GE NetworX Series User manual

THE “OPERATOR”
INTRODUCTION 3
ACCESSING YOUR SYSTEM 3
FUNCTIONS OF THE "OPERATOR" 4
SECTION I. CHECKING SYSTEM STATUS 4
SECTION II. USING THE MENU 5
SECTION III. ARMING YOUR SECURITY SYSTEM 6
SECTION IV. USING THE INSTANT / DELAY OPTION 6
SECTION V. DISARMING YOUR SECURITY SYSTEM 7
SECTION VI. BYPASSING ZONES 7
SECTION VII. ACCESSING ZONE STATUS 8
SECTION VIII. ACCESSING THE HOME CONTROL MENU 9
SECTION IX. ACCESSING DATE/TIME MENU 11
SECTION X. ACCESSING ALARM MEMORY 12
PROGRAMMING/CHANGING ACCESS CODES 13
ACTIVATING EMERGENCY ALARMS 14
THINGS TO KNOW ABOUT THE "OPERATOR" 14
QUICK REFERENCE BACK

INTRODUCTION
The “Operator” is an interactive phone module for Caddx security
controls that interconnects your telephone with your security system. It
allows authorized users to operate the security system from any
TouchTone telephone, whether it is at the protected site or anywhere
else in the world. This manual is furnished to help you understand how
the “Operator” works in conjunction with your security system. You
should first make sure that you fully understand the operation of your
security system as described in the supplied manual before attempting
to use the “Operator”. The “Operator” is Y2K compliant.
ΝIMPORTANT NOTE: Throughout this manual, phrases and messages
will appear in BOLD ITALICS CAPITAL LETTERS. These phrases are
the actual words as stated by the “Operator”.
ACCESSING YOUR SYSTEM
From a protected site, you can access your security system
“Operator” from any of your TouchTone telephones.
Step 1 Pick up the receiver.
Step 2 Within 8 seconds of hearing a dial tone, press the star key
three times. The “Operator” will come on the line.
ρρρ
Step 3 The “Operator” will tell you the System Status including any
warnings, along with the various MENU choices.

From an off-site premise, you can also access the “Operator” using a
TouchTone telephone.
Step 1 Call the phone number of the protected site.
Step 2 When the phone is answered, press the pound key three
times within the first 8 seconds.
# # #
If a person or a device such as a fax/answering machine
answers the call, the “Operator” will come on the line when
the answering machine or person hangs up. Otherwise, the
“Operator” will automatically answer the call after a pre-
designated number of rings occur.
The “Operator” will prompt for a valid user code: “PLEASE
ENTER YOUR CODE”.
Step 3 Enter your code. When it recognizes the valid user code, the
“Operator” will tell you the System Status including any
warnings, along with the various MENU choices.
FUNCTIONS OF THE “OPERATOR”
The “OPERATOR” has a wide variety of functions available to use in
controlling your security system by means of a TouchTone telephone.
Section I. CHECKING SYSTEM STATUS
System status is the first information you will hear when the “Operator”
comes on the line. This will inform you of the present status of your
security system. The messages given for System Status are as follows:
# "SYSTEM IS ARMED, ENTER CODE TO DISARM" - Enter your
code to DISARM.
# "SYSTEM IS READY, ENTER CODE TO ARM" - Enter your code
to ARM your system.
# “SYSTEM IS ARMED IN STAY MODE” – Your system is armed
in the STAY mode and provides exit delays.
# "SYSTEM NOT READY, PLEASE SECURE" – One or more zones
are not secure. Check zone status.

