Blanco BLANCOTHERM 320 KB User manual

BLANCOTHERM 320 KB/320 KBR
Operating Instructions

BLANCOTHERM 320 KB/320 KBR
General information
Warranty This unit was manufactured with care using high-quality materials and mod-
ern production techniques.
The period of warranty from the date of purchase for this unit is 24 months
and for wearing parts and electrical parts six months. The warranty encom-
passes all the malfunctions and faults arising through the material and man-
ufacturing. Malfunctions and faults caused by improper handling and external
influences are excluded. Justified complaints are eliminated free of charge
within the warranty period.
Your right to warranty is proven by the purchase receipt bearing the date of
purchase. Our terms of business and delivery also apply.
Copyright These instructions are protected by copyright. None of this information may
be reproduced, distributed, used to the advantage of our competitors or
made accessible to third parties either completely or in part.
Technical modifications Subject to modifications for the purpose of technical improvement.
Product documentation Operating instructions; Target group: operating personnel, kitchen directors.
Typographical conventions )Important notes on particularities or special cases.
IExplanatory information in chapters or sections containing
instructions.
ªCross reference to a chapter, section or external document.
9Requirement which must be fulfilled before the subsequent steps can
be carried out.
Action or activity which must be carried out.
Unit variant XYZ
A section identified in this way applies only to a particular unit variant or unit
option.
Warnings
Signal word!
Type and source of danger
Possible consequences of noncompliance with the warnings.
Measures to avoid dangers and the consequences thereof.
The signal word (caution, warning, danger) informs of the level of danger.
Caution
warns of possible light bodily injuries and damage to property.
Warning warns of possible serious bodily injury.
Danger warns of possible most severe/deadly bodily injury.

BLANCOTHERM 320 KB/320 KBR
Contents
About this product Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Conditions of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Product features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About this product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cleaning and care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Standards and guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Transportation Checking for/reporting on damage incurred during transportation. . . . . . . 8
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Disposing of packaging material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Startup Prerequisites for operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting the unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operation Unit overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overview of temperature regulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Loading types - Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Displaying the setpoint temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting the setpoint temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Opening the cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Closing the cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Dry loading the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Wet loading the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Direct loading the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Moving the unit to a new location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Temperature maintenance of food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Removing food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Using the unit at a food distribution container . . . . . . . . . . . . . . . . . . . . . 24
Shutting down Shutting the unit down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Help in the event of problems LED/Temperature display does not illuminate . . . . . . . . . . . . . . . . . . . . . 26
LED illuminates, but food temperature is not (adequately) maintained . . . 26
Temperature display illuminates, but food temperature is not
(adequately) maintained . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Temperature display shows the HI fault message . . . . . . . . . . . . . . . . . . 28
Temperature display shows the LO fault message . . . . . . . . . . . . . . . . . 28
Corrosion of stainless-steel parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The unit has external damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cleaning and care Stainless steel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cleaning frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cleaning methods. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cleaning agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Cleaning the unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Removing areas of corrosion on stainless steel . . . . . . . . . . . . . . . . . . . . 31

BLANCOTHERM 320 KB/320 KBR
Maintenance Having the unit regularly maintained . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Treating the sealing cap of the unit socket with a rubber-care agent . . . . 32
Commission a periodical electrical safety inspection. . . . . . . . . . . . . . . . . 32
Checking the connection cable and power plug. . . . . . . . . . . . . . . . . . . . 32
Repairs Authorized persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Description of problem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Disposal Disposing of the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Technical data General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Ordering information BLANCOTHERM 320 KB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
BLANCOTHERM 320 KBR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Accessories Menu set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Gastronorm container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Support crossbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Transport cart (BTT, ROLLI, ROL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Distribution carts (ROLA, BTA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
BLANCO microfiber cleaning cloth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Stainless steel cleaning and care agent BLANCOPOLISH . . . . . . . . . . . . 36
Service CD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

