OWNER’S MANUAL

5015923











17” AIRFRYER

COMBO

Model 1783

!DANGER

•NEVER opperate this appli-

ance within 10ft (3.0 m) of

any structure, combust-

able material or other

gas cylinder.

•NEVER operate this appli-

ance within 25 ft (7.5 m) of

any flammable liquid.

Failure to follow these

instructions may result

in fire, explosion or burn

hazard which could cause

property damage, personal

injury or death.

!WARNING

INSTALLER/ASSEMBLER:

Leave these instructions

with consumer.

!WARNING

CONSUMER:

Retain this manual for

future reference.

!WARNING

This instruction manual

contains important informa-

tion necessary for the proper

assembly and safe use

of the appliance.

!WARNING

Read all warnings and

instructions before assem-

bling the appliance.

!WARNING

Follow all warnings and

instructions while using

the appliance.

!WARNING

This product may expose

you to chemicals including

Di(2-ethylhexyl)phthalate

(DEHP), which are known

to the State of California

to cause cancer and

birth defects or other

reproductive harm.

For more information, go to

www.P65Warnings.ca.gov.

!DANGER

Do not store or use gaso-

line or other flammable

liquids or vapors in the

vicinity of this or any other

appliance.

!DANGER

An LP cylinder not

connected for use shall not

be stored in the vicinity of

this or any other appliance.

!DANGER

Never operate this appli-

ance unattended.

!DANGER

When cooking with oil or

grease, have a type BC

or ABC fire extinguisher

readily available.

!DANGER

IF YOU SMELL GAS:

1. Shut o gas to appliance.

2.Extinguish any open flame.

3.Open lid.

4.If odor continues, keep

away from appliance and

immediately call your gas

supplier or your fire

department.

Failure to follow these

instructions could result

in fire or explosion which

could cause property

damage, personal injury or

death.

!DANGER

•The power cord must be

electrically grounded in

accordance with local codes

or, in the absence of local

codes, with the National

Electrical Code, ANSI/

NFPA 70, or the Canadian

Electrical Code, CSA C22.1.

•Keep the electrical supply

cord and the fuel supply

hose away from any heated

surface(s).

•Use only a Ground

Fault Interrupter (GFI)

protected circuit.

•Never remove the grounding

plug or use with an adapter

of 2 prongs.

•Use only extension cords

with a 3 prong grounding

plug, rated for the power

of the equipment, and

approved for outdoor use

with a W-A marking.

Model 1783 | Owner’s Manual |

B

!DANGER

•NEVER opperate this appli-

ance within 10ft (3.0 m) of

any structure, combust-

able material or other

gas cylinder.

•NEVER operate this appli-

ance within 25 ft (7.5 m) of

any flammable liquid.

Failure to follow these

instructions may result

in fire, explosion or burn

hazard which could cause

property damage, personal

injury or death.

!WARNING

INSTALLER/ASSEMBLER:

Leave these instructions

with consumer.

!WARNING

CONSUMER:

Retain this manual for

future reference.

!WARNING

This instruction manual

contains important informa-

tion necessary for the proper

assembly and safe use

of the appliance.

!WARNING

Read all warnings and

instructions before assem-

bling the appliance.

!WARNING

Follow all warnings and

instructions while using

the appliance.

!WARNING

This product may expose

you to chemicals including

Di(2-ethylhexyl)phthalate

(DEHP), which are known

to the State of California

to cause cancer and

birth defects or other

reproductive harm.

For more information, go to

www.P65Warnings.ca.gov.

!DANGER

Do not store or use gaso-

line or other flammable

liquids or vapors in the

vicinity of this or any other

appliance.

!DANGER

An LP cylinder not

connected for use shall not

be stored in the vicinity of

this or any other appliance.

!DANGER

Never operate this appli-

ance unattended.

!DANGER

When cooking with oil or

grease, have a type BC

or ABC fire extinguisher

readily available.

!DANGER

IF YOU SMELL GAS:

1. Shut o gas to appliance.

2.Extinguish any open flame.

3.Open lid.

4.If odor continues, keep

away from appliance and

immediately call your gas

supplier or your fire

department.

Failure to follow these

instructions could result

in fire or explosion which

could cause property

damage, personal injury or

death.

!DANGER

•The power cord must be

electrically grounded in

accordance with local codes

or, in the absence of local

codes, with the National

Electrical Code, ANSI/

NFPA 70, or the Canadian

Electrical Code, CSA C22.1.

•Keep the electrical supply

cord and the fuel supply

hose away from any heated

surface(s).

•Use only a Ground

Fault Interrupter (GFI)

protected circuit.

•Never remove the grounding

plug or use with an adapter

of 2 prongs.

