Blue Technix CM-BF527 Instructions for use

Hardware User Manual
CM-BF527 v2.x

Blackfin CM-BF527 Hardware User Manual 1
Contact
Bluetechnix Mechatronische Systeme GmbH
Lainzerstraße 162/3
A-1130 Vienna
AUSTRIA/EUROPE
[email protected]
http://www.bluetechnix.com
Document No.: 100-1251-2.2
Document Revision 1
Date: 2010-06-28

Blackfin CM-BF527 Hardware User Manual 2
Table of Contents
BLACKFIN Products ..............................................................................................................................................................................5
BLACKFIN Design Service...................................................................................................................................................................6
1Introduction ..................................................................................................................................................................................7
1.1Overview...............................................................................................................................................................................7
1.2Key Features ........................................................................................................................................................................8
1.3Target Applications...........................................................................................................................................................8
1.4Further Information ..........................................................................................................................................................8
2Specification .................................................................................................................................................................................9
2.1Functional Specification..................................................................................................................................................9
2.2Boot Mode............................................................................................................................................................................9
2.3Memory MAP.................................................................................................................................................................... 10
2.4Electrical Specification .................................................................................................................................................. 11
2.4.1Supply Voltage....................................................................................................................................................... 11
2.4.2Supply Voltage Ripple ......................................................................................................................................... 11
2.4.3On Board Crystal Frequency.............................................................................................................................. 11
2.4.4Real Time Clock Crystal........................................................................................................................................ 11
2.4.5Supply Current ....................................................................................................................................................... 11
2.5Environmental Specification....................................................................................................................................... 11
2.5.1Temperature ........................................................................................................................................................... 11
2.5.2Humidity................................................................................................................................................................... 11
3CM-BF527.................................................................................................................................................................................... 12
3.1Mechanical Outline ........................................................................................................................................................ 12
3.2Footprint............................................................................................................................................................................ 14
3.3Schematic Symbol (Signals of X2 and X3) .............................................................................................................. 15
3.4Connector Pin Assignments........................................................................................................................................ 15
3.4.1Connector X2 – (1-60).......................................................................................................................................... 16
3.4.2Connector X3 – (61-120) ..................................................................................................................................... 17
3.5Reset circuit....................................................................................................................................................................... 19
3.6RJ45 schematic ................................................................................................................................................................ 19
4Software Support ..................................................................................................................................................................... 20
4.1BLACKSheep..................................................................................................................................................................... 20
4.2uClinux ............................................................................................................................................................................... 20
5Application Examples ............................................................................................................................................................. 21
5.1Sample Schematic .......................................................................................................................................................... 21

Blackfin CM-BF527 Hardware User Manual 3
5.2Stand-alone Ethernet based MPEG Webcam........................................................................................................ 22
5.3Design Services................................................................................................................................................................ 23
6Anomalies................................................................................................................................................................................... 24
7Product Changes...................................................................................................................................................................... 25
8Production Report.................................................................................................................................................................... 25
9Document Revision History .................................................................................................................................................. 25
10List of Figures and Tables.................................................................................................................................................. 26

Blackfin CM-BF527 Hardware User Manual 4
© Bluetechnix Mechatronische Systeme GmbH 2010
All Rights Reserved.
The information herein is given to describe certain components and shall not be considered as a
guarantee of characteristics.
Terms of delivery and rights of technical change reserved.
We hereby disclaim any warranties, including but not limited to warranties of non-infringement,
regarding circuits, descriptions and charts stated herein.
Bluetechnix makes and you receive no warranties or conditions, express, implied, statutory or in any
communication with you. Bluetechnix specifically disclaims any implied warranty of merchantability or
fitness for a particular purpose.
Bluetechnix takes no liability for any damages and errors causing of the usage of this board. The user of
this board is responsible by himself for the functionality of his application. He is allowed to use the
board only if he has the qualification. More information is found in the General Terms and Conditions
(AGB).
Information
For further information on technology, delivery terms and conditions and prices please contact
Bluetechnix (http://www.bluetechnix.com).
Warning
Due to technical requirements components may contain dangerous substances.
The Core Modules and development systems
contain ESD (electrostatic discharge) sensitive
devices. Electro-static charges readily
accumulate on the human body and
equipment and can discharge without
detection. Permanent damage may occur on
devices subjected to high-energy discharges.
Proper ESD precautions are recommended to
avoid performance degradation or loss of
functionality. Unused Core Modules and
Development Boards should be stored in the
protective shipping