BLANCOTHERM 320 KB/320 KBR
– 1 –
About this product
Application The BLANCOTHERM 320 KB/320 KBR was designed for the following
applications:
yTemperature maintenance of food in Gastronorm containers
yMaintaining the temperature of food in the stainless-steel basin of the unit
which is filled with hot water
yTransporting food in Gastronorm containers
yDistributing food
The BLANCOTHERM 320 KB/320 KBR was not designed for heating up or
cooking food.
The BLANCOTHERM 320 KB/320 KBR may not be used as a room heater.
The BLANCOTHERM 320 KB/320 KBR is particularly suitable for use in
social facilities (clinics, retirement homes, day care centers), hotels, the food
service industry (banquets, party services) and in cafeterias (canteens, dining
halls).
Conditions of use Environment
The unit may be used when the surrounding temperature is between +15 °C
and +32 °C and at normal humidity (without moisture condensation).
Instruction of third parties
If the unit is lent to third parties, these persons must be instructed in the safe
handling of the unit and possible dangers must be pointed out.
Product features General
The BLANCOTHERM 320 KB/320 KBR is made of polypropylene and has a
stainless-steel basin.
The walls and cover of the unit are filled with PUR foam. The unit can be
heated up. The temperature is thermostatically limited.
The BLANCOTHERM 320 KB/320 KBR is available with two different tem-
perature regulators:
yBLANCOTHERM 320 KB: unit model with a fixed setpoint temperature of
approx. +90 °C
yBLANCOTHERM 320 KBR: unit model with a temperature regulator for
variable setting of the setpoint temperature in 1-degree increments within
a range of +40 °C to +95 °C and "Full Power" mode with a setpoint tem-
perature of approx. +98 °C
The BLANCOTHERM 320 KB/320 KBR has a cover which is held in place
with two stainless-steel bent-clamp closures on the unit.

BLANCOTHERM 320 KB/320 KBR
– 2 –
Operation
The unit can be loaded in the following three ways:
yDry loading:
Gastronorm containers are hung in the dry stainless-steel basin
yWet loading:
Gastronorm containers are hung in the stainless-steel basin which con-
tains four liters of hot water (recommended method of operation)
yDirect loading:
The stainless-steel basin is filled directly with hot liquid food or with hot
water into which food (e. g. hot dogs) will be placed
The stainless-steel basin can hold Gastronorm containers with a maximum
depth of 200 mm.
The capacity of the stainless-steel basin is maximum one Gastronorm con-
tainer GN 1/1 – 200.
The stainless-steel basin can be divided lengthwise by a support crossbar
and crosswise with one or two support crossbars.
When using a support crossbar or two support crossbars crosswise, the fol-
lowing Gastronorm containers can be hung in the stainless-steel basin:
GN 1/2, GN 1/4, GN 2/3, GN 1/3, GN 1/6, GN 2/8 and GN 1/9.
When using a support crossbar lengthwise, the following Gastronorm con-
tainers can be hung in the stainless-steel basin: GN 2/4, GN 1/4 and GN 1/6.
The operating condition of the BLANCOTHERM 320 KB is indicated via an
operation indicator LED.
The BLANCOTHERM 320 KBR unit model has a two-digit temperature dis-
play. The temperature display is located next to the plug recess.
Good insulation keeps the temperature of the food constant for a long period
of time.
The plastic skids on the bottom of the unit guarantee stability. The grooves
on the unit cover allow up to three units to be stacked vertically.
Wear-resistant carrying handles made of stainless steel are attached to the
short sides of the unit.
The cover of the BLANCOTHERM 320 KB/320 KBR is equipped with a menu
holder. The contents of the unit, for example, can be written on the menus.
BLANCO offers various transport carts (BTT, ROLLI, ROL) and distribution
carts (ROLA, BTA) for the BLANCOTHERM 320 KB/320 KBR.
Cleaning
The plug recess is watertight when closed.
The unit can be cleaned in a dishwasher if the temperature in the dishwasher
does not exceed +90 °C.
Repairs
The wear parts (skids and handles) can be easily replaced.

