Blaupunkt 530 Series User manual

Enjoy it.
CAR MULTIMEDIA
SERIES 530
Operating instructions

2
Controls – Device
1 DIS button
Short press: Adjust the display brightness
Long press: Switch o the display
With inserted microSD card with navigation data:
Short press: Start the navigation
In navigation mode: Call up menu of active source
Long press: Switch o the display
2 MENU button
Short press: Call up main menu
In the main menu: Call up menu of active source
Long press: Call up Bluetooth® function directly
3 Rotary/pushbutton
Short press: Switch on device
In operation: Mute audio source
Long press: Switch o device
Turn: Adjust volume
4 Infrared receiver for remote control
5 Microphone
6 Cover
7 Reset button
Access only with open cover
Restoring the original factory settings of the device.
Caution! All personal settings will be lost!
8 microSD card reader
Access only with open cover
The card reader supports microSD cards on which
either audio/video les or navigation data can be
stored.
9 AV-IN socket
Access only with open cover
: USB socket
Access only with open cover
; Touchscreen user interface
< button (Eject)
Eject a DVD/CD
= DVD/CD drive
1
2
3
6
4
5
12
11
13
8
7
9
10

3
Controls – Remote control
? HOME button
Call up main menu
In the main menu: Call up menu of active source
@ / EJECT button
Eject a DVD/CD
A RADIO button
Start radio mode
B DISC button
Starting DVD/CD mode
C DIS button
Short press: Adjust the display brightness
Long press: Switch o the display
D / ZOOM button
Call up overview of audio les
Zoom in on image area
E / BAND button
Call up folder overview
Select waveband/memory bank
F AUDIO button
Select playback language (if available on DVD)
G EQ button
Call up equaliser menu
H / / / button
Navigate in menus/lists
Tuning into stations manually ( / )
Calling stored stations ( / )
I OK button
Conrm selection
J MENU button
Call up DVD menu
Display the folder/le list
K Number buttons 0 - 9
L / RPT button
Repeat function
M button
Delete last character of an entry
N / MIX button
Random track play
O button
Ending/rejecting a phone call
P button
Answer a call
Q GOTO button
Directly select title, chapter, movie or playtime
R button
Mute audio source
S SETUP button
Call up settings menu
T VOL + / – button
Adjusting the volume
U / ANGLE button
Call up overview of movies
Select camera viewing angle (if available on DVD)
V / SUBTITLE button
Call up overview of images
Select subtitle language (if available on DVD)
W button
Start and interrupt playback
X / button
Select title, chapter, movie
Fast searching
Y MAP button
Starting the navigation
Z BT button
Starting Bluetooth mode
[ / POWER button
Switching device on/o
\ SRC button
Select source
16
18
19
21
23
25
26
27
28
20
24
22
17
15
31
29
32
33
35
30
36
37
39
40
34
43
41
38
44
42

4
Contents
Safety notes ................................................................ 5
Symbols used ...........................................................................5
Road safety................................................................................5
General safety notes ..............................................................5
Declaration of conformity....................................................5
Cleaning notes............................................................ 5
Disposal notes............................................................. 5
Scope of delivery ........................................................ 6
Placing the device in operation................................. 6
Switching on/o......................................................................6
Volume........................................................................................6
Main menu ................................................................................6
Setting the reception area...................................................6
Radio mode ................................................................. 7
Start radio mode .....................................................................7
Select memory bank..............................................................7
Tuning into a station..............................................................7
Storing stations manually....................................................7
Storing stations automatically (Travelstore) .................7
Scanning stations....................................................................7
Switching RDS on/o ............................................................7
Switching the REG function
(regional programmes) on/o ...........................................8
Switching the AF (alternative frequencies)
function on/o.........................................................................8
Adjusting the seek tuning sensitivity ..............................8
Selecting the programme type and starting
seek tuning................................................................................8
Switching priority for trac announcements
on/o...........................................................................................8
Navigation (only for devices with navigation)......... 8
Loading navigation data......................................................8
Download of map data.........................................................8
Starting the navigation.........................................................9
Initial startup ............................................................................9
Entering a destination...........................................................9
Address ......................................................................................9
Points of Interest ................................................................. 10
Setting route options ......................................................... 11
Map Settings.......................................................................... 11
DVD/CD/USB/microSDHC media playback............. 12
Basic information ................................................................. 12
DVD/CD mode ...................................................................... 12
USB data carrier .................................................................... 13
microSDHC cards ................................................................. 13
DVD movie playback .......................................................... 13
Audio playback from DVD/CD, USB or microSDHC .. 14
Video playback from DVD/CD, USB or microSDHC... 15
Image playback from DVD/CD, USB or audioSDHC.. 15
Bluetooth mode........................................................ 16
Starting Bluetooth mode .................................................. 16
Registering Bluetooth devices ........................................ 16
Telephone mode - Bluetooth........................................... 16
Audio playback - Bluetooth.............................................. 17
Bluetooth settings ............................................................... 17
External audio/video sources.................................. 18
AV-IN socket........................................................................... 18
Video input............................................................................. 18
External monitor....................................................... 18
Sound settings.......................................................... 18
Volume distribution (fader/balance) ............................ 18
Equalizer.................................................................................. 19
Basic settings ............................................................ 19
General .................................................................................... 19
Video......................................................................................... 19
Sound....................................................................................... 20
Time .......................................................................................... 20
Language................................................................................ 20
Bluetooth ................................................................................ 20
Volume..................................................................................... 20
Useful information ................................................... 20
Warranty.................................................................................. 20
Service...................................................................................... 20
Connection diagram................................................. 21
Appendix................................................................... 22