•Use only extension cords

with a 3 prong grounding

plug, rated for the power

of the equipment, and

approved for outdoor use

with a W-A marking.

!DANGER

•This appliance is for outdoor

use only, and is not to be

used in a building, garage, or

any other enclosed area.

•This device should not be

used in or on recreational

vehicles or boats.

•This appliance is not be

used on or under any apart-

ment or condominium

balcony or deck.

!DANGER

If a fire should occur, keep

away from the appliance

and immediately call your

fire department. DO NOT

attempt to extinguish an oil

or a grease fire with water.

!IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock do not immerse cord, plugs, or appli-

ance in water or other liquid.

4. Close supervision is necessary when any appliance is used by

or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool

before putting on or taking o parts.

6. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions or has been damaged in any manner. Return

appliance to the nearest authorized service facility for examination,

repair, or adjustment.

7. The use of accessory attachments not recommended by the appliance

manufacturer may cause injuries.

8. For Household use and Outdoor use only.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10.Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Extreme caution must be used when moving an appliance containing hot

oil or other hot liquids.

12.To disconnect, turn any control to “o’, then remove plug from wall outlet.

13.Do not use appliance for other than intended use.

14.Fuel, such as charcoal briquettes, is not to be used with appliance.

15.Use only on properly grounded outlet.

16.CAUTION: Risk of Electric Shock. Keep extension cord connection dry

and o the ground.

17. Use only outdoors, do not expose to rain.

18.Be sure that handles are assembled and fastened properly.

SAVE THESE INSTRUCTIONS

For extension cords:

a. A short power-supply cord is provided to reduce the risk resulting from

becoming entangled in or tripping over a longer cord.

b. Longer power-supply cords or extension cords are available and may be

used if care is exercised in their use.

c. If a longer power-supply cord or extension cord is used:

1. The marked electrical rating of the cord set or extension cord should be

at least as great as the electrical rating of the appliance;

2. The cord should be arranged so that it will not drape over the coun-

tertop or tabletop where it can be pulled on by children or tripped over

unintentionally; and

3. The cord set or extension cord should be a grounding-type 3-wire cord.

d. Outdoor extension cords should be used with outdoor use products

and are surface marked with the suix letter “W” and with a tag stating

“Suitable for use with outdoor appliances.”

e. The connection to an Extension cord should be kept dry and

o the ground.

f. Store products indoors when not in use - out of the reach of children.

g. Do not clean this product with a water spray or the like.

!WARNING

This appliance will be hot

during and after use. While

cooking, place unit on

heat-resistant and flame-re-

sistant surfaces to avoid

damage and injury.

| Owner’s Manual | Model 1783

C

TABLE OF CONTENTS

It is the consumer’s responsibility to see that the unit is properly assem-

bled, installed, and maintained. Failure to follow the instructions in this

manual could result in bodily injury and/or property damage.

!DANGER

Indicates an imminently

hazardous situation which,

if not avoided, may result in

death or serious injury.

!WARNING

Indicates the possibility of

serious bodily injury if the

instructions are not followed.

!CAUTION

Indicates a potentially

hazardous situation which,

if not avoided, may result in

minor or moderate injury.

SAFETY ALERT KEY

Read and follow all the notices

throughout the manual.

��

Model Number ___________________________________

Serial Number____________________________________

Date Purchased __________________________________

REGISTER YOUR

PRODUCT

Registration allows our Customer Service Representatives to quickly

provide assistance with your Blackstone product if needed.

The North Atlantic Imports LLC 1-Year Warranty covers replacement parts up

to one year aer the date of purchase. (Please reference the Warranty chapter

for more information.) To enable this warranty, you will need to provide:

• Proof of Purchase/ Receipt/ Order Details

• Your Blackstone product’s Serial Number

• Your Blackstone product’s Model Number

Your Blackstone product’s Serial and Model numbers can be found on your

griddle’s Origin Label. (The Origin Label is a large silver sticker found on the

body of your appliance.)

Register Your Product

CONTENTS

01. REGISTER YOUR PRODUCT ..................................01

02. FOR YOUR SAFETY ..........................................02

Section 01. General Safety .............................................02

Section 02. Griddle Safety Instructions................................04

Section 03. Air Fryer Safety Instructions ..............................05

03. ASSEMBLY GUIDE ...........................................06

04. FUEL | 20 LB. PROPANE TANK ...............................14

Section 01. 20 lb. Liquid Propane Cylinder.............................14

Section 02. Connection & Removal....................................16

Section 03. Leak Test Instructions .....................................18

05. CARE & MAINTENANCE.....................................20

Section 01. General Care...............................................20

Section 02. Griddle Seasoning Instructions............................22

Section 03. Cleaning the Burner Assembly ............................24

Section 04. Cleaning Your Griddle.....................................26

Section 05. Cleaning Your Air Fryer ...................................28

06. IGNITION | AIR FRYER......................................29

07. IGNITION | PIEZO-ELECTRIC................................30

08. TROUBLESHOOTING ........................................31

Section 01. Battery Powered Ignition Troubleshooting.................31

Section 02. Griddle Gas Flow ..........................................32

09. F.A.Q.........................................................34

10. WARRANTY.................................................35

Model 1783 | Owner’s Manual |

D

TABLE OF CONTENTS

It is the consumer’s responsibility to see that the unit is properly assem-

bled, installed, and maintained. Failure to follow the instructions in this

manual could result in bodily injury and/or property damage.