Blackfin CM-BF527 Hardware User Manual 5
BLACKFIN Products
Core Modules:
TCM-BF518: The new Core Module CM-BF518 is powered by Analog Devices' single core
ADSP-BF518 processor; up to 400MHz, 32MB SDRAM, up to 8MB flash. The
2x60 pin expansion connectors are backwards compatible with other Core
Modules.
CM-BF527: The new Blackfin Processor Module is powered by Analog Devices' single
core ADSP-BF527 processor; key features are USB OTG 2.0 and Ethernet. The
2x60 pin expansion connectors are backwards compatible with other Core
Modules.
CM-BF533: Blackfin Processor Module powered by Analog Devices' single core ADSP-
BF533 processor; up to 600MHz, 32MB SDRAM, 2MB flash, 2x60 pin
expansion connectors and a size of 36.5x31.5mm.
TCM-BF537: Blackfin Processor Module powered by Analog Devices' single core ADSP-
BF537 processor; up to 500MHz, 32MB SDRAM, 8MB flash, a size of
28x28mm, 2x60 pin expansion connectors, Ball Grid Array or Border Pads
for reflow soldering, industrial temperature range -40°C to +85°C.
CM-BF537E: Blackfin Processor Module powered by Analog Devices' single core ADSP-
BF537 processor; up to 600MHz, 32MB SDRAM, 4MB flash, integrated
TP10/100 Ethernet physical transceiver, 2x60 pin expansion connectors and
a size of 36.5x31.5mm.
CM-BF537U: Blackfin Processor Module powered by Analog Devices' single core ADSP-
BF537 processor; up to 600MHz, 32MB SDRAM, 4MB flash, integrated USB
2.0 Device, 2x60 pin expansion connectors and a size of 36.5x31.5mm.
CM-BF548: The new Blackfin Processor Module is powered by Analog Devices' single
core ADSP-BF548 processor; key features are 64MB DDR SD-RAM 2x100 pin
expansion connectors.
CM-BF561: Blackfin Processor Module powered by Analog Devices' dual core ADSP-
BF561 processor; up to 2x 600MHz, 64MB SDRAM, 8MB flash, 2x60 pin
expansion connectors and a size of 36.5x31.5mm.
eCM-BF561: Blackfin Processor Module powered by Analog Devices' dual core ADSP-
BF561 processor; up to 2x 600MHz, 128MB SDRAM, 8MB flash, 2x100 pin
expansion connectors and a size of 44x33mm.

Blackfin CM-BF527 Hardware User Manual 6
Development Boards:
EVAL-BF5xx: Low cost Blackfin processor Evaluation Board with one socket for any
Bluetechnix Blackfin Core Module. Additional interfaces are available, e.g.
an SD-Card.
DEV-BF5xxDA-Lite: Get ready to program and debug Bluetechnix Core Modules with this tiny
development platform including an USB-Based Debug Agent. The DEV-
BF5xxDA-Lite is a low cost starter development system including a VDSP++
Evaluation Software License.
DEV-BF548-Lite: Low-cost development board with one socket for Bluetechnix CM-BF548
Core Module. Additional interfaces are available, e.g. an SD-Card, USB and
Ethernet.
DEV-BF548DA-Lite: Get ready to program and debug Bluetechnix CM-BF548 Core Module with
this tiny development platform including an USB-Based Debug Agent. The
DEV-BF548DA-Lite is a low-cost starter development system including a
VDSP++ Evaluation Software License.
EXT-Boards: The following Extender Boards are available: EXT-BF5xx-AUDIO, EXT-BF5xx-
VIDEO, EXT-BF5xx-CAM, EXT-BF5xx-EXP-TR, EXT-BF5xx-USB-ETH2, EXT-
BF5xx-AD/DA, EXT-BF548-EXP and EXT-BF518-ETH. Furthermore, we offer
the development of customized extender boards for our customers.
Software Support:
BLACKSheep: The BLACKSheep VDK is a multithreaded framework for the Blackfin
processor family from Analog Devices that includes driver support for a
variety of hardware extensions. It is based on the real-time VDK kernel
included within the VDSP++ development environment.
LabVIEW: LabVIEW embedded support for Bluetechnix Core Modules is done by
Schmid-Engineering AG: http://www.schmid-engineering.ch
uClinux: All the Core Modules are fully supported by uClinux. The required boot
loader and uClinux can be downloaded from: http://blackfin.uClinux.org.
Upcoming Products and Software Releases:
Keep up-to-date with all the changes to the Bluetechnix product line and software updates at:
http://www.bluetechnix.com .
BLACKFIN Design Service
Based on more than five years of experience with Blackfin, Bluetechnix offers development assistance as
well as custom design services and software development.