5
Safety notes | Cleaning notes | Disposal notes
Safety notes
The car sound system was manufactured according to
the state of the art and established safety guidelines.
Even so, dangers may occur if you do not observe the
safety notes in these instructions.
These instructions are intended to familiarise you with
the most important functions. Detailed information can
be found on the Internet under www.blaupunkt.com.
• Read these instructions carefully and completely
before using the car sound system.
• Keep the instructions at a location so that they
are always accessible to all users.
• Always pass on the car sound system to third parties
together with these instructions.
In addition, observe the instructions of the devices used
in conjunction with this car sound system.
Symbols used
These instructions employ the following symbols:
DANGER!
Warns about injuries
CAUTION!
Warns about damages to the DVD/CD drive
DANGER!
Warns about high volume
The CE mark conrms the compliance with EU
directives.
쏅Identies a sequencing step
• Identies a listing
Road safety
Observe the following notes about road safety:
• Use your device in such a way that you can always
safely control your vehicle. In case of doubt, stop
at a suitable location and operate your device while
the vehicle is standing. As the driver, you may not use
the applications that will distract you from trac (de-
pending on the scope of functions of the device, e.g.
viewing videos, entering a destination).
• Follow the driving recommendations during the
route guidance only if you are not violating any
trac regulations! Trac signs and trac regula-
tions have always priority over driving recommenda-
tions.
• Always listen at a moderate volume to protect
your hearing and to be able to hear acoustic warn-
ing signals (e.g. police sirens). During mute phases
(e.g. when changing the audio source), changing the
volume is not audible. Do not increase the volume
during this mute phase.
General safety notes
Observe the following note to protect yourself against
injuries:
Do not modify or open the device. The device contains
a Class 1 laser that can cause injuries to your eyes.
Use as directed
This car sound system is intended for installation and
operation in a vehicle with 12 V vehicle system voltage
and must be installed in a DIN slot. Observe the output
limits of the device. Repairs and installation, if necessary,
should be performed by a specialist.
Installation instructions
You may only install the car sound system yourself if you
are experienced in installing car sound systems and are
very familiar with the electrical system of the vehicle. For
this purpose, observe the connection diagram at the end
of these instructions.
Declaration of conformity
The Blaupunkt Europe GmbH declares that the device
complies with the basic requirements and the other rel-
evant regulations of the directive 1999/5/EC.
The declaration of conformity can be found on the Inter-
net under www.blaupunkt.com.
Cleaning notes
Solvents, cleaning and scouring agents as well as dash-
board spray and plastics care product may contain in-
gredients that will damage the surface of the car sound
system.
Use only a dry or slightly moistened cloth for cleaning the
car sound system.
Disposal notes
Do not dispose of your old unit in the household
trash!
Use the return and collection systems available to
dispose of the old device, the remote control and
exhausted batteries.