!DANGER

Indicates an imminently

hazardous situation which,

if not avoided, may result in

death or serious injury.

!WARNING

Indicates the possibility of

serious bodily injury if the

instructions are not followed.

!CAUTION

Indicates a potentially

hazardous situation which,

if not avoided, may result in

minor or moderate injury.

SAFETY ALERT KEY

Read and follow all the notices

throughout the manual.

��

Model Number ___________________________________

Serial Number____________________________________

Date Purchased __________________________________

REGISTER YOUR

PRODUCT

Registration allows our Customer Service Representatives to quickly

provide assistance with your Blackstone product if needed.

The North Atlantic Imports LLC 1-Year Warranty covers replacement parts up

to one year aer the date of purchase. (Please reference the Warranty chapter

for more information.) To enable this warranty, you will need to provide:

• Proof of Purchase/ Receipt/ Order Details

• Your Blackstone product’s Serial Number

• Your Blackstone product’s Model Number

Your Blackstone product’s Serial and Model numbers can be found on your

griddle’s Origin Label. (The Origin Label is a large silver sticker found on the

body of your appliance.)

Register Your Product

Q. What types of cooking oils can I use to season my griddle?

A. We recommend the following oils for seasoning purposes: olive oil,

vegetable oil, canola oil, coconut oil, ax seed oil and sesame oil. (Please

reference the Griddle Seasoning Instructions section of the Care &

Maintenance chapter.)

Q. Can I use dish detergent to clean my griddle?

A. Grease cutting dish detergents will erase the seasoning on the griddle and

should not be used aer griddle is seasoned. For tough spots use table salt

and hot water and always coat with a thin layer of oil once you are nished

cleaning. (For griddle cleaning instructions, please reference the Cleaning

Your Griddle section of the Care & Maintenance chapter.)

Q. Why does my griddle surface look dull and dry instead of shiny

and black?

A. Seasoning is a continuous process. Over time and the more oen you use

your griddle top, the more shiny, black and non-stick it will become.

Q: Can I cut directly on the griddle top?

A: Yes, you can. Cutting on the griddle top will not harm it.

Q. What if my griddle starts to rust?

A. If rust appears on the griddle surface, rub it o with steel wool

or low grit sandpaper and re-season the surface (youtube.com/

watch?v=thPE2IgnSiI). Take care to always completely dry your griddle

before storing and keep away from rain and sprinklers. It is also important to

keep your griddle covered. (For proper storage techniques, please reference

the General Care section of the Care & Maintenance chapter.)

*CUSTOMERS IN HUMID OR COASTAL CLIMATES MAY REQUIRE MORE

FREQUENT SEASONINGS AND THE USE OF HEAVIER COOKING OILS TO

AVOID RUSTING AND CORROSION.*

For more FAQ’s visit blackstoneproducts.com/faq

F.A.Q.

OUR CUSTOMER

SERVICE STAFF IS

HERE TO HELP YOU!

For questions regarding your

Blackstone product, or if you need

replacement parts, please register

your griddle at

blackstoneproducts.com/register

and contact us at:

PHONE:

435-252-3030 ext 1

EMAIL:

support@blackstoneproducts.com

 ONLINE:

blackstoneproducts.com/pages/support

We are pleased to help you with any

questions concerning griddle use,

replacement parts, or your warranty.

Our customer service sta can be

reached Monday through Friday

from 7:00 am to 5:00 pm Mountain

Standard Time.

F.A.Q.

| Owner’s Manual | Model 1783

01

If grease or other hot material

drips from appliance onto valve,

hose or regulator:

STEP  Turn o gas

supply immediately.

STEP  Determine the cause

and correct it.

STEP  Clean and inspect

valve, hose and regulator

before continuing.

STEP  Perform a leak test.

(Please reference the Leak Test

Instructions in the Fuel chapter.)

For problems with this appli-

ance, please reference the

Troubleshooting chapter.

FOR YOUR SAFETY

Before proceeding, make certain that you understand the FOR YOUR

SAFETY section of this manual. Hazardous fire or explosion may result if

instructions are ignored.

