DEVICE OVERVIEW
6
<
9; 7
8:
>
A
1 2 3 4 1
5
?
=@

16
DEVICE OVERVIEW
Ceiling-mounted monitor
1Lights on the main unit
2Light switch ON
3Monitor latch
4Vehicle interior lighting switch
5Loudspeaker
6Infrared receiver for IR remote
control IVRC-06
Infrared transmitter for IR
headphones IVHS-01 (accessory)
7Control button
Increase the monitor volume /
navigate in the OSD menu
8Control button
Decrease the monitor volume /
navigate in the OSD menu
9On/off button for the monitor
:Control button MENU
See Instructions / OSD menu.
;Control button CH
Channel selection if the monitor is
connected to a signal controller
IVSC-3302 or IVSC-5502.
<LCD screen
=Signal cable (13 pin)
>System cable (13 pin)
?Adapter cable RCA/jack (13 pin)
@Cable for the interior lighting
(3 pin)
Red = Electrical power supply
(+12V)
White = To the door switch
(Door open = Earth)
Black = Earth
A
AUX sockets
RedRCA = Audio IN (R)
White RCA = Audio IN (L)
Yellow RCA = Video IN

17
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
IR remote control
DPOWER
On/off button for the monitor.
ETV/VIDEO
Input selector: switch between
AV1 and AV2.
FVOL • arrow button
Increase the volume for the
selected monitor.
VOL • arrow button
Decrease the volume for the
selected monitor.
GMUTE
Mute the volume of the
loudspeaker inside the monitor.
HCH • arrow button /
Channel selection if the monitor is
connected to a signal controller
IVSC-3302 or IVSC-5502.
Caution:
The way the CH /buttons
function depends on the monitor
selection, which is made using
the signal controller’s remote
control.
IMENU
See Instructions / OSD menu.
JBattery compartment
DEVICE OVERVIEW
D
H
EF G
I
J

18
CONTENTS
Device overview ..................... 15
Ceiling-mounted monitor................ 16
IR remote control ........................... 17
Contents................................. 18
Notes for the user .................. 19
Precautionary measures ................ 19
Safety notices ........................ 20
Supplied parts ........................ 20
Installing the monitor ............. 21
Installing the monitor (mechanical) . 21
Cables .......................................... 22
Operation ............................... 23
Controlling the interior lighting
(monitor) ....................................... 23
Opening the monitor ...................... 23
Adjusting the position of the
monitor .......................................... 24
Closing the monitor ....................... 24
Switching on the monitor ............... 24
OSD menu .................................... 25
IR headphones IVHS-01
(accessory) ................................... 25
Changing the light bulb ................. 26
Changing the battery in the
remote control ............................... 26
Specifcations ......................... 27
IVMR-7002.................................... 27

19
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
Thank you for choosing a Blaupunkt
product. We hope you enjoy using this
new piece of equipment.
Please read these operating
instructions before using the
equipment for the first time.
The Blaupunkt editors are constantly
working on making the operating
instructions clearer and easier to
understand. However, if you still have
any questions on how to operate the
device, please contact your dealer or
the telephone hotline for your country.
You will find the telephone number
printed at the back of this booklet.
We provide a manufacturer guarantee
for our products bought within the
European Union. You can view the
guarantee conditions at
www.blaupunkt.de or ask for them
directly at:
Blaupunkt GmbH
Hotline
Robert-Bosch-Str. 200
31139 Hildesheim
Germany
We shouldliketopointoutthatthe right
to make a claim under the guarantee
could be forfeited if the device is
changedormodifiedinanywaywithout
the express authorization of the
manufacturer.
Long-termoperationor storageoutside
thespecifictemperaturerangecanlead
to a shortening of the useful life of the
LC display.
NOTES FOR THE USER
Precautionary measures
Pleaseobserve allthewarning notices,
precautionary measures and
maintenance tips contained in these
operating instructions so as to extend
the life of your monitor.
●If you are the driver you must never
use the monitor during the journey
in order to avoid causing a road
accident.
●Do not place the monitor in the
following positions:
1. Positions in which it could
restrict the driver’s view.
2. Positions in which it could
become a danger to safety
(e.g. handbrake, steering wheel,
gearshift lever and airbag).
●Only operate the device with the
recommended voltage supply of
12 V direct current.
●Do not attempt to open or
dismantle the monitor, since you
could suffer an electric shock as a
result.
●If the monitor’s housing is
damaged or broken, take it to your
local specialist dealer or send it in
to our customer service centre.
●Avoid using the monitor in
environments where it is subjected
to dust, dirt or moisture.
●Do not install the monitor in places
where it is subjected to direct
sunlight or extreme temperatures.

