BODYMAX CF820 Dual Pulley User manual

max. 120 kg
~ 180 Min.
CM
256/301 kg
BodyMax CF820 Dual Pulley
SEBR3422.01.01
SKU: SEBR3422 + SEBR2532
Assembly and Operating Instructions
L 169 | W 81 | H 212

2CF820

3
Content
1 GENERAL INFORMATION 7
1.1 Technical Data 7
1.2 Personal Safety 8
1.3 Set-Up Place 9
2 ASSEMBLY 10
2.1 General Instructions 10
2.2 Scope of Delivery 11
2.3 Scope of Delivery: Weight Stack Upgrade 13
2.4 Assembly 14
3 STORAGE AND TRANSPORT 24
3.1 General Instructions 24
4 TROUBLESHOOTING, CARE AND MAINTENANCE 25
4.1 General Instructions 25
4.2 Faults and Fault Diagnosis 25
4.3 Maintenance and Inspection Calendar 26
5 DISPOSAL 26
6 RECOMMENDED ACCESSORIES 27
7 ORDERING SPARE PARTS 28
7.1 Serial Number and Model Name 28
7.2 Parts List 29
7.3 Parts List: Weight Stack Upgrade 29
7.4 Exploded Drawing 30
8 WARRANTY 31
9 CONTACT 33

4CF820

5
Disclaimer
©BodyMax® is a registered brand of the company Sport-Tiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
The equipment is suitable for home use and semi-professional use (e.g. hospitals, clubs, hotels,
schools, etc.). The equipment is not suitable for commercial or professional use (e.g. tness
studio).
Dear customer,
Thank you for choosing training equipment from BodyMax.
BodyMax is your reliable partner for home and commercial gym equipment. We are specialized in
cardio and strength training machines for home and commercial use. Our products are not only
strong, durable, and aordable but also designed to t your personal needs.
The BodyMax headquarter is based in Rutherglen, Glasgow. Our brand was created with the intention
of providing innovative exercise equipment at aordable prices for users of all training levels.
You can nd further information at www.bodymax-tness.com.

6CF820
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
Due to ongoing changes and software optimisations, the manual may have to be updated. If
you notice any discrepancies during assembly or use, please refer to the manual uploaded to the
webshop. The latest manual is always available there.
This equipment has been manufactured according to the latest safety knowledge. As far as possible,
potential safety hazards which could cause injury have been eliminated. Make sure to carefully follow
the instructions and that all parts are securely in place. If required, read through the
instructions again to correct any mistakes.
Please pay close attention to the safety and maintenance instructions given here.
The contract partner cannot be held liable for damage to health, accidents or
damage to the equipment when it is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
NOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

7
1 GENERAL INFORMATION
1.1 Technical Data
Weight and Dimensions
Packaging dimensions (L x W x H) and article weight (gross, incl. packaging) approx.:
Box 1: 216 cm x 97 cm x 17 cm 97 kg
Box 2: 146 cm x 45 cm x 12 cm 30 kg
Box 3 (6x): 27.5 cm x 14.5 cm x 11.5 cm 23 kg
Set-up dimensions (L x W x H) approx.: 168.1 cm x 80.9 cm x 212 cm
Article weight (net, excl. packaging) approx.: 256 kg
Weight Stack
Quantity weight stack: 2
Weight of weight stack: 72 kg per weight stack
Weight plates: 15 + 1 per weight stack
Cable length: 732 cm
Cables: 2
Cable width: 0,48 cm
Pulley diameter: 90 cm
Transmission ratio: 1:2
Maximum load: 300 kg
Maximum user weight (pull-up): 120 kg
Class: H
Weight Stack Upgrade (Optional)
Packaging dimensions (L x W x H) and article weight (gross, incl. packaging) approx.:
Box 1: 75 cm x 30 cm x 12 cm 14 kg
Box 2 (2x): 27.5 cm x 14.5 cm x 11.5 cm 23 kg
Weight of weight stack (with upgrade): 95 kg per weight stack
Weight plates (with upgrade): 20 + 1 per weight stack
Cable length: 709 cm

8CF820
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
+ The owner must communicate all warnings and instructions to the user.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
+ Always start each workout with a light warm-up and end with a cool-down phase.
+ Using the machine as a support during stretching exercises or attaching resistance bands,
ropes or other accessories to it, may cause injuries.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
+ Be aware that if adjustment devices are left protruding, they may impede the user’s
movement.
ATTENTION
+ Do not insert any objects of any kind into the openings of the device.