Section 01

GENERAL SAFETY

PRECAUTIONS

• Do not use this appliance under

overhead combustible surfaces.

• When not in use, turn OFF appli-

ance by rotating the appliance

control knobs to the OFF position

and closing the fuel valve.

If the information in the above

statements is not followed exactly,

serious injuries, re, or death

may occur.

SAFETY TIPS

• Do not place empty cooking

vessel on the appliance while

in operation. Use caution when

placing anything in cooking

vessel while the appliance is

in operation.

• Do not move the appliance when

in use. Allow the cooking vessel

to cool to 115°F (45 °C) before

moving or storing.

• Use long-handled barbecue

utensils and oven mitts to protect

against burns and splatters.

!WARNING

Keep children and pets away

from appliance at all times.

This appliance is not

intended for use by children.

Close supervision is neces-

sary when any appliance is

used by or near children.

!WARNING

This appliance is not

intended for and should

never be used as a heater.

Do not use for purposes

other than intended.

!WARNING

The use of alcohol, prescrip-

tion or non-prescription

drugs may impair the

consumer’s ability to prop-

erly assemble or safely

operate the appliance.

!WARNING

The appliance must be

isolated from the gas supply

piping system by closing its

individual manual shuto

valve during any pressure

testing of the gas supply

piping system at test pres-

sures equal to or less than

1/2 psi (3.5 kPa).

!CAUTION

For residential and house-

hold use only. DO NOT use

for commercial cooking.

For Your SafetyModel 1783 | Owner’s Manual |

02

INSTALLATION SAFETY

This appliance is safety certified

for use in the United States and/

or Canada only. Do not modify

for use in any other location.

Modification will result in a safety

hazard and void warranty.

Use this appliance, as purchased,

only with LP (propane) gas and regu-

lator/valve assembly supplied.

Appliance installation must

conform with local codes, or in

the absence of local codes, with

either the National Fuel Gas Code,

ANSI Z223.1/ NFPA 54, Natural

Gas and Propane Installation Code,

CSA B149.1, or Propane Storage

and Handling Code, B149.2, or the

Standard for Recreational Vehicles,

NFPA 1192, and CSA Z240 RV Series,

Recreational Vehicle Code, as

applicable.

HOW TO TELL IF

MEAT IS COOKED

THOROUGHLY

Meat and poultry cooked with this

appliance oen browns very fast on

the outside.

Use a meat thermometer to be sure

food has reached a safe internal

temperature and cut into food to

check for visual signs of doneness.

When reheating takeout foods

or fully cooked meats like hot

dogs, cook to 165° F/74°C , or until

steaming hot.

Poultry

165° F or 74°C

Juices should run clear and esh

should not be pink.

Beef or Poultry Hamburger

160° F or 71°C

Juices should not be pink and esh

should be brown in the middle.

Beef, Veal, & Lamb

Steaks/Chops

145° F or 63°C

Beef, Veal, & Lamb Roasts

145° F or 63°C

ALL cuts of Pork

160° F or 71°C

Juices should not be pink.

MEAT COOKING

TEMPERATURES

!DANGER

This appliance is not for

frying turkeys.

!WARNING

NEVER partially cook meat

or poultry to finish cooking

later. Cook food completely

to destroy harmful bacteria.

FOOD SAFETY

Food safety is an important part

of enjoying the outdoor cooking

experience. To keep food safe from

harmful bacteria, follow these four

basic steps:

CLEAN: Wash hands, utensils,

and surfaces with hot soapy water

before and aer handling raw meat

and poultry.

SEPARATE: Separate raw meats

and poultry from ready-to eat

foods to avoid cross contamina-

tion. Use clean platter and utensils

when removing cooked foods

from appliance.

COOK: Cook meat and poultry

thoroughly to kill bacteria. Use ther-

mometer to ensure proper internal

food temperatures.

CHILL: Refrigerate prepared foods

and leovers promptly.

For more information visit

foodsafety.gov or Canadian

Partnership for Consumer Food

Safety Education online at

befoodsafe.ca

For Your Safety

If grease or other hot material

drips from appliance onto valve,

hose or regulator:

STEP  Turn o gas

supply immediately.

STEP  Determine the cause

and correct it.

STEP  Clean and inspect

valve, hose and regulator

before continuing.

STEP  Perform a leak test.

(Please reference the Leak Test

Instructions in the Fuel chapter.)

For problems with this appli-

ance, please reference the

Troubleshooting chapter.

FOR YOUR SAFETY

Before proceeding, make certain that you understand the FOR YOUR

SAFETY section of this manual. Hazardous fire or explosion may result if

instructions are ignored.

Section 01

GENERAL SAFETY

PRECAUTIONS

• Do not use this appliance under

overhead combustible surfaces.

