CA Series PC/104 Multiport Serial Module
User’s Manual
www.moxa.com/product
Third Edition, May 2007
Moxa Technologies Co., Ltd.
Tel: [phone]
Fax: [phone]
Web: www.moxa.com
Moxa Technical Support
Worldwide: suppor[email protected]
The Americas [e-mail]

CA Series PC/104 Multiport Serial Module
User’s Manual
The software described in this manual is furnished under a license agreement and may be used only in
accordance with the terms of that agreement.
Copyright Notice
Copyright ©2007 Moxa Technologies Co., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Trademarks
Moxa is a registered trademark of the Moxa Group.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the
part of MOXA.
MOXA provides this document “as is,” without warranty of any kind, either expressed or implied, including, but
not limited to, its particular purpose. MOXA reserves the right to make improvements and/or changes to this
manual, or to the products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, MOXA assumes no
responsibility for its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the
publication.

Table of Contents
Chapter 1 Introduction ...............................................................................................1-1
Overview .............................................................................................................................. 1-2
Package Checklist................................................................................................................. 1-2
Product Features ................................................................................................................... 1-2
Product Specifications ..........................................................................................................1-3
Chapter 2 Hardware Installation ................................................................................2-1
Hardware Installation ...........................................................................................................2-2
Block Diagrams.................................................................................................................... 2-2
I/O Base Address .......................................................................................................... 2-4
Interrupt Vector ............................................................................................................ 2-5
Serial Interface.............................................................................................................. 2-5
IRQ ............................................................................................................................... 2-5
Chapter 3 Software Installation .................................................................................3-1
Windows Vista (32-bit)......................................................................................................... 3-2
Installing the Driver...................................................................................................... 3-2
Using Device Manager to Verify Installation............................................................. 3-11
Port Configuration ...................................................................................................... 3-12
Windows XP, 2003 (32-bit) ................................................................................................ 3-14
Installing the Driver.................................................................................................... 3-14
Using Device Manager to Verify Installation............................................................. 3-22
Port Configuration ...................................................................................................... 3-24
Using PComm............................................................................................................. 3-25
Using Event Log......................................................................................................... 3-25
Disabling the Module ................................................................................................. 3-26
Uninstalling the Module ............................................................................................. 3-27
Windows 2000....................................................................................................................3-29
Installing the Driver.................................................................................................... 3-29
Using Device Manager to Verify Installation............................................................. 3-38
Port Configuration ...................................................................................................... 3-40
Using PComm............................................................................................................. 3-41
Using Event Log......................................................................................................... 3-41
Disabling the Module ................................................................................................. 3-42
Uninstalling the Module ............................................................................................. 3-42
Windows NT....................................................................................................................... 3-45
Installing the Driver.................................................................................................... 3-45
Uninstalling the Module ............................................................................................. 3-49
Windows 95, 98, ME .......................................................................................................... 3-50
Installing the Driver.................................................................................................... 3-50
Uninstalling the Module ............................................................................................. 3-53
Linux .................................................................................................................................. 3-55
DOS.................................................................................................................................... 3-56
Installing the Driver.................................................................................................... 3-56
Driver Setup................................................................................................................ 3-57
Loading the Driver...................................................................................................... 3-59
Unloading the Driver .................................................................................................. 3-59

Chapter 4 Serial Programming Tools........................................................................4-1
Serial Programming Library................................................................................................. 4-2
PComm Utilities ................................................................................................................... 4-2
Installation ....................................................................................................................4-2
PComm Diagnostic....................................................................................................... 4-2
PComm Monitor ........................................................................................................... 4-3
PComm Terminal Emulator.......................................................................................... 4-4
Chapter 5 Pin Assignments .......................................................................................5-1
Box Header Pin Assignments ............................................................................................... 5-1
RS-232..........................................................................................................................5-1
RS-422, 4-wire RS-485 ................................................................................................ 5-1
2-wire RS-485............................................................................................................... 5-2
Serial Cable Pin Assignments............................................................................................... 5-2
DB9(M) Connectors ..................................................................................................... 5-2
DB25(M) Connectors ................................................................................................... 5-3
Appendix A Service Information.................................................................................. A-1
MOXA Internet Services ..................................................................................................... A-2
Problem Report Form .......................................................................................................... A-3
Product Return Procedure.................................................................................................... A-4