BLANCOTHERM 320 KB/320 KBR
– 3 –
Safety
General information The unit has been built using state-of-the-art technology. Accordingly, all the
requirements necessary for safe operation have been fulfilled. Additional dan-
gers do nevertheless exist when the unit is operating. The safety precautions
and warnings in these operating instructions are there to help you protect
yourself against these sources of danger.
Safety precautions
Thoroughly read and observe the safety precautions in this chapter.
The operator is responsible for the observance of the safety precautions in
these operating instructions.
Warnings
Observe the warnings with the danger symbol (warning triangle) in the text.
Operating instructions
These operating instructions must be read carefully before you use the unit
for the first time.
The operator is responsible for ensuring that all users have read these instruc-
tions before using the unit.
Keep these operating instructions in a location which is always accessible to
operating personnel.
About this product Application
The unit may only be used for the applications specified.
The operator is responsible for the appropriate and proper use of the unit.
Conditions of use
The unit is only to be operated under the appropriate environmental
conditions.
The users of the unit must be instructed in its operation and must have read
and understood these operating instructions.
Transportation Upright transport position
Transport the unit in an upright position only.
Stacking several units
Stack no more than three units one on top of another. Secure stacked units
constantly to prevent them from tipping over.
Transportation with a truck or delivery vehicle
Secure the unit on all four sides to prevent it from shifting.
Secure the unit against vertical movement during transportation.
Startup Startup after a storage period
When the unit is brought from a cold storage room to a kitchen, moisture from
the air in the room condenses on the surface of the unit. If the unit is con-
nected to the power the moisture film may cause a short-circuit or an electric
shock.
Do not operate the unit until it has reached room temperature.

BLANCOTHERM 320 KB/320 KBR
– 4 –
Mains connection
The mains voltage and frequency listed on the rating plate must match the
corresponding values of the electrical outlet.
Use only an original power cable.
The unit may not be used if the insulation on the power cable, power plug or
unit plug is damaged.
Always unplug the power plug and unit plug directly at the plug housing.
Unit cover
Operate the unit with the original cover only.
Operation General information
The user must know the dangers involved in the unit and be able to assess
them.
Damage
The unit is only to be used when it is in proper working order.
If the unit is damaged, secure it against being used and notify BLANCO
Service immediately.
Hygiene regulations
Observe the corresponding regulations on foodstuffs and the properties of
the food when maintaining the temperature of food.
Stacking several units
Stack no more than three units one on top of another.
Gastronorm container with liquid food
Food which sloshes around and runs out of the unit can cause scalding.
Always seal Gastronorm containers filled with food with a sealing lid.
Loading
Only load the unit with Gastronorm containers or directly with hot liquid.
Gastronorm containers placed in the unit must be able to withstand a tem-
perature of at least +100 °C. Polycarbonate Gastronorm containers, for
example, may not be used.
Gastronorm containers with upright, rigid handles may not be used in the
unit. Upright handles can damage the cover.
The Gastronorm containers are only to be used when they are in proper
working order. The edge may not be deformed or sharp. If this is not heeded,
the unit may be damaged.
Plastic in the unit can be damaged at temperatures above +100 °C. Do not
place Gastronorm containers or other objects hotter than +100 °C in or on
the unit, e. g. Gastronorm containers heated in a combination steamer.
Tension fractures caused by cold water in hot stainless-steel
basins
When cold water is poured into hot stainless-steel basins, the rapid change
in temperature can cause microscopic tension fractures. These, in turn, can
lead to corrosion. Before filling with cold water, allow stainless-steel basin to
cool down, or fill the hot stainless-steel basin with hot water.