9
1.3 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ Choose a location in which to place the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The free area in the direction from which the exercise equipment is accessed must be at
least 0.6 m larger than the exercise area.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
+ If your device is to be mounted on the wall/ceiling, make sure that you use the appropriate
assembly material to avoid possible damages or personal injuries. The contractual partner
accepts no liability for this.
ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.
+ For Class S and I equipment, the exercise equipment may only be used in areas where
access, supervision and control are specically regulated by the owner.

10 CF820
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
NOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.

11
2.2 Scope of Delivery
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.

1L 1R 34 35 36
2517
18
11 12
7
9
28
27
33
26
21
16
8
12 CF820
Content of box 1
Part no. Description Qty.
1L Main Upright Frame - Left 1
1R Main Upright Frame - Right 1
Content of box 2
Part no. Description Qty.
34 Right Shield 1
35 Left Shield 1
36 Steel Plate 4
Part no. Description Qty.
2 Squat Bar 1
5 Front Top Cross Frame 1
7 Rubber Bumper 4
9 Weight Select Pin 2
11 Top Weight Plate 2
12 Single Pulley Bracket 2
16 Pop Pin 2
Part no. Description Qty.
17 Upper Cross Frame 1
18 Lower Cross Frame 1
21 Top Cross Frame Plate 2
26 Cable (732 cm) 2
27 Clip 2
28 Strap Handle 2
33 Ankle Strap 1
Content of box 3 (6x) Part no. Description Qty.
8 Weight Stack Plate 5

38
40
8
13
2.3 Scope of Delivery: Weight Stack Upgrade
This Dual Pulley Functional Trainer comes with two 72 kg weight stacks. You also have the option of
purchasing a weight stack upgrade kit. With the upgrade kit, the weight stacks come in at 95 kg each.
ATTENTION
If you have purchased the weight stack upgrade kit, make sure to use the top weight plate (38)
with preinstalled weight selector (39) and cables (40) from the upgrade kit. Do not use the top
weight plate (11) with preinstalled weight selector (10) and cables (26) from the main equipment.
Content of box 1
Part no. Description Qty.
38 Top weight plate 2
40 Cable (709 cm) 2
Weight Plate Stickers
Content of box 2 (2x)
Part no. Description Qty.
8 Weight Stack Plate 5

14 CF820
2.4 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
NOTICE
+ First loosely screw all parts together and check that they t properly. Tighten the screws
using the tool only when you are instructed to do so.
+ If you have diculty recognising the graphics, we recommend that you open and/or
download the PDF instructions stored in the webshop on your end device (e.g. smartphone,
tablet or PC). There you have the option of zooming in closer.
Step 1: Assembly of the Main Upright Frames and Cross Frames
NOTICE
Do not tighten the bolts and nuts completely yet.
1. Attach the upper cross frame (17) and two steel plates (36) to the main upright frames (1R &1L)
with a total of four bolts (H10-13), eight washers (W10) and four nuts (M10).
2. Attach the lower cross frame (18) and two steel plates (36) to the main upright frames (1R & 1L)
with a total of four bolts (H10-13), eight washers (W10) and four nuts (M10).
3. Attach the top cross frame (5) and two top cross frame plates (21) to the main upright frames
(1R & 1L) with a total of four bolts (H10-17), eight washers (W10) and four nuts (N10).
4. Attach two pop pins (16) to the pre-installed left and right sliders (13 & 14).
5. Now tighten the bolts and nuts with the appropriate tools. Do not tighten the bolts and nuts
from the lower cross frame (18).