# "TO ACCESS MENU, ENTER [ ρ ]" - This takes you to the MENU
for the other options.
# "ZONE BYPASS ACTIVE" - One or more zones are bypassed.
Check zone status.
# “SYSTEM TROUBLE, ENTER [ ρ ] [2]” – This will identify the
service condition. Consult your security system’s user manual for
more information or call your installer.
# "POWER FAILURE"- Your system has lost electrical power.
# "LOW BATTERY" - Your backup battery has failed a system
battery test.
# "PHONE LINE TROUBLE" - Your system has detected a problem
with the phone line.
# "SYSTEM IS ARMED IN THE STAY MODE. ENTER CODE TO
DISARM. EXIT DOOR DELAY IS OFF."- Your system is
armed in the INSTANT Mode. Refer to page 6for details.
# "WHEN FINISHED, HANG UP" - Disconnect from the
“Operator” by hanging up.
Section II. USING THE MENU
When the “Operator” is on the line, the System Status will be stated. To
access the MENU for the various features of your system, press ρ.
The messages listed below are presented. Press the appropriate
number for the desired MENU selection.
# "FOR ZONE STATUS, ENTER [0]" - For checking open/faulted
zones. Refer to page 8.
# "TO CHANGE AREA, ENTER [1]" - For changing the area.
# “FOR SYSTEM STATUS, ENTER [2]” – For checking
armed/disarmed status of system. Refer to page 4.
# "FOR ALARM MEMORY, ENTER [3]" - For checking Alarm
Memory. Refer to page 12.
# "TO TEST SIREN, ENTER [4]" - For testing the siren.

# "TO CHANGE CODE, ENTER [5]" – To change a user code. This
option available in disarmed state only. Refer to page 13.
# “FOR HOME CONTROL MENU, ENTER [6]” – To access menu
for lights and thermostat control. Refer to page 9.
# “TO RESET SMOKE DETECTOR, ENTER [7]” – To reset
detectors.
# “TO PROGRAM SYSTEM, ENTER [8]” – Accesses program
mode.
# “FOR MORE OPTIONS, ENTER [9]” – Options include a zone
list, and features to set system date and time. Refer to page 11.
Section III. ARMING YOUR SECURITY SYSTEM
When the “Operator” is on the line to a system that is in the DISARMED
state, the System Status will be stated as, "SYSTEM IS READY.
ENTER CODE TO ARM". If there are any bypassed zones, "ZONE
BYPASS ACTIVE" will be stated. Since your security system will ignore
bypassed zones, you may want to check Zone Bypass Status before
ARMING your system (see BYPASSING ZONES THROUGH THE
OPERATOR). If you choose to ARM your system at this point, enter an
authorized 4-digit user code and the “Operator” will say "SYSTEM IS
ARMED, ENTER CODE TO DISARM". Your security system is now in
the ARMED state. You may hang up or go to another MENU option.
Section IV. USING THE INSTANT / DELAY OPTION
(Refer to your security system user's manual to see if your system has
been programmed for the "INSTANT" option. Read and familiarize
yourself with this option.)
While your system is in the ARMED state you may activate the
"INSTANT" option through the “Operator” as follows:
Step 1 Press ρ3 .
The [ρ] accesses the MENU and [3] is the STAY mode.
Step 2 “SYSTEM IS ARMED IN STAY MODE. ENTER CODE
TO DISARM.” Your system is now armed in the STAY
mode with exit delay.
Step 3 At this point, you may enter your code to disarm.

Or to change the armed status to INSTANT, press ρ3
again.
Step 4 “SYSTEM IS ARMED IN STAY MODE. ENTER CODE
TO DISARM. EXIT DOOR DELAY IS OFF.” Your
system is now armed in the INSTANT mode with no exit
delay.
Step 5 To toggle from the INSTANT mode to the STAY mode and
vice versa, simply press ρ3 .
Step 6 To exit, press the #key.
Section V. DISARMING YOUR SECURITY SYSTEM
When the “Operator” is on the line to a system is in the ARMED state,
the System Status will be stated as "SYSTEM IS ARMED, ENTER
CODE TO DISARM". To DISARM your system at this point, enter an
authorized 4-digit user code and the “Operator” will say "SYSTEM
READY, ENTER CODE TO ARM". Your security system is now
DISARMED. You may hang up or go to another MENU option.
Section VI. BYPASSING ZONES
Your security system must be DISARMED to perform the bypass
procedure. When you disarm your system, all bypassed zones will
automatically unbypass. Since your system’s arming procedure ignores
bypassed zones, these instructions should only be given to authorized
persons.
When the “Operator” is on the line, perform the following steps to
bypass or unbypass any of the zones in your security system.
Step 1 Press ρ9 0 .
The [ρ] accesses the main MENU, [9] gives the OPTIONS
menu, and [0] provides the ZONE LIST.
Step 2 The “Operator” will state the condition of each individual
zone with one of the following messages:
 “ZONE 1 IS SECURE. TO BYPASS ENTER [0] NOW.”
 “ZONE 2 IS BYPASSED.”