1
1
Chapter 1Introduction
Welcome to the CA Series of PC/104 communication modules, a multiport serial module for
industrial applications. It is designed for PC/104 CPU boards that accept the PC/104 expansion
interface. Optional DB9 and DB25 cables are available to connect different devices. The device
drivers make full use of the 64-byte Tx/Rx FIFO and on-chip flow control, which allows up to
921.6 Kbps data transmission.
The CA Series includes the following models:
CA-108: 8 ports, RS-232
CA-108-T: 8 ports, RS-232, wide temperature
CA-114: 4 ports, RS-232/422/485
CA-114-T: 4 ports, RS-232/422/485, wide temperature
CA-134I: 4 ports, RS-422/485, optical isolation protection
CA-134I-T: 4 ports, RS-422/485, optical isolation protection, wide temperature
CA-104 V2: 4 ports, RS-232
CA-104-T V2: 4 ports, RS-232, wide temperature
CA-132 V2: 2 ports, RS-422/485
CA-132-T V2: 2 ports, RS-422/485, wide temperature
CA-132I V2: 2 ports, RS-422/485, optical isolation protection
CA-132I-T V2: 2 ports, RS-422/485, optical isolation protection, wide temperature
2 KV optical isolation is provided on optical isolation models. Wide temperature models are rated
for operation between -40 to 85°C.
The following topics are covered in this chapter:
Overview
Package Checklist
Product Features
Product Specifications

CA Series User’s Manual Introduction
1-2
Overview
The CA Series PC/104 module is designed to be used with PC/104 CPU modules or CPU cards
with the PC/104 expansion interface. Models are available for RS-232, RS-422, and RS-485, with
2, 4, or 8 ports. The serial ports are accessed through a 20 or 40-pin box header connector on the
module. DIP switches allow you to configure the I/O base address and INT vector of each port.
The industry-standard MOXA UART (16C550 compatible) is fully programmable. Built-in 15 KV
ESD protection protects devices connected to the serial network.
Package Checklist
MOXA performs a careful mechanical and electrical inspection of each module prior to shipping.
Your module should arrive in perfect electrical order, free of any marks or scratches. Please handle
the module by the edges only, since your body’s static charge can damage the integrated circuits.
When the module is not in use, please keep it in the anti-static package provided. You may also
use this package to return the module if it requires repair.
The CA Series module is shipped with the following items:
yCA Series PC/104 multiport serial module
yDocumentation and Software CD
yQuick Installation Guide
y5-year product warranty statement
Note: Please notify your sales representative if any of the above items are missing or damaged.
Product Features
The CA Series module features the following:
y2, 4, or 8 serial ports (depending on model)
yRS-232, RS-422, or RS-485 operation (depending on model)
y64-byte FIFOs and on-chip flow control
yUp to 921.6Kbps data transmission speed
yBuilt-in 15 KV ESD protection
yConfigurable IRQ and I/O settings
yOnboard Tx, Rx LED indicators for each port
yOptional wide temperature support (-40 to 85°C)

CA Series User’s Manual Introduction
1-3
Product Specifications
CA Series PC/104 Multiport Serial Module
Hardware
I/O controller 16C550C or compatible
Connector Type 40-pin box header (CA-108, CA-114, CA-134I, CA-104 V2)
20-pin box header (CA-132 V2, CA-132I V2)
Interface
Bus PC/104 bus (Ver. 2.4)
No. of Ports 2 ports (CA-132 V2, CA-132I V2)
4 ports (CA-114, CA-134I, CA-104 V2)
8 ports (CA-108)
Max. No. of Modules 4
Signals
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
4-wire RS-485 TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
2-wire RS-485 Data+(B), Data-(A), GND
Performance
Baudrate 50 bps to 921.6 Kbps
Configuration
Parity None, Even, Odd, Space, Mark
Data Bits 5, 6, 7, 8
Stop Bit(s) 1, 1.5, 2
IRQ Shared IRQ for all ports
(includes IRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 15)
FIFO 64 bytes
Additional Settings I/O base address, interrupt vector, serial interface (all by DIP
switch)
Driver Support DOS
Windows 2000, XP, 2003, Vista
Linux 2.4, Linux 2.6
Power and Environment
Operating Temperature Standard models: 0 to 55°C (32 to 131°F)
“-T” models:, -40 to 85°C (-40 to 185°F)
Operating Humidity 5 to 95% RH
Storage Temperature -40 to 70°C (-40 to 158°F)
ESD Protection Embedded 15 KV ESD protection