Blackfin CM-BF527 Hardware User Manual 7
1Introduction
The CM-BF527 is a member of Blackfin based core modules incorporating the consumer temperature
version of the ADSP-BF527 (optional also ADSP-BF525 or ADSP-BF522). It is backwards compatible to
the CM-BF537E for most of its interfaces and can be used as a replacement module on any Bluetechnix
development or evaluation Board. A special feature of this module is the on-board 10/100Mbit Ethernet
interface which includes the physical transceiver chip and USB2.0 OTG Interface. The module allows
easy integration into high demanding applications where space and power are very limited.
1.1 Overview
The Core Module CM-BF527 consists of the following components:
32 MByte
SDRam
60 Pin Expansion Connector A
USB2.0
OTG on
BF527
BF527
600 MHz
Dynamic
Core Voltage
Control
60 Pin Expansion Connector B
Low Voltage
Reset Ethernet
Physical
8MByte
Flash
Figure 1-1: Main components of the CM-BF527 Core Module
Analog Devices Blackfin Processor ADSP-BF527
oADSP-BF527KBCZ with 525MHz
(* please see chapter8 for the correct part number)
32 MB SDRAM
oSDRAM Clock up to 133MHz
oMT48LC16M16A2BG-7 (16Mx16, 256Mbit at 3.3 V)
8 MB of Byte Addressable Flash
oPF48F2000P0ZBQ0 (4Mx16, 64Mbit at 3.3V; addressable by 4 banks, 2Mb each,
controlled over GPIOs)
oAdditional flash memory can be connected through the expansion board as parallel
Flash using asynchronous chip select lines or as a SPI flash.
Low Voltage Reset Circuit
oResets module if power supply goes below 2.93 V for at least 140 ms

Blackfin CM-BF527 Hardware User Manual 8
Dynamic Core Voltage Control
oAllows adjusting of the core voltage by setting software registers on the Blackfin
processor
oCore voltage range: 0.8 – 1.2V
Expansion Connector A
oData Bus
oAddress Bus
oControl Signals
oUSB2.0 OTG
oEthernet Pins
Expansion Connector B
oPG (0..15) SPI, UART, SPORT, GPIO
oJTAG
oTWI (I2C compatible)
oPower
oPPI (Parallel Port Interface) , SPORT
oBoot Mode
oGPIO’s
1.2 Key Features
The CM-BF527 is a low cost compact core module and measures only 36x31mm
Allows quick prototyping of product that comes very close to the final design
Reduces development costs, faster time to market
Very cost effective for small and medium volumes
1.3 Target Applications
Mobile Embedded Device
Generic high performance signal processor module
Internet Connected Embedded System
Industrial Control
1.4 Further Information
Further information, and document updates are available on the product homepage:
http://www.bluetechnix.com/goto/cm-bf527