6
Scope of delivery
The scope of delivery includes:
• Car sound system
• Remote control (incl. battery)
• TMC tuner (only for devices with Europe navigation)
• microSD card with navigation data in the microSD
card slot (only for devices with navigation)
• GPS antenna
• External Bluetooth microphone
• Getting started
• Support frame
• Small parts set
• Installation material
• Connecting cable
Placing the device in operation
Caution!
Transport securing screws
Ensure that the transport securing screws at the top side
of the device are removed before the startup of the de-
vice.
Switching on/o
Switching on/o with the rotary/pushbutton
쏅For switch-on, press the rotary/pushbutton
3 .
쏅For switch-o, hold the rotary/pushbutton
3
pressed for more than 2 seconds.
Switching on/o via vehicle ignition
If the car sound system is connected with the vehicle
ignition and it was switched o with the rotary/pushbut-
ton
3 , it is switched on or o with the ignition.
Volume
Adjusting the volume
You can adjust the volume in steps from 0 (o) to 50
(maximum).
쏅Turn the rotary/pushbutton
3 to change the vol-
ume.
Muting the car sound system (Mute)
쏅Briey press the rotary/pushbutton
3 to mute the
device or to reactivate the previous volume.
Main menu
In the main menu, you press the buttons on the touch-
screen to call up the dierent sources and operating
modes.
쏅Press the MENU button
2 .
- Or -
쏅In the current source, press the button.
The main menu is displayed.
As long as you do not select a new audio source, the
last active audio source is played back.
Note:
The gures used in these instructions are intended
to facilitate the explanations and details may deviate
from your device.
Setting the reception area
This car sound system is designed for operation in dier-
ent regions with dierent frequency ranges and station
technologies. The factory default of the reception area is
"Europe (FM/AM)". If you operate the car sound system
outside of Europe, e.g. in the US or Asia, you may rst
have to set a suitable reception area in the menu:
쏅In the main menu, press the Settings button.
The Settings menu is displayed.
쏅In the bottom area of the Settings menu, press the
General button.
The current setting is displayed behind "Radio region".
쏅Tap twice (double-click) on the Radio region but-
ton to display the list of available reception areas.
쏅Select the desired reception area by double-clicking.
The list is hidden, the selected reception area is set.
쏅Press the button.
The main menu is displayed again.
Scope of delivery | Startup

7
Radio mode
Start radio mode
쏅In the main menu, press the Radio button.
The radio playback menu is displayed.
Select memory bank
Dierent memory banks and wavebands are available.
Up to 6 stations can be stored in each memory bank.
쏅Press the button repeatedly until the desired
memory bank is displayed.
FM1 씮FM2 씮FM3 씮AM1 씮AM2 씮FM1
Tuning into a station
Tuning into stations manually
쏅Briey press the or button once or sev-
eral times to change the frequency in increments.
Enter broadcast frequency directly
If the frequency of the desired stations is known, it can
be entered directly via the touchscreen.
쏅Press the button to display additional operat-
ing options.
쏅Press the button.
A numeric keypad is displayed for the frequency
input.
쏅Enter the frequency of the desired station with the
numeric keypad.
쏅Press the OK button.
The radio playback menu is displayed, the station of
the frequency entered is played back.
Starting station seek tuning
쏅Press the or button for approx. 2 sec-
onds to start station seek tuning.
The radio tunes into the next receivable station.
Note:
For the reception area Europe: In the FM waveband,
only trac information stations are tuned into if the
priority for trac information is switched on.
Storing stations manually
쏅Select the desired memory bank with the but-
ton.
쏅Set the desired station.
쏅Press one of the memory buttons P1  -  P6 for
approx. 2 seconds to store the current station at the
button.
The station is stored.
Storing stations automatically
(Travelstore)
With Travelstore, you can automatically search for and
store the 6 FM stations oering the strongest reception
in the region in the current memory bank. Any previously
stored stations in this memory bank are deleted in the
process.
쏅Select a memory bank.
쏅Press the button to display additional operat-
ing options.
쏅Press the TS button.
The tuner starts the automatic station seek tuning.
After the storing is completed, the radio plays the
station at memory location 1 of the previously se-
lected memory bank.
Note:
For the reception area Europe: With switched-on pri-
ority for trac information, only trac information
stations are stored.
Scanning stations
You can use the scan function to play all the receivable
stations of the current waveband for a few seconds.
쏅Press the button.
The seek tuning searches for stations in the current
waveband. Each receivable station is played for a few
seconds in the process.
쏅Pressing the 
button again selects the currently
scanned station and plays it back.
Switching RDS on/o
Many FM stations broadcast an RDS (Radio Data System)
signal in addition to their programme in the reception
area Europe that allows additional functions, such as the
display of the station name.
쏅Press the button to display additional operat-
ing options.
쏅Press the RDS button to switch the RDS function
on or o.
If the RDS function is switched on, RDS is displayed
in white.
쏅Press the button to hide the additional oper-
ating options, or wait until they are automatically
hidden.
Radio mode