CA Series User’s Manual Introduction
1-4
Other
Dimensions (W x D) 96 x 90 mm
Regulatory Approvals EN55022 Class A, EN55024, EN6100-3-2, EN61000-3-3, FCC
Part 15 Class A
Warranty 5 years

2
2
Chapter 2Hardware Installation
This chapter explains how to install the CA Series PC/104 multiport serial module.
The following topics are covered:
Hardware Installation
Block Diagrams
¾I/O Base Address
¾Interrupt Vector
¾Serial Interface
¾IRQ

CA Series User’s Manual Hardware Installation
2-2
Hardware Installation
Installing the CA Series module is easy. Before inserting the module into the PC/104 slot, you
must first configure the I/O base address, interrupt vector, IRQ, and serial interface (for select
models).
ATTENTION
Safety First!
To prevent damage to your system or board, make sure your embedded PC’s power is turned off
before installing your CA Series module.
Step 1: Shut off power to your embedded PC and to any peripheral devices. After shutting off
power, remove the cover of your embedded PC.
Step 2: Use the DIP switches on the module to select I/O base address, interrupt vector, IRQ, and
serial interface (for select models). Details for each model are provided later in this
chapter.
Step 3: Insert the module firmly into the embedded PC’s PC/104 slot.
Step 4: Screw the control board in place.
Step 5: Connect the cables.
Step 6: Power on the embedded PC.
Block Diagrams
CA-108
SW2: Interrupt Vector
SW1: I/O Base Address
Box Header Connector
PC/104 Slot

CA Series User’s Manual Hardware Installation
2-3
CA-114
SW3
SW4 Serial Interface
SW5
SW1: I/O Base Address
SW2: Interrupt Vector
PC/104 Slot
Box Header Connector
CA-134I, CA-132 V2, CA-132I V2
RS-422/RS-485
2-WIRE/4-WIRE
SW1: I/O Base Address
SW2: Interrupt Vector
PC/104 Slot
Box Header Connector
20-pin for CA-132 V2, CA-132I V2
40-pin for CA-134I
CA-104 V2
SW2: Interrupt Vector
SW1: I/O Base Address
Box Header Connector
PC/104 Slot

CA Series User’s Manual Hardware Installation
2-4
I/O Base Address
Use DIP switch SW1 to set port 1’s I/O base address. The other ports will be configured
automatically. The default I/O base address is 0×180 and allows settings from 0×000 to 0×3FF.
Some popular settings are provided below:
A3 A4 A5 A6 A7 A8 A9
8 1 2 4 8 1 2 Hex
ON ON ON ON ON ON ON 0×000
ON ON ON ON ON ON off 0×200
ON ON ON ON ON off off 0×300
ON ON ON ON off off off 0×380
ON ON ON off off off off 0×3C0
ON ON off off off off off 0×3E0
ON off off off off off off 0×3F0
off off off off off off off 0×3F8
off ON ON ON ON ON ON 0×008
off off ON ON ON ON ON 0×018
off off off ON ON ON ON 0×038
off off off off ON ON ON 0×078
off off off off off ON ON 0×0F8
off off off off off off ON 0×2F8
For example, an I/O base address of 0×180 should be set as follows:
A3 A4 A5 A6 A7 A8 A9 Hex
ON ON ON ON off off ON 0×180
ON DIP
1234567
A3 A4 A5 A6 A7 A8 A9
081
= on, = off
The other serial ports will be set automatically to 0×188, 0×190, 0×198, etc.