Blackfin CM-BF527 Hardware User Manual 9
2Specification
2.1 Functional Specification
32 MByte
SDRam 8MByte Flash
BF527
up to
600MHz
Dynamic
Core Voltage
Control
Low Voltage
Reset
20 Bit Address Bus
16 Bit Data Bus
Ethernet
Physical
Clock
Mem. Control, Ethernet, USB2.0 OTG
Data & Address Bus
Clock-out Boot Mode, JTAG, PPI, SPORT, UART, SPI, TWI,
GPIO
3V3 Power , Reset
Figure 2-1: Detailed Block Diagram
Figure 2-1 shows a detailed block diagram of the CM-BF527 module. Besides the SDRAM control pins
and the Pins used by the Ethernet Physical Transceiver (Port H) the CM-BF527 has all other pins of the
Blackfin processor on its two main 60 pin connectors.
A special feature of the CM-BF527 Core Module is the on-board physical Ethernet transceiver from
Micrel (KSZ8041BL).
Dynamic voltage control allows reduction of power consumption to a minimum adjusting the core
voltage and the clock frequency dynamically in accordance to the required processing power. A low
voltage reset circuit guarantees a power on reset and resets the system when the input voltage drops
below 2.93V.
2.2 Boot Mode
By default the boot mode = 0000 (BMODE3 = low, BMODE2 = low, BMODE1 = low, BMODE0 = low). All
BMODE pins have internal pull down resistors.

Blackfin CM-BF527 Hardware User Manual 10
SwitchSettings
BM3,BM2,BM1,BM0
BootModeDescription
00000(default) Idle‐ NobootReserved
00011 Bootfrom8‐or16‐bitexternalflashmemory
00102Bootfrom16‐bitasynchronousFIFO.
00113BootfromserialSPImemory(EEPROMorflash)
01004BootfromSPIhostdevice
01015BootfromserialTWImemory(EEPROM/flash)
01106BootfromTWIhost
01117BootfromUART0Host
10008BootfromUART1Host
10019Reserved
101010BootfromSDRAM
101111BootfromOTPmemory
110012Bootfrom8‐bitNANDflash viaNFCusingPORTFdatapins
110113Bootfrom8‐bitNANDflash viaNFCusingPORTHdatapins
111014Bootfrom16‐BitHostDMA
111115Bootfrom8‐BitHostDMA
Table 2-1: Boot Mode CM-BF527
Connect BMODE0 to Vcc and leave BMODE1, BMODE2 and BMODE3 pins open for Boot Mode 0001
equals to 8 or 16 bit PROM/FLASH boot mode. This is the default boot mode of the BLACKSheep
software and uClinux.
Note: Boot Modes 8-15 are not supported with the DEV-BF5xx-DALite or EVAL-BF5xx
2.3 Memory MAP
MemoryTypeStartAddress EndAddressSizeComment
FLASH1)
PH9FlagLow
PG11FlagLow
0x200000000x201FFFFF 2MB ¼of8MBFlash,
PF48F2000P0ZBQ0S
FLASH1)
PH9FlagHigh
PG11FlagLow
0x200000000x201FFFFF 2MB ¼of8MBFlash,
PF48F2000P0ZBQ0S
FLASH1)
PH9FlagLow
PG11FlagHigh
0x200000000x201FFFFF 2MB ¼of8MBFlash,
PF48F2000P0ZBQ0S
FLASH1)
PH9FlagHigh
PG11FlagHigh
0x200000000x201FFFFF 2MB ¼of8MBFlash,
PF48F2000P0ZBQ0S
SD‐RAM0x000000000x01FFFFFF 32MB 16BitBus,Micron
MT48LC16M16A2FG
Table 2-2: Memory Map
*)Please be aware that you have to unlock the flash before starting an erase process!
The maximum amount of memory addressable by a single asynchronous memory bank, of the Blackfin
processor is 2MB. In order to be able to use more than 2MB on a single bank, 2 GPIOs are used to select
which 2MB section of flash is visible in the memory window of the Blackfin processor. This frees up the
remaining banks for the user.