5
21 1R 1L 21
18
17
36
16
36
36
14
36
H10-17
H10-17
H10-13
W10
W10 W10
N10
W10
N10
W10
W10
N10
W10
W10
N10
W10
W10
N10
W10
W10
N10
W10
H10-13
H10-13
H10-13
W10
W10
W10
Right Part Left Part
13
15
Right side Left side

16 CF820
Step 2: Assembly of the Weight Stacks
ATTENTION
If you are installing the weight stack upgrade kit at a later point, you must rst disassemble the
entire standard weight stacks and cables.
NOTICE
+ This cable machine comes with a standard 2 x 72 kg weight stack. If you have purchased
the standard version, use the top weight plate (11) that comes with the main equipment.
+ If you have purchased the weight stack upgrade kit, use the top weight plate (38) and
additional weight stack plates (8) from the upgrade kit.
+ The drawing shows the assembly on the left side. Once the assembly is completed on the
left side, the steps must be repeated on the right side as well.
1. Loosen the pre-installed bolts (H10-2) and washers (W10) from the top of the guide rods (6).
2. Slightly tilt the guide rods (6) like shown in the drawing.
3. Slide one rubber bumper (7) over each guide rod (6).
4. Carefully slide 15 weight plates (8) over the guide rods (6) one by one. Make sure the weight
plates are correctly aligned with the hole facing the inside of the machine [standard weight
stack].
4.1. Carefully slide 20 weight plates (8) over the guide rods (6) one by one. Make sure the weight
plates are correctly aligned with the hole facing the inside of the machine [with weight stack
upgrade].
5. Carefully slide the top weight plate (11) over the guide rods (6), making sure the weight selector
(10) goes through the centre hole of the weight plates (8) [standard weight stack].
5.1. Carefully slide the top weight plate (38) over the guide rods (6), making sure the weight selector
(39) goes through the centre hole of the weight plates (8) [with weight stack upgrade].
6. Place the ring of the weight select pin (9) around the top part of the weight selector (10/39).
7. Thread the single pulley bracket (12) at least 1/3 into the weight selector (10/39) and secure
with the pre-installed lock nut.
8. Insert the weight select pin (9) into one of the selector holes.
9. Reattach the guide rods (6) to the top of the main upright frame (1) with the previously loosened
bolts (H10-2) and washers (W10).
10. Repeat the steps 1 to 9 on the right side.

39
38
12
8
9
17
Left side
Assembly: Weight Stack Upgrade

18 CF820
Step 3: Assembly of the Cables
ATTENTION
+ If you have purchased the standard version, use the cables (26) that come with the main
equipment.
+ If you have purchased the weight stack upgrade kit, use the shorter cables (40) from the
upgrade kit. The assembly is identical.
+ The cables should run along the inside of the main frames.
NOTICE
+ The pulleys are pre-installed. For the proper assembly of the cables, you need to uninstall
and reinstall the pulleys. Route the cables while simultaneously reinstalling the pulleys as
you go. Do not fully tighten the bolts and nuts until the cables are fully installed.
+ The following steps show the assembly on the left side. The steps must be repeated on the
right side as well.
1. Start by removing the pulley (P2) in the double pulley bracket (15).
2. Route the ball end of the cable (26 or 40) over the pulley (P1) and reattach the pulley (P2) to the
double pulley bracket (15).
3. Route the cable (26 or 40) up and over the pulleys (P3 and
P4).
4. Route the cable (26 or 40) down and under the pulley (P5).
5. Route the cable (26 or 40) up and over the pulleys (P6 and
P7).
6. Route the cable (26 or 40) down and under the pulley (P8).
7. Thread the bolt end of the cable (26 or 40) at least 1/3 into
the holder on the left slider (14) and secure with the pre-
installed lock nut.
8. Tighten all bolts and nuts with the appropriate tools.
9. Attach the clip (27) and strap handle (28) to the ball end of
the cable (26 or 40).
10. Repeat the steps 1 to 9 on the right side.

19
Left side

20 CF820
Step 4: Cable Adjustment
You can recognize the correct cable tension when the top weight plate rests very lightly on the
weight stack. If the top weight plate is hanging in the air, the cable is too tight. If the cable is visibly
slacking, it is too loose. If the cable is slacking or too tight, it needs adjustment. There are two points
at which the cable can be adjusted.
⚠WARNING
The threaded ends must always be screwed in at least 1/3 of their length.
Option 1: Bolt End of the Cable at the Left/Right Slider
1. Loosen the lock nut.
2. To loosen the cable, turn counterclockwise.
3. To tighten the cable, turn clockwise.
4. Tighten the lock nut.
Option 2: Bolt End of the Single Pulley Bracket
1. If already attached, rst remove the pulley as it will otherwise rotate when adjusting.
2. Loosen the lock nut.
3. To loosen the cable, turn counterclockwise.
4. To tighten the cable, turn clockwise.
5. Reattach the pulley.
6. Tighten the lock nut.
