer connection.
!
!
3.2.3 INITIAL POWER ON
!
After connecting the ServSwitch, power on the computers. The ServSwitch will
get enough power to operate from the computers.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
14
!
!
!
4. Operation
!
!
4.1 Powering Up the System
!
Once all cables have been connected and all computers have been powered on,
the ServSwitch emulates mouse and keyboard signals on each port, allowing your
computer to boot normally. The ServSwitch is now ready for use.
!
!
4.2 Selecting Computers Using Front-Panel Buttons
!
You can instantly select any computer by pressing the port selector buttons on the
front panel. The corresponding LED will light when the port is selected.
!
!
4.3 Function Button
!
The Function button (#5 in Figure 2-1) adjusts the optimal video signal strength
corresponding to the length or quality of DVI cable. It also selects the audio signal
from any of the connected computers’ four ports.
!
To adjust the video signal strength, follow these steps:
!
1. Press the Function button three times.
!
2. Press push button #1 one or two times to adjust the selected port’s input video
strength. One beep = normal or two beeps = enhance.
!
or
!
Press push button #3 one or two times to adjust the selected port’s output
current. One beep = normal or two beeps = enhance.
!
or
!
Press push button #4 one, two, three, or four times to adjust the selected
port’s output emphasis. One beep = no pre-emphasis, two beeps = low pre-
emphasis, three beeps = medium pre-emphasis, or four beeps = high pre-
emphasis.
!
3. Once the setting is finished, press the Function button one time to exit the
setting.

CHAPTER 3: Installation
15
!
!
!
!
To select the audio signal from any of the connected computers’ four ports, press
the Function button in combination with the other push buttons as described
below.
!
1. Press and hold the Function button. Either all the four green LEDs light to
indicate the audio port and the selected computer are the same (this is called
tracking mode) or just one green LED lights to indicate that the audio port is
different from the selected computer port (called non-tracking mode).
!
2. While holding down the Function button, press push button #1, #2, #3, or #4
to select audio port 1, 2, 3, or 4, respectively.
or
Hold down the Function button and press push buttons #1 and #2 together to
enter tracking mode.
!
3. Release the Function button to exit the setting.

4-PORT SERVSWITCH DT SERIES USB/DVI/AUDIO KVM SWITCH
16
!
!
!
Appendix. Troubleshooting
!
!
A.1 Calling Black Box
!
If you determine that your 4-Port ServSwitch DT Series USB/DVI/Audio KVM
Switch is malfunctioning, do not attempt to alter or repair the unit. It contains no
user-serviceable parts. Contact Black Box at 724-746-5500.
!
Before you do, make a record of the history of the problem. We will be able to
provide more efficient and accurate assistance if you have a complete description,
including:
!
•the nature and duration of the problem.
!
•when the problem occurs.
!
•the components involved in the problem.
!
•any particular application that, when used, appears to create the problem or
make it worse.
!
A.2 Shipping and Packaging
!
If you need to transport or ship your 4-Port ServSwitch DT Series USB/DVI/
Audio KVM Switch:
!
•Package it carefully. We recommend that you use the original container.
!
•If you are shipping the 4-Port ServSwitch DT Series USB/DVI/Audio KVM
Switch for repair, make sure you include everything that came in the original
package. Before you ship, contact Black Box to get a Return Authorization
(RA) number.

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
© Copyright 2014. Black Box Corporation. All rights reserved.
!
1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