Blackfin CM-BF527 Hardware User Manual 11
Please do not use the PH9 and PG11 pins as IO flags. You should leave these Pins disconnected! If one or
both IO pins are needed and 4MB or 2 MB flash memory is sufficient for your application, remove the 0Ω
resistors R26 and R19 from your Core Module. The flash address lines A20 and A21 are pulled Low.
To access more than 8MB flash memory (64MB) you can add the 0Ω resistor array R2. But be aware to
not connect the IO pins PG10, PG9 and PG1.
FlashAddressPin BlackfinFlagCMPinNumber
A20PH9 55
A21PG11 8
A22PG10 54
A23PG97
A24PG1 39
Figure 2-2: IO pin to flash address pin assignment
2.4 Electrical Specification
2.4.1 Supply Voltage
3.3V DC +/-10%
2.4.2 Supply Voltage Ripple
100mV peak to peak 0-20 MHz
2.4.3 On Board Crystal Frequency
24 MHz: USB Clock
50 MHz: Blackfin Clock
2.4.4 Real Time Clock Crystal
32.768kHz
2.4.5 Supply Current
Maximum current: 350mA @3.3V
Typical operating conditions:
oProcessor running at 600MHz, Core Voltage 1.2V, SDRAM 20% bandwidth utilization at
130MHz; Ethernet idle: 200mA @ 3.3V
oProcessor running at 300MHz, Core Voltage 0.8V SDRAM 20% bandwidth utilization at
130MHz; Ethernet idle: TBD
oProcessor running at 600MHz, Core Voltage 1.2V, SDRAM 20% bandwidth utilization at
130MHz, Ethernet TX/RX active: TBD
2.5 Environmental Specification
2.5.1 Temperature
Operating at full 600MHz: 0 to + 70° C
2.5.2 Humidity
Operating: 10% to 90% (non condensing)

Blackfin CM-BF527 Hardware User Manual 12
3CM-BF527
3.1 Mechanical Outline
TOP VIEW
All dimensions are given in millimeters!
Figure 3-1: Mechanical outline and Components on top side
Take 0.5mm as a tolerance for the boarder of the board since it is broken out from a multi-board panel
and some additional boarder may remain.
The module is shipped with two 60pin connectors.
h2
h1
21
21
25
26
1
2
12
2
1
1
2
12
21
21
21
Hole1 Hole2
Hole1 Hole2
4
21
3
21
21
2 1
2 1
21
1 2
21
2 1 2 1
2
1
21
12
2
1
21
2
1
21
1 2
2
1
2 1
1
2
2
1
21
2
1
2
1
2
1
2
1
1
2
4
3
5 6
12
1
2
3
0
21
2
1
2
1
2 1
2
1
2
1
21
2 1
2 1
2
1
2
1
21
2
1
2 1
2 1
2 1
21
2
1
2
1
2
1
2
1
2 1
2
1
2
1
2
1
2
1
2
1
1
2
12
2
1
2 1
2
1
2
1
21
2
1
212 1
1
2
1 2
2 1
1 2
2
1
21
21
21
41
2 3
2
1
21
21
12
2 1
2
1
41
2 3
2 1
2
1
21
2 1

Blackfin CM-BF527 Hardware User Manual 13
Figure 3-2: Side View with Connector mounted, 0.5mm tolerances
The total minimum mounting height including receptacle at the motherboard is 6.1mm.
Figure 3-3 shows the TOP VIEW of the bottom placed connectors (through the Board View) of the CM-
BF527 Core Module. All dimensions are given in millimeters!
Figure 3-3: Mechanical outline and Bottom Connectors (top view)
The mechanical outline represents a TOP VIEW of the connectors placed at the bottom of the core board.

Blackfin CM-BF527 Hardware User Manual 14
Note the additional connector X1 (FFC-20) is not supported yet and used for AUDIO functionality in
future revisions with the –C variant of the ADSP-BF527 Chip. X1 is not described in this document any
further.
The connectors on the CM-BF527 are of the following type:
PartManufacturerManufacturerPartNo.
X2,X3Hirose3mmheight FX8‐60P‐SV
Table 3-1: Module connector types
3.2 Footprint
For the baseboard the following connectors have to be used.
PartBaseboardManufacturerManufacturerPartNo.
X2,X3matingHiroseFX8‐60S‐SV
Table 3-2: Baseboard connector types
The footprint of the baseboard may look as shown in Figure 3-4.
Figure 3-4: Recommended footprint of the Core Module (top view)
If there is no need to affix the Core Module, then you may omit the two M2 screwing holes.

