PARTS LIST, ELECTRIC COUNTER TILTING SKILLET, MODEL BTT-12E
BLODGETT OVEN CO ▪44 lakeside Ave ▪Burlington, VT 05446
Tel. [phone] ▪Fax [phone] ▪www.blodgett.com
PARTS LIST
ELECTRIC COUNTER TILTING SKILLET
MODEL BTT-12E

PARTS LIST, ELECTRIC COUNTER TILTING SKILLET, MODEL BTT-12E
FIGURE 1
ITEM PART NO. DESCRIPTION QUANTITY
1. 40285 Lift Off Cover 1
2. 42224 Strainer 1
3. 40676 Bottom Cover 1
4. 43499 Screw 10 - 32 x ½ 4
5. 40283 Console Cover, Left Hand 1

ITEM PART NO. DESCRIPTION QUANTITY
6. 40878 Hi Limit 1
7. 40486 Thermostat Bulb Clamp 1
* * 8. 40848 Dial (EF) 1
40849 Dial (EC) 1
9. 40994 Bezel 1
10. 41005 Thermostat 1
11. 40953 Pilot Light 1
12. 41883 Power Switch 1
13. 40072 Screw, 10-32 x 1/2 2
14. 40259 Knob 2
15. 43500 Rest Bar 1
16. 42721 Thermostat Mounting Bracket 1
17. 43501 Bearing 2
18. 43170 Bearing 2
19. 42013 Earth I.D. Tag 1
20. 40840 Ground Lug 1
21. 40282 Console Cover, Right Hand 1
* * 22. 40943 Contactor (208, 220, 240V) 2
40943 Contactor (380, 415, 220/380, 240/415, 480,
600V)
1
23. 42140 Component Mounting Plate 1
** 24. 40708 Terminal Block Section 3
40708 Terminal Block Section (240/415, 220/380V) 4
25. 40707 End Section 1
26. 40099 Hex Nut, 5/16 - 18 32
27. 41840 Bellville Washer 32
28. 43502 Flat Washer, 5/16 x 1" OD 16
29. 41303 Insulation 1
30. 40397 Spacer 16
** 31. 41389 Element Block, 9 kW, 208V 1

ITEM PART NO. DESCRIPTION QUANTITY
41391 Element Block, 9 kW, 220(380)V 1
41390 Element Block, 9 kW, 240(415)V 1
41392 Element Block, 9 kW, 480V 1
41394 Element Block, 9 kW, 347(600)V 1
32. 43292 Acorn Nut 1
33. 40379 Tilt Handle 1
* ** 34. 40974 Transformer, 380-220, 50/60 Hz, 100VA 1
40974 Transformer, 415-220, 50/60 Hz, 100VA 1
40980 Transformer, 480-240, 60 Hz, 100VA 1
40985 Transformer, 600-240, 60 Hz, 100VA 1
* ** 35. 41765 Fuse 1/2 Amp, 600V (380, 415, 480, 600V) 2
* ** 36. 41769 Fuse Holder (380, 415, 480, 600V) 2
* 37. 40536 Faucet Bracket (Optional) 1
38. 40336 Operating Console Decal 1
39. 43503 Left Console Decal 1
*NOT SHOWN.
** SELECT AS REQUIRED.

ALTERNATE PARTS
Page Item Crown Blodgett
3 8 4736-1 43029

38 3174-1 42888