8
Switching the REG function (regional
programmes) on/o
Some RDS stations divide their programmes into region-
al programmes with dierent contents at certain times.
If the REG function is activated, the car sound system
changes only to those alternate frequencies of the set
station on which the same regional programme is being
broadcast.
쏅Press the REG button to switch the REG function
on or o.
If the REG function is switched on, REG is displayed
in white.
Switching the AF (alternative frequencies)
function on/o
If the AF function is activated, the car sound system auto-
matically tunes into the best receivable frequency for the
station that is currently set.
쏅Press the AF button to switch the AF function on
or o.
If the AF function is switched on, AF is displayed in
white.
Adjusting the seek tuning sensitivity
The seek tuning sensitivity decides whether the auto-
matic station seek tuning nds only strong stations or
also weaker stations that may be noisy.
쏅Press the LO  or DX button to adjust the sensitiv-
ity of station seek tuning.
If LO is displayed, only stations with a strong signal
are found during seek tuning.
If DX is displayed, stations with a strong and weak
signal are found during seek tuning.
Selecting the programme type and
starting seek tuning
You can select a programme type with the PTY function
to purposefully search for stations, for example, that
broadcast rock music or sport events.
쏅Press the button to display additional operat-
ing options.
쏅Press the PTY button to display the programme
types.
쏅Scroll through the list with  / and tap on
the desired programme type to select it.
쏅Press the PTY button to start PTY seek tuning.
If a station broadcasts a programme with the select-
ed programme type, this station is played back.
Switching priority for trac
announcements on/o
In the reception region Europe, an FM station can iden-
tify trac announcements via an RDS signal. If priority for
trac reports is switched on, a trac report is automati-
cally switched through, even if the car sound system is
currently not in radio mode.
쏅Press the TA button to switch the priority for trac
announcements on or o.
If the priority for trac announcements is switched
on, TA is displayed in white.
Navigation
(only for devices with navigation)
Loading navigation data
The navigation software and map data are located on a
microSD card. For devices with navigation, the device is
delivered with the microSD card in the microSD card slot.
To be able to use the navigation, the microSD card must
be inserted in the card slot.
Important note:
The card reader supports microSD cards on which
either audio/video les or navigation data can be
stored. The microSD card for the navigation may not
contain any other les besides the navigation data.
쏅Open the cover
6 underneath the rotary/pushbut-
ton.
쏅Insert the microSD card with its labelled side to the
left (attened corner to the top) and its contacts rst
into the card slot
8 until it clicks into place.
Download of map data
To ensure that you have the latest version of the map data
when you purchase the device, you have 30 days from
the rst GPS positioning to download the latest version
of the map data once and free of charge to the standard
microSD card from the Internet at www.naviextras.com.
You can always purchase map material from this site at
a later time.
Important note:
If the microSD card is lost or damaged, the naviga-
tion map license associated with the card will be lost.
In this case, the license must be purchased anew with
a new microSD card.
Radio mode | Navigation

9
Starting the navigation
쏅In the main menu, press Navigation to start the
navigation mode.
The navigation menu is displayed. If you start the
navigation for the rst time, the setup wizard is dis-
played.
Initial startup
If you start the navigation for the rst time, a setup wizard
appears which performs the basic settings for the naviga-
tion.
쏅Adjust the language for the navigation. This can be
a dierent language from the other functions of the
device.
쏅Conrm the selection with .
The end-user license agreement is displayed.
쏅Read the end-user license agreement. If you agree
with the terms and conditions, press .
The conguration wizard starts.
쏅Press to continue.
쏅Select a voice for the voice output of the navigation.
Various voices are available for the languages.
쏅Conrm the selection with .
쏅Specify the time format and the units for the naviga-
tion. Next, press .
On the next screen, you can perform your preferred
route settings.
쏅If necessary, change the entries by pressing the dis-
played menu entries.
쏅Press ,after you adjusted the settings.
쏅Touch , to nish the conguration.
The navigation menu is displayed.
Entering a destination
Destinations can be entered in dierent ways: Via the ad-
dress or as point of interest from the database of points
of interest. Points of interest can be sights, museums, sta-
diums, petrol stations.
Address
쏅Open the navigation menu.
쏅Press on Find .
The menu for the destination entry is displayed.
쏅Press Find Address .
The menu for the address entry is displayed.
쏅Enter the country, city and street in succession as
well as the intersection or house number. To do so,
press the corresponding entry in the address entry
menu.
A menu for text entry is displayed.
쏅Enter the desired destination via the keyboard.
With every character entered, the entry in the input
line is automatically completed.
Navigation

10
쏅If the name of the desired destination is displayed in
the address line, press the button.
The selected destination is displayed on the map.
쏅Press Next to start the route guidance.
The calculation of the route starts. Depending on the
distance between start and destination, the route
calculation may take some time.
After the route calculation is complete, the param-
eters of the route, such as distance and time, are
displayed. In addition, the entire route is displayed
on the map.
쏅Press Go! to start the route guidance.
Points of Interest
쏅Open the navigation menu.
쏅Press on Find .
The menu for the destination entry is displayed.
쏅Press Find Places .
The point of interest menu is displayed.
쏅You can select a point of interest from one of the
four predened categories Petrol Station, Parking,
Restaurant and Accommodation or start a separate
search.
쏅For example, press on Petrol Station to quickly
nd a petrol stations.
A list of petrol stations in the vicinity of the vehicle is
displayed. The petrol stations are sorted by distance
to vehicle.
쏅Select a petrol station from the list by pressing on the
list entry.
The petrol stations is displayed on the map.
쏅Press Next .
The route course and the route data are displayed.
쏅Press Go! to start the route guidance.
Navigation