Blackfin CM-BF527 Hardware User Manual 15
3.3 Schematic Symbol (Signals of X2 and X3)
PH13/ND_BUSY/ERxCLK/HOST_D13
3
PH15/ND_ALE/COL/HOST_D15
4
Vin 3V3
9
Vin 3V3
10
PF0/PPI D0/DR0PRI /ND_D0A
11
PF2/PPI D2/RSCLK0/ND_D2A
12
PF4/PPI D4/TFS0/ND_D4A/TACLK0
13
PF6/PPI D6/DT0SEC/ND_D6A/TACI0
14
PF8/PPI D8/DR1PRI
15
PF10/PPI D10/RFS1/SPI SEL7
16
PF12/PPID12/DT1PRI/SPISEL2/CDG
17
PF14/PPI D14/DT1SEC/UART1TX
18
PG6/DT0PRIA/TMR2/PPIFS3
19
PPIFS1/TMR0
20
PPIFS1/TMR0
21
PG13/DMAR0/UART1RXA/H_ADR
22
PG8/TMR4/RFS0A/UART0RX/TACI4
23
PG4/SPI MOSI/DT0SECA
24
PG2/SPISCK
25
Bmode0
26
GND
27
TCK
28
TDI
29
TRST
30
EMU
31
TMS
32
TDO
33
Bmode2
34
Bmode3
35
Bmode1
36
PG3/SPI MISO/DR0SECA
37
PG7/TMR3/DR0PRIA/UART0TX
38
PG1/SPISS/SPISEL1
39
PG12/DMAR1/UART1TXA/H_ACK
40
PPIClk/TMRCLK
41
PG5/TMR1/PPIFS2
42
PF15/PPID15/DR1SEC/UART1RX
43
PF13/PPID13/TSCLK1/SPISEL3/CUD
44
PF11/PPI D11/TFS1/CZM
45
PF9/PPI D9/RSCLK1/SPI SEL6
46
PF7/PPI D7/DR0SEC/ND_D7A/TACI1
47
PF5/PPI D5/TSCLK0/ND_D5A/TACLK1
48
PF3/PPI D3/DT0PRI/ND_D3A
49
PF1/PPI D1/RFS0/ND_D1A
50
GND
51
GND
52
PG0/HWAIT
57
PH14/ND_CLE/ERxDV/HOST_D14
58
A1 61
A3 62
A5 63
A7 64
A9 65
A11 66
A13 67
A15 68
A17 69
A19 70
GND 79
AMS3 80
AWE 81
NMI 82
D0 83
D2 84
D4 85
D6 86
D8 87
D10 88
D12 89
D14 90
D15 91
D13 92
D11 93
D9 94
D7 95
D5 96
D3 97
D1 98
RESET 99
AOE 100
ARE 101
AMS2 102
A18 112
A16 113
A14 114
A12 115
A10 116
A8 117
A6 118
A4 119
A2 120
CM-BF527
CLK_out
5
SDA
6
PG9/TMR5/RSCLK0A/TACI5
7
PG11/TMR7/HOST_WR
8PG10/TMR6/TSCLK0A/TACI6
54
PH9/SPISEL5/ETxD2/HOST_D9/TACLK3
55
SCL
56
SCLK 78
ABE1 71
ABE0 111
USBD- 104
USBD+ 77
USB_OTG_ID 105
ARDY 76
VDD-RTC 103
VA25 106
TX- 107
TX+ 108
LED_FD 109
LED_SPEED 110
LED_ACT 72
GND 73
RX+ 74
RX- 75
USB_VBUS
53
VppOTP
1
PH10/ND_CE/ERxD2/HOST_D10
60
PH11/ND_WE/ETxD3/HOST_D11
2
PH12/ND_RE/ERxD3/HOST_D12
59
CM‐BF527
U?
Figure 3-5: Schematic Symbol of Module
Note: For compatibility, some pin names appear twice on the connector. X1 is not supported yet and
not shown in the symbol.
3.4 Connector Pin Assignments
In the following tables you will find pin assignments for the Core Module connectors. Most pins are
directly connected to the Blackfin processor. If not, please read the Notes below the table.