Step 3 You may toggle (reverse) the bypass condition of a
particular zone. After that zone number is stated, press
0.
Step 4 The “Operator” will say "PLEASE WAIT" before
repeating the status of that zone, and continue scrolling
through the remaining zones.
Step 5 Press a zone number followed by #to proceed directly
to that zone number.
For example, to go to zone 9 you would press 9#.
Step 6 Press #to exit the Zone Bypass section of the MENU.
Section VII. ACCESSING ZONE STATUS
When the “Operator” is on the line, the Zone Status option of the MENU
can be reached by performing the following steps:
Step 1 Press ρ0 .
The star [ρ] key accesses the main MENU and the zero
[0] accesses the Zone Status information.
Step 2 The “Operator” will state the name(s) of any zone(s) and
their conditions with one of the following messages:
# "ZONE 1 IS OPEN. TO BYPASS, ENTER [ρ] NOW"
# "ZONE 1 IS BYPASSED"
# "FIRE, ZONE 1"
# "FIRE TROUBLE, ZONE 1"
# "TAMPER, ZONE 1"

Section VIII. ACCESSING THE HOME CONTROL MENU
The Home Control Menu section provides information concerning the
lights and temperature control provided through your security system.
HOME CONTROL – LIGHTS/APPLIANCES
When the “Operator” is on the line, perform the following steps to turn
lights/appliances on or off.
Step 1 Press ρ6 .
The [ρ] accesses the main MENU and [6] goes to the
HOME CONTROL menu.
Step 2  “TO TURN LIGHT OFF, ENTER [0].”
 “TO TURN LIGHT ON, ENTER [1].”
 “THERMOSTAT CONTROL, ENTER [2].” (For
instructions on this menu item, please refer to the steps
in the next segment.)
Step 3 Press zero 0 to turn lights on or off.
Step 4 The “Operator” will begin scrolling through each of the
thirty-two outputs with one of the following messages:
 "LIGHT 1, ENTER [0] TO TURN OFF"
 "LIGHT 2, ENTER [0] TO TURN ON.”
Step 5 As each is recited, you can enter zero 0to turn the
light on/off.
Pressing a Light number followed by the # key will take
you directly to that light. After the condition of a light has
changed, the “Operator” will state its condition before
scrolling through the remainder of lights.
Step 6 To exit, press #or hang up.

HOME CONTROL – THERMOSTAT CONTROL
When the “Operator” is on the line, perform the following steps to
change the thermostat control. The thermostat control has three
separate modes:
 Thermostat mode  Fan mode  Day mode
(NOTE: The “Operator” will only function with a special type of
thermostat, which may not be currently available in your area.
Contact your installer.)
Step 1 Press ρ6 2 .
The [ρ] accesses the MENU and [6] takes you to the HOME
CONTROL menu, then [2] proceeds to the THERMOSTAT
CONTROL section.
Step 2  “INSIDE TEMPERATURE IS ZERO.”
 “OUTSIDE TEMPERATURE IS ZERO.”
 “THERMOSTAT MODE IS EMERGENCY. TO CHANGE,
ENTER [0].”
 “FAN MODE IS AUTO. FOR ON MODE, ENTER [1].”
 “DAY MODE IS ON. TO SELECT NIGHT MODE,
ENTER [2].”
 “DAY MODE HEAT SET POINT IS ZERO. TO CHANGE,
ENTER [3].”
 “NIGHT MODE HEAT SET POINT IS ZERO. TO
CHANGE, ENTER [4].”
 “DAY MODE COOL SET POINT IS ZERO. TO
CHANGE, ENTER [5].”
 “NIGHT MODE COOL SET POINT IS ZERO. TO
CHANGE ENTER [6].”
Step 3 When you have heard the status of the THERMOSTAT
mode, when you enter a number to change, the
“Operator” will ask you to “PLEASE WAIT.”