11
Setting route options
In the route options, the vehicle type, type of route
(quick, short, dynamic) and additional parameters are
dened which are required by the device to calculate the
route according to your requirements.
You dene the route options during the initial congura-
tion of the navigation, but you can change them for any
route guidance.
Adjusting route options before the route guidance
쏅Call up the navigation menu.
쏅Press More… .
쏅Press Settings .
The settings menu for the navigation is displayed.
쏅Press on the button to display the second page.
쏅Press Route Settings .
The route settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back repeatedly until the navigation menu
is displayed again.
Changing route options during route guidance
쏅During a route guidance, press the More button.
쏅Press Route Settings .
The route settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back .
The route guidance is displayed again.
Map Settings
With the map settings, you can adjust the view mode
(2D or 3D), the viewing angle of the map, the colours and
the display of buildings and points of orientation on the
map. In addition, you can specify for categories of points
of interest whether they should be displayed on the map,
e.g. car dealerships, cafés, restaurants.
쏅Call up the navigation menu.
쏅Press More… .
쏅Press Settings .
The settings menu for the navigation is displayed.
쏅Press on the button to display the second page.
쏅Press Map Settings .
Navigation

12
Navigation | DVD/CD/USB/microSDHC media playback
The map settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back repeatedly until the navigation menu
is displayed again.
Note:
You can also change the map settings during the
route guidance:
쏅During a route guidance, press the More button.
쏅Press Map Settings .
The map settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back .
The route guidance is displayed again.
DVD/CD/USB/microSDHC media
playback
Basic information
The car sound system can be used to play audio DVDs/
CDs (CDDA) and DVD/CD-R/RWs with audio or MP3 les
as well as MP3 or WMA les on USB data carriers and
microSDHC cards.
In addition, you can view movies and images from DVDs/
VCDs/CDs, USB data carriers and microSDHC cards on the
display or a connected monitor.
For safety reasons, the playback of movies and images on
the integrated monitor is allowed only while the vehicle
is standing and the hand brake is applied. The "BRAKE"
cable must be connected with the hand brake connec-
tion of the vehicle (see Connection diagram at the end
of these instructions). The movie playback on an external
monitor is also possible while driving.
Notes:
• To ensure proper functioning, use only CDs with
the Compact-Disc logo and DVDs with the DVD
logo.
• Blaupunkt cannot guarantee the awless func-
tion of copy-protected DVDs/CDs and all DVD/CD
blanks, USB data carriers and microSD cards avail-
able on the market.
Note the following information when preparing an MP3/
WMA data carrier:
• Naming of tracks and directories:
– Max. 32 characters without the le extension
".mp3" or ".wma" (the use of more characters re-
duces the number of tracks and folders that the
car sound system can recognise)
• DVD/CD formats: DVD/CD-R/RW, Ø: 12 cm
• DVD/CD data formats: ISO 9669 Level 1 and 2, Joliet
• CD burn speed: Max. 16x (recommended)
• USB format/le system: mass storage device / FAT/
FAT16/FAT32
• microSD card le system: FAT/FAT16/FAT32
• File extension of audio les:
– .MP3 for MP3 les
– .WMA for WMA les
•WMAles only without Digital Rights Management
(DRM) and created with Windows Media® Player ver-
sion 8 or later
• MP3 ID3 tags: Version 1 and 2
• Bit rate for creating audio les:
– MP3: 32 to 320 kbps
– WMA: 32 to 192 kbps
• Maximum number of les and directories:
– USB medium: Up to 10,000 entries
– microSD cards: Up to 10,000 les.
DVD/CD mode
Inserting a DVD/CD
Risk of severe damage to the DVD/CD drive!
Noncircular contoured DVDs/CDs and DVDs/
CDs with a diameter of 8 cm (mini DVDs/CDs)
must not be used.
We accept no responsibility for any damage to the
drive that may occur as a result of the use of unsuitable
DVDs/CDs.
쏅Insert the DVD/CD with its printed side up into the
DVD/CD tray
= until you feel a slight resistance.
The drive automatically draws in the DVD/CD and
checks its data. Afterwards, the playback starts in
DVD/CD or MP3 mode.
Note:
You must not hinder or assist the drive as it automati-
cally draws in the DVD/CD.
Ejecting a DVD/CD
쏅Press the button
< to eject an inserted DVD/CD.
Note:
You must not hinder or assist the drive as it ejects the
DVD/CD.