BLANCOTHERM 320 KB/320 KBR
– 5 –
Operation
If the unit is operated with the cover open for an extended period, a large
amount of heat is lost. Operate the unit only with the cover closed. A unit con-
nected to the power supply may only be opened briefly to place food inside
or to remove food.
Do not operate external heat sources inside the unit.
Do not put an open flame inside the unit.
The unit cover does not seal completely when closed. If sealed completely, a
vacuum would be created inside when cooling, and it would be impossible to
remove the cover.
As the cover does not seal completely, hot steam can exit the unit during
temperature maintenance of food. Danger of scalding!
Change of location
The unit can be heavy when loaded (up to 45 kg). Lifting heavy loads can
cause injuries. This applies in particular for people who already have weak-
ened musculoskeletal systems.
To minimize danger to your health, always lift the unit with a second person.
If possible, use suitable equipment to lift the unit.
Lift and carry the unit with the carrying handles only, never use the locking
levers for this purpose. If the unit is lifted or carried via the locking levers, the
cover can open and the bottom section of the unit can drop.
The unit cover does not seal completely when closed. If sealed completely, a
vacuum would be created inside when cooling, and it would be impossible to
remove the cover.
As the cover does not seal completely, extra caution is advised with wet load-
ing or direct loading with hot liquid. When lifting and carrying the unit, hot
steam or hot liquid could exit between the rim of the stainless-steel basin and
the cover and cause scalding.
It is especially dangerous when one person carries the unit in front of his/her
body using both hands. If the unit is tilted toward a person's body while it is
being lifted up, set down or carried, hot liquid can exit and cause scalding.
If possible, wait to fill the unit with liquid until it is at it's intended location.
Move the unit while upright, preferably with two people.
Secure units stacked one on top of another from tipping before changing
their location.
If a portable support (e. g. transport cart) is used to change the location of a
unit or max. three stacked units, all possible measures must be taken to
prevent damage to people and objects. This includes the following, among
others:
yDo not exceed the maximum loading capacity of the support
ySecure the unit(s) to the portable support so that they cannot tip over
yAlways move the unit(s) with two people
yOnly sloping surfaces with an incline < 10° may be crossed
ySecure the unit(s) from rolling away accidentally
The skids on the unit are worn down when it is moved directly on the floor.
To prevent the skids from wearing down, do not pull or push the unit directly
on the floor.
The edges and corners of the plastic body can be damaged by forceful
impacts. Water can seep into the unit walls in this case, especially when
cleaning in a dishwasher. The water which seeps in can cause irreparable
damage to the heater. Always handle the unit with care. Avoid impacts.

BLANCOTHERM 320 KB/320 KBR
– 6 –
Cleaning and care Hygiene
The provisions of the hygiene guidelines 93/43/EEC as well as your national
hygiene regulations must be complied with.
Cleaning frequency
Clean the unit after each use.
Cleaning methods
Use only approved cleaning methods.
Do not use pointed or sharp objects for cleaning.
Do not use a steam jet device or high-pressure cleaner.
Cleaning agents
Use only approved cleaning agents.
Do not use scouring agents. Scouring agents scratch the surface.
Do not use the following cleaning agents or cleaning agents containing the
following substances (damage to material!):
yEthyl alcohol, isopropyl alcohol and higher alcohols
yAcetone
yCleaning benzene
yTurpentine
yAcetic ester
Unit socket
Water which penetrates into the unit socket can cause a short circuit. If this
happens, there is a risk of electric shock.
Unplug the power plug and unit plug before cleaning the unit. Store the power
cable in a suitable place and protect it from moisture. Seal the unit socket
watertight with the sealing cap.

BLANCOTHERM 320 KB/320 KBR
– 7 –
Maintenance Electrical safety: re-inspection
At least once every six months, have a periodical electrical safety inspection
carried out by a professional electrician in accordance with the DIN VDE 0702
series of standards.
Connection cable and power plug
At least once every six months, check the connection cable and power plug
for mechanical damage and signs of excessive aging in accordance with
BGV A 2 or the corresponding national regulations.
Repairs Authorized persons
The unit may only be repaired by professionals trained by BLANCO. Notify
BLANCO Service in case of damage.
The warranty will be invalidated if the unit is repaired by anyone else.
Standards and guidelines Observe the applicable standards, guidelines and safety regulations.
The operator is responsible for compliance with the applicable standards,
guidelines and safety regulations.

BLANCOTHERM 320 KB/320 KBR
– 8 –
Transportation
Checking for/reporting on
damage incurred during
transportation
)It is imperative that the unit be checked immediately after delivery for
damage incurred during transportation (visual inspection).
Record on the waybill (description of defect) any damage incurred during
transportation, doing so in the presence of the carrier.
Have the carrier confirm the damage (signature).
Retain the unit and notify BLANCO of the damages with the waybill.
– or –
Do not accept the unit and return it to BLANCO via the carrier.
)This procedure will ensure correct processing of claims. If transportation
damage is reported later the consignee must provide evidence of this.
Scope of delivery
(1) BLANCOTHERM 320 KB/320 KBR
(2) Power cable
(3) Operating instructions
The exact scope of delivery and the unit model is shown in the delivery
documentation.
Unpacking Open the transportation packaging at the places provided. Do not rip or
cut it!
Check the scope of delivery.
Disposing of packaging
material )Packaging materials can be handed over to a recycling center after quot-
ing the disposal contract number. If the applicable disposal contract
number is not available, this can be obtained by contacting BLANCO.
Dispose of packaging material correctly and in an environmentally
responsible manner.