• When not in use, turn OFF appli-

ance by rotating the appliance

control knobs to the OFF position

and closing the fuel valve.

If the information in the above

statements is not followed exactly,

serious injuries, re, or death

may occur.

SAFETY TIPS

• Do not place empty cooking

vessel on the appliance while

in operation. Use caution when

placing anything in cooking

vessel while the appliance is

in operation.

• Do not move the appliance when

in use. Allow the cooking vessel

to cool to 115°F (45 °C) before

moving or storing.

• Use long-handled barbecue

utensils and oven mitts to protect

against burns and splatters.

!WARNING

Keep children and pets away

from appliance at all times.

This appliance is not

intended for use by children.

Close supervision is neces-

sary when any appliance is

used by or near children.

!WARNING

This appliance is not

intended for and should

never be used as a heater.

Do not use for purposes

other than intended.

!WARNING

The use of alcohol, prescrip-

tion or non-prescription

drugs may impair the

consumer’s ability to prop-

erly assemble or safely

operate the appliance.

!WARNING

The appliance must be

isolated from the gas supply

piping system by closing its

individual manual shuto

valve during any pressure

testing of the gas supply

piping system at test pres-

sures equal to or less than

1/2 psi (3.5 kPa).

!CAUTION

For residential and house-

hold use only. DO NOT use

for commercial cooking.

For Your Safety

| Owner’s Manual | Model 1783

03

• Maximum weight on side shelf (if

present) is 10 lbs.

• The grease tray must be removed

and emptied aer each use.

• Do not remove grease tray until

griddle has completely cooled.

• Do not obstruct the ow of

combustion and ventilation air.

• Clean griddle oen, prefer-

ably aer each use. (Please

reference the Cleaning Your

Griddle section of the Care &

Maintenance chapter.)

Section 02

GRIDDLE SAFETY INSTRUCTIONS

!WARNING

Ensure that the fuel nozzle

is housed within the

burner opening.

!WARNING

Adding a large amount

of cold or frozen food (or

food with significant water

content) to a hot griddle may

cause griddle to warp.

TURNING GRIDDLE OFF

Turn all knobs to OFF position. Turn

fuel o at the source.

!WARNING

Do not leave the lid

closed for more than 30

minutes while cooking.

For Your SafetyModel 1783 | Owner’s Manual |

04

Section 03

AIR FRYER SAFETY INSTRUCTIONS

!DANGER

•Operating the air fryer

can cause the griddle to

become hot. Do not touch

hot surfaces. Use protec-

tive gloves or mitts when

opening drawers to prevent

burns, as the drawer face

may be hot.

•Do not place fryer drawers

on griddle surface.

•Do not place fryer drawers

on or near a hot gas or

electric burner, or in a

heated oven.

!DANGER

DO NOT operate this appli-

ance any closer than 36

inches from the sides of the

appliance and 10 inches

from overhead combus-

tible construction including

walls and ceilings.

!WARNING

Minimum clearance from

sides and back of unit to

combustible constructions is

36 inches from sides and 36

inches from back.

A = 36” (914mm)

!WARNING

DO NOT clean with

alcohol or any other flam-

mable substance.

AIR FRYER

• Do not restrict the ow of the

combustion air or the hot

exhaust gasses.

• Blow out drawers before cooking

to keep passageways clean.

• Remove items from bottom shelf

of the unit before operating the

air fryer.

• Allow to cool before putting

on or taking o parts, cleaning

or moving.

EXTENSION CORDS

Longer power-supply cords or exten-

sion cords are available and may be

used if care is exercised in their use.

FOOD

• Do not cook food in the drawer

without the basket in place.

• Do not overll basket, air needs

to ow around and between the

pieces of food.

• Use a food thermometer to

conrm food is cooked.

• If food begins to burn, turn o

burners and close tank valve.

• Food in the baskets will become

very hot, use gloves and/or tongs

to handle food.

• Do not add liquids (water or

sauces) to hot food in the drawer

as it may ash to steam and

cause burns.

• Use caution when removing

drawers as hot food or hot liquids

may spill.

A

AA A

A

For Your Safety

• Maximum weight on side shelf (if

present) is 10 lbs.

• The grease tray must be removed

and emptied aer each use.

• Do not remove grease tray until

griddle has completely cooled.

• Do not obstruct the ow of

combustion and ventilation air.

• Clean griddle oen, prefer-

ably aer each use. (Please

reference the Cleaning Your

Griddle section of the Care &

Maintenance chapter.)

Section 02

GRIDDLE SAFETY INSTRUCTIONS

!WARNING

Ensure that the fuel nozzle

is housed within the

burner opening.

!WARNING

Adding a large amount

of cold or frozen food (or

food with significant water

content) to a hot griddle may

cause griddle to warp.