13
USB data carrier
This device features a USB port under the cover at the
front of the device.
Connecting a USB data carrier
쏅Open the cover
6 underneath the rotary/pushbut-
ton.
쏅Insert the USB data carrier in the USB socket
: .
The device automatically switches to USB mode. The
data are read, the playback starts with the rst media
le recognized by the device.
Removing the USB data carrier
쏅Turn o the car sound system.
쏅Disconnect the USB data carrier.
microSDHC cards
This device features an microSDHC card slot under the
cover at the front of the device.
Inserting the microSDHC card
쏅Open the cover
6 underneath the rotary/pushbut-
ton.
쏅Insert the microSDHC card with its labelled side to
the left (attened corner to the top) and its contacts
rst into the card slot
8 until it clicks into place.
The device automatically switches to microSDHC
mode. The data are read, the playback starts with the
rst media le recognized by the device.
Removing the microSDHC card
쏅If necessary, open the cover
6 .
쏅Push on the microSDHC card until it disengages.
쏅Pull the microSDHC card out of the card slot
8 .
DVD movie playback
The car sound system can play video DVDs and VCDs. Af-
ter inserting the DVD, the playback starts automatically.
The DVD menu is displayed.
You can navigate in the DVD menu by touching the corre-
sponding buttons in the DVD menu on the touchscreen.
After starting the movie via the menu of the DVD, the
movie is displayed. The playback menu for DVDs is hid-
den.
쏅Briey touch the touchscreen once to display the
playback menu again.
The playback menu is shown.
[]Pause playback, call up DVD menu.
[] Select previous chapter.
[/] Interrupt playback and continue playback.
[] Select next chapter.
[] Call up keypad for direct selection of titles,
chapters or playing time.
[] Show additional operating options.
쏅Tap on to display additional operating op-
tions of the playback menu.
[] Hide additional operating options.
[] Display equalizer.
[] Dene range for repeat function.
[] Select playback language (only if supported
by the DVD).
[] Show subtitles (only if supported by the
DVD).
[] Switch repeat function for title, chapter or
area A-B on/o.
[] Adjust image.
DVD/CD/USB/microSDHC media playback

14
Audio playback from DVD/CD, USB or
microSDHC
The principles of audio playback (MP3/WMA) from data
carriers are identical for all sources.
쏅Select the desired source via the main menu.
The device changes to the desired source and the
playback starts.
If the playback does not start with the audio playback,
쏅press the button to change to the folder/file list.
쏅Press the button to display all the folders and
files of the data carrier.
- Or -
쏅Press the button to display all the audio les of
the data carrier.
[] Scroll through the list page by page.
[] Scroll through the list page by page.
[] Change to next higher folder level.
[] Open selected folder or start titles.
- Or -
Briey tap twice (double-click) on the name
of the folder/track. The folder is opened/the
track is started.
[] Exit the folder/le list.
After starting a title, the playback menu is displayed.
[] Display the folder/le list.
[] Short press: Title selection.
Long press: Fast searching.
[/] Interrupt playback and continue playback.
[] Short press: Title selection.
Long press: Fast searching.
[] Show additional operating options.
쏅Tap on to display additional operating op-
tions of the playback menu.
[] Hide additional operating options.
[] Display keypad to directly enter the number
of the desired title.
[] Start and end REPEAT function.
The REPEAT mode changes each time the
button is pressed.
Display REPEAT mode
Repeat current track
Repeat current folder
Repeat all tracks of data carrier
[] Start MIX random track play and end it
again.
If the MIX function is switched on, the
symbol is displayed in white.
The MIX mode depends on the selected
REPEAT function.
REPEAT
mode
display
MIX mode
No random track play
Mixing tracks of the current
folder
Mixing tracks of the data
carrier
[] Display equalizer.
DVD/CD/USB/microSDHC media playback