Step 4 If you selected the change mode for any of the last four
items mentioned in Step 2, the “Operator” will prompt:
“ENTER NEW SET POINT FOLLOWED BY [#] ”
Step 5 The “Operator” will then repeat the mode with the
changes, and continue with the options. You can continue
to make changes as desired. If a change is not entered,
the “Operator” will return to the main Menu.
Step 6 To exit, press # or hang up when finished.
Section IX. ACCESSING DATE/TIME MENU
When the “Operator” is on the line, perform the following steps to set
the DATE.
Step 1 Press ρ9 6 .
The [ρ] accesses the MENU and [9] proceeds to the
OPTIONS menu, then [6] proceeds to the DATE section.
Step 2 “PLEASE ENTER YOUR CODE.” Enter your user code.
“ENTER WEEKDAY.”
Enter the day of the week using the following options:
Step 3
[1] Sunday
[2] Monday [3] Tuesday [4] Wednesday [5] Thursday [6] Friday [7] Saturday
Step 4 “ENTER MONTH FOLLOWED BY [#].”
For example, September would be 9 # .
Step 5 “ENTER DAY FOLLOWED BY [#].”
For example, the 27th day would be 2 7 # .
Step 6 “ENTER YEAR FOLLOWED BY [#].”
For example, the year 2002 would be entered as
2 0 0 2 # .
Step 7 The “Operator” will automatically return to the MENU.

When the “Operator” is on the line, perform the following steps to set
the TIME.
Step 1 Press ρ9 7 .
The [ρ] accesses the MENU and [9] proceeds to the
OPTIONS menu, then [7] proceeds to the TIME section.
Step 2 “PLEASE ENTER YOUR CODE.” Enter your user code.
Step 3 “ENTER HOUR FOLLOWED BY [#].”
For example, 2 o’clock would be 2 # .
Step 4 “ENTER MINUTES FOLLOWED BY [#].”
For example, to set 18 minutes after the hour would be
1 8 #
Step 5 “ENTER [1] FOR AM. ENTER [2] FOR PM.” Press
[1] for AM or [2] for PM.
Step 6 The “Operator” will automatically return to the MENU.
Section X. ACCESSING ALARM MEMORY
While your system is in the DISARMED state, the Alarm Memory section
of the MENU is accessed with these steps:
Step 1 Press ρ3 .
The [ρ] accesses the MENU and [3] accesses the ALARM
MEMORY.
Step 2 The “Operator” will state the name of all zones that were
bypassed or faulted during the last alarm by stating one
of the following messages:
 "ALARM, ZONE 1"
 "ZONE 1 BYPASSED"
 "FIRE, ZONE 1"
 "FIRE TROUBLE, ZONE 1"
 "TAMPER, ZONE 1"
Step 3 If all zones were normal during last alarm, the
“Operator” would state the System Status.

PROGRAMMING/CHANGING ACCESS CODES
Your security system can be armed and disarmed through the
“Operator” by the Master code or the auxiliary codes. Refer to your
security system user's manual for the number of codes available in your
system. The Code Change section of the MENU is accessed in the
DISARMED state.
Step 1 Press ρ5 .
The [ρ] accesses the MENU and [5] reaches the CHANGE
CODE instructions.
Step 2 “PLEASE ENTER YOUR CODE.” Enter your user code.
Step 3 “ENTER TWO DIGIT CODE NUMBER.” Enter the 2-
digit user code that you want to change.
Step 4 “CODE IS XXXX. ENTER NEW CODE.” Enter the new
user code.
NOTE: If the code is blank, the “Operator” will state the
code as [15] [15] [15] [15].
Step 5 “ENTER TWO DIGIT CODE NUMBER.”
Step 6 At this time, you may either enter another two-digit
code you would like to change and repeat Steps 4 – 8,
or you may exit now.
Step 7 Press # to exit or hang up.
REMOVING AUXILIARY CODES - To remove an Auxiliary user code,
use the sequence above (steps 1 – 4), and program the new code as
ρρρρ