TURNING GRIDDLE OFF

Turn all knobs to OFF position. Turn

fuel o at the source.

!WARNING

Do not leave the lid

closed for more than 30

minutes while cooking.

For Your Safety

| Owner’s Manual | Model 1783

05

ASSEMBLY GUIDE

EXPLODED VIEW

PARTS

QTY

1.1a

Griddle Knob Bezel

1

1.1b

Air Fryer Knob Bezel

1

1.2

Motor Switch

1

1.3

Gas Rail

1

1.4

H Burner

1

PARTS

QTY

1.5

Regulator Hose

1

1.7

Motor Assembly

1

10.1

Drawer Front Panel

1

10.2

Drawer Trivet

1

3

4

1.1a

8

1

1.1b

1.3

1.2

1.7

7

6

10.2

10

10.1

12

9

11

1.5

1.4

2

5

Model 1783 | Owner’s Manual |

06

Assembly Guide

ILLUSTRATED PARTS LIST

1 Griddle body (1 piece) 2 Griddle top (1 piece) 3 Hood (1 piece)

4 Hood handle (1 piece) 5 Grease cup (1 piece) 6 Side handles (2 pieces)

7 Power cord bracket (1 piece) 8 Griddle control knob (1 piece) 9 Air fryer control knob (1 piece)

10 Drawer assembly (1 piece) 11 Drawer handle (1 piece) 12 Feet (4 pieces - preassembled)

| Owner’s Manual | Model 1783

07

Assembly Guide

13 Hardware pack (1 piece)

a.M6x15 Screws (12 pieces)

b.M5x15 Screws (4 pieces)

c.Spares

ELECTRIC REQUIREMENTS: 120V 60Hz 12.7A

TOOLS NEEDED: Phillips Head

Screwdriver & Adjustable Wrench

NOT INCLUDED:

20 lb LP Gas Tank

13a

13b 13c

Model 1783 | Owner’s Manual |

08

Assembly Guide

ASSEMBLY INSTRUCTIONS

Please read all instructions thoroughly before proceeding. Make sure all

the plastic packing material is removed before assembling

Find a large, clean area to assemble your griddle. Please refer to the parts list

and assembly diagrams as necessary.

Griddle assembly involves large components; therefore, it is advised to

have two people assemble the unit.

STEP  With the help of another person, li the griddle top with

hood assembly, take out the protective washers from griddle legs and place

the griddle top on the main body by aligning the four (4) pins to the holes of

the body. Make sure the front pins are fully seated in the holes, then push the

griddle top back to lock the griddle in place.

Make sure the front pins are fully

seated in the holes, then push the

griddle top and hood back to lock

the griddle in place.

| Owner’s Manual | Model 1783

09

Assembly Guide

!WARNING

The manufacturer has made

every eort to eliminate any

sharp edges. However, you

should handle all compo-

nents with care to avoid

accidental injury.

Some parts may contain

sharp edges, especially

as noted in these instruc-

tions. Wear protective

gloves if necessary.

!WARNING

The use of alcohol, prescrip-

tion or non-prescription

drugs may impair the

consumer’s ability to prop-

erly assemble or safely

operate the appliance.

!CAUTION

Two people are recom-

mended for the assembly

of this product.

STEP  Attach the hood handle

to the griddle hood with two (2)

M6x15 screws.

STEP  Attach the le side handle to the griddle unit with four (4)

M6x15 screws. Repeat this step with the right side handle.

Model 1783 | Owner’s Manual |

10

Assembly Guide

STEP  Attach the drawer handles by rst removing the two small

thumb screws from inside the drawer and taking o the front panel of

the drawer. Next, attach the drawer handle to the front panel with four

(4) M5X15 screws. Re-attach the front panel with the previously removed

thumb screws.

STEP  Place the two (2) control knobs on the unit by aligning the at

portion of the “stem” with the at portion of the knob. Push the control

knobs onto unit until rmly seated.

Be sure to install handle correctly,

with the handle facing down.

| Owner’s Manual | Model 1783

11

Assembly Guide

STEP  Use two (2) M6x15 screws to attach the power cord bracket.

STEP  Place the rear grease cup on the back of the unit. Connect

the 20lb propane tank (not included). (Please reference the Connection &

Removal section of the Propane chapter.)

Model 1783 | Owner’s Manual |

12

Assembly Guide

STORING YOUR

GRIDDLE

Store griddle in a cool, dry loca-

tion. Always cover griddle if stored

outdoors. Choose from a variety of

griddle covers oered by Blackstone.

When protecting griddle with so

cover, use the “tenting” method to

prevent water from accumulating

on griddle top. “Tenting” involves

placing an object (a bowl, tennis

ball or PVC pipe) beneath so cover

in the center of griddle in order to

allow water to slide o. “Tenting”

helps prevent rust.