BLANCOTHERM 320 KB/320 KBR
– 9 –
Startup
Prerequisites for operation 9The unit has no known defects or visible damage
Connecting the unit )The unit does not have an "On/Off" switch. The unit is "switched on" by
connecting it to the power supply.
Caution!
Danger of damage!
If the unit is not rated for the mains voltage or frequency which is available,
the unit's electronics may suffer permanent damage.
Before connecting, ensure that the mains voltage and frequency listed on
the rating plate match the corresponding values of the electrical outlet.
Ensure that no objects which are sensitive to heat are located inside the
unit.
Open the sealing cap of the unit socket by turning the locking grip
counter-clockwise.
Fold sealing cap over and snap into the recess.
Insert unit plug into the unit socket.

BLANCOTHERM 320 KB/320 KBR
– 10 –
BLANCOTHERM 320 KB
Plug the power plug into the electrical outlet.
The operation indicator LED illuminates and signals that the unit is con-
nected to the power supply.
BLANCOTHERM 320 KBR
IThe factory setting of the unit is "Full Power" mode (FP). The unit reaches
the maximum temperature (approx. +98 °C) in "Full Power" mode.
Plug the power plug into the electrical outlet.
The temperature display performs a LED self-test and temporarily dis-
plays 88 .
The temperature display then switches to the actual temperature.
The dot LED to the right of the second temperature-display digit indicates
that heating is active.
)When the temperature regulator switches heating off, the LED to the right
next to the second digit goes out. The temperature regulator can switch
heating off if the setpoint temperature is not yet reached. If the setpoint
temperature is undershot, heating is switched on again and the LED
illuminates again.

BLANCOTHERM 320 KB/320 KBR
– 11 –
Operation
Unit overview
(1) Unit plug
(2) Power cable
(3) Power plug
(4) Sealing cap; unit socket is located behind this
(5) Recessed area for the sealing cap when folded out
(6) Plug recess
(7) On the plug recess:
BLANCOTHERM 320 KB: Film layer with an operation indicator LED
BLANCOTHERM 320 KBR: Temperature regulator
(8) Locking grip of the sealing cap
(9) Menu holder
(10) Locking latch
(11) Locking lever
(12) Carrying handle
(13) On the underside: skids
(14) Support crossbar for small Gastronorm containers (accessory)
(15) Stainless-steel basin
(16) Cover
(17) Stacking grooves
)A menu can be placed in the menu holder. You can write the name of the
food contained in the unit on the menu with a felt-tip pen.

BLANCOTHERM 320 KB/320 KBR
– 12 –
Overview of temperature regu-
lation
Temperature control
BLANCOTHERM 320 KB
)With the BLANCOTHERM 320 KB, the setpoint temperature is fixed at
+90 °C. Instead of the temperature display and buttons, these units fea-
ture a film layer with an operation indicator LED. This LED illuminates con-
tinuously as long as the unit is connected to the power supply.

BLANCOTHERM 320 KB/320 KBR
– 13 –
BLANCOTHERM 320 KBR
(1) Temperature display: when the unit is switched on, the actual tempera-
ture inside the unit is displayed. The setpoint temperature is displayed
when a button is pressed.
(2) "up" button: raises the setpoint temperature (press repeatedly or hold
down for several seconds).
(3) "down" button: lowers the setpoint temperature (press repeatedly or hold
down for several seconds).
(4) Dot LED "heating in progress": illuminates when heating is active.
Loading types - Overview The unit can be loaded in the following three ways:
Dry loading with Gastronorm containers
yGastronorm containers are hung in the dry stainless-steel basin
yWhen filling with a small amount of food, we recommend preheating the
unit
Procedure for dry loading:
ªSection "Dry loading the unit" on page 17.
Wet loading with Gastronorm containers
yGastronorm containers are hung in the stainless-steel basin which con-
tains four liters (specified fill amount) of hot water
yWhen loading with a small amount of food, we recommend preheating
the unit
yAdvantages of wet loading:
– High level of heat transfer to the Gastronorm container(s) via hot steam.
– The water is a good heat reservoir.
– BLANCOTHERM 320 KBR: The temperature distribution in the unit is
more even than with dry loading. The temperature regulator functions
more precisely here.
Procedure for wet loading:
ªSection "Wet loading the unit" on page 19.