ACTIVATING EMERGENCY ALARMS
IMPORTANT NOTICE: In order to activate an EMERGENCY alarm through
the “Operator”, the telephone you are using MUST hold a continuous
audible tone while the button is held down. See page 15 of this booklet
or check with your installing company to see if these EMERGENCY
activations have been programmed into your security system. If so, the
following list will tell you how to activate an EMERGENCY alarm:
FIRE ALARM Press and hold [1] key for 2 full seconds.
AUXILIARY ALARM Press and hold [2] key for 2 full seconds.
PANIC ALARM Press and hold [3] key for 2 full seconds.
EMERGENCY alarms can be programmed to be silent or audible at the
protected site while possibly reporting an alarm to a monitoring center
that could dispatch the proper authorities.
THINGS TO KNOW ABOUT THE “OPERATOR”
1. TouchTone telephones are required to use the “Operator” with
your security system. Rotary dial telephones will not function with
the “Operator”.
2. For Emergency activation (Fire, Auxiliary, Panic) through the
“Operator”, you MUST be using a Touch-tone telephone that holds
a continuous tone as long as the key is depressed. Check your
phones to make sure they comply with this requirement.
3. If your phone is answered by an answering machine when you are
calling your system from an off-site location, there will be a short
pause waiting for the answering machine to disconnect so the
“Operator” can answer the call.
4. If your phone is answered by an answering/fax machine or any
other device that produces continuous tones for the first 8-10
seconds, the “Operator” will not be able to answer an incoming call
for the remote operation of your system.
5. Zone and light/appliance descriptions are generic, but can be
customized by your security installer to fit the needs of your
system.

Installing/Service Company _________________________________
For Service Call __________________________________________
Central Station ___________________________________________
EMERGENCY ACTIVATION KEYS (check if enabled)
Press and hold the key for 2 full seconds.
Fire [1] Auxiliary Emergency [2] Police [3]
# of Rings To Answer _______
ZONE DESCRIPTIONS
01 _________________________ 17 _________________________
02 _________________________ 18 _________________________
03 _________________________ 19 _________________________
04 _________________________ 20 _________________________
05 _________________________ 21 _________________________
06 _________________________ 22 _________________________
07 _________________________ 23 _________________________
08 _________________________ 24 _________________________
09 _________________________ 25 _________________________
10 _________________________ 26 _________________________
11 _________________________ 27 _________________________
12 _________________________ 28 _________________________
13 _________________________ 29 _________________________
14 _________________________ 30 _________________________
15 _________________________ 31 _________________________
16 _________________________ 32 _________________________

SYSTEM NOTES

NETWORX NX540E “OPERATOR”
ρ ρ ρ TO ACCESS “OPERATOR”
ρ MENU
ρ 0 ZONE STATUS
ρ 1 CHANGE AREA
ρ 2 SYSTEM STATUS
ρ 3 ALARM MEMORY
ρ 4 TEST SIREN
ρ 5 CHANGE CODE
ρ 6 HOME CONTROL MENU
ρ 6 0 TURN LIGHTS OFF
ρ 6 1 TURN LIGHTS ON
ρ 6 2 THERMOSTAT CONTROL
ρ 7 RESET SMOKE DETECTORS
ρ 8 PROGRAM SYSTEM
ρ 9 OPTIONS
ρ 9 0 ZONE LIST
ρ 9 6 SET DATE
ρ 9 7 SET TIME
QUICK REFERENCE
These quick reference charts have
been designed for your convenience.
They can be cut out on the dotted
lines and put in a wallet or purse.
NX540E “OPERATOR” USER MANUAL
I-NX540-OM Rev C (April 2003)
NETWORX NX540E “OPERATOR”
ρ ρ ρ TO ACCESS “OPERATOR”
ρ MENU
ρ 0 ZONE STATUS
ρ 1 CHANGE AREA
ρ 2 SYSTEM STATUS
ρ 3 ALARM MEMORY
ρ 4 TEST SIREN
ρ 5 CHANGE CODE
ρ 6 HOME CONTROL MENU
ρ 6 0 TURN LIGHTS OFF
ρ 6 1 TURN LIGHTS ON
ρ 6 2 THERMOSTAT CONTROL
ρ 7 RESET SMOKE DETECTORS
ρ 8 PROGRAM SYSTEM
ρ 9 OPTIONS
ρ 9 0 ZONE LIST
ρ 9 6 SET DATE
ρ 9 7 SET TIME