FIRST TIME CLEANING

GRIDDLE COOKING SURFACE:

Blackstone Griddles are pre-treated

with cooking oil to prevent rust and

damage during shipping. For rst

time use, wash griddle with hot,

soapy water.

THIS IS THE ONLY TIME YOU

SHOULD USE SOAP ON THE

GRIDDLE COOKING SURFACE.

Rinse and dry completely. Proceed

with seasoning instructions. (Please

reference the Griddle Seasoning

Instructions section)

!WARNING

NEVER APPLY COLD

WATER ACROSS THE

WHOLE SURFACE OF A

HOT GRIDDLE AT ONCE.

This may cause warping.

!CAUTION

DO NOT USE SOAP ON

THE GRIDDLE COOKING

SURFACE. This will destroy

the griddle’s seasoning.

NEED HELP?

Register your Blackstone product at

blackstoneproducts.com/register and

contact Blackstone Customer Service for

missing parts, assembly and operation

questions:

PHONE:

435-252-3030 ext 1

EMAIL:

support@blackstoneproducts.com

 ONLINE:

blackstoneproducts.com/pages/support

Care & Maintenance

STEP  Proceed to the Griddle Seasoning Instructions section

of the Care & Maintenance chapter. Enjoy cooking outdoors on your

Blackstone 17” Airfryer Combo!

| Owner’s Manual | Model 1783

13

Assembly Guide

CANADIAN LIQUID

PROPANE CYLINDER

REQUIREMENTS

• The LP cylinder must be

constructed and marked in accor-

dance with the specications for

LP gas cylinders, T.C.

 LB. LP TANK

The 20 lb. LP Tank used with

your griddle must meet the

following requirements:

LP Tanks must be constructed

and marked in accordance with

specications for LP Tanks of the

U.S. Department of Transportation

(DOT) or for Canada, CAN/

CSA-B339, tanks, spheres and tubes

for transportation of dangerous

goods. Transport Canada (TC).

See LP Tank collar for marking.

!WARNING

Turn o LP supply at

cylinder when appliance

is not in use.

LP LIQUEFIED

PETROLEUM GAS

LP gas is nontoxic, odorless and

colorless when produced. For

safety and easy detection, LP gas

has been given an odor similar to

rotten cabbage.

LP gas is highly ammable and

may ignite unexpectedly when

mixed with air.

 LB. LIQUID

PROPANE CYLINDER

REQUIREMENTS

• Check to be sure that cylinders

have a D.O.T. Certication and

that they have been date tested

by a LP gas supplier within ve

years of use.

• All LP tank supply systems must

include a collar to protect the

cylinder valve.

• Use only a 18 x 12 inch, 20lb

LP cylinder.

• The cylinder must be constructed

and marked in accordance

with the Specications for

LP - Gas Cylinders of the U .S.

Department of Transportation (D

.O .T .) or the National Standard

of Canada, CAN/CSA-B339,

Cylinders, Spheres, and Tubes

or Transportation of Dangerous

Goods; and Commission,

as applicable.

FUEL |  LB.

PROPANE TANK

Section 01

 LB. LIQUID PROPANE CYLINDER

Fuel | 20 lb. Propane TankModel 1783 | Owner’s Manual |

14

CANADIAN LIQUID

PROPANE CYLINDER

REQUIREMENTS

• The LP cylinder must be

constructed and marked in accor-

dance with the specications for

LP gas cylinders, T.C.

 LB. LP TANK

The 20 lb. LP Tank used with

your griddle must meet the

following requirements:

LP Tanks must be constructed

and marked in accordance with

specications for LP Tanks of the

U.S. Department of Transportation

(DOT) or for Canada, CAN/

CSA-B339, tanks, spheres and tubes

for transportation of dangerous

goods. Transport Canada (TC).

See LP Tank collar for marking.

!WARNING

Turn o LP supply at

cylinder when appliance

is not in use.

LP LIQUEFIED

PETROLEUM GAS

LP gas is nontoxic, odorless and

colorless when produced. For

safety and easy detection, LP gas

has been given an odor similar to

rotten cabbage.

LP gas is highly ammable and

may ignite unexpectedly when

mixed with air.

 LB. LIQUID

PROPANE CYLINDER

REQUIREMENTS

• Check to be sure that cylinders

have a D.O.T. Certication and

that they have been date tested

by a LP gas supplier within ve

years of use.

• All LP tank supply systems must

include a collar to protect the

cylinder valve.

• Use only a 18 x 12 inch, 20lb

LP cylinder.

• The cylinder must be constructed

and marked in accordance

with the Specications for

LP - Gas Cylinders of the U .S.