CA Series User’s Manual Hardware Installation
2-5
Interrupt Vector
Use DIP switch SW2 to set port 1’s interrupt vector. The default interrupt vector is 0×1C0, with
SW2 set as follows:
A3 A4 A5 A6 A7 A8 A9 Hex
ON ON ON off off off ON 0×1C0
ON DIP
1234567
A3 A4 A
5
A6 A
7
A8 A9
01C
= on, = off
Serial Interface
For the CA-114, use S3, S4, and S5 to select the serial interface as follows:
Mode S3 S4 S5
RS-232 --- --- ON
RS-422 --- ON off
4-wire RS-485 ON off off
2-wire RS-485 off off off
For the CA-134I, CA-132 V2, and CA-132I V2, use the 2-WIRE/4-WIRE and RS-422/RS-485
DIP switches to select the serial interface as follows:
Interface 2-WIRE/4-WIRE RS422/RS485
RS-422 --- OFF
4-wire RS-485 OFF ON
2-wire RS-485 ON ON
IRQ
Before selecting an IRQ, please enter the PC’s BIOS and reserve a dedicated IRQ for the module.
On the module, the IRQ is set by a jumper. Before inserting the module into the PC/104 slot, use
the jumper to select an IRQ (3, 4, 5, 6, 7, 9, 10, 11, 12, or 15).

3
3
Chapter 3Software Installation
After installing the CA Series module in your embedded computer, the next step is installing the
software. Drivers for various operating systems are provided, including DOS, Windows, and
Linux. This chapter explains how to install and remove the CA Series driver.
The following topics are covered in this chapter:
Windows Vista (32-bit)
¾Installing the Driver
¾Using Device Manager to Verify
Installation
¾Port Configuration
Windows XP, 2003 (32-bit)
¾Installing the Driver
¾Using Device Manager to Verify
Installation
¾Port Configuration
¾Using PComm
¾Using Event Log
¾Disabling the Module
¾Uninstalling the Module
Windows 2000
¾Installing the Driver
¾Using Device Manager to Verify
Installation
¾Port Configuration
¾Using PComm
¾Using Event Log
¾Disabling the Module
¾Uninstalling the Module
Windows NT
¾Installing the Driver
¾Uninstalling the Module
Windows 95, 98, Me
¾Installing the Driver
¾Uninstalling the Module
Linux
DOS
¾Installing the Driver
¾Driver Setup
¾Loading the Driver
¾Unloading the Driver

CA Series User’s Manual Software Installation
3-2
Windows Vista (32-bit)
The Windows Vista (32-bit) drivers conform to the Win32 COMM API standard and support all
models in the CA Series. In the following instructions, the CA-114 is used as an example.
Installing the Driver
1. After turning the embedded computer on, log into Windows as Administrator.
2. Insert the Document and Software CD in your PC’s CD-ROM drive.
3. Select Add Hardware from Control Panel/Classic View.
4. A window will appear stating that Windows needs your permission to continue. Click
Continue.

CA Series User’s Manual Software Installation
3-3
5. The Add Hardware Wizard will open. Click Next to continue.
6. Select Install the hardware that I manually select from a list (Advanced) and click Next to
continue.

CA Series User’s Manual Software Installation
3-4
7. Select Multi-port serial adapters and click Next to continue.
8. Click Have Disk.
9. For 32-bit (x86) platforms, select the \CA Series\Software\Windows Vista\x86 folder on the
CD and click OK to continue.

CA Series User’s Manual Software Installation
3-5
10. Select your CA Series model and click Next to continue.

CA Series User’s Manual Software Installation
3-6
11. If you see a warning that the software has not passed Windows Logo testing, click Install this
driver software anyway.
12. After the files have been installed, click Finish.

CA Series User’s Manual Software Installation
3-7
13. After the module is installed, you will be prompted to install the new serial ports. A Found
New Hardware Wizard window will open for the first serial port, port 0. Select Locate and
install driver software (recommended) to continue.
