BLOTZ B06-CS-100 User manual

6mm 3x3 Tower Block Foyer
B06-CS-100
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Foyer (B06-CS-100)
Remove the front piece and its rear support from
the sprue.
Glue the support to the back of the piece using the
holes / lugs provided.
Now remove the rear wall and its rear support
from the sprue.
Glue the support to the back of the piece using the
holes/lugs provided.
Take the two side walls and glue them to the
front piece (with the doors towards the front of
the model). Then attach the rear wall. Allow the
model to dry.
Take the entrance piece from the sprue.

Flip the model upside down and insert the
entrance way piece. The four lugs on it should
slot into the holes provided.
Finally remove the eight decorative strips from the
sprue and attach them to the building using the
lugs/holes provided.

6mm 3x3 Tower Block Middle
B06-CS-150
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Mid-Section (B06-CS-150)
Take two identical wall pieces and the two
support from the sprue. (check the lugs on the
sides of the walls to ensure they are the same).
Glue the one support to the back of each wall as
shown above. Leave them to dry.
Take the four ‘C’ shaped supports from the sprue
and glue each one to the bottom rear of each of
the four wall pieces as shown above. The arms of
the ‘C’ should fit between the lower windows
with the base of the ‘C’ protruding (see next pic)
Glue the four walls together as shown above. It is
easiest to do this if you have the building upside down
as shown. Leave to dry.
Take the twelve decorative strips from the sprue
and attach three to each side of the building as
shown above.

6mm 3x3 Tower Block oof
B06-MW-200
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
oof Section (B06-CS-200)
Remove the four walls and ‘C’ supports from the
sprue. Glue the supports to the back of the walls
as shown above so that they protrude from the
lower edge of the wall.
Glue each wall piece in turn to the roof piece.
Finally glue one of the decorative strips to each
side of the building as shown above.