Department of Transportation (D

.O .T .) or the National Standard

of Canada, CAN/CSA-B339,

Cylinders, Spheres, and Tubes

or Transportation of Dangerous

Goods; and Commission,

as applicable.

FUEL |  LB.

PROPANE TANK

Section 01

 LB. LIQUID PROPANE CYLINDER

Fuel | 20 lb. Propane Tank

PLEASE NOTE: Your retailer can help you

match a replacement tank to your griddle.

LP Tank valve must have:

• Type 1 outlet compatible with

regulator of appliance.

• Safety relief valve.

• UL listed Overll Protection

Device (OPD). This OPD safety

feature is identied by a unique

triangular hand wheel. Use only

LP Tanks equipped with this type

of valve.

• LP Tank must be arranged for

vapor withdrawal and include

collar to protect LP Tank valve.

Always keep new and

exchanged LP Tanks in upright

position during use,

transit or storage.

LP TANK FILLING

Use only licensed and experienced

dealers. LP dealer must purge new

tank before lling.

Volume of propane in tank will vary

by temperature. A frosty regulator

indicates gas overll. Immediately

close LP Tank valve and call local LP

gas dealer for assistance.

Do not release liquid propane (LP)

gas into the atmosphere.

To remove gas from LP Tank, contact

a certied LP dealer or local re

department for assistance.

LP TANK EXCHANGE

Leak test new and exchanged

LP tanks BEFORE connecting

to appliance. Please reference

the Leak Test Instructions

section.

Many retailers oer the option of

replacing empty LP tanks through

an exchange service.

Use only those reputable exchange

companies that inspect, precision

ll, test and certify their tanks.

Exchange tank only for an OPD

safety feature-equipped tank.

Place dust cap on cylinder valve

outlet whenever the cylinder is

not in use.

Only install the type of dust cap

on the cylinder valve outlet that is

provided with the cylinder valve.

Other types of caps or plugs may

result in leakage of propane.

!DANGER

•NEVER store a spare LP

cylinder/bottle under or

near the appliance or in an

enclosed area.

•NEVER fill a LP cylinder/

bottle beyond 80% full.

•DO NOT store an LP tank/

bottle in an area where

children play.

•LP cylinder should only

be stored outside and in a

cool, dry place.

•NEVER leave an LP tank/

bottle inside a vehicle

which may become over-

heated by the sun.

If the information above is

not followed exactly, a fire

causing death or serious

injury may occur.

An overfilled or improp-

erly stored cylinder is a

hazard due to possible gas

release from the safety relief

valve. This could cause

intense fire with risk of

property damage, serious

injury or death.

If you see, smell or hear gas

escaping, immediately get

away from the LP cylinder

and appliance and call

fire department.

20 lb. Propane Tank | Fuel | Owner’s Manual | Model 1783

15

!DANGER

Do not insert any tool or

foreign objects into the valve

outlet or safety relief valve.

The valve may be damaged

resulting in a leak. Leaking

propane may result in explo-

sion, fire, severe personal

injury, or death.

If a leak is detected at any

time, STOP and call the

fire department.

If unable to stop a gas leak,

immediately close LP tank

valve and immediately

contact an LP gas supplier

or fire department.

!WARNING

Do not insert a POL trans-

port plug (plastic part with

external threads) into the

Type 1 tank valve outlet. It

will defeat the Safety Relief

Valve feature.

REGULATOR SAFETY

If regulator fails in unit, it must be

replaced with a Blackstone approved

model and must only be replaced by

a professionally licensed, authorized

dealer. Failure to comply will void

the warranty.

FITTINGS & HOSES

• Annual checking and tightening

of metal ttings is recommended.

• Cylinder supply system must be

arranged for vapor withdrawal.

Before each use, check to see if hoses

are cut or worn. Replace damaged

hoses before using appliance.

Use only Blackstone approved

replacement parts for valve, hose, or

regulator.

Section 02

CONNECTION & REMOVAL

 LB. LP TANK

REMOVAL FOR

TRANSPORT OR

STORAGE

STEP  Turn OFF all control

knobs. Turn LP cylinder OFF by

turning hand-wheel clockwise to a

full stop.

STEP  Turn coupling nut

counterclockwise by hand only. Do

not use tools to disconnect.

STEP  Li LP tank up and o

of support bracket.

STEP  Install safety cap onto

LP tank valve.

Always use cap and strap

supplied with valve.

Failure to use safety cap as directed

may result in serious personal injury

and/or property damage.

A disconnected LP tank in storage or

during transportation must have a

safety cap installed (as shown).

LP Tank valve

Safety cap

Retainer strap

Fuel | 20 lb. Propane Tank

Model 1783 | Owner’s Manual |

16

Black Stone 1783 User manual

Popular Kitchen Appliance manuals by other brands
