Black Box LPB208A-R2 User manual

Supply power to Wireless Access Point
or VoIP phone through Cat.5 cable
along with data transmitting.
Fanless Design
IEEE 802.3af Power-over-Ethernet (PSE) Compliant
Full power(15.4w) Support for Every PoE-TP Port
Auto Detect Powered Device and Consumption levels
Thermal Shutdown Protection (Tj > 150℃)
10/100Mbps Auto-Detect Half/Full Duplex
8-Port Fast Ethernet Switch with 4 PoE Ports
Customer
Support
Information
DECEMBER 2009
LPB208A-R2

Page 2
8-Port Fast Ethernet Switch with 4 PoE Ports
Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
We‘re here to help! If you have any questions about your application
or our products, contact Black Box Tech Support at 724-746-5500
or go to blackbox.com and click on “Talk to Black Box.”
You’ll be live with one of our technical experts in less than 20 seconds.
724-746-5500 | blackbox.com

Page 3
Table of Contents
1. Specifications ........................................................................................................................................................................................
2. Overview ...............................................................................................................................................................................................
2.1 Introduction .......................................................................................................................................................................................
2.2 Features ............................................................................................................................................................................................
2.3 What’s Included .................................................................................................................................................................................
2.4 ...........................................................................................................................................................................
2.5
3. Installation ...........................................................................................................................................................................................
7
8
8
9
10
8
8
103.1 Starting LPB208A-R2 Up .................................................................................................................................................................
Front & Rear Panel
LED Description ................................................................................................................................................................................
3.2 hardware and Cable Installation ......................................................................................................................................................
9
10

Federal Communications Commission and Industry Canada Radio Frequency Interference
Statements
Caution
This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in
strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been
tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart
B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the
equipment is operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user at his own expense will be required to take whatever measures may be necessary to
correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emis sion from digital apparatus set out in the
Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A computing device pursuant to Subpart J
of part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in
a commercial environment.
Circuit devices are sensitive to static electricity, which can damage their delicate electronics. Dry weather conditions or
walking across a carpeted floor may cause you to acquire a static electrical charge.
To protect your device, always:
Electronic Emission Notice
• Touch the metal chassis of your device to ground the static electrical charge before you pick up the circuit device.
• Pick up the device by holding it on the left and right edges only.
Page 4 724-746-5500 | blackbox.com
8-Port Fast Ethernet Switch with 4 PoE Ports

Page 5
Normas Oficiales Mexicanas (NOM)
Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano
mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de
operación. Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato
eléctrico sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en
libreros o gabinetes que impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor,
estufas u otros aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación,
o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos
colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de
ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
FCC Statements

Page 6 724-746-5500 | blackbox.com
European Community (CE) Electromagnetic Compatibility Directive
This equipment has been tested and found to comply with the protection requirements of European Emission Standard
EN55022/EN61000-3 and the Generic European Immunity Standard EN55024.
EMC:
EN55022(2003)/CISPR-2( 2002): class A
IEC61000-4-2 (2001): 4KV CD, 8KV AD
IEC61000-4-3( 2002): 3V/m
IEC61000-4-4(2001):1KV (power line), 0.5KV (signal line)
8-Port Fast Ethernet Switch with 4 PoE Ports

Page 7
Specification
1. Specifications
Standards:
Transmission:
Data Transfer Rate:
MAC Address and Self-learning:
Buffer Memory:
Flow Control:
Switching Method:
Connectors:
UTP Cable:
PSE Power Feeding Supports:
Diagnostic LEDs:
Power Requirement:
Power Consumption:
Operation Temperature:
Storage Temperature:
Operation Humidity:
Emission:
IEEE802.3/802.3u/802.3x , IEEE802.3af Power over Ethernet
10/100Mbps supports full or half duplex
PPS (packets per second)
100Mbps - 148,800 PPS
10Mbps - 14,880 PPS
Up to 1K
96Kbyte on chip frame buffer
IEEE802.3x compliant for full-duplex Backpressure, flow control for half-duplex
Store & forward
8 10/100Mbps RJ-45 ports
10BASE-T - UTP Cat. 3, 4, 5 or up
100BASE-TX - UTP Cat. 5 or up
(Port 1 to 4) “Endpoint” via TP pin 1, 2, 3, 6
System LED --Power
PoE LED PoE Act (Port 1 to 4)
Per Port LED--Link/Act, 10/100Mbps
AC Line, 100-240V, 50-60Hz
Max. 4W (in case no PD device connected) or Max. 65W (with 4 x 15.4W PoE devices
connected)
0to40C
10% to 90%
Complies with EMI Standard
FCC Class A
CE Mark
88
880to55C
5% to 90%
44(H) x 220(W) x 130.5(D) mm
Storage Humidity:
Dimensions:

2. Overview
2.1 Introduction
2.2 Features
2.3 What’s Included
The Fast switch, an 8 port desktop Fast switch, meets the demand of bandwidth. This desktop switch seamlessly
integrates with the rest of the network through its auto-negotiating and non-blocking design. To break through the
bottlenecks at the core of network, the switch provides up to 1.6 Gbps aggregate bandwidth and seamless migration and
the most cost effective method for bringing high-speed networking to the desktop.
PoE allows power to be supplied to end devices, such as Wireless Access Points or VoIP Phones, directly through the
existing LAN cables. By supplying the power endpoint, you can centralize power distribution and backup without the need
to increase infrastructure. The PSE switch complies with IEEE 802.3af, its advanced auto-sensing algorithm enables
providing power devices (PD) discovery, classification, current limit, and other necessary functions. It also supports high
safety with short circuit protection and power-out auto-detection to PD.
• Conforms to IEEE 802.3 10Base-T,IEEE 802.3u 100Base-TX and IEEE 802.3x flow control standards
• Supports 10/100Mbps auto-detect half/full duplex
• Supports TP interface MDI/MDI-X auto crossover
• Supports 802.3x flow control pause packet for full duplex
• Supports IEEE 802.3af compliant
• LEDs to indicate: Link/Act, Speed, Power Status and PoE activity
• Alarm contact function
• Desktop for easy installation
• Auto detect powered device and consumption levels
• Smart feature for PD on/off, PD detection, power level, PD status and power feeding priority
• Automatic Fault Detection(Over/Under Voltage & Current)
• Thermal shutdown protection(Tj>150C)
• Fanless design
Your package should include the following items. If anything is missing or damaged, please contact Black Box Technical
Support at 724-746-5500.
• 8-Port Fast Ethernet Switch with 4 PoE Ports
• (1) AC Power Cord
• This user’s manual CD
Page 8 724-746-5500 | blackbox.com
8-Port Fast Ethernet Switch with 4 PoE Ports

Page 9
Front & Rear Panel
2.4 Front & Rear Panel
2.5 LED Description
There are diagnostic LEDs located on the Front panel of LPB208A-R2. These LED indicators provide administrators with
real-time system status. The following table gives descriptions of the function of each LED indicator.
1243
56 78
POWER
POE ACT
LINK / ACT
10/100
Diagnostic LEDs 10/100 Mbps RJ-45 Ports
LED Color Function
Power
PoE ACT
(Port1to4)
Link/ ACT
10/ 100 Mbps
Green
Green
Green
Green
Lit when power is on
Off when no power
Lit when PoE feeding power is active
Off when PoE no working
Lit when link up
Blinks when transmitting or receiving data
Off when link down
Lit when 100Mbps is active
Off when 10Mbps is active
AC Line 100-240V 50/60 Hz
POWER
POE ACT
LINK / ACT
10 / 100

Page 10 724-746-5500 | blackbox.com
8-Port Fast Ethernet Switch with 4 PoE Ports
3. Installation
3.1 Starting LPB208A-R2 Up
This section will give users a quick start:
1. Take your LPB208A-R2 out of the package box.
2. Power on the LPB208A-R2. Refer to the Wiring the Power Inputs section for wiring instructions. After the LPB208A-R2
is powered on, the power LED on the LPB208A-R2 will light up. Refer to the LED Indicators section for descriptions of
the function of each LED indicators.
3. Connect one side of an Ethernet cable into the LPB208A-R2's TP port, while the other side is connected to the
attached device. The LED will light up when the cable is correctly connected. Refer to the LED Indicators section for
descriptions of the function of each LED indicator
4. After all necessary connections are established, and the corresponding LED indicators all light up and indicate that
each status is normal, the installation is now finished.
At the beginning, please follow below instruction first:
With the plug and play design, the Fast switch is easy in installation and use. Network and port status can be easily
monitored and done trouble-shooting via diagnostic LEDs. Wiring auto crossover on all ports of the switch also allows the
connection to server or PC to free from cabling problems.
1. In the switch, TP port supports MDI/MDI-X auto-crossover, so both types of cable, straight-through (Cable pin-outs for
RJ-45 jack 1, 2, 3, 6 to 1, 2, 3, 6 in 10/100M TP) and crossed-over (Cable pin-outs for RJ-45 jack 1, 2, 3, 6 to 3, 6, 1,
2) can be used. It means you do not have to tell from them, just plug it.
2. Use Cat. 5 grade RJ-45 TP cable to connect to a TP port of the switch and the other end is connected to a network-
aware device such as a workstation or a server.
3. Repeat the above steps, as needed, for each RJ-45 port to be connected to a Fast 10/100 TP device.
4. For Fast Ethernet TP network connection.
5. The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of 100 meters.
6. Insert the power cord. The embedded internal power unit using different AC power cord is available for different areas.
3.2 Hardware and Cable Installation

3.2 Hardware and Cable Installation (Cont.)
PSE TP Switch with Powered Device (PD)
Cabling Requirements
Cabling Requirements for TP Ports
1. Connect the PSE switch to an AC power source.
2. Install the TP media cable to the IEEE 802.3af PD for port 1 to 4.
3. Install the media cable for network connection.
4. Port 5 to 8 are pure TP ports for non-PoE devices.
To ensure a successful installation and keep the network performance good, please take a care on the cabling
requirement. Cables with worse specification will render the LAN to work poorly.
For Fast Ethernet TP network connection:
Straight-through cable: pin-outs for RJ-45 connector 1,2,3,6 to 1,2,3,6
Cross-over cable: pin-outs for RJ-45 connector 1,2,3,6 to 3,6,1,2
The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of 100 meters.
This device supports MDI/MDI-X auto-crossover, so both types of cable, straight-through and cross-over can be used.
•
•
End Point
PoE PD/ PoE Splitter
End Point
PoE PD/ PoE Splitter
Cat. 5 Cable
Port 1~4
Hardware and Cable Installation
Page 11

724-746-5500 | blackbox.com
About Black Box
Black Box Network Services is your source for more than 118,000 networking and infrastructure products. ou ll find everything.’
from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by
free, live 24/7 Tech support available in 20 seconds or less.
Copyright 2009. All rights reserved.
Black Box Tech Support: FREE! Live. 24/7.
Tech support the
way it should be.
Great tech support is just 20 seconds away at 724-746-5500 or blackbox.com.