15
Video playback from DVD/CD, USB or
microSDHC
쏅Select the desired source via the main menu.
The device changes to the desired source and the
playback starts.
If the playback does not start with the video playback,
쏅press the button to change to the folder/file list.
쏅Press the button to display all the folders and
files of the data carrier.
- Or -
쏅Press the button to display all the video les
of the data carrier.
Note:
Folders and videos are selected and started as de-
scribed under audio playback.
If you selected a movie, the playback is started. During
the movie playback, the playback menu is hidden.
쏅Briey touch the touchscreen once to display the
playback menu again.
The playback menu is shown.
[] Display the folder/le list.
[] Select previous movie.
[/] Interrupt playback and continue playback.
[] Select next movie.
[] Call up keypad for direct selection of movie
or playing time.
[] Show additional operating options.
쏅Tap on to display additional operating op-
tions of the playback menu.
[] Hide additional operating options.
[] Display equalizer.
[] Switch repeat function for movie or folder
on/o.
[] Adjust image.
Image playback from DVD/CD, USB or
audioSDHC
쏅Select the desired source via the main menu.
The device changes to the desired source and the
playback starts.
If the playback does not start with the image playback,
쏅press the button to change to the folder/file list.
쏅Press the button to display all the folders and
files of the data carrier.
- Or -
쏅Press the button to display all the images of
the data carrier.
Note:
Folders and images are selected and started as de-
scribed under audio playback.
DVD/CD/USB/microSDHC media playback

16
Bluetooth mode
The Bluetooth® function allows registering cell phones
and media playback devices with the car sound system.
When you register a cell phone with the car sound sys-
tem, you can make phone calls with the built-in hands-
free function. You can access the lists of dialled numbers
and the phone book of the registered cell phone.
If the connected Bluetooth® device supports the func-
tions A2DP and AVRCP, you can play the music via the
car sound system and control the playback. During a call,
the music playback is interrupted and continued again
after the call.
If a cell phone is registered via Bluetooth® and a call is re-
ceived during the playback of another source, the source
playback is interrupted and the call menu is displayed.
Starting Bluetooth mode
쏅In the main menu, press on Bluetooth .
- Or -
쏅Press the MENU button
2 for approx. 2 seconds.
The Bluetooth® menu is displayed. It contains the list
of known Bluetooth® devices. Other audio sources
are switched o.
[] Add new Bluetooth® device.
[] Display options menu.
쏅Press the Connect button of the Bluetooth® de-
vice with which you want to establish a connection.
When the device is in range, the connection is estab-
lished and the menu for the device is displayed.
쏅Press the Delete button if you want to delete the
Bluetooth® device from the list.
Registering Bluetooth devices
If you want to register a device with the car sound system
for the rst time, proceed as follows:
쏅Ensure that Bluetooth® is activated at the car sound
system and at your Bluetooth® device.
쏅In the options menu of the Bluetooth® mode, enter a
pairing code (see Bluetooth® settings).
쏅Search for new devices/connections on your Blue-
tooth® device.
쏅The car sound system appears as "BP 530" in the list
of Bluetooth® devices.
쏅Establish the connection; you may have to enter the
pairing code that was previously entered on the car
sound system.
The connection is being established and the menu
for the registered device is displayed.
Note:
If a telephone is connected with the car sound sys-
tem, the Bluetooth® icon is displayed at the top
right edge of the display in all audio/video sources.
Telephone mode - Bluetooth
If you connected a phone with the car sound system via
Bluetooth®, the following menu appears.
[] Display the phone menu.
[] Display the playback menu.
[] Disconnect connection with current device.
[] Call up the phone book.
[] Call up caller lists.
[] Display options menu.
쏅Enter a phone number with the keypad and press the
button.
- Or -
쏅Select a contact/number via the caller lists or phone
book and press the Dial button in the pop-up
window.
The connection is being established.
Bluetooth mode

17
If a call is coming in, the call menu is displayed.
[] Reject a call.
[] Answer a call.
Audio playback - Bluetooth
If an audio streaming device is connected with the car
sound system via Bluetooth®, you can play back the mu-
sic via the car sound system and control the playback.
쏅Press the button to change to the audio play-
back.
[] Display the phone menu.
[] Display the playback menu.
[] Disconnect connection with current device.
[] Short press: Title selection.
Long press: Fast searching.
[] Interrupt playback and continue playback.
[] Short press: Title selection.
Long press: Fast searching.
[] Display equalizer.
Bluetooth settings
In the options menu for Bluetooth®, you can make the
basic settings for the Bluetooth® mode.
쏅Press the button.
The options menu is displayed.
Bluetooth – Bluetooth® can be switched on or o.
Auto connect – If "Auto Connect" is activated, the
device automatically connects with known Blue-
tooth® devices as soon as they are in range.
Auto answer – If "Auto Answer" is activated, incom-
ing phone calls are automatically answered.
Microphone – Select the microphone to be used for
the hands-free system via Bluetooth®.
Pairing code – Many Bluetooth® devices request the
pairing code before establishing the connection. You
can dene it here.
Phone book sync – To be able to access the phone
book of a connected telephone, you must rst syn-
chronise it via this menu entry.
쏅Press to exit the options menu.
Bluetooth mode