Blackfin CM-BF527 Hardware User Manual 16
3.4.1 Connector X2 – (1-60)
Please mind the mounted pull up and pull down resistors on the Core Module. See the third column of
Table 3-3.
Pin
No.
SignalNameSignaltype
1VppOTPPower1)
2PH11/ND_WE/ETxD3/HOST_D11 IO
3PH13/ND_BUSY/ERxCLK/HOST_D13 IO
4PH15/ND_ALE/COL/HOST_D15 IO
5CLKBUFIO
6SDA IO
7PG9/RSCLK0A/TMR5/TACI5 IO
8DNU2)orPG11/TMR7/HOST_WR
ˉ
ˉˉˉˉˉˉˉˉ IO
–
10kpulldown
9Vin3V3Power
10Vin3V3Power
11PF0/PPID0/DR0PRI/ND_D0A IO
12PF2/PPID2/RSCLK0/ND_D2A IO
13PF4/PPID4/TFS0/ND_D4A/TACLK0 IO
14PF6/PPID6/DT0SEC/ND_D6A/TACI0 IO
15PF8/PPID8/DR1PRI IO
16PF10/PPID10/RFS1/SPISEL7
ˉ
ˉˉˉˉˉˉˉ IO
17PF12/PPID12/DT1PRI/SPISEL2
ˉ
ˉˉˉˉˉˉˉ /CDG IO
18PF14/PPID14/DT1SEC/UART1TX IO
19PG6/DT0PRIA/TMR2/PPIFS3 IO
20PPIFS1/TMR0IO
21PPIFS1/TMR0IO
22PG13/DMAR0/UART1RXA/H_ADR/TACI2 IO
23PG8/TMR4/RFS0A/UART0RX/TACI4 IO
24PG4/SPIMOSI/DT0SECA IO
25PG2/SPISCKIO
26Bmode0I‐10kpulldown
27GND Power
28TCK I‐10kpullup
29TDII‐10kpullup
30TRS
T
ˉˉˉˉˉ I‐4k7pulldown
31EMUˉˉˉˉ O
32TMS I
–
10kpullup
33TDO O
34Bmode2I‐10kpulldown
35Bmode3I‐10kpulldown
36Bmode1I‐10kpulldown
37PG3/SPIMISO/DR0SECA IO
38PG7/TMR3/DR0PRIA/UART0TX IO
39PG1/SPISSˉˉˉˉˉ /SPISEL1ˉˉˉˉˉˉˉˉ IO
40PG12/DMAR1/UART1TXA/H_ACK IO
41PPICLK/TMRCLKIO
42PG5/TMR1/PPIFS2IO

Blackfin CM-BF527 Hardware User Manual 17
43PF15/PPID15/DR1SEC/UART1RX/TACI3 IO
44PF13/PPID13/TSCLK1/SPISEL3
ˉ
ˉˉˉˉˉˉˉ /CUD IO
45PF11/PPID11/TFS1/CZM IO
46PF9/PPID9/RSCLK1/SPISEL6
ˉ
ˉˉˉˉˉˉˉ IO
47PF7/PPID7/DR0SEC/ND_D7A/TACI1 IO
48PF5/PPID5/TSCLK0/ND_D5A/TACLK1 IO
49PF3/PPID3/DT0PRI/ND_D3A IO
50PF1/PPID1/RFS0/ND_D1A IO
51GND Power
52GND Power
53USB_VBUSI/O
54PG10/TMR6/TSCLK0A/TACI6 IO
55DNU2)orPH9/SPISEL5ˉˉˉˉˉˉˉˉ/ETxD2/HOST_D9/TACLK3 IO
–
10kpulldown
56SCL O
57PG0/HWAI
T
IO
58PH14/ND_CLE/ERxDV/HOST_D14 IO
59PH12/ND_RE/ERxD3/HOST_D12 IO
60PH10/ND_CE/ERxD2/HOST_D10 IO
Table 3-3: Connector X2 pin assignment
1) Internally connected to 2.5V. If you want to program the OTP memory, just power this pin with 7.0V.
2) These IO pins are normally used to access more flash memory. They should not be used as general
purpose IO pins. For more information please see chapter 2.3.
3.4.2 Connector X3 – (61-120)
Please mind the mounted pull up and pull down resistors on the Core Module. See the third column of
Table 3-4.
PinNo.SignalNameSignaltype
61A1 O
62A3 O
63A5 O
64A7 O
65A9 O
66A11O
67A13O
68A15O
69A17O
70A19O
71ABE1ˉˉˉˉ  O
72LED_AC
T
IO
73GNDPower
74RX+IO
–
49R9pullupto2V5
75RX‐IO
–
49R9pullupto2V5
76ARDYI
77USBD+I/O
78SCLKO