20
NOTES FOR THE USER
Note
We recommend that you allow a
specialist workshop to carry out the
installation.
Safety notices
Please observe the following safety
noticesduringinstallationandwhilst
making the connections.
-Disconnect the negative and
positive terminals of the battery.
-When doing so, please observe the
safety notices provided by the
vehicle manufacturer.
-Before drilling the holes necessary
for mounting the equipment and for
laying cables, please make sure
that concealed cables, the fuel tank
and fuel lines cannot be damaged
in the process!
Supplied parts
Themonitorissuppliedwithalltheparts
listed below. Please check that the
rangeofpartssuppliedwithyourdevice
is complete. If one of the listed parts is
missing, please contact your dealer
immediately.
●Monitor (including mounting fixture
and screws)
●Remote control IVRC-06 with
battery
●5 m long 13-pin system cable
(for signal controller IVSC-3302 or
IVSC-5502)
●Connection adapter (13-pin RCA/
jack)
●Operating instructions
SUPPLIED PARTS

21
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
INSTALLING THE MONITOR
Screws for securing the
ceiling-mounted monitor
Installing the monitor
(mechanical)
Select a suitable position for secure
installation of the monitor:
●The device must not distract the
driver or restrict the driver’s view.
●The ability to enter and get out of
the vehicle must not be impeded.
●The device must not be installed in
such a way that could prevent the
other vehicle components from
functioning properly (e.g. sliding
sunroof).
●Make sure that the device is
installed in a safe and secure
position and that it cannot become
detached in the event of an
emergency stop.
●Do not attach the device merely to
the roof liner.
●If you need to drill additional holes,
make sure you do not drill through
the sheet metal of the vehicle’s
roof.
●Avoid using the monitor over a
longer period of time whilst the
engine is off in order to prevent the
battery from becoming discharged.
Screws for securing the
mounting plate

22
Cables
INSTALLING THE MONITOR
Systemcable
(13 pin)
Cable for the
interior lighting
(3 pin)
Adapter cable
Interior lighting connection (3 pin)
Red = Operating voltage (+12 V)
White = To the door switch
(Door open = Earth)
Black = Earth
To avoid discharging the battery, we
recommend you use a switched
operating voltage (ignition).
Warning notice:Theoperatingvoltage
cable must be protected with at least a
1.5Afuse.
Monitor connection (13 pin)
Connect the system cable (13 pin) >
to a signal controller (IVSC-3302 or
IVSC-5502). (The voltage supply is
provided by these devices. Operating
instructions are supplied with the
devices).
Or
Use the plug-in adapter cable ?to
connect to the 12 V supply voltage and
an external video/DVD device:
Red = ACC+12V
Yellow = +12 V direct current
Black = Earth
Red RCA = Audio IN (R)
White RCA = Audio IN (L)
Yellow RCA = Video IN
Jack (blue) = Infrared loop-through
for connection to the
IR-sensor input of
DVD-ME2 / DVD-ME3.
Attention:To beusedonlyinconjunction
with DVD-MEx series products!
>
Signal cable
(monitor hous-
ing) (13 pin)
?
=@

23
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
Controlling the interior lighting
(monitor)
There are two switches for the lights:
ON 2and interior lighting 4.
ON :
This button is used to switch the lights
on/off.
Interior lighting :
If activated, the lights only come on
when the vehicle’s doors are opened.
OPERATION
Opening the monitor
➮Pull back the monitor release latch
3to flip down the LCD display.
➮To watch television, lower the
monitor until it is at an angle of
approx. 90°to the monitor’s base
unit.
2 4
3

24
OPERATION
Adjusting the position of the
monitor
The monitor can be rotated by up to
approx. 30°to the right and left from its
central viewing position.
Closing the monitor
➮Turn the monitor back to its central
viewing position and push it into its
base unit so that it clips back into
the releasing/locking mechanism.
Switching on the monitor
Press the power-on button 9on the
mainunitorthebuttonDontheremote
control to switch the monitor on/off.
Note:
The button 9lights up blue before the
monitorisswitchedon.Thismeansthat
the monitor is connected to the 12 V
voltage supply.
D
H
EF G
I
J
9; 7
8:

25
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
OPERATION
OSD menu
Operation
➮Press the MENU button :on the
display or the MENU button Ion
the remote control to open the
OSD menu.
●Use the arrow buttons 7/ 8or
I/to select the options.After
you press the MENU button :or
Iyou can use the arrow buttons
to change the settings.
➮Select the “EXIT” option to close
the OSD menu again.
SPEAKER ON
ZOOM
BRIGHTNESS
CONTRAST
COLOR
TINT
REVOLVE LEFT-RIGHT
UP-DOWN
RESET PICTURE
EXIT
●SPEAKER ON
Switch the internal loudspeaker on/
off (same function as the MUTE
button Gon the remote control).
The sound then continues to be
outputted over the IR headphones
IVHS-01 (accessory).
●ZOOM (picture size)
Change the picture height/width
- FULL
- NORMAL
- WIDE
●BRIGHTNESS:
To adjust the brightness
●CONTRAST:
To adjust the contrast
●COLOR:
To adjust the colour
●TINT:
To adjust the picture shade (only
for NTSC)
●REVOLVE:
To revolve the screen display
- LEFT - RIGHT:
Mirror horizontally
- UP - DOWN:
Mirror vertically
●RESET PICTURE:
To reset the configured parameters
to the factory default settings.
●EXIT:
To close the OSD menu
IR headphones IVHS-01
(accessory)
The IR transmitter window 6must not
be covered up when using the IR
headphones IVHS-01 (accessory).

26
Light bulb specifications
Diameter: 8 mm
Length: 28 mm
Voltage: 12 V, 3 W
Changing the battery in the
remote control
➮Push the button on the battery
compartment Jto the right (seeA
below).
➮Pull the battery compartment J
out of the remote control (see B
below).
➮Change the 3 V battery (CR 2025).
Changing the light bulb
➮Detach the monitor from the ceiling
plate (4 screws).
➮Remove the 6 screws from the
rear.
➮Carefully lift off the rear wall.
➮Take out the old bulb (see picture
below).
➮Fit a new bulb (12 V, 3 W).
➮Refit the monitor.
OPERATION
Bulb
Screws for securing the
ceiling-mounted monitor
B
AJ

27
DANSK
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
SPECIFICATIONS
IVMR-7002
Screen size: 7" Monitor
Screen resolution: 480 (H) x 3 (RGB) x 234 (V)
Active area: 154,08 (H) x 86,58 (V)
Signal system: Dual system NTSC/PAL
Brightness: 320 cd/m2
Contrast ratio: 400:1
Viewing angle: Left/right: 60/60 degrees
Up/down: 50/40 degrees
Video input level: 1.0 Vpp ±10 %
Audio input level: 0.3 Vrms
Carrier frequency for IR sensor: L-CH: 2.3 MHz
R-CH: 2.8 MHz
Operating voltage (direct current): 10-16V
Current consumption: IVMR “On” 0,7A(at +12V)
Current consumption: IVMR “Off” 90 mA (at +12V)
Quiescent current consumption:
“Ignition off” 15 uA (at +12 V)
Operating temperature: 0 - 60 °C
Storage temperature: - 30°C to +80°C
Dimensions: 233 x 219 x 54 mm
Weight: ≤1150 g
Subject to changes!

07.05 CM/ASA - 8 622 404 487
Service-Nummern / Service numbers / Numéros du service après-
vente / Numeri del servizio di assistenza / Servicenummers /
Telefonnummer för service / Números de servicio / Números de
serviço / Servicenumre
Country: Phone: Fax:
Germany (D) 0180-5000225 05121-49 4002
Austria (A) 01-610 39 0 01-610 393 91
Belgium (B) 02-525 5444 02-525 5263
Denmark (DK) 44 898 360 44-898 644
Finland (FIN) 09-435 991 09-435 99236
France (F) 01-4010 7007 01-4010 7320
Great Britain (GB) 01-89583 8880 01-89583 8394
Greece (GR) 210 94 27 337 210 94 12 711
Ireland (IRL) 01-46 66 700 01-46 66 706
Italy (I) 02-369 6331 02-369 62464
Luxembourg (L) 40 4078 40 2085
Netherlands (NL) 0800 400 1010 0800 400 1040
Norway (N) 66-817 000 66-817 157
Portugal (P) 2185 00144 2185 00165
Spain (E) 902 52 77 70 91 410 4078
Sweden (S) 08-7501850 08-7501810
Switzerland (CH) 01-8471644 01-8471650
Czech. Rep. (CZ) 02-6130 0446 02-6130 0514
Hungary (H) 76 511 803 76 511 809
Poland (PL) 0800-118922 022-8771260
Turkey (TR) 0212-335 06 71 0212-3460040
USA (USA) 800-2662528 708-6817188
Brasil
(Mercosur) (BR) 0800 7045446 [phone]
Malaysia
(Asia Pacific) (MAL) [phone] [phone]
Blaupunkt GmbH
Robert-Bosch-Str. 200
D-31139 Hildesheim