18
External audio/video sources
AV-IN socket
This device features an external AV input for audio and
video playback. The AV-IN socket is located under the
cover at the front of the device.
Danger!
Increased risk of injury from connector.
In case of an accident, the protruding connec-
tor in the AV-IN socket may cause injuries. The use of
straight plugs or adapters leads to an increased risk of
injury.
쏅Start the AV-IN mode with the button AV-IN .
The display shows the audio or video playback of the
AV source.
Video input
This device features a video input at the rear of the device
for connecting a camera that is available as an option. If a
camera is connected, you can display the camera image.
쏅In the main menu, press the Camera button.
External audio/video sources | External monitor | Sound settings
External monitor
This device features an output for connecting an external
monitor for the rear area of the vehicle (see Connection
diagram at the end of these instructions).
쏅Select the desired source via the main menu and
start the lm playback, e.g. from a DVD.
The lm is displayed on the monitor of the device.
쏅Call up the main menu.
쏅Press the button.
The lm is also displayed on the external monitor.
Sound settings
Volume distribution (fader/balance)
You can adjust the volume distribution in the vehicle
for all sources.
쏅In the main menu or on the control bar of the current
audio source, press the button.
The equalizer menu is displayed.
쏅Press the button.
The menu for fader and balance is displayed.
쏅Adjust fader and balance with  / or
 / .
쏅Next, press .
The setting is stored, the current source is displayed
again.

19
Sound settings | Basic settings
Equalizer
You can adjust the equalizer for all sources.
쏅In the main menu or on the control bar of the current
audio source, press the button.
The equalizer menu is displayed.
쏅Select a preset equalizer via the buttons.
- Or -
쏅Press the User button to adjust the level of the
available frequency bands according to your prefer-
ences.
Note:
With the [Reset ]button, you can reset the custom-
ised setting again.
- Or -
쏅Press the Flat button for a linear sound playback.
쏅Press the Loudness button to switch increasing
the bass at low volume on or o.
쏅Next, press .
The setting is stored, the current source is displayed
again.
Basic settings
In the settings menu, you can adjust the basic settings
for the dierent functions of the device to your require-
ments.
쏅In the main menu, press the [Settings ]button.
The settings menu is displayed, the General sub-
menu is activated.
쏅Call up the submenus with the buttons in the lower
area of the settings menu.
General
The following settings are possible:
Radio region – Select the reception region for the radio
reception.
Blackout – If this value is set, the display of the radio is
completely switched o after 10 or 20 sec. without use.
Dimmer mode – Adjust the display brightness
Beep – Switch conrmation beep on/o
TFT calibration – The touchscreen can be calibrated
here.
SWC – The buttons of a connected steering wheel con-
trol can be congured here.
Software version – Display of the current software ver-
sion.
Load factory settings – Resets all personalised settings.
Video
The following settings are possible:
Set password – Dene a password if you want to use the
parental controls.
Rating level – The rating of DVDs can be dened here.
If set to "Adult", all movies can be played back. If a pass-
word was congured, the rating level can be changed
only with the password

20
Sound
The following settings are possible:
Subwoofer – Switch subwoofer on/o
Subwoofer lter – Make the setting according to the
subwoofer used (settings: 80/120/160 Hz).
Dynamic sound – Switch dynamic bass on/o
Time
The following settings are possible:
Date – Set the date
Clock mode – Selection between 12 and 24-h mode
Time – Set the time
Auto clock – Switch automatic clock setting on or o
with the time data transmitted via RDS.
Language
The following settings are possible:
OSD – Language for the user interface of the device.
DVD audio – The audio playback of DVDs is started in the
language dened here.
DVD subtitle – The subtitles of DVDs are shown in the
language dened here.
DVD menu – The DVD menu is displayed in the language
dened here.
Bluetooth
The following settings are possible:
Bluetooth – Bluetooth® can be switched on or o.
Auto connect – If "Auto Connect" is activated, the device
automatically connects with known Bluetooth® devices
as soon as they are in range.
Auto answer – Phone calls from connected telephones
are automatically answered if this option is enabled.
Pairing code – Many Bluetooth® devices request the
pairing code before establishing the connection. You can
dene it here.
Microphone – Select the microphone to be used for the
hands-free system via Bluetooth®.
Volume
You can adjust the volume ratio for all audio sources in
the volume menu.
Useful information
Warranty
We provide a manufacturer's warranty for products
bought within the European Union. For devices pur-
chased outside the European Union, the warranty terms
issued by our respective responsible domestic agency
are valid. The warranty terms can be called up from
www.blaupunkt.com.
Service
If you ever need to use a repair service, you will nd in-
formation about service partners in your country under
www.blaupunkt.com.
Subject to technical changes!
Basic settings | Useful information