Blackfin CM-BF527 Hardware User Manual 18
79GNDPower
80AMS3ˉˉˉˉ  O
81AWEˉˉˉ  O
82NMIˉˉˉ  I‐10kpullup
83D0 IO
84D2 IO
85D4 IO
86D6 IO
87D8 IO
88D10IO
89D12IO
90D14IO
91D15IO
92D13IO
93D11IO
94D9 IO
95D7 IO
96D5 IO
97D3 IO
98D1 IO
99RESE
T
ˉˉˉˉˉ  I/Oseechapter3.5
100AOEˉˉˉ  O
101AREˉˉˉ  O
102AMS2ˉˉˉˉ  O
103VDD‐RTCPower
104USBD‐ I/O
105USB_OTG_IDI
106VA25PowerOut
107TX‐IO
–
49R9pullupto2V5
108TX+IO
–
49R9pullupto2V5
109LED_FDIO
110LED_SPEEDIO
111ABE0ˉˉˉˉ  O
112A18O
113A16O
114A14O
115A12O
116A10O
117A8 O
118A6 O
119A4 O
120A2 O
Table 3-4: Connector X3 pin assignment

Blackfin CM-BF527 Hardware User Manual 19
3.5 Reset circuit
The reset of the flash and the processor are connected to a power monitoring IC. The output can be
used as power on reset for external devices, see Figure 3-6.
Figure 3-6: Schematic of reset circuit on the Core Module
3.6 RJ45 schematic
The KSZ8721BLI is connected via the RMII to the processor.
Figure 3-7: Schematic for RJ45 Connection
DesignatorValueTypeDescriptionQuantity
X1RJLBC‐060TC1 RJ45withtransformer1
R4,R527RResistor 2
R8,R9220RResistor 2
V1,V2USBLC6‐2P6 TSV‐Diode 2
Table 3-5: Parts List RJ45
3.3V
RESET
470R
R12
GND
1
VDD
3
RESET 2
TCM809SENB713
U5
RESET of ADSP-BF5xx
GND
99
RESET of Flash
CoreModule
Exte rnal
LED_SPEED
LED_ACT
Rx+
Rx‐
Tx‐
Tx+
49R9
R2
49R9
R3
49R9
R7 49R9
R6
xRx+
xRx‐
xTx‐
xTx+
220R
R8
220R
R9
3V3
GND
GND
GND
3V3
3
Td-
2
Rd-
8
Td+
1
14 13
Rd+
7
9
11
10
12
RJ451:1LED
X1
1
3
25
4
6
D‐TVS‐USB2.0
V1
1
3
2 5
4
6
D‐TVS‐USB2.0
V2
GND
GND2.5V_VA
2.5V_VA
GND
10u
C1
0R
R1
CoreModule External
RJLBC-060TC1
Taimag
75
76
107
108
110
72
REXT 10
GND1
VddIO
17 GND0
LED1/SPEED 31
VddPLL
2
LED0/WAYEN 30
XO 8
REFCLK / XI 9
RESET 32
MDIO
11 MDC
12
RxD3/PHYAD0
13
RxD2/PHYAD1
14
RxD1/PHYAD2
15
RxD0/DUPLEX
16
Rx_DV/CRSDV/CONFIG2
18
Rx_CLK
19
Rx_ER/ISO
20
Tx_CLK
22 Tx_EN
23 TxD0
24 TxD1
25 TxD2
26 TxD3
27
INT_P 21
COL/CONFIG0
28 CRS/CONFIG1
29
Tx- 6
Tx+ 7
Rx- 4
Rx+ 5
VddA
3
KSZ8041NL
U?
3.3V_A_PHY
3.3V_A_PHY
3.3V_A_PHY
3.3V_A_PHY
106
100R