BLANCOTHERM 320 KB/320 KBR
– 14 –
Direct loading into the stainless-steel basin
yThe stainless-steel basin is filled directly with hot liquid food or with hot
water into which food (e. g. hot dogs) will be placed
yFood loaded directly into the unit is heated to the fixed specified temper-
ature (BLANCOTHERM 320 KB) or the set temperature
(BLANCOTHERM 320 KBR). This must be taken into account with sen-
sitive foods (e. g. sausages)
yThe liquid must be hot when filled in, as the unit was not designed to heat
up a large amount of water
yAs the unit must be filled with hot food or liquid, preheating is not
necessary
Procedure for direct loading:
ªSection "Direct loading the unit" on page 21.
)With direct loading, salt and other substances come into direct contact
with the stainless-steel basin. Contact with these substances can cause
very light corrosion. For this reason, the stainless-steel basin must be
cleaned very thoroughly after being used for direct loading and must then
be rubbed dry.
Displaying the setpoint
temperature
BLANCOTHERM 320 KBR
IThe temperature range of the temperature regulator lies between +40 °C
and +95 °C. The maximum temperature (approx. +98 °C) is reached in
the unit in "Full Power" mode (FP). "Full Power" mode is the factory set-
ting of the unit.
Connect the unit to the power supply.
ªSection "Connecting the unit" on page 9.
The temperature display performs a LED self-test and temporarily dis-
plays 88 .
The temperature display then switches to the actual temperature.
A dot LED to the right of the second temperature-display digit indicates
that heating is active.
To display the setpoint temperature, briefly press any button at the tem-
perature regulator.
The setpoint temperature is displayed. FP indicates "Full Power" mode,
i. e. the maximum setpoint temperature.
The display automatically switches back to the actual temperature a few
seconds later.

BLANCOTHERM 320 KB/320 KBR
– 15 –
Setting the setpoint
temperature
BLANCOTHERM 320 KBR
)The lowest temperature setting is +40 °C, and the highest FP
(Full Power), which corresponds to a temperature of approx. +98 °C.
)While the setpoint temperature is being set, the unit switches off heating
automatically. The dot LED to the right of the second temperature-display
digit does not illuminate. When the setpoint temperature is set, heating
switches on automatically if the actual temperature is too low.
9Unit is connected to the power supply
To lower the setpoint temperature, press the "down" button briefly sev-
eral times in succession.
After the first press, the setpoint temperature is displayed (FP indicates
"Full Power" mode). Each subsequent press reduces the setpoint tem-
perature by 1 °C.
– or –
Press and hold down the "down" button.
After approx. 1 second, the temperature setting changes continuously.
To raise the setpoint temperature, press the "up" button repeatedly.
After the first press, the setpoint temperature is displayed (FP indicates
"Full Power" mode). Each subsequent press increases the setpoint tem-
perature by 1 °C.
– or –
Press and hold down the "up" button.
After approx. 1 second, the temperature setting changes continuously.
When setting is complete, wait until the temperature display switches to
the actual temperature.
The last setting of the setpoint temperature is saved automatically.
IThe unit continuously saves the setpoint temperature. If the voltage sup-
ply is interrupted, the last set setpoint temperature is active.
IIf the voltage supply is interrupted while a new setpoint temperature is
being set, the previous setpoint temperature remains unchanged. The
unit saves a new setpoint temperature when the temperature display
returns to the actual temperature.

BLANCOTHERM 320 KB/320 KBR
– 16 –
Opening the cover Open both locking levers until the locking latches disengage.
Remove cover from unit body.
Closing the cover Place cover on the unit body.
Hook the locking latches on both sides (1.) and close the locking
levers (2.).
